Citroen DS5 2014 1.G Owner's Manual

99Comfort

Switching the system off




Turn the air flow control to the
left until all of the indicator
lamps go off.

Avoid prolonged operation in interior
air recirculation mode or driving for
long periods with the system off (risk of
condensation and deterioration of air
quality). This action switches off the air conditioning and
the ventilation.
Temperature related comfort is no longer
assured but a slight flow of air, due to the
movement of the vehicle, can still be felt.



Modify the settings (temperature, air flow
or air distribution) or press the "AUTO "

button to reactivate the system with the
values set before it was switched off.



9. Maximum air conditioning




If you want to quickly cool
the air in the passenger
compartment, press this
button; "LO"
is displayed.
To return to the previous settings, press the
button again.


Switch off the demisting/defrosting
of the rear screen and door mirrors
as soon as appropriate, as lower
current consumption results in
reduced fuel consumption.


Front Demist -
Defrost







Rear screen and door mirrors demist -
defrost



It is possible to stop the
demisting/defrosting operation
before it is switched off
automatically by pressing the
button again. The indicator
lamp associated with the
button goes off.













Automatic visibility programme

Switching on







With Stop & Start, when demisting has
been activated, the STOP mode is not
available.


Switching off

The demisting/defrosting switches off automatically
to prevent an excessive consumption of current.



Select this programme
to demist or defrost the
windscreen and side windows
as quickly as possible.
The system automatically manages the air
conditioning, air flow and air intake, and
provides optimum distribution towards the
windscreen and side windows.



To stop the programme, press either
the "visibility"
button again or "AUTO "
,
the indicator lamp in the button goes off
and the indicator lamp in the "AUTO "

button comes on.
The system starts again with the values in
use before it was overridden by the visibility
programme.



Press this button (located on
the air conditioning system
control panel) to demist /defrost
the rear screen and the door
mirrors. The indicator lamp
associated with the button
comes on.









The rear screen demist - defrost
can only operate when the engine is
running.

101Comfort

004
Driving

Starting-switching off the engine




Insert the electronic key in the reader.


Press the brake pedal for vehicles with
an automatic or electronic gearbox, or
fully declutch for vehicles with a manual
gearbox.

Starting using
the electronic key
Starting with the "Keyless
Entry and Starting" system

If one of the starting conditions is not
met, a reminder message appears in
the instrument panel screen. In some
circumstances, it is necessary to turn
the steering wheel slightly while pressing
the "START/STOP" button to assist
unlocking of the steering; a message
warns you when this is needed.
With a manual gearbox
, put the gear lever in neutral.
With an electronic gearbox
, put the gear lever in N
.
With an automatic gearbox
, put the gear lever in P
or N
.

For Diesel vehicles
, in
temperatures below zero the
engine will not start until the
preheater warning lamp has gone off.
If this warning lamp comes on after
pressing "START/STOP", you should
hold the brake or clutch pedal down
until the warning lamp goes off and
do not press the START/STOP button
again.



With the electronic key inside the vehicle
(it is not necessary to put it in the reader),
press the brake pedal for vehicles with
an automatic or electronic gearbox, or
fully declutch for vehicles with a manual
gearbox.

Press the " START/STOP
"
button.
The engine starts (see the
warning below for Diesel
vehicles).


Press the " START/STOP
"
button.
The engine starts (see the
warning below for Diesel
vehicles).
The "Keyless Entry and Starting" device
must be in the recognition zone.
For safety reasons, do not leave
this zone with the vehicle running.

105Driving

Switching off using the
electronic key



Immobilise the vehicle.


Electronic key left in the reader

If the electronic key is left in the reader,
on opening the driver's door a message
appears to warn you.



Stopping with the "Keyless
Entry and Starting" system



Immobilise the vehicle.

If the vehicle is not immobilised, the
engine will not stop.
















Ignition on without
starting



With the electronic key inside
the vehicle, press the " START/
STOP
" button.
The engine stops and the
steering column locks.

Press the " START/STOP
" button
The engine stops and the
steering column locks.











Anti-theft protection


Electronic engine immobiliser

The keys contain an electronic chip which has
a secret code. When the ignition is switched
on, this code must be recognised in order for
starting to be possible.
This electronic engine immobiliser locks the
engine management system a few minutes
after the ignition is switched off and prevents
starting of the engine by anyone who does not
have the key.
In the event of a malfunction, you are informed
by a message in the instrument panel screen.
In this case, your vehicle does not start; contact
a CITROËN dealer as soon as possible.

