Page 1071 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 4E2 – 2IREAR DRUM BRAKES
DAEWOO V–121 BL4
lining, will not only wear the lining, but also will
make it difficult, if not impossible, to obtain proper
brake performance.
S  An out–of–round drum

Page 1072 of 2643

DAEWOO LACETTI 2004  Service Repair Manual REAR DRUM BRAKES  4E2 – 3
DAEWOO V–121 BL4
MAINTENANCE AND REPAIR
ON–VEHICLE SERVICE
BRAKE ADJUSTMENT
Removal Procedure
1.  Release the parking brake.
2.  Operate the brake at least 10 times unt

Page 1073 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 4E2 – 4IREAR DRUM BRAKES
DAEWOO V–121 BL4
Installation  Procedure
1.  Position the rear brake drum. Fasten the drum det-
ent screw.
Tighten
Tighten the drum detent screw to 4 NSm (35 lb–in).
2.

Page 1074 of 2643

DAEWOO LACETTI 2004  Service Repair Manual REAR DRUM BRAKES  4E2 – 5
DAEWOO V–121 BL4
8.  Unfasten the trailing shoe and lining assembly hold-
down return spring.
9.  Disconnect the trailing shoe and lining assembly on
the right side.
10.

Page 1075 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 4E2 – 6IREAR DRUM BRAKES
DAEWOO V–121 BL4
7.  Position the leading shoe and the adjuster assem-
bly against the backing plate.
8.  Fasten the lower return spring to the leading shoe.
9.  Install t

Page 1076 of 2643

DAEWOO LACETTI 2004  Service Repair Manual REAR DRUM BRAKES  4E2 – 7
DAEWOO V–121 BL4
16.  Install the brake drum and fasten it with the drum
detent screw.
Tighten
Tighten the drum detent screw to 4 NSm (35 lb–in).
17.  Install the rear

Page 1077 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 4E2 – 8IREAR DRUM BRAKES
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the wheel cylinder to the backing plate with
the wheel cylinder bolt.
Tighten
Tighten the wheel cylinder–to–backin

Page 1078 of 2643

DAEWOO LACETTI 2004  Service Repair Manual REAR DRUM BRAKES  4E2 – 9
DAEWOO V–121 BL4
Installation  Procedure
1.  Install the hub with bolts.
Tighten
Tighten the hub botls to 65 NSm (48 lb–ft).
2.  Install the brake wheel cylinder assemb

Page 1079 of 2643

DAEWOO LACETTI 2004  Service Repair Manual 4E2 – 10IREAR DRUM BRAKES
DAEWOO V–121 BL4
UNIT REPAIR
WHEEL CYLINDER
Disassembly Procedure
1.  Remove the wheel cylinder assembly from the
backing plate. Refer to ”Wheel Cylinder Assembly”
in

Page 1080 of 2643

DAEWOO LACETTI 2004  Service Repair Manual REAR DRUM BRAKES  4E2 – 11
DAEWOO V–121 BL4
6.  Attach to the wheel cylinder the spring assembly,
followed by the pistons, the seals, and the boots.
7.  Inspect the pistons for free movement.
8.
