Technical data
ENGINES AND GEARBOXES
Diesel engineHDi160 PEF
GearboxElectronic gearbox system (6-speed)

Model codeRHH
Cubic capacity (cc) 1 997
Bore x stroke
(mm)
85 x 88

Max power: EU standard
(kW) 11 0

Max power engine speed (rpm)
3 750

Max torque: EU standard
(Nm)
340

Max torque en
gine speed (rpm)

2 000

F
uel Diesel

Catalytic converter yes

P
article emission filter yes

Oil capacities
(in litres)
Engine (with filter replacement)

-

WEIGHTS AND TOWED LOADS (in kg)
Diesel engineHDi 160PEF
GearboxElectronic gearbox system (6-speed)

Model codeRHC



-
Unladen weight-



- Kerb weight *
1 735



-
Gross vehicle weight (GVW)
2 265


- Gross train wei
ght (GT W) on a 12% gradient2 765


- Braked trailer
(within GTW limit)on a 10% or 12% gradient 500



- Braked trailer ** (with load transfer with the GTW limit)
800



- Unbraked trailer
500


-
Recommended nose weight

75

*

The kerb weight is equal to the unladen weight + driver (75 kg).
**
The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding
To make use of the 300 kg load transfer, the driver must be alone in the vehicle with no luggage in the vehicle.
The GTW and towed load values indicated are valid up to a maximum altitude of 1 000 metres; the towed load mentioned must be reduced b
y 10 % for each additional 1 000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C, limit the towed load.

QUESTIONANSWER SOLUTION
With the engine off, the system switches off after a few minutes of use.When the en
gine is switched off, the system's operating time depends on
the battery charge.
The switch-o
ff is normal: the system switches to economy mode and
switches off to prevent discharging of the vehicle's battery.
Start the vehicle's engine to increase the batterycharge.
Pla
yback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).
Some fi les supplied with the memory stick may greatly slow down access
to reading the memory stick (multiplication by 10 of the catalogue time). Delete the fi les supplied with the memory stickand limit the number of sub-folders in the fi le structure on the memory stick.

When I connect myiPhone as telephone and
to the USB port at thesame time, I am unable
to play the music fi les. When the iPhone connects automaticall
y as a telephone, it forces the
streaming function. The streaming function takes the place of the USBfunction which is then not useable. Disconnect and reconnect to the USB port
(the USB function takes priority over streaming).
FREQUENTLY ASKED QUESTIONS

309

The system is coded in such a way that it will only
operate in your vehicle.







AUDIO SYSTEM/BLUETOOTH

01 First steps


For safety reasons, the driver must only carry out
operations which require prolonged attention while
the vehicle is stationary.
When the engine is switched o
ff and to prevent
discharging of the battery, the audio system may switch off after a few minutes.



CONTENTS

02 Steering mounted controls

03 Main menu

04 Audio

05 Using the telephone

06 Audio settings

07 Configuration

08 Screen menu maps

Frequently asked questions p.
p.
p.
p.
p.
p.
p.
p.
p.
0
311
312
3
13
323
331
332
3
33
335

