DAEWOO NUBIRA 2004 Service Repair Manual

5A1 – 162IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1863
EDS 4 OUTPUT OPEN
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output ampere of the EDS 4 is less than 10mA.
S No DTC P1861, P1862.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1863 sets, the possible cause of fault
could be EDS4 valve.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 163
DAEWOO V–121 BL4
DTC P1863 – EDS 4 Output Open
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 4 ON/OFF.
Does the EDS 4 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector.
3. Measure the resistance between terminals 5
and 7 of the transaxle wiring connector.
Is the resistance within the values shown?TFT
25°C (77°F)
6 ΩGo to Step 7Go to Step 4
41. Remove the oil pan.
2. Disconnect the wiring connector of EDS 4.
3. Measure the resistance between terminal 2 of
the EDS 4 and terminal 5 of the transaxle con-
nector.
4. Measure the resistance between terminal 1 of
the EDS 4 and terminal 7 of the transaxle con-
nector.
Is the resistance within the values shown? 0 WGo to Step 6Go to Step 5
51. Repair the circuit (between terminal 2 and ter-
minal 5) for an open.
2. Repair the circuit (between terminal 1 and ter-
minal 7) for an open.
Is the repair complete?–System OK–
6Replace the EDS 4.
Is the replacement complete?–System OK–
71. Disconnect the transaxle wiring connector and
TCM connector.
2. Measure the resistance between terminal 5 of
the transaxle wiring connector and terminal C7
of the TCM wiring connector.
3. Measure the resistance between terminal 7 of
the transaxle wiring connector and terminal A3
of the TCM wiring connector.
Is the resistance within the values shown? 0 WGo to Step 9Go to Step 8
8Repair the transaxle wiring harness for an open.
Is the repair complete?–System OK–
9Replace the TCM.
Is the replacement complete?–Go to Step 10–
101. After the repair, use a scan tool ”clear info”
function and road tests the vehicle.
2. Review the ”DTC info”.
3. Has the last test failed or is the current DTC
displayed?–Begin diagno-
sis againRepair verified
exit DTC chart

5A1 – 164IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1864
EDS 5 OUTPUT SHORTED TO GROUND
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output voltage of the EDS 5 is less than 2 volt.
S No DTC P1865, P1866.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1864 sets, the possible cause of fault
could be EDS valve.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 165
DAEWOO V–121 BL4
DTC P1864 – EDS 5 Output Shorted To Ground
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 5 ON/OFF.
Does the EDS 5 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector.
3. Measure the resistance between terminals 5
and 10 of the transaxle wiring connector.
Is the resistance within the values shown?TFT
25°C (77°F)
6 ΩGo to Step 7Go to Step 4
41. Remove the oil pan.
2. Disconnect the wiring connector of EDS 5.
3. Measure the resistance between terminal 2 of
EDS 5 and ground.
4. Measure the resistance between terminal 1 of
EDS 5 and ground.
Is the resistance within the values shown?
Go to Step 6Go to Step 5
5Repair the internal line(EDS 5) for a short to ground.
Is the repair complete?–System OK–
6Replace the EDS 5.
Is the replacement complete?–System OK–
71. Disconnect the transaxle wiring connector and
TCM connector.
2. Measure the resistance between terminal 5 of
the transaxle wiring connector and ground.
3. Measure the resistance between terminal 10 of
the transaxle wiring connector and ground.
Is the resistance within the values shown?
Go to Step 9Go to Step 8
8Repair the transaxle wiring harness for a short to
ground.
Is the repair complete?–System OK–
9Replace the TCM.
Is the replacement complete?–Go to Step 10–
101. After the repair, use a scan tool ”clear info”
function and road tests the vehicle.
2. Review the ”DTC info”.
3. Has the last test failed or is the current DTC
displayed?–Begin diagno-
sis againRepair verified
exit DTC chart

5A1 – 166IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1865
EDS 5 OUTPUT SHORTED TO POWER
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output voltage of the EDS 5 (at ON) is 12 volt.
S No DTC P1864, P1866.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1865 sets, the possible cause of fault
could be EDS5.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 167
DAEWOO V–121 BL4
DTC P1865 – EDS 5 Output Shorted To Power
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 5 ON/OFF.
Does the EDS 5 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Remove the oil pan.
2. Disconnect the wiring connector of EDS 5.
3. Turn the ignition ON, with the engine OFF.
4. Measure the voltage of EDS 5 wiring connector
terminal 2.
Is the resistance within the values shown?11–14VGo to Step 4Go to Step 5
4Repair the internal line(EDS 5) for a short to power.
Is the repair complete?–System OK–
5Replace the EDS 5.
Is the replacement complete?–Go to Step 6–
61. Check if any DTCs are set.
2. Are any DTCs displayed that have not been
diagnosed?–Go to ”Applica-
ble DTC table”System OK

