8W - 80 - 13PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08013
CAV CIRCUIT FUNCTION
1 B1 20YL/DB RIGHT REAR WHEEL SPEED SENSOR (Ð)
2 B2 20YL RIGHT REAR WHEEL SPEED SENSOR (+)
3 B3 20LG/DB LEFT REAR WHEEL SPEED SENSOR (Ð)
4 B4 20LG LEFT REAR WHEEL SPEED SENSOR (+)
5 Z12 18BK/OR GROUND
6 B6 20WT/DB RIGHT FRONT WHEEL SPEED SENSOR (+)
7 B7 20WT RIGHT FRONT WHEEL SPEED SENSOR (Ð)
8 B8 20RD/DB LEFT FRONT WHEEL SPEED SENSOR (+)
9 B9 20RD LEFT FRONT WHEEL SPEED SENSOR (Ð)
10 Ð Ð
11 Ð Ð
12 Ð Ð
13 L50 20WT/TN STOP LAMP SWITCH OUTPUT
14 Ð Ð
15 G19 20LG/BR ABS WARNING LAMP DRIVER
16 B116 20GY ABS PUMP MOTOR RELAY CONTROL
17 Ð Ð
18 Ð Ð
19 Ð Ð
20 B120 16BR/WT ABS PUMP MOTOR RELAY OUTPUT
21 Ð Ð
22 Ð Ð
23 Ð Ð
24 Ð Ð
25 Ð Ð
26 Ð Ð
27 Ð Ð
28 Ð Ð
29 Ð Ð
30 Ð Ð
31 Ð Ð
32 Ð Ð
33 Ð Ð
34 Ð Ð
35 Ð Ð
36 Ð Ð
37 Ð Ð
38 Ð Ð
39 Ð Ð
40 Ð Ð
41 Ð Ð
42 B142 20BR/YL LEFT FRONT DUMP SOLENOID CONTROL
43 B143 20DG/YL RIGHT FRONT DUMP SOLENOID CONTROL
44 Ð Ð
45 Ð Ð
46 B146 20BR/LB LEFT REAR DUMP SOLENOID CONTROL
47 B47 20RD/LB ABS SYSTEM RELAY OUTPUT
48 B148 20DB/LB RIGHT REAR DUMP SOLENOID CONTROL
49 Ð Ð
50 Ð Ð
(CONTINUED ON NEXT PAGE)
BLACK
60 20 41 121
CONTROLLER
ANTI-LOCK
BRAKE40

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 14 8W-80 CONNECTOR PIN-OUTS
PLR08014
(CONTINUED)
CAV CIRCUIT FUNCTION
51 D21 20PK SCI TRANSMIT
52 Ð Ð
53 Ð Ð
54 Ð Ð
55 Ð Ð
56 Ð Ð
57 B57 20BR/BK ABS SYSTEM RELAY CONTROL
58 Ð Ð
59 Ð Ð
60 F12 20DG/WT ABS MODULE FEED
CAV CIRCUIT FUNCTION
1 K7 20OR 8 VOLT SUPPLY
2 K4 20BK/LB SENSOR GROUND
3 K24 20GY/BK CRANKSHAFT POSITION SENSOR SIGNAL
CRANKSHAFT
POSITION
(CKP) SENSOR
CAV CIRCUIT FUNCTION
1 Ð Ð
2 Ð Ð
3 D1 20VT/BR CCD BUS (+)
4 Z12 22BK/TN GROUND
5 Z12 22BK/TN GROUND
6 D20 20LG SCI RECEIVE
7 D21 20PK SCI TRANSMIT
8 Ð Ð
9 Ð Ð
10 Ð Ð
11 D2 20WT/BK CCD BUS (Ð)
12 Ð Ð
13 Ð Ð
14 Ð Ð
15 Ð Ð
16 A14 16RD/WT FUSED B(+)
BLACK
DATA LINK
CONNECTOR 18
916
CAV CIRCUIT FUNCTION
1 M1 22PK FUSED B(+)
2Ð Ð
3 M2 20YL DOME LAMP FEED
DOME LAMP1 3
BLACK
31
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 15 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08015
CAV CIRCUIT FUNCTION
