display Citroen NEMO 2008.5 1.G Owner's Guide

70
Mobile telephone with hands-free function
Managing incoming calls
When an incoming call arrives, the message
"Phone" appears on the audio display, if the
radio is on.
Simple call
To accept a call, press the green
button.
Dual call
To accept a second call while already on the
phone, press the green button once.
To switch back to the first call, press the
green button again.
To refuse the second call while already on
the phone, press the red button.
To end the call, press the red button again.
To refuse or finish a call, press
the red button.
To switch communication between the
system and the mobile telephone (private
mode) and vice-versa, press the green
button .
Managing outgoing calls
With the keypad
Enter the number of the person you are
calling on the mobile telephone keypad.
Press the "Call" button of the mobile
telephone.
Depending on the mobile telephone model,
the call will be automatically transferred to
hands-free mode, otherwise press the green
button.
To redial the last number dialled, hold
down the green button until the number is
redialled.
With voice commands
Press the green button.
Wait for the sound signal and/or the display
of the message "Phone" on the audio
display.
Say the voice identity of the person to call.
The system repeats the voice identity for
confirmation and automatically makes the
call.
If the voice identity repeated by the system
is not correct, press the red button to cancel
and restart the procedure.
Deleting the system
To delete the contents of the system’s
memory, press the green and red buttons at
the same time for over two seconds.
This operation deletes all of the matched
mobile telephones, as well as all of the
telephone numbers recorded in the memory.
For the next hands-free communication,
you must restart the procedure for the first
connection to the system (matching).
Good practice
You can match up to three mobile
telephones in the system.
For safety reasons and because
matching operations require prolonged
attention on the part of the driver, matching
operations between the mobile telephone
and the Bluetooth® hands-free kit must be
carried out with the vehicle stationary, and
the ignition switched on.
To use voice commands, you must
have already recorded and linked a
voice identity to the telephone number to
be called; refer to your mobile telephone
handbook.
The management of the second call
by the system is only possible if the
function is activated on the mobile
telephone.

92
Air bags
FRONT AIR BAGS
The front air bags are incorporated in the
centre of the steering wheel for the driver
and in the fascia for the front passenger.
Activation
They are deployed simultaneously, unless
the passenger ’s front air bag has been
disarmed, in the event of a serious front
impact.
The front air bag inflates between the front
occupant of the vehicle and the fascia to
cushion his forward movement.
Disarming
The passenger ’s front air bag alone can be
disarmed. The air bag is disarmed from the
trip computer.
The air bag warning light on the
instrument panel is lit throughout
the period of disarming.
To ensure the safety of your child,
it is essential to disarm the passenger
air bag when you install a rear-facing child
seat on the front passenger seat. Otherwise,
the child would risk being killed or seriously
injured if the air bag were to inflate.
Refer to the "MENU" section of
chapter 3, then select OFF
on the "Passenger air bag" menu.
Operating fault
If the two air bag warning lights are lit
continuously, do not install a rear-facing
child seat. Consult a CITROËN dealer .
If this warning light comes
on on the instrument panel,
accompanied by an audible signal
and a message on the display,
consult a CITROËN dealer without delay
to have the system checked. The air bags
may no longer be triggered in the event of a
serious impact.

106
Battery
The batteries contain harmful
substances such as sulphuric acid and
lead. They must be discarded in accordance
with the provisions of the law and must not,
in any circumstances, be discarded with
household waste.
Take used batteries to a special collection
point.
Before disconnecting the battery, you must
wait for 2 minutes after switching off the
ignition.
Never disconnect a terminal when the
engine is running.
Never charge a battery without first
disconnecting the terminals.
Close the windows and doors before
disconnecting the battery.
After every reconnection of the battery,
switch on the ignition and wait 1 minute
before starting to allow the electronic
systems to be initialised. If slight difficulties
are experienced after this, please consult a
CITROËN dealer . It is advisable to disconnect the battery
if the vehicle is not to be used for a
period of more than one month.
If the battery has been disconnected
for some time, it may be necessary to
reinitialise the following functions:
- the display parameters (date, time, language, distance unit and temperature
unit),
- the radio stations,
- the central locking.
Some settings are cleared and must be
reprogrammed, consult a CITROËN dealer .

122
Fuel
FILLING WITH FUEL
Low fuel level
When the minimum fuel tank
level is reached, this warning
light comes on. At this moment,
you have approximately 6 litres
remaining. Fill up without delay to avoid
running out of fuel.
The fuel tank must be filled with the engine
off .
- Open the fuel filler flap.
- Hold the cap with one hand.
- With the other hand, insert the key and turn it a third of a turn.
- Remove the cap. When the fuel filler flap is open, a
safety system prevents sliding of the
side door.
A label affixed to the inside of the flap
reminds you of the type of fuel to be used.
When filling the fuel tank, do not continue
after the 3rd cut-off of the nozzle. This could
cause malfunctions.
The capacity of the fuel tank is
approximately 45 litres.
After filling the fuel tank, lock the cap and
close the flap.
FUEL CIRCUIT DEACTIVATED
In the event of a serious collision, a device
automatically cuts off the fuel supply to the
engine and the vehicle’s electrical supply.
This also automatically unlocks the doors
and switches on the interior lights.
A message is displayed on the instrument
panel (depending on model).
Turn the key to position STOP to avoid the
battery being discharged.

Check that there is no smell or leak of fuel
outside the vehicle.
Reactivating
To continue driving, manually re-establish
the fuel supply and the electrical supply:
- with the ignition key in position STOP,
turn it to position RUNNING,
- move the direction indicators control stalk all the way upwards,
- put it to position "Stop",
- move the direction indicators control stalk all the way downwards,
- put it to position "Stop" again,
- move it all the way upwards again,
- put it to position "Stop" again,
- move it all the way downwards again,
- put it to position "Stop" again,
- turn the ignition key to position STOP.