5A1 – 168IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1866
EDS 5 OUTPUT OPEN
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output ampere of the EDS 5 is less than 10mA.
S No DTC P1864, P1865.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1866 sets, the possible cause of fault
could be EDS valve.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 169
DAEWOO V–121 BL4
DTC P1866 – EDS 5 Output Open
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 5 ON/OFF.
Does the EDS 5 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector.
3. Measure the resistance between terminals 5
and 10 of the transaxle wiring connector.
Is the resistance within the values shown?TFT
25°C (77°F)
6 ΩGo to Step 7Go to Step 4
41. Remove the oil pan.
2. Disconnect the wiring connector of EDS 5.
3. Measure the resistance between terminal 2 of
the EDS 5 and terminal 5 of the transaxle con-
nector.
4. Measure the resistance between terminal 1 of
the EDS 5 and terminal 10 of the transaxle
connector.
Is the resistance within the values shown? 0 WGo to Step 6Go to Step 5
51. Repair the circuit (between terminal 2 and ter-
minal 5) for an open.
2. Repair the circuit (between terminal 1 and ter-
minal 10) for an open.
Is the repair complete?–System OK–
6Replace the EDS 5.
Is the replacement complete?–System OK–
71. Disconnect the transaxle wiring connector and
TCM connector.
2. Measure the resistance between terminal 5 of
the transaxle wiring connector and terminal C7
of the TCM wiring connector.
3. Measure the resistance between terminal 10 of
the transaxle wiring connector and terminal
A10 of the TCM wiring connector.
Is the resistance within the values shown? 0 WGo to Step 9Go to Step 8
8Repair the transaxle wiring harness for an open.
Is the repair complete?–System OK–
9Replace the TCM.
Is the replacement complete?–Go to Step 10–
101. After the repair, use a scan tool ”clear info”
function and road tests the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart

5A1 – 170IZF 4 HP 16 AUTOMATIC TRANSAXLE
DAEWOO V–121 BL4
DIAGNOSTIC TROUBLE CODE(DTC) P1867
EDS 6 OUTPUT SHORTED TO GROUND
Circuit Description
The pressure control valves (EDS valves 3,4,5 and 6) are
precision electronic pressure regulators that control the
operation of the clutches, brakes and lock–up clutch.
The valve reduces the system pressure with which the
downstream solenoid valves and electrical pressure regu-
lating valves are supplied. It is possible to use smaller so-
lenoid valves as a result. The EDS require a constant input
pressure.
Conditions for Setting the DTC
S Output voltage of the EDS 6 is less than 2 volt.
S No DTC P1868, P1869.
S Immediately after the above condition occurs.
Action Taken When The DTC Sets
S The Malfunction Indicator Lamp(MIL) will illuminate.S The TCM will record operating conditions at the
time the diagnostic fails. This information will be
stored in the Failure Records buffer.
S Adopt Emergency/ Substitute mode and constant
4th gear by hydraulic control.
S After ignition OFF/ON : 3rd gear by hydraulic con-
trol. Possible P, R and N also possible.
S Power supply cut off to the EDS valve.
Conditions for Clearing the MIL/DTC
S The MIL will turn OFF when the malfunction has
not occurred after three–ignition cycle.
S A history DTC will clear after 40 consecutive warm
up cycles without a fault.
S Using a scan tool can clear history DTCs.
Diagnostic Aids
S When DTC P1867 sets, the possible cause of fault
could be EDS valve.

ZF 4 HP 16 AUTOMATIC TRANSAXLE 5A1 – 171
DAEWOO V–121 BL4
DTC P1867 – EDS 6 Output Shorted To Ground
StepActionValue(s)YesNo
1Perform an On–Board Diagnostic (EOBD) System
Check.
Is the check completed?–Go to Step 2Go to ”On–
Board Diagnos-
tic System
Check”
21. Install the scan tool.
2. Turn the ignition ON, with the engine OFF.
3. Select ”Actuating” on the scan tool.
4. Actuate EDS 6 ON/OFF.
Does the EDS 6 change ON/OFF?ON/OFFGo to ”Diag-
nostic Aids”Go to Step 3
31. Turn the ignition OFF.
2. Disconnect the transaxle wiring connector.
3. Measure the resistance between terminals 5
and 11 of the transaxle wiring connector.
Is the resistance within the values shown?TFT
25°C (77°F)
6 ΩGo to Step 7Go to Step 4
41. Remove the oil pan.
2. Disconnect the wiring connector of EDS 6.
3. Measure the resistance between terminal 2 of
EDS 6 and ground.
4. Measure the resistance between terminal 1 of
EDS 6 and ground.
Is the resistance within the values shown?
Go to Step 6Go to Step 5
5Repair the internal line(EDS 6) for a short to ground.
Is the repair complete?–System OK–
6Replace the EDS 6.
Is the replacement complete?–System OK–
71. Disconnect the transaxle wiring connector and
TCM connector.
2. Measure the resistance between terminal 5 of
the transaxle wiring connector and ground.
3. Measure the resistance between terminal 11 of
the transaxle wiring connector and ground.
Is the resistance within the values shown?
Go to Step 9Go to Step 8
8Repair the transaxle wiring harness for a short to
ground.
Is the repair complete?–System OK–
9Replace the TCM.
Is the replacement complete?–Go to Step 10–
101. After the repair, use a scan tool ”clear info”
function and road tests the vehicle.
2. Review the ”DTC info”.
Has the last test failed or is the current DTC dis-
played?–Begin diagno-
sis againRepair verified
exit DTC chart
