Page 53 of 288
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53
2
Engine Oil ConsumptionWhen the engine has passed the break-in period, oil
consumption may reach 0.5 % of the fuel consumption
recorded in actual operating circumstances. In isolated
cases and in arduous operating conditions, oil
consumption may increase to 1 % of the fuel
consumption recorded in actual operating
circumstances.
Engine oil consumption depends on the driving style
adopted and the operating conditions. It can only be
judged after the engine has passed the break-in period.
SAFETY TIPS Check the vehicle’s lights and the general condition
of the vehicle before each trip.
Keep tires at the recommended inflation pressure.
All occupants should fasten their seat belts before each trip.
Driving in an environmentally responsible manner will reduce noise, fuel consumption and exhaust
emissions.
Allow the engine to warm up under low load use.
Avoid unnecessarily hard acceleration, driving with the throttle fully open, and carrying loads not
specifically needed on the journey.
Stop the engine during lengthy waiting periods, for example at traffic lights.
Remove ancillary parts, such as wind deflectors and roof racks, as soon as they are no longer needed.
Page 65 of 288
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 65
3
To install:
1. With the rear bench seat facing in the direction of travel, insert the legs of the rear bench seat in the
respective seat mounting cups on the floor.
2. Slide the rear bench seat forwards with some force as far as it will go, until the release levers are heard
to engage and all release levers are parallel to the
vehicle floor.
Retrofitting Seat Mounting Cups
WARNING!
Additional rear bench seats can be added if seat
mounting cups are properly installed.
For reasons of safety, only have seat mounting
cups retrofitted by an authorized Sprinter Dealer.
Never exceed the maximum permissible number
of rear bench seats for the specific vehicle.
For more information contact your authorized
Sprinter Dealer.
Page 77 of 288
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 77
3
SPEED CONTROL (OPTIONAL)Set / accelerate speed (1)
Set / decelerate speed (2)
Off (3)
Resume set speed (4) The speed control allows you to drive in a more
relaxed manner, for example over long distances, as it
automatically maintains the set speed by actively
regulating the throttle setting.
The speed control lever on th
e steering column is used
to activate and oper ate the speed control.
NOTE: The responsibility for the driving speed is
always that of the driver. The cruise control is only an
aid for the driver.
NOTE: A change of gear does not shut off the cruise
control.
Every speed traveled above 25 mph (40 km/h) can be
set.
Once the speed is set, it is maintained constant by the
speed control, the accelerator pedal can be released.
Page 84 of 288
84 UNDERSTANDING THE FEATURES OF YOUR VEHICLECONTROL AND OPERATION OF RADIO
TRANSMITTERS
Radio, Telephone and Two Way Radio MOBILE TELEPHONE AND TWO WAY RADIO AND
FAX MACHINES
Radio transmitters, such as a mobile telephone or a
citizens band unit should only be used inside the
vehicle they are connected to an antenna that is
installed on the outside of the vehicle.
Refer to the radio transmitter operation instructions
regarding use of an external antenna.
WARNING!
Please do not forget that your primary responsi-
bility is to drive the vehicle. Only operate the ra-
dio, telephone, navigation system, two-way radio
or fax when road and traffic conditions permit.
Otherwise you could be distracted from the traffic
and cause an accident. Always obey local laws and
regulations.
Remember that at a speed of just 30 mph (about 50
km/h), your vehicle is covering a distance of 50
feet (about 14 m) every second.
WARNING!
Never operate radio transmitters equipped with a
built-in or attached antenna (i.e., without being
connected to an external antenna) from inside the
vehicle while the engine is running. Doing so
could lead to a malfunction of the vehicle’s elec-
tronic system, possibly resulting in severe person-
al injuries and death.
Page 86 of 288
86 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
GLOVE COMPARTMENTTo open glove compartment:
Pull handle (1)COMPARTMENTS IN FRONT DOORSLocked (1)
Unlocked (2)
WARNING!
Your primary responsibility is to drive the vehicle.Do not use cup holder while the vehicle is in
motion. Otherwise you could be distracted from
traffic and cause an accident or liquid could spill
from the containers due to for example breaking
or other vehicle movement.Place only containers that fit into the cup holder toprevent spills.
