DODGE NEON 1997 1.G Wiring Diagrams Workshop Manual

Downloaded from www.Manualslib.com manuals search engine Component Page
Right Instrument Panel Speaker
(Premium).......................8W-80-31
Right License Lamp.................8W-80-31
Right Park/Turn Signal Lamp..........8W-80-31
Right Power Mirror..................8W-80-32
Right Rear Door Lock Motor...........8W-80-32
Right Rear Fog Lamp................8W-80-32
Right Rear Speaker..................8W-80-32
Right Rear Wheel Speed Sensor........8W-80-32
Right Repeater Lamp................8W-80-33
Right Tail/Stop Lamp................8W-80-33
Right Turn Signal Lamp..............8W-80-33
Solid State Fan Relay................8W-80-33
Stop Lamp Switch...................8W-80-33Component Page
Sunroof Slide Switch.................8W-80-34
Sunroof Vent Switch.................8W-80-34
Throttle Position Sensor (TPS).........8W-80-34
Torque Convertor Clutch (TCC)
Solenoid (ATX)...................8W-80-34
Trunk Lamp.......................8W-80-34
Turn Signal/Hazard Switch............8W-80-35
Upstream Heated Oxygen Sensor.......8W-80-35
Vapor Canister Leak Detector..........8W-80-35
Vehicle Speed Sensor.................8W-80-35
Windsheild Washer Pump Motor........8W-80-36
Wiper Motor.......................8W-80-36
8W - 80 - 4 8W - 80 CONNECTOR PIN-OUTSPL
DESCRIPTION AND OPERATION (Continued)

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 4 8W-80 CONNECTOR PIN-OUTS
PLR08004
CAV CIRCUIT FUNCTION
1 C3 18DB/BK A/C COMPRESSOR CLUTCH RELAY OUTPUT
2 Z1 20BK GROUND
CAV CIRCUIT FUNCTION
1 C21 22DB/OR A/C CYCLING SWITCH OUTPUT
2 F20 22WT FUSED IGNITION SWITCH OUTPUT (RUN)
3 C2 22DB/YL MODE SWITCH OUTPUT
BLACK
A/C CYCLING
SWITCH
31
BLACK
71
CAV CIRCUIT FUNCTION
1Z8 14BK/VT GROUND
Z8 18BK/VT GROUND
2 C7 14BK/TN HIGH BLOWER MOTOR DRIVER
3 C6 14LB M2 BLOWER MOTOR DRIVER
4 C5 14LG M1 BLOWER MOTOR DRIVER
5 C4 14TN LOW BLOWER MOTOR DRIVER
6 C2 22DB/YL*MODE SWITCH OUTPUT
7 E2 22OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
7 E2 22OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
*WITH A/C A/C-HEATER
CONTROL
SWITCH
CAV CIRCUIT FUNCTION
1 C20 20BR/OR A/C SWITCH SENSE
2 C22 20DB/WT LOW PRESSURE SWITCH OUTPUT BLACK21
A/C HIGH
PRESSURE
SWITCH
1
A/C COMPRESSOR
CLUTCH
BLACK
2
2
1
A/C-HEATER
BLOWER MOTOR (WITH A/C)
BLACK
CAV CIRCUIT FUNCTION
1 C1 14DG FUSED IGNITION SWITCH OUTPUT (RUN)
2 C7 14BK/TN HIGH BLOWER MOTOR DRIVER

