DAEWOO NUBIRA 2004 Service Repair Manual

5A1 – 172IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1868
EDS 6 OUTPUT SHORTED TO POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output voltage of the EDS 6 (at ON) is 12 volt.
S No DTC P1867, P1869.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1868 sets, the possible cause of fault
could be TCM.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 173
DAEWOO V–121 BL4
DTC P1868 – EDS 6 Output Shorted To Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 6 ON/OFF.
Does the EDS 6 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Remove the oil pan.
2. Disconnect the wiring connector of EDS 6.
3. Turn the ignition ON, with the engine OFF.
4. Measure the voltage terminal 2 of the EDS 6
wiring connector.
Is the voltage within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the internal line(EDS 6) for a short to power.
Is the repair complete?–System OK–
5Replace the EDS 6.
Is the replacement complete?–Go to Step 6–
61. Check if any DTCs are set.
2. Are any DTCs displayed that have not been
diagnosed?–Go to ”Applica-
ble DTC table”System OK

5A1 – 174IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1869
EDS 6 OUTPUT OPEN
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output ampere of the EDS 6 is less than 10mA.
S No DTC P1867, P1868.
S Immediately after the above condition occurs.
Action Taken When The DTC SetsS The Malfunction Indicator Lamp(MIL) will illuminate.
S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1869 sets, the possible cause of fault
could be EDS valve.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 175
DAEWOO V–121 BL4
DTC P1869 – EDS 6 Output Open
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 6 ON/OFF.
Does the EDS 6 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector.
3. Measure the resistance between terminals 5
and 11 of the transaxle wiring connector.
Is the resistance within the values shown?TFT
25°C (77°F)
6 ΩGo to Step 7Go to Step 4
41. Remove the oil pan.
2. Disconnect the wiring connector of EDS 6.
3. Measure the resistance between terminal 2 of
the EDS 6 and terminal 5 of the transaxle con-
nector.
4. Measure the resistance between terminal 1 of
the EDS 6 and terminal 11 of the transaxle
connector.
Is the resistance within the values shown? 0 WGo to Step 6Go to Step 5
51. Repair the circuit (between terminal 2 and ter-
minal 5) for an open.
2. Repair the circuit (between terminal 1 and ter-
minal 11) for an open.
Is the repair complete?–System OK–
6Replace the EDS 6.
Is the replacement complete?–System OK–
71. Disconnect the transaxle wiring connector and
TCM connector.
2. Measure the resistance between terminal 5 of
the transaxle wiring connector and terminal C7
of the TCM wiring connector.
3. Measure the resistance between terminal 11 of
the transaxle wiring connector and terminal
A12 of the TCM wiring connector.
Is the resistance within the values shown? 0 WGo to Step 9Go to Step 8
8Repair the transaxle wiring harness for an open.
Is the repair complete?–System OK–
9Replace the TCM.
Is the replacement complete?–Go to Step 10–
101. After the repair, use a scan tool ”clear info”
function and road tests the vehicle.
2. Review the ”DTC info”.
3. Has the last test failed or is the current DTC
displayed?–Begin diagno-
sis againRepair verified
exit DTC chart

5A1 – 176IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1871
EDS VALVE POWER SUPPLY CIRCUIT SHORTED TO
POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S If the voltage applied to high side driver is higher
than the threshold(6V) with high side driver switch
off status then a fault is detected.
S No DTC P1870.
S Immediately after the above condition occurs.
Action Taken When The DTC SetsS The Malfunction Indicator Lamp(MIL) will illuminate.
S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1871 sets, the possible cause of fault
could be EDS valve power supply line.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 177
DAEWOO V–121 BL4
DTC P1871 – EDS Valve Power Supply Circuit Shorted to Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Start engine and allow it to warm up at idle.
4. Put gear selector in Part and set the parking
brake.
5. Observe ”EDS 3,4,5,6’s input ampere and out-
put ampere” on the scan tool.
Is the amperes within the values shown?EDS ampere
(0–2 Amp)Go to
Diag-
nostic Aids"Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector and
TCM connector.
3. Measure the voltage of the transaxle wiring
terminal 5.
Is the voltage within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the circuit for a short to power.
Is the action complete?–System OK–
51. Remove the oil pan.
2. Disconnect the EDS valve wiring connector.
3. Turn the ignition ON.
4. Measure the voltage of the EDS 3 terminal 2.
5. Measure the voltage of the EDS 4 terminal 2.
6. Measure the voltage of the EDS 5 terminal 2.
7. Measure the voltage of the EDS 6 terminal 2.
Is the voltage within the values shown?11–14VGo to Step 6Go to Step 7
6Repair the circuits(power supply lines) for a short to
power.
Is the action complete?–System OK–
7Replace the TCM.
Is the action complete?–Go to Step 8–
81. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart

