8–8 BODY DIMENSIONNUBIRA/LACETTI
1–3. ENGINE ROOM
Unit: mm(in.)
Fig. 7

NUBIRA/LACETTIBODY DIMENSION 8–9
1–4. BACK PANEL LOWER
NOTCHBACKUnit: mm(in.)
Fig. 8

8–10 BODY DIMENSIONNUBIRA/LACETTI
HATCHBACK
Fig. 9

NUBIRA/LACETTIBODY DIMENSION 8–11
1–5. SIDE OUTER
NOTCHBACKUnit: mm(in.)
Fig. 10

8–12 BODY DIMENSIONNUBIRA/LACETTI
HATCHBACK
Fig. 11

NUBIRA/LACETTIBODY DIMENSION 8–13
2. REPAIR DRAWING
2–1. FRAME DOOR OPENING
NOTCHBACK
Fig. 12

8–14 BODY DIMENSIONNUBIRA/LACETTI
HATCHBACK
Fig. 13

NUBIRA/LACETTIBODY DIMENSION 8–15
2–2. WINDSHIELD AND REAR GLASS
NOTCHBACKUnit: mm (in.)
Fig. 14

8–16 BODY DIMENSIONNUBIRA/LACETTI
HATCHBACK
Fig. 15

NUBIRA/LACETTIBODY DIMENSION 8–17
3. GAP CHART
NOTCHBACK
Fig. 16