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 5 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08005
CAV CIRCUIT FUNCTION
1 C22 20DB/WT LOW PRESSURE SWITCH OUTPUT
2 C21 20DB/OR A/C CYCLING SWITCH OUTPUT
A/C LOW
PRESSURE SWITCH
BLACK
12
CAV CIRCUIT FUNCTION
1 B142 20BR/YL LEFT FRONT DUMP SOLENOID CONTROL
2 B143 20DG/YL RIGHT FRONT DUMP SOLENOID CONTROL
3 B146 20BR/LB LEFT REAR DUMP SOLENOID CONTROL
4 B148 20DB/LB RIGHT REAR DUMP SOLENOID CONTROL
5 Z1 18BK GROUND
6 Z1 18BK GROUND
BLACK
CAV CIRCUIT FUNCTION
1 F12 18DG/WT ABS RELAY FEED
2 Ð Ð
3 B116 20GY ABS PUMP MOTOR RELAY CONTROL
4 B57 20BR/BK ABS SYSTEM RELAY CONTROL
5 A20 12RD/DG FUSED B(+)
6 B120 12BR/WT ABS PUMP MOTOR RELAY OUTPUT
7 G19 20LG/BR ABS WARNING LAMP DRIVER
8 Ð Ð
9 B47 20RD/LB ABS SYSTEM RELAY OUTPUT
10 Z1 14BK GROUND
DARK
GRAY
ABS HYDRAULIC
MODULATOR 31
64
ABS RELAY BOX 51
10 6
CAV CIRCUIT FUNCTION
1 R45 18DG/LB DRIVER AIRBAG SQUIB LINE 2
2 R43 18BK/LB DRIVER AIRBAG SQUIB LINE 1
3 R47 18DB/LB LEFT IMPACT SENSOR LINE 1
4 R49 18LB LEFT IMPACT SENSOR LINE 2
5 R42 18BK/YL PASSENGER AIRBAG SQUIB LINE 1
6 R44 18DG/YL PASSENGER AIRBAG SQUIB LINE 2
7 R46 18BR/LB RIGHT IMPACT SENSOR LINE 1
8 R48 18TN RIGHT IMPACT SENSOR LINE 2
9 R41 18BK/TN AIRBAG WARNING LAMP DRIVER
10 Z6 18BK/PK GROUND
11 R50 18BR/YL PASSENGER AIRBAG PRESSURE SWTICH SENSE
12 R51 18VT/YL PASSENGER AIRBAG PRESSURE SWITCH GROUND
17 F15 18DB/WT FUSED IGNITION SWITCH OUTPUT (RUN/START)
18 D2 20WT/BK CCD BUS (Ð)
19 D1 20VT/BR CCD BUS (+)
20 F25 18TN/LG FUSED IGNITION SWITCH OUTPUT (RUN)
11 1
22 12
AIRBAG CONTROL
MODULEYELLOW

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 6 8W-80 CONNECTOR PIN-OUTS
PLR08006
CAV CIRCUIT FUNCTION
1 E2 22OR FUSED PANEL LAMPS DIMMER SWITCH SIGNAL
2 Z3 20BK/OR GROUND BLACK12
ASH
RECEIVER
LAMP
BACK-UP LAMP
SWITCH (MTX)GRAY
CAV CIRCUIT FUNCTION
A L1 20VT/BK REVERSE LAMP SENSE
B F20 20WT FUSED IGNITION SWITCH OUTPUT (RUN)ABAB
CAV CIRCUIT FUNCTION
1 K4 18BK/LB SENSOR GROUND
2 G31 18VT/LG AMBIENT TEMPERATURE SENSOR SIGNAL
2
1 54
3
CAV CIRCUIT FUNCTION
1 C5 14LG M1 BLOWER MOTOR DRIVER
2 C6 14LB M2 BLOWER MOTOR DRIVER
3Ð Ð
4 C7 14BK/TN HIGH BLOWER MOTOR DRIVER
5 C4 14TN LOW BLOWER MOTOR DRIVER
BLOWER MOTOR
RESISTOR
BLOCK
3 25 4
1BLACK
CAV CIRCUIT FUNCTION
1 G9 20GY/BK RED BRAKE WARNING LAMP DRIVER
2 Z1 20BK GROUND
BRAKE WARNING
LAMP SWITCH
BATTERY
TEMPERATURE SENSOR12
BLACK
BLACK
21