Do not fill containers to a height where the
contents could spill, especially hot liquids.
Otherwise you may scald yourself.
Page 92 of 288
92 UNDERSTANDING YOUR INSTRUMENT PANELLegend For Instrument Cluster And Indicator Lamps
1. Tachometer (Engine rpm), refer to "Tachometer (Engine rpm)".
2. Turn signal indicator lamp (left), refer to "Multifunction Switch".
3. Turn signal indicator lamp (right), refer to "Multifunction switch".
4. ASR warning lamp or ESP
* warning lamp .
5. Speedometer.
6. Multi-function indicator, refer to "Multi-Function Indicator".
7. Gear selector lever position .
8. Coolant temperature gauge, refer to "Coolant Temperature Gauge".
* 2500 Type vehicles only 9. Fuel gauge with reserve fuel indicator lamp
(yellow), refer to "Fuel Gauge with Reserve Fuel
Indicator Lamp".
10. Warning and indicator lamps.
11. Odometer/trip meter selector, refer to "Odometer and Trip Meter".
Clock/outside temperature display selector, refer
to "Clock and Outside Temperature Display".
12. Instrument lighting brighter/dimmer, refer to "Instrument Lighting".
Page 93 of 288
UNDERSTANDING YOUR INSTRUMENT PANEL 93
4
Indicator Lamp Symbolsv
Acceleration skid control (ASR)
or electronic stabi lity program (ESP)*
or slippery surface warning.
1
Airbag Malfunction (USA only).
Parking brake applied.
A
High beam on, refer to "Multifunction Switch".
#
Battery not being charged,
refer to "Battery Charge Indicator Lamp".
Water in fuel filter, refer to "Water in Fuel
Indicator Lamp".
2
Brake pads worn.
:
Engine oil level too low,
refer to "Engine Oil Level Indicator Lamp".
/
Coolant level too low,
refer to "Coolant Level Indicator Lamp".
;
Brake fluid level too low and electronic brake force
distribution (EBD) malfunction (USA only).
*2500 Type Vehicles only.
3
Brake fluid level too low and electronic brake force
distribution (EBD) malfunction (Canada only).
<
Seat belt warning lamp.
-
Anti-lock brake system (ABS) malfunction.
Electronic stability program (ESP)* malfunction.
±
Engine control unit malfunction.
k
Acceleration skid control (ASR) malfunction
and brake assist system (BAS)
1malfunction.
™
Constant RPMs on.
W
Fluid level in windshield washer low.
q
Preheating.
Page 101 of 288
UNDERSTANDING YOUR INSTRUMENT PANEL 101
4
Tachometer (Engine rpm)Do not exceed the maximum permissible engine speed.
NOTE: To protect the engine, its fuel supply is
interrupted when the maximum rpm is reached.
Despite this, the maximum rpm can still be exceeded in
overrun mode (e.g. when driving downhill).
Coolant Temperature GaugeThe coolant temperature is displayed when the key is
in position 2 in the ignition lock.
If corrosion inhibitor/antifreeze is present in the
correct concentration in the coolant, the coolant
temperature will be between 185 °F (+85 °C) and
250 °F (+120 °C), depending on operating conditions.
If the needle reaches the red section, do not continue to
drive the vehicle.