5A1 – 178IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1874
SOLENOID VALVE POWER SUPPLY CIRCUIT SHORTED
TO POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S No DTC P1873.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1874 sets, the possible cause of fault
could be solenoid valve power supply line.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 179
DAEWOO V–121 BL4
DTC P1874 – Solenoid Valve Power Supply Circuit Shorted to
Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
Then, start engine and allow it to warm up at
idle.
3. Put gear selector in Park and set the parking
brake.
4. Observe ”solenoid 1,2” on the scan tool.
Is the solenoid ON ?–Go to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector and
TCM connector.
3. Measure the voltage of the transaxle wiring
terminal 3.
Is the voltage within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the circuit for a short to power.
Is the action complete?–System OK–
51. Remove the oil pan.
2. Disconnect the solenoid 1,2 wiring connector.
3. Turn the ignition ON.
4. Measure the voltage of the solenoid 1 terminal
2.
5. Measure the voltage of the solenoid 2 terminal
2.
Is the voltage within the values shown?11–14VGo to Step 6Go to Step 7
6Repair the circuits(power supply lines) for a short to
power.
Is the action complete?–System OK–
7Replace the TCM.
Is the action complete?–Go to Step 8–
81. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart

5A1 – 180IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
RangePark/
Neutr
alRever
seD321
GearNR1st2nd3rd4th1st2nd3rd1st2nd1st
Solenoid Valve
1ONON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFFON/
OFF
Solenoid Valve
2ONONONOFFOFFOFFONOFFOFFONOFFON
Line Pressure
Control Sole-
noid Valve 3
(EDS 3)OFFOFFOFFONON/
OFFON/
OFFOFFONON/
OFFOFFONOFF
Line Pressure
Control Sole-
noid Valve 4
(EDS 4)ONOFFONONONOFFONONONONONON
Line Pressure
Control Sole-
noid Valve 5
(EDS 5)OFFOFFONONOFFOFFONONOFFONONON
Line Pressure
Control Sole-
noid Valve 6
(EDS 6)ONOFFONONONOFFONONONONONON
Brake BAAAAAAAA
Brake CH
Brake DH
Clutch EAAAAAA
Brake FHHHHHHH
Lock–up
ClutchA
A = Applied
H = Holding
ON = The solenoid is energized.
OFF = The solenoid is de–energized.
** = Manual Second–Third gear is only available above approximately 100 km/h (62 mph).
*** = Manual First–Second gear is only available above approximately 60 km/h (37 mph).
Note : Manual First–Third gear is also possible at high vehicle speed as a safety feature.
DIAGNOSTIC TROUBLE CODE(DTC) P1881
2–1 SHIFT MALFUNCTION
Circuit Description
The special feature of 4HP 16 Auto Transaxle is that it op-
erates without freewheels. Shifting between individual
gears takes place by means of overlapping clutch engage-
ment and release.
The advantage of overlap shifting are as follows:
– The transaxle can be of more compact design
and is lighter on account of the absence of free-
wheels and the lower number of shift elements.– Lower drag losses, i.e. higher efficiency.
– Lower peak torque acting on the components and
driveline.
However, overlap shifting necessitates high–performance
hardware and software, and precision engine signals.
Conditions for Setting the DTC
S Transmission oil temperature is greater than –10°C
(14°F).
S Selector lever is not in N(Neutral), P(Park) position.
S System voltage is greater than 9 volts.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 181
DAEWOO V–121 BL4
S No input speed error DTCs P0715, P0716, or
P0717.
S Output speed is greater than 256 rpm.
S Input speed is greater than 400 rpm.
S 2–1 gear shift is active.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.
S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
3rd gear.S Open lock–up clutch.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1881 sets, the possible cause of fault
could be TCM.
DTC P1881 – 2–1 Shift Malfunction
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
Then, start engine and allow it to warm up at
idle.
3. Observe ”idle rpm, TPS” on the scan tool.
Was a problem found?–Go to ”Engine
Diagnostic In-
formation”Go to Step 3
3Inspect ”ECM”. Refer to Section 1F, System Diagno-
sis, EOBD System Check.
Was a problem found?–Go to ”Engine
Diagnostic In-
formation”Go to Step 4
41. Turn the ignition OFF.
2. Disconnect the TCM wiring connector.
3. Measure the voltage between terminal B3 and
B13 of the transaxle wiring connector.
4. Turn the ignition ON.
5. Measure the voltage between terminal C15 and
B13 of the transaxle wiring connector.
6. Measure the voltage between terminal C16 and
B13 of the transaxle wiring connector.
Is the voltage within the values shown?11–14VGo to Step 5Go to ”System
Voltage Low or
High”
5Replace the TCM.
Is the action complete?–Go to Step 6–
61. After the repair, use a scan tool ”clear info”
function and road test the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Replace the
transaxle as-
semblyRepair verified
exit DTC chart