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 7 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08007
CAV CIRCUIT
1 A1 14RD
2 A2 12PK/BK
3 A3 12RD/WT
4 A4 14BK/RD
CAV CIRCUIT
1 A1 14RD
2 A2 12PK/BK
3 A3 12RD/WT
4 A4 14BK/RD BLACK
BLUE
BLACK
BLUE
12
3421
43
716
1816 7
81
CAV CIRCUIT
1 A41 14YL
2 C21 20DB/OR
3 L61 22LG
4 V10 18BR
5 X3 18BK/RD
6 F12 20DG/WT
7 R46 18BR/LB
8 R48 18TN
9 L35 18BR/RD
10L13 22BR/YLL13 22BR/YL
11 D1 20VT/BR
12 D2 20WT/BK
13 L50 22WT/TN
14 L3 16RD/OR
15 R47 18DB/LB
16 R49 18LB
CAV CIRCUIT
1 A41 14YL/BK
2 C21 22DB/OR
3 L61 22LG
4 V10 18BR
5 X3 20BK/RD
6 F12 20DG/WT
7 R46 18BR/LB
8 R48 18TN
9 L35 20BR/RD
10 L13 20BR/YL
11 D1 20VT/BR
12 D2 20WT/BK
13 Ð
14 L3 14RD/OR
15 R47 18DB/LB
16 R49 18LB
BROWNBROWN
716
1816 7
81
CAV CIRCUIT
1G19 20LG/BRG19 20LG/BR
2 G9 20GY/BK
3 F20 20WT
4 G6 20GY
5G7 20WT/ORG7 20WT/OR
6 G12 20TN/BK
7 G20 20VT/YL
8 G21 20GY/LB
9 L60 22TN
10 Ð
11 G3 20BK/PK
12 F61 18WT/OR
13M1 18PKM1 20PK
14 L9 18BK/WT
15 L44 18VT/BK
16 L43 18VT
CAV CIRCUIT
1 G19 22LG/OR
2 G9 22GY/BK
3 F20 20WT
4 G6 22GY
5 G7 22WT/OR
6 G12 22TN/BK
7 G20 22VT/YL
8 G21 22GY/LB
9 L60 22TN
10 Ð
11 G3 22BK/PK
12 F61 18WT/OR
13 M1 22PK
14 L9 22BK/WT
15 L44 20VT/RD
16 L43 20VT
l DOUBLE CRIMP WITH RKE
C101 C101
C102
C102
C103
C103

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 8 8W-80 CONNECTOR PIN-OUTS
PLR08008
CAV CIRCUIT
1 L1 18VT/BK
2 L50 20WT/TN
3 M1 22PK
4Ð
5 L7 20BK/YL
6 A141 18DG/WT
7 G4 20DB
8Ð BLACK
85
41
BLACK
58
14
CAV CIRCUIT
1 L1 20VT/BK
2 L50 22WT/TN
2 L50 20WT/TN*3 M1 20PK
4Ð
5 L7 20BK/YL
6 A141 16DG/WT
7 G4 20DB
8Ð C105 C105
CAV CIRCUIT
1 B1 20WT/BK
2 B2 20DG/WT
3 B3 20LG/DB
4 B4 20LG
BLACK
41
BLACK
CAV CIRCUIT
1 B1 20YL/DB
2 B2 20YL
3 B3 20LG/DB
4 B4 20LG 14
C108
C108
CAV CIRCUIT
1 T40 14BR
2 G7 20WT/OR
3 G4 20DB
4 K141 20TN/WT
5 C20 20BR/OR
6 G20 20VT/YL
7 F12 20DG/WT
8Ð
9 G3 20BK/PK
10 Z12 20BK/TN
11 Ð
12 Ð
13 K173 20DG
14 Ð
CAV CIRCUIT
1 T40 14BR
2 G7 18WT/OR
3 G4 20DB
4 K141 20TN/WT
5 C20 18BR
6 G20 20VT/YL
7 F12 18DB/WT
8Ð
9 G3 20BK/PK
10 Z12 18BK/TN
11 Ð
12 Ð
13 K173 20LG
14 Ð
51
10 6
BLACKBLACK
CAV CIRCUIT
1 Z1 20BK
2 K39 20GY/RD
3 K40 20BR/WT
4 K59 20VT
5 K7 20OR
6 A142 18DG/OR
7 K60 20YL/BK
8 G6 20GY
9 K6 20VT/WT
10 K4 20BK/LB15
610
CAV CIRCUIT
1 Z1 18BK
2 K39 18GY/RD
3 K40 18BR/WT
4 K59 18VT
5 K7 18OR
6 A142 18DG/OR
7 K60 18YL/BK
8 G6 18GY
9 K6 20VT/WT
10 K4 20BK/LBC161C161
C160
C160
BLACKBLACK
1
87
14 1
8 7
14
* WITH A/T