1 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
2 Z1 18BK GROUND
3 K4 20BK/LB SENSOR GROUND
4 K141 20TN/WT DOWNSTREAM HEATED OXYGEN SENSOR SIGNAL
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER AIRBAG SQUIB LINE 2
2 R43 18BK/LB DRIVER AIRBAG SQUIB LINE 1
YELLOW
DRIVER SIDE
AIRBAG 2 1
CAV CIRCUIT FUNCTION
1 K52 20PK/BK DUTY CYCLE EVAP/PURGE SOLENOID CONTROL
2 F12 20DG/WT FUSED IGNITION SWITCH OUTPUT (RUN/START) BLACK2 1
DUTY CYCLE
EVAP/PURGE
SOLENOID
CAV CIRCUIT FUNCTION
A K4 20BK/LB*SENSOR GROUND
A K4 20BK/RDlSENSOR GROUND
B K2 20TN/DB*ENGINE COOLANT TEMPERATURE SENSOR SIGNAL
B K2 20TN/BKlENGINE COOLANT TEMPERATURE SENSOR SIGNAL
C G20 20VT/YL ENGINE COOLANT TEMPERATURE GAUGE SIGNAL
BLACK
ENGINE COOLANT
TEMPERATURE (ECT)
SENSOR
BA
CB A
C
*2.0L SOHC ENGINEl2.0L DOHC ENGINE
BLACK
2
4
1
3
DOWNSTREAM HEATED
OXYGEN SENSOR
CAV CIRCUIT FUNCTION
1 K35 20GY/YL EXHAUST GAS RECIRCULATION SOLENOID CONTROL
2 F12 18DB/WT FUSED IGNITION SWITCH RELAY OUTPUT BLACK
21
(EGR)
TRANSDUCER
SOLENOID

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 16 8W-80 CONNECTOR PIN-OUTS
PLR08016
CAV CIRCUIT FUNCTION
1 G6 18GY OIL PRESSURE SWITCH SENSOR
2Ð Ð
1 2
ENGINE OIL
PRESSURE SWITCHGREEN
CAV CIRCUIT FUNCTION
1 L7 20BK/YLHEADLAMP SWITCH FEED TO FRONT FOG LAMP SWITCH
2 L35 20BR/RD FRONT FOG LAMP SWITCH TO RELAY
2L35 20BR/RDFRONT FOG LAMP SWITCH TO REAR FOG LAMP SWITCH
3 Z3 22BK/OR GROUND
FRONT FOG LAMP
SWITCH
CAV CIRCUIT FUNCTION
1 K11 18WT/DB INJECTOR NO. 1 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
FUEL INJECTOR NO. 1
CAV CIRCUIT FUNCTION
1 K12 18TN INJECTOR NO. 2 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
FUEL INJECTOR NO. 2
BLACK
21
BLACK
21
CAV CIRCUIT FUNCTION
1 K13 18YL/WT INJECTOR NO. 3 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
FUEL INJECTOR NO. 3
BLACK
21
FUEL INJECTOR NO. 4
CAV CIRCUIT FUNCTION
1 K14 18LB/BR INJECTOR NO. 4 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
BLACK
21
BLACK
123

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 17 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08017
CAV CIRCUIT FUNCTION
1 Z1 18BK GROUND
2 Z2 18BK GROUND