Page 139 of 288
STARTING AND OPERATING
5
CONTENTS
Power Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Starting the Engine . . . . . . . . . . . . . . . . . . . . . . . . . 141Maximum Engine Speed . . . . . . . . . . . . . . . . . . 142Constant RPMs (Optional) . . . . . . . . . . . . . . . . 143
Stopping the Engine . . . . . . . . . . . . . . . . . . . . . . . . 144
Automatic Transmission . . . . . . . . . . . . . . . . . . . . 145Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145Accelerator Position . . . . . . . . . . . . . . . . . . . . . . 146Stopping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146Maneuvering . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146Gear Selector Lever Position . . . . . . . . . . . . . . . 147Gear Selection for Special Circumstances . . . . 148
Transmission Selector Lever, Manually
Unlocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150Reversing Aid (Optional) . . . . . . . . . . . . . . . . . 150
Loading the Vehicle . . . . . . . . . . . . . . . . . . . . . . . . 153Loading Guidelines . . . . . . . . . . . . . . . . . . . . . . 154
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155Service Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155Brake Pad Wear Indicator . . . . . . . . . . . . . . . . . 156Brake Indicator and Electronic Brake Force
Distribution (EBD) Indicator Lamp . . . . . . . . . 157Parking Brake Indicator Lamp . . . . . . . . . . . . . 158Parking Brake . . . . . . . . . . . . . . . . . . . . . . . . . . . 159Driving Safety Systems . . . . . . . . . . . . . . . . . . . 160Anti-Lock Brake System (ABS) Indicator
Lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 161Anti-Lock Brake System (ABS) . . . . . . . . . . . . . 162Electronic Brake Force Distribution (EBD) . . . 164Acceleration Skid Control Indicator Lamp
(ASR) and Brake Assist System (BAS)
1
if equipped . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Acceleration Skid Control (ASR) Warning
Lamp and Electronic Stability Program
(ESP)
1 – if equipped . . . . . . . . . . . . . . . . . . . . . 166
Acceleration Skid Control (ASR) . . . . . . . . . . . 167
Page 140 of 288
140 STARTING AND OPERATING
Deactivating the Acceleration Skid
Control (ASR) . . . . . . . . . . . . . . . . . . . . . . . . . . . 168Brake Assist System (BAS)
(vehicle type 2500 only) . . . . . . . . . . . . . . . . . . . 169Indicator Lamp Electronic Stability Program
(ESP) (type 2500 vehicles only) . . . . . . . . . . . . 170Electronic Stability Program (ESP)
(vehicle type 2500 only) . . . . . . . . . . . . . . . . . . . 171
Auxiliary Drive (Optional) . . . . . . . . . . . . . . . . . . 172
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Wheels and Tires . . . . . . . . . . . . . . . . . . . . . . . . . . 173Tire Grip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175Hydroplaning . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Tire Pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175Tire Pressures of Loaded Vehicle in PSI (kPa) . . . 177Vehicle type 2500 C/HC/SHC . . . . . . . . . . . . 177Vehicle type 3500 C/HC/SHC . . . . . . . . . . . . 177Comfort Tire Pressures in PSI (kPa) . . . . . . . . 178Comfort Tire Pressures in PSI (kPa) . . . . . . . . 178
Snow Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
Fuel Requirements . . . . . . . . . . . . . . . . . . . . . . . . . 179Fuel Filter with Water Separator . . . . . . . . . . . 180Diesel Fuels for Use at Very Low
Temperatures . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Refueling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Programmed Top Speed (Optional) . . . . . . . . . . 182
Bleeding Diesel Fuel System . . . . . . . . . . . . . . . . . 183
Draining Fuel Filter with Water Separator . . . . . 184Bleeding the Diesel Fuel Syst em . . . . . . . . . . . 185
Permissible Roof Load . . . . . . . . . . . . . . . . . . . . . . 186
Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186Trailer Hitches (Optional) . . . . . . . . . . . . . . . . . 186Electrical Connections (Optional) . . . . . . . . . . 186Vehicle and Trailer Weights and Ratings . . . . 187Loading a Trailer . . . . . . . . . . . . . . . . . . . . . . . . 187Checking Weights of Vehicle and Trailer . . . . 188Attaching a Trailer . . . . . . . . . . . . . . . . . . . . . . . 188Towing a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . 189Parking a Trailer . . . . . . . . . . . . . . . . . . . . . . . . . 191
Emissions Control System (Catalytic Converter) 192
Inhalation of Exhaust Gas . . . . . . . . . . . . . . . . . . . 192
Fording (Wading Capability) . . . . . . . . . . . . . . . . 192
Body Builder Guideline . . . . . . . . . . . . . . . . . . . . . 193A Special Note Concerning Vehicle
Alteration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