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 9 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08009
CAV CIRCUIT
1 F35 16RD/YL
2 P36 16PK/VT
3 P35 16OR/VT
4 Z8 14BK/VT
5 P33 16OR/BK
6 P34 16PK/BK
7 F21 14TN
8 P99 18GY
9 P90 18LG/BK
10 P91 18WT/BK
11 P93 18YL/BK
12 P95 18DB/WT
13 Q16 14BR/WT
14 Q26 14VT/WT
15 X54 22VT
15 X54 22VT
16 X56 22DB/RD
16 X56 22DB/RD
7 1
16 81 7
816 BLUEBLUE
llWITH A/C
CAV CIRCUIT
1 F35 18RD/YL
1 F35 18RD/YL
2 P36 18PK/VT
3 P35 18OR/VT
4 Z8 14BK/VT
5 P33 18OR/BK
6 P34 18PK/BK
7 F21 14TN
8P99 18GYP99 18GY
9P90 18LG/BKP90 18LG/BK
10P91 18WT/BKP91 18WT/BK
11 P93 18YL/BK
12 P95 18DB/WT
13 Q16 14BR/WT
14 Q26 14VT/WT
15 X54 22VT
16 X56 22DB/RD C205C205
CAV CIRCUIT
1 C2 22DB/YLll
2 F20 22WTll
3 C21 22DB/ORll
4 C1 14DG
5Ð
6 C7 14BK/TN
CAV CIRCUIT
1 C2 22DB/YLll
2 F20 22WTll
3 C21 22DB/ORll
4 C1 14DG
5Ð
6 C7 14BK/TN
BLUE64
3146
13BLUE
C206
C206
CAV CIRCUIT
1 E2 22OR
2 Z3 20BK/OR
CAV CIRCUIT
1 E2 22OR
2 Z3 20BK/OR
C203
C203
CAV CIRCUIT
1 M1 18PK
2 M23 22YL/BK
3 Z3 18BK/OR
4Ð
5 F10 18YL/RD
6 Z8 18BK/VT
CAV CIRCUIT
1 M1 22PK
2 M2 22YL
3 Z3 20BK/OR
4Ð
5 F10 18YL/RD
6 Z8 18BK/VT
REDRED
46
31
64
13
C225 C225
GRAYGRAY
2
12
1

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 10 8W-80 CONNECTOR PIN-OUTS
1
58
10
BLACK
101BLACK
PLR08010
CAV CIRCUIT
1Ð
2L7 20BK/YLL7 20BK/YL
3 L62 18BR/RD
4 L63 18DG/RD
5 X51 22BR/YL
6G4 18DBG4 20DB
7 X52 22DB/WT
8 L38 18BR/WT
9 G16 20BK/LB
10 P33 16OR/BK
11 P34 16PK/BK
12 M2 20YL
13 X57 22BR/LB
14 Ð
15 X58 22DB/OR
16 C15 14BK
CAV CIRCUIT
1 F35 18RD/YL
2 P36 18PK/VT
3 P35 18OR/VT
4 P99 18GY
5 P33 18OR/BK
6P34 18PK/BKP34 18PK/BK
7 F21 14TN
8Ð
9 P90 18LG/BK
10 P91 18WT/BK
11 P93 18YL/BK
12 P95 18DB/WT
13 Q16 14BR/WT
14 Q26 14VT/WT
15 X53 22DG
16 X55 22BR/RD
CAV CIRCUIT
1 F35 16RD/YL
2 P36 16PK/VT
3 P35 16OR/VT
4 P99 18GY
5 P33 16OR/BK
6 P34 16PK/BK
7 F21 14TN
8Ð
9 P90 18LG/BK
10 P91 18WT/BK
11 P93 18YL/BK
12 P95 18DB/WT
13 Q16 14BR/WT
14 Q26 14VT/WT
15X53 22DGX53 22DG
16X55 22BR/RD
X55 22BR/RD
CAV CIRCUIT
1Ð
2L7 20BK/YLL7 20BK/YL
3 L62 20BR/RD
4 L63 20DG/RD
5 X51 22BR/YL
6 G4 20DB
7 X52 22DB/WT
8 L38 18BR/WT
9 G16 20BK/LB
10P33 16OR/BKP33 16OR/BK
11P34 16PK/BKP34 16PK/BK
12 M2 22YL
13 X57 22BR/LB
14 Ð
15 X58 22DB/OR
16 C15 14BK/WT
GRAYGRAY
BLUEBLUE
71
16 816 9
81916
18 17
8 16C230 C230
C231
C231
CAV CIRCUIT
1 M2 22YL
2 P36 16PK/VT
3 A41 14YL/BK
4 P35 16OR/VT
5 Z2 20BK/LG
6 G5 20DB/WT
7 P36 18PK/VT
8 A41 14YL/BK
9 P35 16OR/VT
10 F35 16RD/YLC241
C241
CAV CIRCUIT
1Ð
2 P36 16PK/VT
3 A41 14YL/BK
4 P35 16OR/VT
5Ð
6Ð
7 P36 18PK/VT
8 A41 14YL/BK
9 P35 16OR/VT
10 Ð

