DAEWOO NUBIRA 2004 Service Repair Manual

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 37
DAEWOO V–121 BL4
DTC 13
Passenger Belt Pretensioner Deployment Loop
Resistance Is High
CAUTION : The sensing and diagnostic module(SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 1 minute after the ignition is
OFF and the fuse has been removed. If the airbags
and pretensioners are not disconnected, do not be-
gin service until one minute has passed after discon-
necting power to SDM. Otherwise, injury could result.
CAUTION : During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.Never power the supplemental inflatable re-
straints(SIR) when the SDM is not rigidly attached to
the vehicle. All SDM mounting bolts must be carefully
tightened , and the arrow on the SDM must be point
toward the front of the vehicle to ensure proper op-
eration of the SIR. The SDM could be activated if it is
powered when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible in-
jury.
Step
ActionValue(s)YesNo
1Visually inspect the connector and the wiring of pas-
senger belt pretensioner. Is the connector discon-
nected?–Connect the
connector.Go to Step 2
21. Confirm the ignition switch ”OFF”.
2. Disconnect the connector of the passenger belt
pretensioner.
3. Disconnect the connector of SDM wiring.
4. Check the resistance between the terminal 1,2
of SDM and the terminal 1,2 of passenger belt
pretensioner.Is the resistance 10KΩ?
10K ΩGo to Step 3Replace the
airbag wiring.
31. Replace the SDM.
2. Confirm the ignition switch ”ON”.
3. Erase the DTC using scan tool.
4. Perform the SIR Diagnostic System Check.
Does the DTC still exist?–Go to Step 4System is OK.
4Replace the passenger belt pretensioner.–––

8B – 38ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
J3B18B05
341 2
SDM Driver
Pretensioner
ModulePassenger
Pretensioner
Module
PNKPNK/
DK BLUDK BLU/
WHT BLK/WHT PPL YEL/
DK BLUDK BLU/
WHTRED/
BLK
DK
BLU
G202 C301
126 1
2
38 76
DIAGNOSTIC TROUBLE CODE (DTC) 14
PASSENGER BELT PRETENSIONER DEPLOYMENT
LOOP RESISTANCE IS LOW
Circuit Description
When the ignition switch is turned to ON, the sensing and
diagnostic module(SDM) will perform turn–on test to diag-
nose critical malfunctions within SDM itself.
Upon passing these test ignition and deployment loop volt-
ages are measured to ensure that they are within their nor-
mal voltage ranges. The SDM monitors the voltages at the
driver low and the passenger low to detect shorts to
ground or voltage in the deploy loops.The SDM checks the wiring connection to the passenger
airbag module by letting the infinitesimal current flow
through the internal circuit and verify the resistance.
DTC 14 Will Set When
S The resistance of passenger belt pretensioner
deploy loop is lower than 1.5 ohms.
S The shorting bar is damaged and then the SDM
must be replaced .

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 39
DAEWOO V–121 BL4
DTC 14
Passenger Belt Pretensioner Deployment Loop
Resistance Is Low
CAUTION : The sensing and diagnostic module(SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 1 minute after the ignition is
OFF and the fuse has been removed. If the airbags
and pretensioners are not disconnected, do not be-
gin service until one minute has passed after discon-
necting power to SDM. Otherwise, injury could result.
CAUTION : During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.Never power the supplemental inflatable re-
straints(SIR) when the SDM is not rigidly attached to
the vehicle. All SDM mounting bolts must be carefully
tightened , and the arrow on the SDM must be point
toward the front of the vehicle to ensure proper op-
eration of the SIR. The SDM could be activated if it is
powered when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible in-
jury.
Step
ActionValue(s)YesNo
1Visually inspect the connector and the wiring of pas-
senger belt pretensioner. Is the connector discon-
nected?–Connect the
connector.Go to Step 2
21. Confirm the ignition switch ”OFF”.
2. Disconnect the connector of the passenger belt
pretensioner.
3. Disconnect the connector of SDM wiring.
4. Check the resistance between the terminal 1
and 2 of passenger belt pretensioner. Is the
resistance ?Go to Step 3Replace the
airbag wiring.
31. Replace the SDM.
2. Confirm the ignition switch ”ON”.
3. Erase the DTC using scan tool.
4. Perform the SIR Diagnostic System Check.
Does the DTC still exist?–Go to Sep 4System is OK.
4Replace the passenger belt pretensioner.–––

