DODGE STRATUS COUPE 2004 2.G Owners Manual

2. If you press the display switch less than 3 seconds, you
can turn on/off the display.3. If you press the display switch more than 3 seconds,
less than 6 seconds, you can alternate the temperature
reading between Fahrenheit and Celsius.!P. 182.
I08A0660
I08A0590
STARTING AND DRIVING 181
5

4. If you press the display switch more than 6 seconds,
less than 9 seconds, you can turn on/off the automatic
anti-glare.!1775. If you press the display switch more than 9 seconds,
less than 12 seconds, you can adjust for compass vari-
ance.!183
I08A0670I08A0610
182 STARTING AND DRIVING

6. If you press the display switch more than 12 seconds,
you can recalibrate compass variance.!186Outside temperature (if so equipped)
When the ignition key is in the ªACCº or ªONº position,
the current outside temperature is displayed.I08A0590
I08A0600
STARTING AND DRIVING 183
5

To alternate the temperature reading between
Fahrenheit and Celsius
Press the display switch above 3 seconds, less than 6
seconds until the display blinks ÉF and ÉC.
Press the display switch to toggle between the Fahrenheit
and Celsius readings within 5 seconds.
After 5 seconds of inactivity, the original item (Outside
temperature/Compass) is again displayed.
NOTE
²
The outside temperature can be displayed from
-40ÉF (-40ÉC)
²If the outside temperature is below -40ÉF (-40ÉC) or
over 140ÉF (60É C) an error message ªSCº or ªOCº
will be shown in the display. If an error message
(ªSCº or ªOCº) will be shown in the display, have
the system checked at an authorized dealer.
²If the outside temperature drops below about 37ÉF
(3ÉC)
²The outside temperature displayed may differ from
the actual temperature on account of surrounding
conditions, driving conditions, etc.
I08A0590
184 STARTING AND DRIVING

Compass operation
When the ignition key is in the ªACCº or ªONº position,
the vehicle's current directional heading (N, NE, E, SE, S,
SW, W and NW) will be displayed.
Magnetic variation of compass
Under certain circumstances, as during a long distance
cross-country trip, it will be necessary to adjust for
magnetic variation of compass. Magnetic variation of
compass is the difference between earth's magnetic northand true geographic north. If not adjusted to account for
magnetic variation of compass, your compass could give
false readings.
To adjust for magnetic variation of compass
1. Press the display switch more than 9 seconds, less than
12 seconds. The current zone number will appear in the
display.
I08A0600
I08A0610
STARTING AND DRIVING 185
5

2. Find your current location and variance zone number
on the zone map.
3. Press the display switch until the new zone number
appears in the display. After 5 seconds of inactivity, the
original item (Outside temperature/Compass) displayed
again.NOTE
²
Do not attach ski racks, antennas, or any other object
to the vehicle by means of a magnet. Such magnets
will affect the operation of the compass.
²If the compass deviates from the correct indication
soon after repeated adjustment, have the compass
checked at an authorized dealer.
²The compass may not indicate the correct compass
point in the places shown below:
²Vehicles in tunnels or parked in buildings
²Expressways, near railroads, underneath railroad
cables, or over subways
²Near transformer stations or high voltage power
lines
In these cases, the correct direction will be displayed once
the vehicle returns to a place where the earth's magnetic
field is stable.
D11C0690
186 STARTING AND DRIVING

To calibrate the compassIf the display reads ªCALº (A), there may be a strong
magnetic field interfering with the compass. In this case,
the compass may need calibration.
If the ªCALº is displayed, drive the vehicle in a circle at
about 5 mph (8km/h) or less until the ªCALº goes off.
I08A0650
D11C0110
STARTING AND DRIVING 187
5

If the ªCALº is not displayed, but compass calibration is
required, press and hold the display switch for 12 sec-
onds, or until ªCALº is displayed. With ªCALº dis-
played, drive the vehicle in a circle at less than 5mph
(8km/h) or less until the ªCALº goes off.
Cleaning of the mirror
When cleaning the mirror, use a paper towel or similar
material dampened with glass cleaner. Do not spray glass
cleaner directly on the mirror as that may cause the liquid
cleaner to enter the mirror housing.
Electric remote-controlled outside mirrors
The outside rearview mirrors can be adjusted when the
ignition key is in the ªONº or ªACCº position.
Place the lever to the same side as the mirror whose
adjustment is desired:
L - Left outside mirror adjustment
R - Right outside mirror adjustment
I08B2160
188 STARTING AND DRIVING

NOTE
²
After adjustment, return the lever to the centered
position.
Press the left, right, up or down switches to adjust the
mirrors as desired.
1. Up
2. Down
3. Right
4. Left
CRUISE/SPEED CONTROL
Cruise/speed control is an automatic speed control sys-
tem. It lets you keep the same driving speed. Cruise/
speed control can be used at 25mph (40km/h) or more. It
is especially useful for freeway driving. Cruise/speed
control does not work at speeds below about 25mph
(40km/h).
A-Main switch
B-Cruise/speed control lever
I10A1190
STARTING AND DRIVING 189
5

CAUTION!
²For safety reasons, the main switch (A) should be
set to the OFF position when you are not using the
cruise/speed control system.
²Cruise/speed control is not recommended when
driving conditions will not allow you to stay at the
same speed, such as in heavy traffic or on roads
that are winding, icy, snow-covered, wet, or slip-
pery, or on a steep downhill.
²For vehicles with manual transaxles, if you shift to
ªNº (Neutral) in cruise/speed control mode with-
out pressing the clutch first, the engine will run
too fast and might be damaged.
NOTE
²
Cruise/speed control may not be able to keep your
speed on uphills or downhills.
²Your speed may drop on a steep uphill. You must
use the accelerator if you want to stay at your set
speed.
²Your speed may increase to more than the set speed
on a steep downhill. You must use the brake to
control your speed. If your speed increases too
much, turn off the cruise/speed control. (Refer to
the section ªTo deactivateº on page 192.)
To activate
1. Momentarily push in the main switch (A) at the end of
the cruise/speed control lever.
I10A1490