Downloaded from www.Manualslib.com manuals search engine 978W-1
8W - 80 - 11 PL-RHD 8W-80 CONNECTOR PIN-OUTS
PLR08011
GRAY
1 2
GRAY
2 1
CAV CIRCUIT
1 P33 16OR/BK
2 P34 16PK/BK
CAV CIRCUIT
1 P33 18OR/BK
2 P34 18PK/BK
GRAY
1 2
GRAY
2 1
CAV CIRCUIT
1 P33 16OR/BK
2 P34 16PK/BK
CAV CIRCUIT
1 P33 18OR/BK
2 P34 18PK/BK C301C301
C303C303
CAV CIRCUIT
1Ð
2Ð
3 M4 18GY/BK
CAV CIRCUIT
1 L50 20WT/TN
2 Z1 20BK
3 M4 22GY/BK
BLACK
BLACK
1 3
C309C309
BLACK
1 2
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK 2 1
BLACK
C315
C315
BLACKBLACK
1 2
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK
BLACKBLACK
1 2
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK 2 1
2 1
C324C324 C323
C323
31

Downloaded from www.Manualslib.com manuals search engine 978W-1
PL-RHD 8W - 80 - 12 8W-80 CONNECTOR PIN-OUTS
PLR08012
CAV CIRCUIT FUNCTION
1 K7 20OR 8 VOLT SUPPLY
2 K4 20BK/LB SENSOR GROUND
3 K44 20TN/YL CAMSHAFT POSITION SENSOR SIGNAL
CAV CIRCUIT FUNCTION
1 X3 20BK/RD HORN RELAY CONTROL
2Ð Ð
3Ð Ð
4Ð Ð
NATURAL
1 4
CLOCKSPRING
CAV CIRCUIT FUNCTION
1 T141 14YL/RD CLUTCH PEDAL POSITION SWITCH SIGNAL
2 A41 14YL IGNITION SWITCH FEED
CLUTCH PEDAL
POSITION SWITCH (MTX)BLACK
1 2
BLACKBLACK
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK
CAV CIRCUIT
1 P34 18PK/BK
2 P33 18OR/BK 122 1
C325C325
CAMSHAFT
POSITION SENSOR
31
BLACK
CAV CIRCUIT
1 L1 18VT/BK
2 L7 18BK/YL
3 Z1 18BK
4 L38 18BR/WT
5 L50 18WT/TN
6 L63 18DG/RD
CAV CIRCUIT
1 L1 18VT/BK
2 L7 18BK/YL
3 Z1 18BK
4 L38 18BR/WT
5 L5018WT/TN
6 L63 18DG/RD
C340C340
CAV CIRCUIT
1 L1 18VT/BK
2 L7 18BK/YL
3 Z1 16BK
4 L38 18BR/WT
5 L50 18WT/TN
6 L62 18BR/RD
CAV CIRCUIT
1 L1 18VT/BK
2 L7 18BK/YL
3 Z1 18BK
4 L38 18BR/WT
5 L50 18WT/TN
6 L63 18DG/RD
C341C341
14
25
36
BLACK
41
52
63BLACK
14
25
36
BLACK
41
52
63BLACK
