DODGE NEON 1997 1.G Wiring Diagrams Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 23 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08023
CAV CIRCUIT FUNCTION
1 P90 18LG/BK LEFT/RIGHT POWER MIRROR VERTICAL SUPPLY
2Ð Ð
3 P93 18YL/BK LEFT POWER MIRROR (VERTICAL)
4 P95 18DB/WT LEFT POWER MIRROR (HORIZONTAL)
5 P99 18GY LEFT POWER MIRROR SUPPLY
6 P91 18WT/BK LEFT/RIGHT POWER MIRROR HORIZONTAL SUPPLY
GRAY
LEFT
POWER MIRROR
6 43 1
BLACK
LEFT REAR
DOOR LOCK
MOTOR
CAV CIRCUIT FUNCTION
1 P34 18PK/BK DOOR UNLOCK DRIVER
2 P33 18OR/BK DOOR LOCK DRIVER 2 1
CAV CIRCUIT FUNCTION
1 X51 22BR/YL LEFT REAR SPEAKER (+)
2 X57 22BR/LB LEFT REAR SPEAKER (Ð)
BLACK
CAV CIRCUIT FUNCTION
1 B3 20LG/DB LEFT REAR WHEEL SPEED SENSOR (Ð)
2 B4 20LG LEFT REAR WHEEL SPEED SENSOR (+) 2 1
LEFT REAR
WHEEL SPEED
SENSOR
BLACK
LEFT REAR
SPEAKER
1 2
CAV CIRCUIT FUNCTION
1 Q12 14BR LEFT FRONT UP
2 Q26 14VT/WT MASTER SWITCH LEFT FRONT DOWN
3 F21 14TN FUSED IGNITION SWITCH OUTPUT (RUN/START)
4 Q16 14BR/WT MASTER SWITCH LEFT FRONT UP
5 Q22 14VT LEFT FRONT DOWN
LEFT POWER
WINDOW SWITCH
LEFT REAR FOG LAMP
CAV CIRCUIT FUNCTION
1 L38 18BR/WT REAR FOG LAMP FEED
2 Z1 18BK GROUND
2 1
BLACK
WHITE
12
3
45

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 24 8W-80 CONNECTOR PIN-OUTS
PLR08024
CAV CIRCUIT FUNCTION
1 L50 18WT/TN TAIL/STOP
2 L7 18BK/YL TAIL/STOP
3 Z1 18BK GROUND
LEFT TAIL/STOP
LAMP
CAV CIRCUIT FUNCTION
1 Q21 14WT RIGHT FRONT DOWN
2 Q11 14LB RIGHT FRONT UP
3 Z8 14BK/VT GROUND
4 F21 14TN FUSED IGNITION SWITCH OUTPUT (RUN/START)
5 Q26 14VT/WT MASTER SWITCH LEFT FRONT DOWN
6 Q16 14BR/WT MASTER SWITCH LEFT FRONT UP
NATURAL1 3 5
2 4 6
MASTER
POWER WINDOW
SWITCH
CAV CIRCUIT FUNCTION
1 L61 18LG LEFT TURN SIGNAL
2 Z1 18BK GROUND
LEFT REPEATER
LAMP
CAV CIRCUIT FUNCTION
1 L63 18DG/RD LEFT TURN SIGNAL LAMP FEED
2 Z1 18BK GROUND
LEFT TURN
SIGNAL LAMP
CAV CIRCUIT FUNCTION
A M23 22YL/BK TIME OUT RELAY
B Z3 18BK/OR GROUND
C M1 18PK FUSED B(+)
DÐ Ð
BLACK
DC
AB
MAP/READING
LAMPS DC
AB
2 1
NATURAL
3 1 2
BLACK
2 1
GRAY

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 25 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08025
CAV CIRCUIT FUNCTION
1 L1 20VT/BK REVERSE LAMP SENSE
2 T41 20BR/YL PARK/NEUTRAL POSITION SWITCH SENSE
3 F20 20WT FUSED IGNITION SWITCH OUTPUT (RUN/START)
