3. Turn the ignition key to the ON position without
starting the engine.
4. Depress brake pedal.
5. Shift automatic transmission to Neutral (N).
6. Using the point of a ballpoint pen or similar object,
depress the recessed transfer case Neutral (N) button for
4 seconds.
7. After shift is completed and the Neutral (N) light
comes on release Neutral (N) button.
8. Start engine.
9. Shift automatic transmission into Reverse (R).
10. Release brake pedal for five seconds and ensure that
there is no vehicle movement.
11. Repeat steps 9 and 10 with the transmission in Drive
(D).12. Turn ignition key to the unlocked OFF position.
13. Shift automatic transmission into Park (P).
14. Attach vehicle to tow vehicle with tow bar.
NOTE:Items 1 through 5 are requirements that must be
met prior to depressing the Neutral (N) selection button,
and must continue to be met until the 4 seconds elapses
and the shift has been completed.
If any of these requirements (with the exception of3-Key
ON) are not met prior to depressing the Neutral (N)
button or are no longer met during the 4 second timer,
then the Neutral (N) indicator light will flash continu-
ously until all requirements are met or until the Neutral
(N) button is released.
NOTE:The ignition key must be ON for a shift to take
place and for the position indicator lights to be operable.
If the key is not ON, the shift will not take place and no
position indicator lights will be on or flashing.
362 STARTING AND OPERATING

CAUTION!
Damage to the transmission may occur if the trans-
mission is shifted into Park (P) with the transfer case
in Neutral (N) and the engine RUNNING. With the
transfer case in Neutral (N) ensure that the engine is
OFF prior to shifting the transmission into Park (P)
Shifting OUT of Neutral (N)
Use the following procedure to prepare your vehicle for
normal usage.
1. Bring vehicle to a complete stop.
2. Shut engine OFF.
3. Turn the ignition key to the ON position without
starting the engine.
4. Depress brake pedal.
5. Shift automatic transmission to Neutral (N).6. Using the point of a ballpoint pen or similar object,
depress the recessed transfer case Neutral (N) button for
1 second.
7. After the Neutral (N) indicator light turns off release
the Neutral (N) button.
8. After the Neutral (N) button has been released the
transfer case will shift to the position identified by the
selector switch.
9. Shift automatic transmission into Park (P).
10. Start the engine.
11. Shift automatic transmission into Drive (D).
NOTE:Items 1 through 5 are requirements that must be
met prior to depressing the Neutral (N) selection button,
and must continue to be met until 1 second elapses and
the shift has been completed.
If any of these requirements are not met prior to depress-
ing the Neutral (N) button or are no longer met during
STARTING AND OPERATING 363
5

the 1 second time, then all of the position indicator lights
will flash continuously until all requirements are met or
until the Neutral (N) button is released.
NOTE:The ignition key must be ON for a shift to take
place and for the position indicator lights to be operable.
If the key is not On, the shift will not take place and no
position indicator lights will be on or flashing.
NOTE:Flashing neutral (N) position indicator light
indicates that shift requirements have not been met.
CAUTION!
²Do not use a bumper mounted clamp-on tow bar
on your vehicle. The bumper face bar will be
damaged.
²Do not disconnect the rear driveshaft because
fluid will leak from the transfer case and damage
internal parts.
EQUIPMENT IDENTIFICATION PLATE
The equipment Identification Plate is located on the hood
inner surface.
The following information about your vehicle is dis-
played on this plate: Model, Wheelbase, Vehicle Identifi-
cation Number, Truck Order Number, and code numbers
with descriptions of all production and special equip-
ment on the truck as shipped from the factory.
NOTE:Always refer to the equipment identification
plate when ordering parts.
364 STARTING AND OPERATING

HAZARD WARNING FLASHER
The flasher switch is on the top of the steering column,
just behind the steering wheel. Press the flasher switch
and all front and rear directional signals will flash
intermittently.
Press the switch a second time to turn off the emergency
flashers.This is an emergency warning system and should not be
used when the vehicle is in motion. Use it when your
vehicle is disabled and is creating a safety hazard for
other motorists.
If it is necessary to leave the vehicle to go for service, the
flasher system will continue to operate with the ignition
key removed and the vehicle locked.
366 WHAT TO DO IN EMERGENCIES

Four-Wheel Drive Vehicles
The manufacturer recommends towing with all wheels
OFFthe ground. Acceptable methods are to tow the
vehicle on a flatbed or with one end of the vehicle raised
and the opposite end on a towing dolly.
Two-Wheel Drive Vehicles
Provided that the transmission is operable, tow with the
transmission in Neutral and the ignition key in the OFF
position along with the front wheels raised and the rear
wheels on the ground. The speed must not exceed 30
mph (50 km/h) and the distance must not exceed 15
miles (25 km).If the vehicle is to be towed more than 15 miles (25 km )
or faster than 30 mph, it must be towed on a flatbed, or
with the rear wheels raised and the front wheels on the
ground, or with the front end raised and the rear wheels
on a towing dolly.
NOTE:Towing the vehicle, with the rear wheels on the
ground, at more than 30 mph (50 km/h) or for more than
15 miles (25 km ) can cause severe transmission damage.
WHAT TO DO IN EMERGENCIES 379
6

