DODGE STRATUS COUPE 2005 2.G Owners Manual

working properly. The SRS warning light is shared by the
driver 's air bag, the front passenger 's air bag, and the
optional side air bags.
The air bags will operate only when the ignition switch is
in the ``ON'' or ``START'' position
WARNING!
²If any of the following conditions occur, the SRS
is not working properly and you should immedi-
ately have it inspected by an authorized dealer;
²The SRS warning light does not illuminate
when you start the vehicle.
²The SRS warning light does not go out after
several seconds.
²The SRS warning light comes on while driving.
SRS servicing
The entire SRS must be inspected by an authorized dealer
10 years after the vehicle's manufacture date as shown on
the certification label located on the center pillar of the
vehicle, on the driver's side.
WARNING!
²Any maintenance performed on or near the com-
ponents of the SRS should be performed only by
an authorized dealer. Do not permit anyone else to
do service, inspection, maintenance or repair on
any SRS components or wiring. Similarly, no part
of the SRS should ever be handled, removed or
disposed of by anyone except at an authorized
dealer.
Improper work on the SRS components or wiring
could result in an accidental air bag deployment
or could make the SRS inoperative. Either of these
situation could result in serious injury.
²Do not modify your steering wheel or any other SRS
components or related vehicle part. For example,
replacement of the steering wheel, or modifications
to the front bumper or body structure can negatively
affect SRS performance and may lead to possible
injury.
²If your vehicle has received any front-end dam-
age, you should have the SRS inspected by an
authorized dealer to make sure it is in proper
working order.
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 101
3

WARNING!
²On vehicles with side air bags, do not modify
your front seats, center pillar or center console.
Such modifications can adversely affect SRS per-
formance and may lead to possible injury.
Also, if you discover any tear or open seam in the
seat fabric near the side air bag, have the seat
inspected by an authorized dealer.
²On vehicles with side air bags, if your vehicle has
received any damage on either side, you should
have the SRS inspected by an authorized dealer to
make sure it is in proper working order.
NOTE:
²
When you transfer ownership of the vehicle to another
person, we urge you to alert the new owner that it is
equipped with the SRS and refer that owner to the
applicable sections in this owner 's manual.
²If you decide to junk or scrap your vehicle, we urge
you to first take it to an authorized dealer so that the
SRS can be made safe for disposal.
Caution label
Passenger restraint warning/caution labels for the SRS
are located in the vehicle as shown in the illustration.
102 SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS

Transporting Pets
Airbags deploying in the front seat could harm your pet.
An unrestrained pet will be thrown about and possibly
injured, or injure a passenger during panic braking or in
a collision.
Pets should be restrained in the rear seat in pet harnesses
or pet carriers that are secured by seat belts.
SEATS, SEAT BELTS, CHILD RESTRAINTS AND AIR BAGS 103
3

INSTRUMENTS AND CONTROLS
CONTENTS
mInstrument cluster......................108
NMeter cluster.........................108
NIndicator and warning light package........109
NSpeedometer.........................110
NTachometer..........................110
NFuel gauge..........................111
NOdometer/Trip odometer................112
NEngine coolant temperature gauge..........113
NTurn signal indicators/hazard warning lights . . 114
NHigh beam indicator...................114
NTheft-alarm indicator...................114
NDoor-ajar warning light and chime.........114NAnti-lock braking system warning light
(if so equipped).......................115
NCruise/speed control indicator............115
NLow-fuel warning light and chime..........115
NFront fog light indicator (if so equipped).....116
NCharging system warning light............116
NOil pressure warning light...............116
NMalfunction indicator light
(SERVICE ENGINE SOON)...............117
NSupplemental Restraint System (SRS)-air bag
warning light.........................118
NBrake warning light....................119
NSeat belt reminder/warning light...........120
4

NChanging the setting for warning operation . . . 120
NAutomatic transaxle indicator
(if so equipped).......................121
NTraction Control System warning light
(if so equipped).......................121
NWasher fluid level indicator..............121
mCombination headlights, dimmer and
turn signal lever
.......................122
NHeadlights..........................122
NLight auto-cutout feature
(headlights, fog lights, etc.)...............122
NWhen you want to keep the lights on
(time delay)..........................122
NHeadlight reminder chime...............123
NHeadlight flasher (high/low beam).........123
NDimmer (high/low beam change)..........124
NTurn signals..........................124
mFog light switch (if so equipped)...........125
mHazard warning flasher switch............126
mInstrument panel light dimmer control.......127
mElectric rear window defroster.............127
mWindshield wipers......................128
mIntermittent wipers.....................129
mWindshield washer.....................130
mPrecautions to observe when using wipers
and washers
..........................130
mDome light...........................131
mLights (dome lights, etc.) auto-cutout
function
.............................132
mReading lights.........................133
mRear personal lights.....................134
mHorn switch..........................134
mGarage door opener (if so equipped)........134
NTraining the Universal Transceiver..........135
106 INSTRUMENTS AND CONTROLS

NCanadian Programming/Gate Programming . . . 137
NOperation...........................138NReprogramming a Signal Button...........139
INSTRUMENTS AND CONTROLS 107
4

INSTRUMENT CLUSTER
Meter cluster
1. Fuel gauge
2. Tachometer
3. Speedometer
4. Engine coolant temperature gauge
5. Odometer6. Trip odometer
7. Trip odometer reset button
D01A2700
108 INSTRUMENTS AND CONTROLS

Indicator and warning light package
1. Washer fluid level indicator!P. 121
2. Anti-lock braking system warning light
(if so equipped)!P. 1 1 5
3. Low-fuel warning light!P. 1 1 5
4. Brake warning light!P. 1 1 95. Supplemental Restraint System (SRS) - air bag
warning light!P. 1 1 8
6. Seat belt reminder/warning light!P. 120
7. Turn signal indicators/hazard warning light!P. 1 1 4
8. Trunk-ajar warning light!P115
9. Front fog light indicator!P. 1 1 6
10. Door-ajar warning light!P. 1 1 4
D50A439D
INSTRUMENTS AND CONTROLS 109
4

11. High beam indicator!P. 1 1 4
12. Cruise control indicator!P. 1 1 5
13. Theft-alarm indicator!P. 1 1 4
14. Malfunction indicator light
(SERVICE ENGINE SOON)!P. 1 1 7
15. Oil pressure warning light!P. 1 1 6
16. Charging system warning light!P. 1 1 6
17. Overheating warning light!P. 1 1 8
18. Traction control system warning light
(if so equipped)!P. 121
19. Automatic transaxle indicator
(Vehicles with Autostick automatic transaxle-if so
equipped)!P. 121
Speedometer
The speedometer indicates vehicle speed.
·The outer scale indicates miles per hour.
·The inner scale indicates kilometers per hour.
Tachometer
The tachometer indicates engine revolutions per minute.
This allows the driver to determine the most efficient
gear range and engine speed combinations.
D04A0500
2.4 liter
engine3.0 liter
engine
110 INSTRUMENTS AND CONTROLS
