Untwisting Procedure, Seat Belt................49
Vanity Mirrors...........................114
Vehicle Certification Label...................433
Vehicle Identification Number (VIN).............6
Vehicle Loading..........................400
Vehicle Modifications/Alterations...............7
Vehicle Security Alarm (Security Alarm)..........18
Vehicle Storage...........................324
Viscosity, Engine Oil.......................499
Warning Lights (Instrument Cluster Description) . . .224
Warnings and Cautions.......................6
Warranty Information......................574
Washer
Adding Fluid..........................508
Washers, Windshield.......................147
Washing Vehicle..........................524
Water
Driving Through........................373
Wheel and Wheel Trim.....................525
Wheel and Wheel Trim Care.................525
Wind Buffeting...........................210
Window Fogging.........................325
Windows................................37
Power................................37
Windshield Defroster.......................95
Windshield Washers.......................147
Fluid................................508
Windshield Wiper Blades....................507
Windshield Wipers........................147
Wiper Blade Replacement...................507
Wipers, Intermittent.......................148
Wipers, Rain Sensitive......................150
10
INDEX 599

INSTALLATION OF RADIO TRANSMITTING
EQUIPMENT
Special design considerations are incorporated into this
vehicle’s electronic system to provide immunity to radio
frequency signals. Mobile two-way radios and telephone
equipment must be installed properly by trained person-
nel. The following must be observed during installation.
The positive power connection should be made directly
to the battery and fused as close to the battery as possible.
The negative power connection should be made to body
sheet metal adjacent to the negative battery connection.
This connection should not be fused.
Antennas for two-way radios should be mounted on the
roof or the rear area of the vehicle. Care should be used
in mounting antennas with magnet bases. Magnets may
affect the accuracy or operation of the compass on
vehicles so equipped.
The antenna cable should be as short as practical and
routed away from the vehicle wiring when possible. Use
only fully shielded coaxial cable.
Carefully match the antenna and cable to the radio to
ensure a low Standing Wave Ratio (SWR).
Mobile radio equipment with output power greater than
normal may require special precautions.
All installations should be checked for possible interfer-
ence between the communications equipment and the
vehicle’s electronic systems.