3 G4 18DB FUEL LEVEL SENSOR SIGNAL
4 A141 18DG/WT FUEL PUMP RELAY OUTPUT
LT GRAY
FUEL PUMP
MODULE 41
BLACK
CAV CIRCUIT FUNCTION
1 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
2 K20 18DG GENERATOR FIELD DRIVER
GENERATOR 21
CAV CIRCUIT FUNCTION
1 M1 22PK FUSED B(+)
2 Z3 20BK/OR GROUND12
GLOVE BOX
LAMP AND SWITCHGRAY
HEADLAMP DIMMER
AND OPTICAL HORN
SWITCH 41BLACK
CAV CIRCUIT FUNCTION
1 L4 14VT/WT DIMMER SWITCH LOW BEAM OUTPUT
2 L2 14LG HEADLAMP SWITCH OUTPUT
3 L3 14RD/OR DIMMER SWITCH HIGH BEAM OUTPUT
4 L20 14LG/WT FUSED B(+)
BLACK
HEADLAMP
SWITCH 1
2
9
73
4
5
6 8
CAV CIRCUIT FUNCTION
1 E1 20TN PANEL LAMPS DIMMER SWITCH SIGNAL
2 L2 14LG HEADLAMP SWITCH OUTPUT
3 M2 22YL TIME OUT RELAY
4 F33 20PK/RD FUSED B(+)
5G26 20LB KEY-IN IGNITION SWITCH SENSEG26 20LB KEY-IN IGNITION SWITCH SENSE
6G16 20BK/LB LEFT FRONT DOOR JAMB SWITCH SENSEG16 20BK/LB LEFT FRONT DOOR JAMB SWITCH SENSE
7 L20 14LG/WT FUSED B(+)
8 A3 12RD/WT FUSED B(+)
9L7 20BK/YL PARK LAMP SWITCH OUTPUT
L7 20BK/YL PARK LAMP SWITCH OUTPUT
CAV CIRCUIT FUNCTION
1Ð Ð
2 L43 20VT LEFT HEADLAMP FEED
3 Z1 20BK GROUND
4 E2 20OR ILLUMINATION FEED
5 L13 20BR/YL HEADLAMP LEVELING SIGNAL TO MOTORSHEADLAMP LEVELING
SWITCH
12 345
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 18 8W-80 CONNECTOR PIN-OUTS
PLR08018
CAV CIRCUIT FUNCTION
A X2 18DG/RD HORN RELAY OUTPUT
B Z1 20BK GROUND
BLACK
BA
HORN NO. 1
CAV CIRCUIT FUNCTION
A X2 18DG/RD HORN RELAY OUTPUT
B Z1 20BK GROUND
BLACK
BA
HORN NO.2
CAV CIRCUIT FUNCTION
A K4 18BK/LB SENSOR GROUND
B K21 18BK/RD INTAKE AIR TEMPERATURE SENSOR SIGNAL
C K6 18VT/WT 5 VOLT SUPPLY
D K1 18DG/RD MAP SENSOR SIGNAL
BLACK
AD
(IAT/MAP) SENSOR
CAV CIRCUIT FUNCTION
1 K59 18VT IDLE AIR CONTROL MOTOR NO. 4 DRIVER
2 K40 18BR/WT IDLE AIR CONTROL MOTOR NO. 1 DRIVER
3 K60 18YL/BK IDLE AIR CONTROL MOTOR NO. 2 DRIVER
4 K39 18GY/RD IDLE AIR CONTROL MOTOR NO. 3 DRIVERIDLE AIR
CONTROL (IAC)
MOTOR
CAV CIRCUIT FUNCTION
1 K17 18DB/TN IGNITION COIL NO. 2 DRIVER
2 A142 18DG/OR AUTOMATIC SHUTDOWN RELAY OUTPUT
3 K19 18BK/GY IGNITION COIL NO. 1 DRIVER
IGNITION
COIL PACK
14
BLACK
31
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 19 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08019