A
ABS...............................................................181Accessories...................................................227Accessory position.....................................33,77Accessory socket, 12V ..........................104, 105Adjusting headlamps .....................................154Adjusting head restraints...........................94,97Adjusting seat belt height..............................185Adjusting the steering wheel..........................103Airbags ....................................................63, 187Airbags, curtain...................................... 189, 190Airbags, front.........................................187, 190Airbags, lateral.......................................189, 190Air conditioning................................................44Air conditioning, digital............................111, 112Air fi lter..........................................................r240Air fl ow.............................................................44Air vents.........................................................110Alarm...............................................................83Anti-lock braking system (ABS).....................181Anti-pinch...................................................86, 88Anti-theft..........................................................33Armrest.......................................................... 104Armrest, front ................................................. 106Armrest, rear..................................................r107Ashtray..........................................................104ASR...............................................................181Assistance, emergency braking.....................181Assistance call.......................................179, 253Audible warning.............................................179Audio streaming (Bluetooth) ..........295,322, 324Audio system.................................................309Automatic headlamps ..............................56, 151Automatic illumination of headlamps .....147, 150
Automatic operation of hazardwarning lamps.............................................178Automatic rain sensitivewindscreen wipers ...............................157,159Auxiliary socket......................106, 295, 296,321
Backup starting ................................................34Backup switching off........................................f34Battery................................47-49,101, 218,239Battery, charging............................................219Battery, remote control..............................79, 80Black panel......................................................69Bluetooth (hands-free) ...........................278,323Bluetooth (telephone) ............................278, 323Boot.................................................................82Boot (unlocking)...............................................74
Boot fl oor, removable.....................................108Brake discs....................................................241Brake lamps...................................................212Brake pads....................................................241Brakes ...........................................................241
Changing a bulb.....................................207-214Changing a fuse.....................................215-217Changing a wheel...................................200-206Changing a wiper blade .........................160, 222Changing the date .................................298, 332Changing the remote control battery...............79Changing the time ...........................69,298, 332Checking levels......................................236-239Checking the engine oil level...........................67Checking tyre pressures (using the kit).........199Checks....................................................234-241Children ..................................166-175, 186, 188Child seats....................................................166Child seats, conventional........................169-174Cigar lighter...................................................r105Clock................................................69, 298, 332Closing the boot...............................................82Closing the doors.......................................74,76Connectors, audio.................106, 295, 296, 321Coolant level............................................64, 236Coolant temperature indicator.........................r64Courtesy lamps..............................................161Cruise control........................................136, 139Cup holder.....................................................r104
B
Capacity, fuel tank ...........................................89Cables, high voltage......................................233CD .........................................................292,316CD MP3.........................................292, 317,318Central locking ...........................................74, 76
CDate (display)........................................298, 332Daytime running lamps ..........................207, 210Deactivating ESP...........................................183Deactivating the passenger airbag................188Deadlocking ...............................................77,78
D

343Alphabetical index
Defrosting..............................................102, 116Demisting...............................................102, 116Diesel...................................................42,43,57Diesel additive level.......................................238Dimensions ....................................................247Dipped beam ...........................56, 146,207, 208Dipstick ....................................................67, 236Directional lighting.................................155, 156Direction indicators........152, 178, 207,210, 212Driving economically .......................................44Driving positions (storing)................................96Dynamic emergency braking.........................123Dynamic stability control (DSC) .......62,181, 183
EBA(Emergency braking assistance) .................181EBFD.............................................................181Eco-driving......................................................44Economy mode..............................................221Eco off.............................................................f43Electronic brake force distribution (EBFD).........................................................181Electronic engine immobiliser....................r33,80Emergency boot release..................................82Emergency call...................................... 179, 253Emergency warning lamps............................178eMyWay ...................................................69, 255Energy economy mode..................................221Engine, Diesel .........................91, 234,235, 245
Filling with fuel............................................89-91Fitting a wheel...............................................205Fitting roof bars..............................................226Fittings, boot..................................................108Flashing indicators.................................152,178Flat bed lorry or trailer.............................r51,224Foglamps, front......................148,156, 207,211Foglamps, rear......................................r148, 213Folding/unfolding
the door mirrors ........................................... 102Front seats..................................................94-96Fuel............................................................44, 91Fuel consumption ......................................44, 46Fuel consumption fi gures ................................ 46Fuel fi ller cap ...................................................89Fuel fi ller fl ap .............................................89, 90Fuel gauge...........................................21, 54, 89Fuel tank ....................................................89, 90Fusebox, dashboard ......................................216Fuses.............................................................215
EF
G.P.S. ............................................................262Gearbox, electronic............................... 129, 241Gear lever, electronic gearbox system ..........129Guidance.......................................................262Guide-me-home.....................................150, 152
Engine compartment...............................50,234Engine compartment fusebox........................217Engine oil level indicator..........................r67,236Engines..................................................244,245Environment...................9,44,79, 111, 11 6, 239
Halogen headlamps.......................................207Hands-free kit ........................................278, 323Hazard warning lamps ...........................109, 178Head-up display............................. 134, 137, 139Headlamp adjustment....................................154Headlamps, directional..........................155, 207Headlamp wash.............................................158Head restraints, front.................................94,97Head restraints, rear......................................r101Heated seats...................................................98Heating .................................................... 44, 100Height and reach adjustment,steering wheel.............................................103High voltage................................47-49, 220, 233Hill start assist...............................................128History.............................................................46Hybrid.....................................................8, 26-51Hybrid fl ow.......................................................40Hybrid selector.................................................35Hybrid system .........................................8, 26-51
H G

