69Monitoring

Airbags on temporarily. This lamp comes on for a few seconds when you turn on the ignition, then goes off.
This lamp should go off when the engine is started. If it does not go off, contact a CITROËN dealer or a qualified workshop.
fixed. One of the airbag or seat belt pretensioner systems has a fault. Have it checked by a CITROËN dealer or a qualified workshop.

Directional headlamps flashing. The directional headlamps system has a fault. Have it checked by a CITROËN dealer or a qualified workshop.

Seat belt(s) not fastened / unfastened
fixed or flashing accompanied by an audible signal.
A seat belt has not been fastened or has been unfastened. Pull the strap then insert the tongue in the buckle.
Warning / indicator lampStateCauseAction / Observations

Coolant temperature
gauge
With the hybrid system active: - in zone A , the temperature is correct, - in zone B , the temperature is too high; the central STOP warning lamp comes on, accompanied by an audible signal and a message in the instrument panel screen. You must stop as soon as it is safe to do so. Wait a few minutes before switching off the engine. Contact a CITROËN dealer or a qualified workshop.
After driving for a few minutes, the temperature and pressure in the cooling system increase. To top up the level:  wait for the engine to cool,  unscrew the cap by two turns to allow the pressure to drop,  when the pressure has dropped, remove the cap,  top up the level to the "MA X" mark.
Be aware of the risk of burns when topping up the cooling system. Do not fill above the maximum level (indicated on the reservoir).

71Monitoring
Service indicator
More than 1 800 miles (3 000 km) remain before the next service is due
When the ignition is switched on, no service information appears in the screen.
System which informs the driver when the next service is due, in accordance with the manufacturer's servicing schedule. The point at which the service is due is calculated from the last indicator zero reset. It is determined by two parameters: - the distance travelled, - the time elapsed since the last service. Between 600 miles (1 000 km) and 1 800 miles (3 000 km) remain before the next service is due
For 5 seconds after the ignition is switched on, the spanner symbolising the service operations comes on. The distance recorder display line indicates the distance remaining before the next service is due. Example: 1 700 miles (2 800 km) remain before the next service is due. For 5 seconds after the ignition is switched on, the screen indicates:
5 seconds after the ignition is switched on, the spanner goes off ; the distance recorder the spanner goes off ; the distance recorder the spanner goes offresumes its normal operation. The screen then indicates the total and trip distances.
Less than 600 miles (1 000 km) remain before the next service is due
Example: 560 miles (900 km) remain before the next service is due. For 5 seconds after the ignition is switched on, the screen indicates:
5 seconds after the ignition is switched on, the distance recorder resumes its normal operation. The spanner remains on to indicate that a service must be carried out soon.
Illumination of the key is accompanied by a message in the instrument panel screen.

Service overdue
Every time the ignition is switched on, an overdue service is immediately signaled by flashing of the spanner and the fixed illumination of the Service warning lamp.
The distance remaining may be weighted by the time factor, depending on the driving conditions. Therefore, the spanner may also come on if you have exceeded the period since the last service, indicated in the maintenance and warranty guide .
Following this operation, if you wish to disconnect the battery, lock the vehicle and wait at least five minutes for the zero reset to be taken into account.
5 seconds after the ignition is switched on, the distance recorder resumes its normal operation. The spanner remains on .
Service indicator zero reset
After each service, the service indicator must be reset to zero. The procedure for resetting to zero is as follows:  switch off the ignition,  press and hold the trip distance recorder
zero reset button,  switch on the ignition; the distance recorder display begins a countdown,  when the display indicates "=0" , release the button; the spanner disappears.
Retrieving the service information
You can access the service information at any time.  Press the trip distance recorder zero reset button. The service information is displayed for a few seconds, then disappears.