8B – 40ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
J3B18B05
341 2
SDM Driver
Pretensioner
ModulePassenger
Pretensioner
Module
PNKPNK/
DK BLUDK BLU/
WHT BLK/WHT PPL YEL/
DK BLUDK BLU/
WHTRED/
BLK
DK
BLU
G202 C301
126 1
2
38 76
DIAGNOSTIC TROUBLE CODE (DTC) 15
PASSENGER BELT PRETENSIONER DEPLOYMENT
LOOP IS SHORTED TO GROUND
Circuit Description
When the ignition switch is turned to ON, the sensing and
diagnostic module(SDM) will perform turn–on test to diag-
nose critical malfunctions within SDM itself.
Upon passing these test ignition and deployment loop volt-
ages are measured to ensure that they are within their nor-
mal voltage ranges. The SDM monitors the voltages at the
driver low and the passenger low to detect shorts to
ground or voltage in the deploy loops.The SDM checks the wiring connection to the passenger
airbag module by letting the infinitesimal current flow
through the internal circuit and verify the resistance.
DTC 15 Will Set When
S The belt pretensioner wiring of passenger’s high is
shorted to ground.
S The belt pretensioner wiring of passenger’s low is
shorted to ground.

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 41
DAEWOO V–121 BL4
DTC 15
Passenger Belt Pretensioner Deployment Loop Is
Shorted To Ground
CAUTION : The sensing and diagnostic module(SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 1 minute after the ignition is
OFF and the fuse has been removed. If the airbags
and pretensioners are not disconnected, do not be-
gin service until one minute has passed after discon-
necting power to SDM. Otherwise, injury could result.
CAUTION : During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.Never power the supplemental inflatable re-
straints(SIR) when the SDM is not rigidly attached to
the vehicle. All SDM mounting bolts must be carefully
tightened , and the arrow on the SDM must be point
toward the front of the vehicle to ensure proper op-
eration of the SIR. The SDM could be activated if it is
powered when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible in-
jury .
Step
ActionValue(s)YesNo
11. Confirm the ignition switch ”OFF”.
2. Wait for a minute to discharge the SDM char-
ger.
3. Visually inspect the connector and the air wir-
ing.
Is the connector disconnected?–Connect the
connector.Go to Step 2
21. Check the resistance between the SDM and
the high, low wiring of passenger belt preten-
sioner and the ground.. Is the resistance
10KΩ?
10K ΩGo to Step 3Replace the
airbag wiring.
31. Replace the SDM.
2. Confirm the ignition switch ”ON”.
3. Erase the DTC using scan tool.
4. Perform the SIR Diagnostic System Check.
Does the DTC still exist?–Go to Step 4System is OK.
4Replace the passenger belt pretensioner.–––

8B – 42ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
J3B18B05
341 2
SDM Driver
Pretensioner
ModulePassenger
Pretensioner
Module
PNKPNK/
DK BLUDK BLU/
WHT BLK/WHT PPL YEL/
DK BLUDK BLU/
WHTRED/
BLK
DK
BLU
G202 C301
126 1
2
38 76
DIAGNOSTIC TROUBLE CODE (DTC) 16
PASSENGER BELT PRETENSIONER DEPLOYMENT
LOOP IS SHORTED TO POWER
Circuit Description
When the ignition switch is turned to ON, the sensing and
diagnostic module(SDM) will perform turn–on test to diag-
nose critical malfunctions within SDM itself.
Upon passing these test ignition and deployment loop volt-
ages are measured to ensure that they are within their nor-
mal voltage ranges. The SDM monitors the voltages at the
driver low and the passenger low to detect shorts to
ground or voltage in the deploy loops.The SDM checks the wiring connection to the passenger
airbag module by letting the infinitesimal current flow
through the internal circuit and verify the resistance.
DTC 16 Will Set When
S The belt pretensioner wiring of passenger’s high is
shorted to battery wiring.
S The belt pretensioner wiring of passenger’s low is
shorted to battery wiring.