345
Alphabetical index
Parking sensors, front....................................142Parking sensors, rear....................................r141Particle emission fi lter............................238, 240Passenger compartment fi lter........................240Player, CD MP3 .............................292,317, 318Port, USB.......................................106, 292, 319Power..............................................................r38Priming the fuel system.................................235Protecting children..................166-175, 186, 188Puncture........................................................194
R
Radio .....................................................288, 313Ready..............................................................35Ready lamp.....................................................35Rear foglamp ................................................. 212Rear screen (demisting)........................102, 116Recharging the battery..........................148, 213Reduction of electrical load...........................220Regeneration of the particleemissions fi lter.............................................r240Reinitialising the remote control ......................79Remote control...........................................74-81Removing a wheel .........................................203Removing the mat ......................................... 105Repair kit, puncture.......................................194Replacing bulbs......................................207-214Replacing fuses......................................215-217Replacing the air fi lter....................................r240Replacing the oil fi lter....................................r240
T
Replacing the passenger compartment fi lter........................................r240Replacing wiper blades.........................160,222Reset history.................................................... 46Resetting the service indicator........................r66Resetting the trip recorder...............................r68Reversing camera.........................................143Reversing lamp..............................................212Risk areas (update).......................................266Roof bars.......................................................226Routine checks .......................................236-241Running out of fuel (Diesel)...........................235
Table of weights .............................................246Tables of engines................................... 244, 245Tables of fuses...............................................215Tank, fuel .........................................................90Technical data.........................................244-247Te l ephone ..............................................278, 323Temperature, coolant .......................................64
Temperature control for heated seats..............98Temporary tyre repair kit ................................194
Side repeater.................................................r211Ski fl ap...........................................................107Snow chain ....................................................248Spare wheel...................................................200Speed limiter..........................................136, 137Speedometer.............................................r38,54Spotlamps, side ..................................... 153, 211Start.................................................................31Starting the engine..........................................42Starting the vehicle............................31, 34, 130Steering mounted controls, audio..........258, 311Stopping the vehicle ...........................31, 34,132Stop & Start .............................89,113, 116,218,233,235, 236, 239Storage...........................................104,106-108Storing driving positions ..................................96Switching off the engine....................31, 34, 132Synchronising the remote control....................79Synthesiser, voice..........................................272System, navigation........................................262
S
Safety for children...................166-175, 186, 188Screen, colour and mapping.......................... 259Screen, instrument panel...........................54, 70Screen, monochrome ............................312,333Screen, multifunction (with audio equipment).....312Screen menu map.........................300, 333,334Screenwash, front..........................................158Seat, rear bench......................................99,101Seat adjustment.........................................94, 95Seat belts................................................184-186Seats, rear................................................r99-101Serial number, vehicle...................................248Service indicator..............................................r65Servicing.......................................................... 44Setting the clock..............................69, 298, 332Short-cut menus............................................260Sidelamps ..............146, 147,152, 207, 210,212

351Visual search
Maintenance - Technical data


Dimensions ......................................... 247
Identifi cation markings ........................ 248
High voltage cables ......................... 49-50

Running out of fuel, Diesel ......... 234, 235
12 V battery ................................. 218-220
Load reduction, economy mode ...220-221
Engine compartment fuses ......... 215, 217

Opening the bonnet ............................ 233
Diesel weights .................................... 246

Checking levels ........................... 236-239
- oil - brake fluid - power steering fluid - coolant- screenwash/headlamp wash fluid
Checking components ................. 239-241
- 12 V battery - air filter - passenger compartment filter - oil filter - particle emissions filter - brake pads/discs - electric parking brake
Under the bonnet, Diesel .................... 234
Diesel engines .................................... 245
Electric motor...................................... 244

Changing bulbs............................ 207-214



- front

- rear
