Citroen DS4 RHD 2013.5 1.G Owner's Manual

229Driving





Parking sensors

This system indicates the proximity of an
obstacle (person, vehicle, tree, gate, etc.)
which comes within the field of detection of
sensors located in the bumper.
Certain types of obstacle (stake, roadworks
cone, etc.) detected initially will no longer be
detected at the end of the manoeuvre due to
the presence of blind spots.

This function cannot, in any
circumstances, take the place of the
vigilance and responsibility of the
driver.
The system is switched on by engaging reverse
gear. This is accompanied by an audible signal.
The system is switched off when you exit
reverse gear.

Rear parking sensors


Audible assistance

The proximity information is given by an
intermittent audible signal, the frequency of which
increases as the vehicle approaches the obstacle.
The sound emitted by the speaker (right or left)
indicates the side on which the obstacle is located.
When the distance between the vehicle and
the obstacle becomes less than approximately
thirty centimetres, the audible signal becomes
continuous.




Visual assistance

This supplements the audible signal by
displaying bars in the multifunction screen
which move progressively nearer to the vehicle.
When the obstacle is near, the "Danger"
symbol is displayed in the screen.

Front parking sensors
Operating fault

In the event of a malfunction of
the system, when reverse gear
is engaged this warning lamp
is displayed in the instrument panel and/or a
message appears in the screen, accompanied
by an audible signal (short beep).
Contact a CITROËN dealer or a qualified
workshop. In addition to the rear parking sensors, the
front parking sensors are triggered when an
obstacle is detected in front and the speed of
the vehicle is still below 6 mph (10 km/h).
The front parking sensors are interrupted if
the vehicle stops for more than three seconds
in for ward gear, if no further obstacles are
detected or when the speed of the vehicle
exceeds 6 mph (10 km/h).


The function will be deactivated
automatically if a trailer is being towed
or a bicycle carrier is fitted (vehicle
fitted with a towbar or bicycle carrier
recommended by CITROËN).

In bad weather or in winter, ensure
that the sensors are not covered with
mud, ice or snow. When reverse gear is
engaged, an audible signal (long beep)
indicates that the sensors may be dirty.
Certain sound sources (motorcycle,
lorry, pneumatic drill, etc.) may trigger
the audible signals of the parking
sensor system.


Deactivation/Activation of the
front and rear parking sensors
The function is deactivated by pressing this button.
The indicator lamp in the button comes on.
Pressing this button again reactivates the function.
The indicator lamp in the button goes off.

The sound emitted by the speaker
(front or rear) indicates whether the
obstacle is in front or behind.

231Driving

010
Checks

TOTAL & CITROËN


Partners in performance and
protecting the environment

Innovation in the search for
performance
For over 40 year, the TOTAL Research and
Development departments have developed for
CITROËN, lubricants to match the latest technical
innovations on CITROËN vehicles, both for
competition and for everyday motoring.
For you, this is an assurance that you will obtain of
the best per formance for your engine.


Optimum protection for
your engine
By having your CITROËN vehicle
serviced with TOTAL lubricants, you
are contributing towards improving the
life and per formances of your engine,
while also protecting the environment.

prefers

235Checks











Bonnet


Opening




Open the front left door.


Pull the interior bonnet release lever A
,
located at the bottom of the door aperture.

Push the exterior safety catch B
to the left
and raise the bonnet.


Unclip the stay C
from its housing on the
back of the bonnet.


Fix the stay in the notch to hold the bonnet
open.
The location of the interior bonnet
release lever prevents opening of
the bonnet while the front left door is
closed.
Do not open the bonnet in high winds.
When the engine is hot, handle the
exterior safety catch and the bonnet
stay with care (risk of burns).






Before doing anything under the
bonnet, switch off the Stop & Start
system to avoid any risk of injury
resulting from an automatic change to
START mode.


Closing




Take the stay out of the support notch.


Clip the stay in its housing on the back of
the bonnet.


Lower the bonnet and release it at the end
of its travel.


Pull on the bonnet to check that it is
secured correctly.

Running out of fuel
(Diesel)


On vehicle fitted with HDi engines, the fuel
system must be primed if you run out of fuel;
refer to the corresponding engine compartment
view.

1.6 litre HDi engine




Fill the fuel tank with at least five litres of
diesel.


Open the bonnet.


If necessary, unclip the styling cover for
access to the priming pump.


Squeeze and release the priming pump
repeatedly until resistance is felt (there
may be resistance at the first press).


Operate the starter until the engine starts
(if the engine does not start at the first
attempt, wait around 15 seconds before
trying again).


If the engine does not start after a few
attempts, operate the priming pump again
then start the engine.


Clip the styling cover back in place.


Close the bonnet.

If the tank on your vehicle is fitted with
a misfuel prevention device, refer to the
"Misfuel prevention (Diesel)" section.







2 litre HDi engine




Fill the fuel tank with at least five litres of
Diesel.


Open the bonnet.


If necessary, unclip the style cover for
access to the priming pump.


Slacken the bleed screw.


Squeeze and release the priming pump
repeatedly until fuel appears in the
transparent pipe.


Tighten the bleed screw.


Operate the starter until the engine starts
(if the engine fails to start at the first
attempt, wait around 15 seconds before
trying again).


If the engine fails to start after a few
attempts, operate the priming pump again,
then the starter.


Put the style cover back in position and
clip it in place, ensuring that it has clipped
correctly.


Close the bonnet.

If the engine does not start first
time, don't keep trying but start the
procedure again from the beginning.

237Checks














Petrol engines

The various caps and covers allow access for
checking the levels of the various fluids and for
replacing certain components.


1.
Power steering reservoir.

2.
Screenwash and headlamp wash reser voir.

3.
Coolant reservoir.

4.
Brake fluid reser voir.

5.
Battery/Fuses.

6.
Fusebox.

7.
Air filter.

8.
Engine oil dipstick.

9.
Engine oil filler cap.

Diesel engines

The various caps and covers allow access for
checking the levels of the various fluids, for
replacing certain components and for priming
the fuel system.


1.
Power steering reservoir.

2.
Screenwash and headlamp wash reser voir.

3.
Coolant reservoir.

4.
Brake fluid reser voir.

5.
Battery/Fuses.

6.
Fusebox.

7.
Air filter.

8.
Engine oil dipstick.

9.
Engine oil filler cap.

10.
Priming pump * .

11.
Bleed screw * .

*
According to engine.
