8–18 BODY DIMENSIONNUBIRA/LACETTI
Fig. 17

NUBIRA/LACETTIBODY DIMENSION 8–19
HATCHBACK
Fig. 18

8–20 BODY DIMENSIONNUBIRA/LACETTI
Unit: mm(in.)
Fig. 19

NUBIRA/LACETTI SEALING, CAULKING AND DEADNER 9–1
SECTION 9
SEALING, CAULKING AND DEADNER
CONTENTS
1. SEALING & CAULKING 9 – 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. DEADNER 9 – 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.GENERAL DESCRIPTION9–14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2.REPAIR PROCEDURE9–14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9–2 SEALING, CAULKING AND DEADNER NUBIRA/LACETTI
1. SEALING & CAULKING
Note : Seal the following areas to prevent air leaks water leaks, and rust.
ENGINE ROOM.
Fig. 1 Engine Room

NUBIRA/LACETTI SEALING, CAULKING AND DEADNER 9–3
ENGINE ROOM
Fig. 2 Engine Room

9–4 SEALING, CAULKING AND DEADNER NUBIRA/LACETTI
DASH
Fig. 3 Dash

NUBIRA/LACETTI SEALING, CAULKING AND DEADNER 9–5
FLOOR & TRUNK ROOM
Fig. 4 Floor & Trunk Room

9–6 SEALING, CAULKING AND DEADNER NUBIRA/LACETTI
REAR LAMP & TRUNK ROOM
Fig. 5 Rear Lamp

NUBIRA/LACETTI SEALING, CAULKING AND DEADNER 9–7
Fig. 6 Rear Lamp