PARK/NEUTRAL
POSITION SWITCH (ATX)13
BLACK
CAV CIRCUIT FUNCTION
1 R51 18VT/YL PASSENGER AIRBAG PRESSURE SWITCH GROUND
2 R50 18BR/YL PASSENGER AIRBAG PRESSURE SWITCH SENSE
3 R44 18DG/YL PASSENGER AIRBAG SQUIB LINE 2
4 R42 18BK/YL PASSENGER AIRBAG SQUIB LINE 1PASSENGER SIDE
AIRBAG
4 1YELLOW
CAV CIRCUIT FUNCTION
1Ð Ð
2 F121 18TN/BK POWER FOLDING MIRROR RELAY OUTPUT
3Ð Ð
4 P110 18OR RELAY COIL FEED
5 Z8 18BK/VT GROUND
6 Z8 18BK/VT GROUND
6 Z8 18BK/VT GROUND
7Ð Ð
8 P90 18LG/BK POWER MIRRORS
9Ð Ð
POWER FOLDING
MIRROR RELAY
CAV CIRCUIT FUNCTION
1 F121 18TN/BK POWER FOLDING MIRROR FEED
1 F121 18TN/BK POWER MIRROR SWITCH FEED
2 F21 14TN FUSED IGNITION SWITCH OUTPUT (RUN)
POWER MIRROR
FUSE HOLDER
14
58
POWER MIRROR
SWITCH-C1
CAV CIRCUIT FUNCTION
1 Z8 18BK/VT GROUND
2 F121 18TN/BK POWER FOLDING MIRROR FEED
3 P94 18WT/YL RIGHT POWER MIRROR (HORIZONTAL)
4 P92 18YL RIGHT POWER MIRROR (VERTICAL)
5 P110 18OR LEFT/RIGHT POWER MIRROR VERTICAL SUPPLY
6 P91 18WT/BK LEFT/RIGHT POWER MIRROR HORIZONTAL SUPPLY
7 P95 18DB/WT LEFT POWER MIRROR (HORIZONTAL)
8 P93 18YL/BK LEFT POWER MIRROR (VERTICAL)
BLACK
21 3
4 6
7 95
8
BLACK
2 1
GRAY

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 26 8W-80 CONNECTOR PIN-OUTS
PLR08026
CAV CIRCUIT FUNCTION
1 P99 18GYLEFT/RIGHT POWER FOLDING MIRROR (B+) EXT (B-) RET
2Ð Ð
POWER MIRROR
SWITCH-C2
CAV CIRCUIT FUNCTION
1 Q42 18LB POWER SUNROOF CLOSE
2Ð Ð
3 Q41 18WT POWER SUNROOF OPEN
4 Q46 18OR POWER SUNROOF VENT OPEN/CLOSE LIMIT
5 Q43 18VT POWER SUNROOF VENT
6 Z8 18BK/VT GROUND
RED
POWER
SUNROOF
MOTOR 3 2 1 4 5 6
CAV CIRCUIT FUNCTION
1 K10 20WT POWER STEERING PRESSURE SWITCH SENSE
2 Z12 22BK/TN GROUND
BLACK
21
POWER STEERING
PRESSURE SWITCH
CAV CIRCUIT FUNCTION
41 Ð Ð
42 Ð Ð
43 K4 20BK/LB SENSOR GROUND
44 K7 20OR 8 VOLT SUPPLY
45 K10 20WT POWER STEERING PRESSURE SWITCH SENSE
46 A14 18RD/WT FUSED B(+)
47 Z11 20BK/WT GROUND
48 K40 20BR/WT IDLE AIR CONTROL MOTOR NO. 3 DRIVER
49 K60 20YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
50 Z12 20BK/TN GROUND
51 K141 20TN/WT DOWNSTREAM HEATED OXYGEN SENSOR SIGNAL
52 G31 18VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
53 Ð Ð
54 Ð Ð
55 Ð Ð
56 G12 20TN/BK GENERATOR LAMP DRIVER
57 K39 20GY/RD IDLE AIR CONTROL MOTOR NO. 1 DRIVER