73Monitoring
Engine oil level indicator
Lack of oil
This is indicated by the flashing of " O I L" or an alert message in the instrument panel, accompanied by illumination of the service warning lamp and an audible signal. If the lack of oil is confirmed by a check using the dipstick, it is essential that the level is topped up to prevent damage to the engine. Refer to the "Checking levels" section.
Indicator fault
This is indicated by the flashing of "OIL- -" or the appearance of an alert message in the instrument panel. Contact a CITROËN dealer or a qualified workshop. In the event of a fault with the electric gauge, the oil level is no longer monitored. If the system is faulty, you should check the engine oil level using the dipstick under the bonnet. Refer to the "Checking levels" section.
This information is displayed for a few seconds when the ignition is switched on, at the same time as the service information.
The check of this level is only valid if the vehicle is on a level sur face, with the engine having been off for more than 30 minutes.
Oil level correct

System for manual adjustment of the brightness of the instruments and controls in relation to the exterior brightness.
Lighting dimmer
Activation
When the lighting is on:
 press the button to change the brightness of the instruments and controls,  when the level of brightness required is reached, release the button.
Deactivation
When the lighting is off, or in day mode on vehicles fitted with daytime running lamps, pressing the button does not have any effect.
The total and trip distances are displayed for thirty seconds when the ignition is switched off, when the driver's door is opened and when the vehicle is locked or unlocked.
Distance recorders
Total distance recorder
System which measures the total distance travelled by the vehicle since its first registration.
To conform to legislation in the country you are crossing, change the units of distance (miles or km) via the configuration menu.
Trip distance recorder
System which measures a distance travelled during a day or other period since it was reset
to zero by the driver.  With the ignition on, press the button until zeros appear.

75Monitoring
System allowing certain screens to be switched off for night driving (available only with eMyWay). The instrument panel remains on with the vehicle speed, electronic gearbox gear selected, cruise control or speed limiter information, if in use, and the low fuel alerts if necessary. If there is an alert or a change in a function or to a setting, the black panel mode is interrupted.
Black panel (black screen)
with eMyWay
For more information, refer to the eMyWay part of the "Audio and telematics" section.

Clock
The analogue clock does not have an adjustment button. To set the time, refer to the section relating to the screen (audio system) configuration menu. The clock is synchronised with the screen time; once the the setting has been confirmed in the screen, the hands will turn to synchronise with the screen, and each time the ignition is switched on.
Setting the date and time
Audio system / Bluetooth
Press MENU .
Using the arrows, select " Personalisation-configuration " and confirm.
Using the arrows, select " Display configuration " and confirm.
Using the arrows, select " Date and time adjustment " and confirm.
Select the setting to be modified. Confirm by pressing OK , then make the change and confirm again to save the modification.
Adjust the settings one by one, confirming by pressing the OK button. Next select the " OK " tab on the screen then confirm to exit from the " Date and time adjustment " menu.

77Monitoring
eMyWay
Press SETUP to display the " Configuration " menu.
Select " Display configuration " and confirm.
Select " Set date and time " and confirm.
Select " Synchronize the minutes with GPS " so that setting the minutes is done automatically by satellite reception.
Adjust the settings one by one.
Then select " OK " on the screen and confirm to save the settings.
The clock, located in the dashboard, is synchronised with the time in the screen. It is set once the time is adjusted using the " SETUP " menu and every time the ignition is switched on.
Select the setting to adjust. Confirm by pressing OK , then adjust the setting and confirm again to save the modification.

Trip computer
System that gives you information on the current journey (range, fuel consumption…).
 When the trip required is displayed, press the control for more than two seconds or use the left hand thumb wheel of the steering mounted controls.
Instrument panel screen
Information display
 Press the button on the end of the wiper control stalk to display the various tabs in succession.
- The current information tab with: ● t h e r a n g e , ● the current fuel consumption.
- Trip "1" with: ● the average speed, for the first trip. ● the average fuel consumption.
- Trip "2" with: ● the average speed, for the second trip. ● the consumption history (with 16/9 colour screen), ● the average fuel consumption.
Reset trip
- Radio or media. - Satellite navigation.