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 43
DAEWOO V–121 BL4
DTC 16
Passenger Belt Pretensioner Deployment Loop Is
Shorted Power
CAUTION : The sensing and diagnostic module(SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 1 minute after the ignition is
OFF and the fuse has been removed. If the airbags
and pretensioners are not disconnected, do not be-
gin service until one minute has passed after discon-
necting power to SDM. Otherwise, injury could result.
CAUTION : During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.Never power the supplemental inflatable re-
straints(SIR) when the SDM is not rigidly attached to
the vehicle. All SDM mounting bolts must be carefully
tightened , and the arrow on the SDM must be point
toward the front of the vehicle to ensure proper op-
eration of the SIR. The SDM could be activated if it is
powered when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible in-
jury.
Step
ActionValue(s)YesNo
11. Confirm the ignition switch ”OFF”.
2. Wait for a minute to discharge the SDM char-
ger.
3. Visually inspect the connector and the air wir-
ing.
Is the connector disconnected?–Connect the
connector.Go to Step 2
21. Check the resistance between the SDM and
the high, low wiring of passenger belt preten-
sioner and the battery.
Is the resistance 10KΩ?
10K ΩGo to Step 3Replace the
airbag wiring.
31. Replace the SDM.
2. Confirm the ignition switch ”ON”.
3. Erase the DTC using scan tool.
4. Perform the SIR Diagnostic System Check.
Does the DTC still exist?–Go to Step 4System is OK.
4Replace the passenger belt pretensioner.–––

8B – 44ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
J3B18B06
YEL
10AI/P
Fuse
Box
1 PNKC201
C207
SDM
BLK/
WHTF1
Hot in Run and Start
65 17
G202
DIAGNOSTIC TROUBLE CODE (DTC) 23
BATTERY VOLTAGE HIGH
Circuit Description
When the ignition switch is turned to ON, the sensing and
diagnostic module(SDM) will perform turn–on test to diag-
nose critical malfunctions within SDM itself.
Upon passing these test ignition and deployment loop volt-
ages are measured to ensure that they are within their nor-
mal voltage ranges. The SDM monitors the voltages at the
driver low and the passenger low to detect shorts to
ground or voltage in the deploy loops.The SDM checks the wiring connection to the passenger
airbag module by letting the infinitesimal current flow
through the internal circuit and verify the resistance. But
if the voltage is out of range, SDM is unable to check the
airbag system properly.
DTC 23 Will Set When
S The voltage supplied from the battery is over 16.5
volts.

SUPPLEMENTAL INFLATABLE RESTRAINTS (SIR) 8B – 45
DAEWOO V–121 BL4
DTC 23
Battery Voltage High
CAUTION : The sensing and diagnostic module(SDM)
can maintain sufficient voltage to deploy the airbags
and pretensioners for 1 minute after the ignition is
OFF and the fuse has been removed. If the airbags
and pretensioners are not disconnected, do not be-
gin service until one minute has passed after discon-
necting power to SDM. Otherwise, injury could result.
CAUTION : During service procedure, be very careful
when handling the SDM. Never strike or jar the SDM.Never power the supplemental inflatable re-
straints(SIR) when the SDM is not rigidly attached to
the vehicle. All SDM mounting bolts must be carefully
tightened , and the arrow on the SDM must be point
toward the front of the vehicle to ensure proper op-
eration of the SIR. The SDM could be activated if it is
powered when it is not rigidly attached to the vehicle,
resulting in unexpected deployment and possible in-
jury.
Step
ActionValue(s)YesNo
1Check the vehicle’s charging system including alter-
nator. Refer toSection 1E, Engine Electrical.
Is the charging system OK?–Go to Step 3Go to Step 2
2Repair the charging system.
Is the repair completed?–Check the sys-
tem again.–
31. Disconnect the negative battery cable.
2. Replace the SDM. Is the repair completed?–Check the sys-
tem again.–

8B – 46ISUPPLEMENTAL INFLATABLE RESTRAINTS (SIR)
DAEWOO V–121 BL4
J3B18B06
YEL
10AI/P
Fuse
Box
1 PNKC201
C207
SDM
BLK/
WHTF1
Hot in Run and Start
65 17
G202
DIAGNOSTIC TROUBLE CODE (DTC) 24
BATTERY VOLTAGE HIGE
Circuit Description
When the ignition switch is turned to ON, the sensing and
diagnostic module(SDM) will perform turn–on test to diag-
nose critical malfunctions within SDM itself.
Upon passing these test ignition and deployment loop volt-
ages are measured to ensure that they are within their nor-
mal voltage ranges. The SDM monitors the voltages at the
driver low and the passenger low to detect shorts to
ground or voltage in the deploy loops.The SDM checks the wiring connection to the passenger
airbag module by letting the infinitesimal current flow
through the internal circuit and verify the resistance. But
if the voltage is out of range, SDM is unable to check the
airbag system properly.
DTC 24 Will Set When
S The voltage supplied from the battery is lower than
10.6 volts.