With the electronic key in the reader or the
Keyless Entry and Starting key inside the
vehicle, pressing the "START/STOP" button,
with no action on the pedals
, allows the
ignition to be switched on.


Remove the electronic key from the reader.



Press the "START/STOP" button,
the instrument panel comes on
but the engine does not start.


Press the button again to switch
off the ignition and so allow the
vehicle to be locked.


With the ignition on, the system goes
into energy economy mode when
necessary to maintain the state of
charge of the battery.


Switching off the engine leads to a loss
of braking assistance.

Emergency starting with the
Keyless Entry and Starting
system
When the electronic key is in the recognition
zone and your vehicle does not start after
pressing the "START/STOP" button:



Insert the electronic key in the reader.


Press the brake pedal on vehicles with an
automatic or electronic gearbox, or fully
declutch with a manual gearbox.


Press the "START/STOP" button.
The engine starts.
In the event of an emergency only, the engine
can be switched of without conditions. To do
this, press and hold the "START/STOP" button
for about 3 seconds.
In this case the steering column locks as soon
as the vehicle stops.
If the electronic key is no longer in the
recognition zone when driving or when you
(later) request switching off the engine, a
message appears in the instrument panel.

Emergency switch- off
Electronic key not recognised by
the "Keyless Entry and Starting"
system



Press and hold the "START/STOP"
button for about 3 seconds if you want to
force switching off the engine (note that
restarting will not be possible without the
key).

107Driving

It is recommended that you do not
apply the parking brake in very cold
conditions (ice) and during towing
(breakdown, caravan...).
For this, with the ignition on, deactivate
the automatic functions and release the
parking brake manually:



Manual gearbox:
engage first gear
or reverse.


Electronic gearbox:
select
position A
or R
.


Automatic gearbox:
select
position P
or R
.


The electric parking brake combines
2 operating modes:


- Automatic Application/Release

Application is automatic when the engine
stops, release is automatic on use of the
accelerator (this mode is activated by
default),

- Manual Application/Release

Manual application of the parking brake is
done by pulling control lever A.

Manual release is done by pulling
then
releasing the control lever, while pressing
the brake pedal
When the driver's door is opened, there is an
audible signal and a message is displayed if
the brake is not applied.

Programming the automatic
mode
Depending on the country of sale of the vehicle,
the automatic application when the engine is
switched off and the automatic release when
you press the accelerator can be deactivated.
You can contact a CITROËN dealer or a
qualified workshop to have it activated.

In this case, programming is done via
the configuration menu.









Electric parking brake


If deactivated, the parking brake must
be applied and released manually.
If this warning lamp comes on in
the instrument panel, the automatic
mode is deactivated.
Never leave the vehicle without
checking that the parking brake is on.
This warning lamp comes on
fixed.


Label on door panel

With the ignition on or the engine running, to
release the parking brake, press
the brake

pedal
, pull
then release control lever A
.
The full release of the parking brake is
confirmed by:

Manual release



- the braking warning lamp and
the P
warning lamp in the control
lever A
going off,

- display of the message "Parking
brake off ".
If you pull the control lever A
without pressing
the brake pedal, the parking brake will not
be released and a message appears in the
instrument panel.
If necessary, you can make a maximum
application
of the parking brake. It is obtained
by means of a long pull
on control lever A
,
until you see the message "Parking brake
applied fully" and an audible signal is heard.

Maximum application is essential:



- in the case of a vehicle towing a caravan
or a trailer, if the automatic functions are
activated but you are applying the parking
brake manually,

- when the slope you are parked on may
vary (e.g. on a ferry, on a lorry, during
towing).



Maximum application


In the case of towing, a loaded vehicle
or parking on a gradient, make a
maximum application of the parking
brake then turn the front wheels
towards the pavement and engage a
gear when you park.
After a maximum application, the
release time will be longer.

Before leaving the vehicle, check that
parking brake warning lamps in the
instrument panel and the control lever A

are on fixed, not flashing.
With the vehicle stationary, to apply the parking
brake whether the engine is running or off, pull

control lever A
.


Manual application

The application of the parking brake is
confirmed by:


- illumination of the braking warning
lamp and of the P
warning lamp in
the control lever A
,

- display of the message "Parking
brake on".
When the driver’s door is opened with the
engine running, there is an audible signal and a
message is displayed if the parking brake has
not been applied, unless the selector lever is
in position P
(Park) in the case of an automatic
gearbox.