58 K59 20VT IDLE AIR CONTROL MOTOR NO. 4 DRIVER
59 Ð Ð
60 Ð Ð
50 41
60 51
70 61
80 71
POWERTRAIN CONTROL
MODULE Ð C1BLACK
(CONTINUED ON NEXT PAGE)
21
WHITE

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 27 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08027
CAV CIRCUIT FUNCTION
61 K6 20VT/WT 5 VOLT SUPPLY
62 K29 20WT/PK STOP LAMP SWITCH SENSE
63 Ð Ð
64 C28 18DB/OR A/C COMPRESSOR CLUTCH RELAY CONTROL
65 D21 20PK SCI TRANSMIT
66 G7 20WT/OR VEHICLE SPEED SENSOR SIGNAL
67 K51 18DB/YL AUTOMATIC SHUT DOWN RELAY CONTROL
68 K52 20PK/BK DUTY CYCLE EVAP/PURGE SOLENOID CONTROL
69 Ð Ð
70 Ð Ð
71 Z2 18BK/OR Ð
72 K107 18OR VAPOR CANISTER PUMP SWITCH DRIVER
73 G21 20GY/LB TACHOMETER SIGNAL
74 K31 18BR FUEL PUMP RELAY CONTROL
75 D20 20LG SCI RECEIVE
76 Ð **Ð
76 T41 20BR/YLllPARK/NEUTRAL POSITION SWITCH SENSE
77 K106 18WT/LG VAPOR CANISTER SOLENOID DRIVER
78 Ð Ð
79 Ð **Ð
79 K54 20OR/BKllTORQUE CONVERTOR CLUTCH SOLENOID CONTROL
80 Ð Ð
(CONTINUED)
*2.0L (SOHC) ENGINEl2.0L (DOHC) ENGINE
**MTXllATX
CAV CIRCUIT FUNCTION
1Ð Ð
2 K19 18BK/GY IGNITION COIL NO. 1, 3 DRIVER
3 K17 18DB/TN IGNITION COIL NO. 2, 4 DRIVER
4 K20 18DG GENERATOR FIELD DRIVER
5 V32 20YL/RD SPEED CONTROL FEED
6 A142 18DG/OR AUTOMATIC SHUT DOWN RELAY OUTPUT
7 K13 18YL/WT INJECTOR NO. 3 DRIVER
8 G3 20BK/PK CHECK ENGINE LAMP DRIVER
9Ð Ð
10 Z12 18BK/TN GROUND
11 Ð Ð
12 Ð Ð
13 K11 18WT/DB INJECTOR NO. 1 DRIVER
14 Ð Ð
15 Ð Ð
16 K14 18LB/BR INJECTOR NO. 4 DRIVER
17 K12 18TN INJECTOR NO. 2 DRIVER
18 K173 20LG RAD FAN PULSE CONTROL
19 Ð Ð
20 F12 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN/START)
21 Ð Ð
22 Ð Ð
23 G4 20DB FUEL LEVEL SENSOR SIGNAL
24 K42 20BK/LGlKNOCK SENSOR SIGNAL
24 K42 20DB/LG
*KNOCK SENSOR SIGNAL
31 40
21 30
11 20
110
POWERTRAIN CONTROL
MODULE Ð C2
BLACK
(CONTINUED ON NEXT PAGE)

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 28 8W-80 CONNECTOR PIN-OUTS
PLR08028
*2.0L (SOHC) ENGINEl2.0L (DOHC) ENGINE
CAV CIRCUIT FUNCTION
25 Ð Ð
26 K2 20TN/DB*ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
26 K2 20TN/BKlENGINE COOLANT TEMPERATURE SENSOR SIGNAL
27 Ð Ð
28 Ð Ð
29 Ð Ð
30 K41 20BK/DG UPSTREAM HEATED OXYGEN SENSOR SIGNAL
31 Ð Ð
32 K24 20GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
33 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