Your vehicle has a simple ignition key actuated test
which you can use prior to going to the test station. To
check if your vehicle's OBD system is ready, you must do
the following:
1. Insert your ignition key into the ignition switch.
2. Turn the ignition to the ON position, but do not crank
or start the engine. If you crank or start the engine, you
will have to start this test over.
3. As soon as you turn your key to the ON position, you
will see your MIL symbol come on as part of a normal
bulb check.
4. Approximately 15 seconds later, one of two things will
happen:
a. The MIL light will blink for approximately 5 sec-
onds and then remain on until the first engine crank orthe key is turned off. This means that your vehicle's
OBD system isnot readyand you shouldnotproceed
to the I/M station.
b. The MIL light will remain fully illuminated until the
first engine crank or the key is turned off. This means
that your vehicle's OBD system isreadyand you can
proceed to the I/M station.
If your OBD system isnot readyyou should see your
dealer or repair facility. If your vehicle was recently
serviced or had a battery failure or replacement, you may
need to do nothing more than drive your vehicle as you
normally would in order for your OBD system to update.
A recheck with the above test routine may then indicate
that the system is now ready.
Regardless of whether your vehicle's OBD system is
ready or not ready, if the MIL symbol is illuminated
during normal vehicle operation, you should have your
MAINTAINING YOUR VEHICLE 389
7

Cavity Mini Fuse/Color Description
F10 10 Amp Red Spare
F11 10 Amp Red Heated Mirrors
F12 20 Amp YellowCluster Battery
Feed
F13 10 Amp RedIgnition Run
HVAC Module/
Heated Rear
Glass (EBL) Re-
lay
F14 10 Amp RedABS Module Ig-
nition Run
F15 15 Amp BlueBattery Feed
Blue Tooth,
Compass/Trip
Computer
(CMTC), Sentry
Key DiagnosticsCavity Mini Fuse/Color Description
F16 20 Amp YellowReconfigurable
Power Outlets
F17 20 Amp YellowIgnition Run /
Rear Park Assist
/ Second Row
Heated Seats
F18 20 Amp YellowCigar Lighter
Ignition
F19 10 Amp Red Spare Fuse
F20 15 Amp BlueHeating & Air
Conditioning
w/ATC Only
Battery Feed
F21 25 Amp NaturalAmplifier Bat-
tery Feed
MAINTAINING YOUR VEHICLE 423
7

Special Additives...................... 413
Torque Converter...................... 280
Axle Fluid............................. 441
Axle Lubrication (Axle Fluid)............... 414
Ball Joints............................. 400
Battery.......................384,385,386,397
Charging............................ 375
Emergency Starting..................... 375
Gas Caution.......................... 375
Keyless Transmitter Replacement (RKE)....... 26
Saving Feature (Protection)............... 139
Belts, Drive............................ 394
Belts, Seat.............................. 40
Body Mechanism Lubrication............... 401
B-Pillar Location........................ 309
Brake Assist System...................... 296
Brake Control System, Electronic............. 295
Brake Fluid............................ 441Brake System........................291,410
Anti-Lock (ABS)....................291,295
Disc Brakes.......................... 410
Fluid Check.......................... 410
Hoses.............................. 411
Master Cylinder....................... 410
Parking............................. 290
Warning Light.....................195,199
Brakes............................... 291
Brake/Transmission Interlock............... 276
Break-In Recommendations, New Vehicle........ 74
Bulb Replacement....................... 430
Bulbs, Light............................ 430
Calibration, Compass..................... 166
Camera, Rear........................... 156
Capacities, Fluid........................ 439
Caps, Filler
Fuel................................ 336
INDEX 463
10

Gross Vehicle Weight Rating................ 346
GVWR............................343,346
Hands-Free Phone (UConnectŸ)........87,236,237
Hard Drive (HDD)....................206,236
Hazard
Driving Through Flowing, Rising, or Shallow
Standing Water........................ 288
Hazard Warning Flasher................... 366
Headlights............................ 430
Cleaning............................ 418
Delay.............................. 139
High Beam........................... 143
High Beam/Low Beam Select Switch........ 143
Lights On Reminder.................... 141
Passing............................. 143
Replacing............................ 430
Heated Mirrors.......................... 87
Heated Seats........................... 118Heater............................... 251
Heater, Engine Block..................... 276
High Beam Indicator..................... 194
High Beam/Low Beam Select (Dimmer) Switch . . 143
Hitches
Trailer Towing........................ 351
HomeLinkt(Garage Door Opener) Transmitter . . . 168
Hood Release.......................... 135
Hoses................................ 409
Ignition.............................12,17
Key ................................. 12
Lock................................ 17
Ignition Key Removal..................... 12
Illuminated Entry........................ 20
Immobilizer (Sentry Key)................... 13
Infant Restraint........................64,65
Inflation Pressure Tires.................... 322
Information Center...................... 159
INDEX 469
10

Information Center, Vehicle................. 159
Inside Rearview Mirror.................... 83
Instrument Cluster....................... 193
Instrument Panel and Controls.............. 191
Instrument Panel Lens Cleaning............. 419
Integrated Power Module (Fuses)............ 427
Interior Appearance Care.................. 418
Interior Fuses.......................... 421
Interior Lighting........................ 138
Interior Lights.......................... 138
Intermittent Wipers (Delay Wipers)........... 144
Introduction............................. 4
Inverter Outlet (115V)..................... 177
Jack Location........................... 367
Jack Operation.......................367,370
Jacking Instructions...................... 371
Key, Programming........................ 15Key, Replacement........................ 15
Key, Sentry (Immobilizer)................... 13
Keyless Entry System...................... 20
Keys................................. 12
Knee Bolster............................ 53
Lane Change and Turn Signals.........142,193,432
Lap/Shoulder Belts.....................40,46
LATCH
(Lower Anchors and Tether for CHildren)....... 68
Life of Tires............................ 319
Liftgate................................ 35
Lights..............................77,137
Airbag............................61,203
Anti-Lock Warning..................... 195
Automatic Headlights................... 140
Back-Up............................. 432
Brake Warning........................ 199
Bulb Replacement...................... 430
470 INDEX