BLACK
51
10 6
IGNITION
SWITCH
CAV CIRCUIT FUNCTION
1 Z1 22BK GROUND
2 G9 22GY/BK RED BRAKE WARNING LAMP DRIVER
3 A2 12PK/BK FUSED B(+)
4 A22 12BK/OR IGNITION SWITCH OUTPUT (RUN)
5Ð Ð
6Ð Ð
7 A1 14RD FUSED (B+)
8 A31 14BK/WT IGNITION SWITCH OUTPUT (ACC/RUN)
9 A21 14DB IGNITION SWITCH OUTPUT (RUN/START)
10 A41 14YL/BK IGNITION SWITCH OUTPUT (START)
CAV CIRCUIT FUNCTION
1 K241 20GY/BK IMMOBILIZER SENSOR
2 K240 20GY IMMOBILIZER SENSOR
IMMOBILIZER
ENGINE SENSOR
CAV CIRCUIT FUNCTION
1 K241 20GY/BK IMMOBILIZER ENGINE SENSOR
2 K4 20BK/LB SENSOR GROUND
3K7 20OR 8 VOLT SUPPLYK7 20OR 8 VOLT SUPPLY
4 K240 GY IMMOBILIZER ENGINE SENSORIMMOBILIZER
SENSOR
CAV CIRCUIT FUNCTION
1Ð Ð
2 L3 16RD/OR DIMMER SWITCH HIGH BEAM OUTPUT
3 L60 22TN RIGHT TURN SIGNAL
4 G10 20LG/RD SEAT BELT SWITCH SENSE
5 G5 20DB/WT FUSED IGNITION SWITCH OUTPUT (RUN/START)
6 M1 22PK FUSED B(+)
7 G21 22GY/LB TACHOMETER SIGNAL
8 Z3 16BK/OR GROUND
9 R41 18BK/TN AIRBAG WARNING LAMP DRIVER
10 G7 22WT/OR VEHICLE SPEED SENSOR SIGNAL
BLACK
5 1
10 6
INSTRUMENT CLUSTER Ð C1
CAV CIRCUIT FUNCTION
1 G6 22GY OIL PRESSURE SWITCH SENSE
2 G19 22LG/OR ABS WARNING LAMP DRIVER
3 G3 22BK/PK CHECK ENGINE LAMP DRIVER
4 G20 22VT/YL ECT GAUGE SENSOR SIGNAL
5 G26 20LB KEY-IN IGNITION SWITCH SENSE
6 G9 22GY/BK RED BRAKE WARNING LAMP DRIVER
7 G12 22TN/BK GENERATOR LAMP DRIVER
8 L61 22LG LEFT TURN SIGNAL
9 E2 22OR PANEL LAMPS DRIVER
10 G4 20DB FUEL LEVEL SENSOR SIGNAL
BLACK
5 1
10 6
INSTRUMENT CLUSTER Ð C2
1 2
BLACK
12
34
BLACK
GRAY
NATURAL
12
34

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 20 8W-80 CONNECTOR PIN-OUTS
PLR08020
CAV CIRCUIT FUNCTION
1 G16 20BK/LB LEFT FRONT DOOR JAMB SWITCH SENSE
2 G26 20LB KEY-IN IGNITION SWITCH SENSE
GREEN
KEY-IN SWITCH
2 1
CAV CIRCUIT FUNCTION
1 K42 20DB/LG*KNOCK SENSOR SIGNAL
1 K42 20BK/LGlKNOCK SENSOR SIGNAL
2 K4 20BK/LB SENSOR GROUND
BLACK
*2.0L SOHC ENGINEl2.0L DOHC ENGINE
**WITH INTERMITTENT WIPERS 21
KNOCK
SENSOR
CAV CIRCUIT FUNCTION
1 R47 18DB/LB LEFT IMPACT SENSOR LINE 1
2 R49 18LB LEFT IMPACT SENSOR LINE 2
BLACK
21
LEFT
AIRBAG IMPACT SENSOR
LEFT BACK-UP
LAMP