34 Ð Ð
35 K22 20OR/DB THROTTLE POSITION SENSOR SIGNAL
36 K1 18DG/RD MANIFOLD ABSOLUTE PRESSURE SENSOR SIGNAL
37 K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
38 C20 18BR A/C SWITCH SENSE
39 Ð Ð
40 K35 20GY/YL EXHAUST GAS RECIRCULATION SOLENOID CONTROL
(CONTINUED)
CAV CIRCUIT FUNCTION
1 E2 22OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z3 20BK/OR GROUND
BLACK
1 2
PRNDL
LAMP
CAV CIRCUIT FUNCTION
1 C25 14LG RADIATOR FAN RELAY OUTPUT
2 Z1 14BK GROUND
RADIATOR
FAN MOTOR
CAV CIRCUIT FUNCTION
1Ð Ð
2 X51 22BR/YL LEFT REAR SPEAKER (Ð)
3 X52 22DB/WT RIGHT REAR SPEAKER (+)
4 X53 22DG LEFT FRONT SPEAKER (+)
5 X54 22VT RIGHT FRONT SPEAKER (+)
6 X57 22BR/LB LEFT REAR SPEAKER (Ð)
7 X58 22DB/OR RIGHT REAR SPEAKER (Ð)
1
BLACK
2
RADIO - C1
BLACK
7
1

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 29 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08029
CAV CIRCUIT FUNCTION
1Ð Ð
2 X55 22BR/RD LEFT FRONT SPEAKER (Ð)
3 X56 22DB/RD RIGHT FRONT SPEAKER (Ð)
4 L7 20BK/YL PARK LAMP SWITCH OUTPUT
5 E2 22OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
6 X12 20RD/WT FUSED IGNITION SWITCH OUTPUT (ACC/RUN)
7 M1 22 PK FUSED B(+)
CAV CIRCUIT FUNCTION
1 E2 220R FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z2 22BK/LG GROUND
3 F20 22WT FUSED IGNITION SWITCH OUTPUT (RUN)
4 A4 14BK/RD FUSED B(+)
5 C15 14BK/WT REAR WINDOW DEFOGGER RELAY OUTPUT
BLACK
51
REAR WINDOW
DEFOGGER SWITCH
CAV CIRCUIT FUNCTION
1 R46 18BR/LB RIGHT IMPACT SENSOR LINE 1
2 R48 18TN RIGHT IMPACT SENSOR LINE 2
BLACK
21
RIGHT
AIRBAG IMPACT SENSOR
RIGHT BACK-UP
LAMP
CAV CIRCUIT FUNCTION
1 L1 18VT/BK BACK-UP LAMP SENSE
2 Z1 18BK GROUND
RADIO - C2
GRAY
71
CAV CIRCUIT FUNCTION
1– –
2 F61 18WT/OR FOG LAMP FEED
3 L38 18BR/WT REAR FOG LAMP FEED
4 L2 14LG HEADLAMP SWITCH FEED
5 Z3 22BK/OR GROUND
5 Z3 20BK/OR GROUND
6 E2 22OR FUSED ILLUMINATION FEED
7 L35 20BR/RD FRONT FOG LAMP FEED
8– –
REAR FOG
LAMP SWITCH
18
GREEN
2 1
GRAY

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 30 8W-80 CONNECTOR PIN-OUTS
PLR08030
WHITE
RIGHT DOOR
LOCK SWITCH
21
5
4312
3
45CAV CIRCUIT FUNCTION
1 P35 18OR/VT RIGHT DOOR LOCK SWITCH OUTPUT
2 Z8 18BK/VT GROUND
3 F35 18RD/YL FUSED B(+)
4 Z8 18BK/VT GROUND
5 P36 18PK/VT DOOR UNLOCK SWITCH OUTPUT
CAV CIRCUIT FUNCTION