CAV CIRCUIT FUNCTION
1 L1 18VT/BK BACK-UP LAMP SENSE
2 Z1 18BK GROUND
CAV CIRCUIT FUNCTION
1 Z2 22BK/LG**GROUND
2 V5 18DG/YL WIPER RELAY COMMON
3 V10 18BR WINDSHIELD WASHER RELAY OUTPUT
4 V3 18BR/WT WIPER SWITCH LOW SPEED OUTPUT
5 F13 18DB FUSED IGNITION SWITCH OUTPUT (RUN/ACC)
6 V4 18RD/YL WIPER SWITCH HIGH SPEED OUTPUT
GRAY
INTERMITTENT
WIPE/WASH
SWITCH 61
2 1
BLACKGRAY

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 21 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08021
CAV CIRCUIT FUNCTION
1 Z8 18BK/VT GROUND
2 P36 18PK/VT DOOR UNLOCK SWITCH OUTPUT
3 F35 18RD/YL FUSED B(+)
4 P35 18OR/VT LEFT DOOR LOCK SWITCH OUTPUT
5 P36 18PK/VT LEFT DOOR UNLOCK SWITCH OUTPUT
WHITE
LEFT DOOR
LOCK SWITCH 12
3
45
CAV CIRCUIT FUNCTION
1 Q22 14VT LEFT FRONT DOWN
2 Q12 14BR LEFT FRONT UP
LEFT DOOR
WINDOW MOTOR
BLACK
21
LEFT FOG
LAMP
CAV CIRCUIT FUNCTION
1 L39 20LB/WT FRONT FOG LAMPS SWITCH OUTPUT
2 Z1 20BK GROUND
BLACK
LEFT FRONT
DOOR LOCK
MOTOR
CAV CIRCUIT FUNCTION
1 P34 18PK/BK DOOR UNLOCK DRIVER
2 P33 18OR/BK DOOR LOCK DRIVER 2 1
CAV CIRCUIT FUNCTION
1 X55 22BR/RD LEFT FRONT SPEAKER (Ð)
2 X53 22DG LEFT FRONT SPEAKER (+)
1 2
BLACK
LEFT FRONT
DOOR SPEAKER
1 2
BLACK

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 22 8W-80 CONNECTOR PIN-OUTS
PLR08022
CAV CIRCUIT FUNCTION
1 B8 20RD/DB LEFT FRONT WHEEL SPEED SENSOR (+)
2 B9 20RD LEFT FRONT WHEEL SPEED SENSOR (-)
BLACK
21
LEFT FRONT
WHEEL SPEED SENSOR
CAV CIRCUIT FUNCTION
1 L3 16RD/OR DIMMER SWITCH HIGH BEAM OUTPUT
2 L43 18VT FUSED LEFT LOW BEAM OUTPUT
3Z1 18BK GROUND
Z1 18BK GROUND
LEFT HEADLAMP
CAV CIRCUIT FUNCTION
1 X53 22DG LEFT FRONT SPEAKER (+)
2 X55 22BR/RD LEFT FRONT SPEAKER (Ð)
BLACK
1 2
LEFT INSTRUMENT
PANEL SPEAKER (PREMIUM)
CAV CIRCUIT FUNCTION
1 L61 18LG LEFT TURN SIGNAL
2 L7 18BK/YL PARK LAMP SWITCH OUTPUT
3 Z1 18BK GROUND
LEFT PARK/TURN
SIGNAL LAMP
CAV CIRCUIT FUNCTION
1 L43 22VT LEFT HEADLAMP FEED
2 L13 22BR/YL HEADLAMP LEVELING SIGNAL FROM SWITCH
3 Z1 22BK GROUND
LEFT HEADLAMP
LEVELING MOTOR
CAV CIRCUIT FUNCTION
1 Z1 20BK GROUND
2 L7 20BK/YL PARK LAMP SWITCH OUTPUT
NATURAL
LEFT
LICENSE LAMP1 2
2
BLACK
123
BLACK
1 3
BLACK
1
3