1 Q21 14VT RIGHT FRONT DOWN
2 Q11 14LB RIGHT FRONT UP
BLACK
RIGHT DOOR
WINDOW MOTOR21
CAV CIRCUIT FUNCTION
1 L39 18LB/WT FRONT FOG LAMPS SWITCH OUTPUT
2 Z1 20BK GROUND
RIGHT FOG
LAMP
CAV CIRCUIT FUNCTION
1 X56 22DB/RD RIGHT FRONT SPEAKER (Ð)
2 X54 22VT RIGHT FRONT SPEAKER (+)
1 2
BLACK
RIGHT FRONT
DOOR SPEAKER
BLACK
CAV CIRCUIT FUNCTION
1 P34 18PK/BK DOOR UNLOCK DRIVER
2 P33 18OR/BK DOOR LOCK DRIVER
RIGHT FRONT
DOOR LOCK
MOTOR2 1
1 2
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 31 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08031
CAV CIRCUIT FUNCTION
1 B6 20WT/DB RIGHT FRONT WHEEL SPEED SENSOR (+)
2 B7 20WT RIGHT FRONT WHEEL SPEED SENSOR (Ð)2 1BLACK
RIGHT FRONT
WHEEL SPEED SENSOR
CAV CIRCUIT FUNCTION
1 L3 16RD/OR DIMMER SWITCH HIGH BEAM OUTPUT
2 L44 18VT/BK FUSED RIGHT LOW BEAM OUTPUT
3 Z1 18BK GROUND
RIGHT
HEADLAMP
CAV CIRCUIT FUNCTION
1 X54 22VT RIGHT FRONT SPEAKER (+)
2 X56 22DB/RD RIGHT FRONT SPEAKER (Ð)
RIGHT INSTRUMENT
PANEL SPEAKER (PREMIUM)
BLACK
1 2
CAV CIRCUIT FUNCTION
1 L60 18TN RIGHT TURN SIGNAL
2 L7 18BK/YL PARK LAMP SWITCH OUTPUT
3 Z1 18BK GROUND
RIGHT PARK/TURN
SIGNAL LAMP
CAV CIRCUIT FUNCTION
1 L43 22VT RIGHT HEADLAMP FEED
2 L13 22BR/YL HEADLAMP LEVELING SIGNAL FROM SWITCH
3 Z1 22BK GROUND
RIGHT HEADLAMP
LEVELING MOTOR
CAV CIRCUIT FUNCTION
1 Z1 20BK GROUND
2 L7 20BK/YL LICENSE LAMP FEED
RIGHT LICENSE
LAMP
2
BLACK
123
BLACK
2 1
NATURAL
1 3
BLACK
1
3

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 32 8W-80 CONNECTOR PIN-OUTS
PLR08032
GRAY
RIGHT
POWER MIRROR6 43 1
CAV CIRCUIT FUNCTION
1 P90 18LG/BK LEFT/RIGHT POWER MIRROR VERTICAL SUPPLY
2Ð
3 P92 18YL LEFT POWER MIRROR (VERTICAL)
4 P94 18WT/YL LEFT POWER MIRROR (HORIZONTAL)
5 P99 18GY Ð
6 P91 18WT/BK LEFT/RIGHT POWER MIRROR HORIZONTAL SUPPLY
BLACK
RIGHT REAR
DOOR LOCK
MOTOR
CAV CIRCUIT FUNCTION
1 P34 18PK/BK DOOR UNLOCK DRIVER
2 P33 18OR/BK DOOR LOCK DRIVER 2 1
RIGHT REAR
FOG LAMP
CAV CIRCUIT FUNCTION
1 L38 18BR/WT REAR FOG LAMP FEED
2 Z1 18BK GROUND
CAV CIRCUIT FUNCTION
1 X52 22DB/WT RIGHT REAR SPEAKER (+)
2 X58 22DB/OR RIGHT REAR SPEAKER (Ð)
CAV CIRCUIT FUNCTION
1 B1 20WT/BK RIGHT REAR WHEEL SPEED SENSOR (Ð)
2 B2 20DG/WT RIGHT REAR WHEEL SPEED SENSOR (+)
BLACK
2 1
RIGHT REAR
WHEEL SPEED
SENSOR
BLACK
RIGHT REAR
SPEAKER
1 2
2 1
BLACK
