DODGE VIPER 2004 ZB / 2.G Owner's Manual

4. The Security light will periodically flash, once every 6
seconds, to show that the system is still armed.
CAUTION!
If the Security lamp flashes twice every 6 seconds,
then the vehicle was tampered with!
Entering the Trunk with the System Armed
To enter the trunk with the system armed, the Remote
Keyless Entry Trunk button must be pressed. This will
pop the trunk open and allow access without alarming or
disarming the Vehicle Theft Alarm System.
NOTE:If the key is used and the system is armed, then
the Vehicle Theft Alarm System will start alarming.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21
2

Security System Disarm
There are two ways to disarm the system:
1. Driver door key cylinder: Insert the key in the cylinder
located under the driver's door mirror. This will disarm
the Vehicle Theft Alarm System and open the driver's
door.2. Or, press the UNLOCK button on the Remote Keyless
Entry transmitter. The front and rear park and turn signal
lights will flash to acknowledge the signal. (See the
Remote Keyless Entry Section of this manual for opera-
tion)
NOTE:The vehicle will not start unless the Vehicle
Theft Alarm System is disarmed by either of the two
methods above. Inserting the key in the ignition WILL
NOT disarm the system (it will start the alarming pro-
cess!)
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Tamper Alert
If the horn sounds 3 times when you unlock the vehicle
using the Remote Keyless Entry transmitter or key, the
alarm has been activated. Check the vehicle for tamper-
ing.
NOTE:If the Security lamp flashes twice every 6
seconds, then the vehicle was tampered with.
WINDOWS
Power Windows
The power window switches are located between the
driver and passenger seats on the center tunnel bezel, just
to the left of the parking brake. The switch on the left side
controls the driver's window and the switch on the right
controls the passenger's window. The power window
switches are active when the ignition is in RUN or
ACCESSORY.The power window switch also works during accessory
delay. This delay feature will allow the windows to be
functional up to 2 minutes after the vehicle has been
turned off. This feature can be disabled at the dealership
if desired.
NOTE:Windows cannot be driven up during accessory
delay with a door open.
NOTE:If the windows are completely closed, each
respective window will drop slightly when either door is
opened. The windows return to their full up position
when the door is again closed. This is necessary to clear
the seal when either door is opened.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23
2

Auto Down Feature
Both windows have an auto down feature. Press the
window switch to the second detent, release, and the
window will go down automatically. Press the switch a
second time in either direction to stop the window.To open the window to a desired positon, press and hold
the window switch in the first detent until the window
has reached the desired position and then release it when
you want the window to stop.
Power Accessory Delay Feature
The Power Accessory Delay feature provides the cus-
tomer with the ability to operate the power windows,
and the radio for 2 minutes after the ignition switch is
turned off. If the key is removed from the ignition and the
driver door is opened prior to the completion of the
2±minute timer, the feature is immediately cancelled. The
Power Accessory Delay feature is initially enabled, but
may be enabled or disabled at the dealership.
NOTE:The Window Up switch will not function with
the door open and while the system is in the Power
Accessory Delay mode. If the window is in the process of
going up, opening the door will stop the window move-
ment immediately.
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

Wind Buffeting
Wind buffeting can be described as the perception of
pressure on the ears or a helicopter-type sound in the
ears. Your vehicle may exhibit wind buffeting with the
windows down, or the top down. This is a normal
occurrence and can be minimized.
TRUNK SAFETY WARNING
WARNING!
Do not allow children to have access to the trunk,
either by climbing into the trunk from outside, or
through the inside of the vehicle. Always close the
trunk lid when your vehicle is unattended. Once in
the trunk, young children may not be able to escape.
If trapped in the trunk, children can die from suffo-
cation or heat stroke.
Trunk Internal Emergency Release
NOTE:As a security measure, a Trunk Internal Emer-
gency Release lever is built into the trunk latching
mechanism. In the event of an individual being locked
inside the trunk, the trunk can simply be opened by
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25
2

pulling on the lever attached to the trunk latching
mechanism, which is coated so that it glows in a dark-
ened trunk.
OCCUPANT RESTRAINTS
One of the most important safety features in your Viper
is the restraint system. This system consists of the driv-
er's and passenger's seat belts, airbags for the driver and
passenger, and a passenger airbag on/off switch located
in the center console compartment for deactivating the
passenger airbag system.
Please pay close attention to the information in this
section. It tells you how to use your restraint system
properly to keep you and your passenger as safe as
possible. Whichever system you have, all of the warnings
in this section apply.
WARNING!
In a collision, you and your passenger can suffer
much greater injuries if you are not properly buck-
led up. You can strike parts of the inside of your
vehicle or your passenger, or you can be thrown out
of the vehicle. Always be sure you and your passen-
ger are buckled up properly.
Buckle up even though you are an excellent driver. Even
on short trips. Someone on the road may be a poor driver
and cause a collision that includes you. And this can
happen far away from home or on your street.
Research has shown that seat belts save lives. They also
can reduce the seriousness of injuries in a collision. Some
of the worst injuries happen when people are thrown
from the vehicle. Seat belts provide protection against
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

that, and they reduce the risk of injury caused by striking
the inside of the vehicle. Everyone in a motor vehicle
needs to be buckled up all the time.
Lap/Shoulder Belts
Each seat belt is a combined lap/shoulder belt system.
The belt webbing retractor will lock only during very
sudden stops or impacts. This feature allows the shoulder
part of the belt to move freely with you under normal
conditions. But, in a collision, the belt will lock and
reduce the risk of your striking the inside of the vehicle or
being thrown out.
WARNING!
Wearing a seat belt incorrectly is dangerous. Seat
belts are designed to go around the large bones of
your body. These are the strongest parts of your body
and can take the forces of a collision the best.
Wearing your belt in the wrong place could make
your injuries in a collision much worse. You might
suffer internal injuries, or you could even slide out
of part of the belt. Follow these instructions to wear
your seat belt safely and to keep your passengers
safe, too.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27
2

Lap/Shoulder Belt Operating Instructions
1. Enter the vehicle and close the door. Sit back and
adjust the seat.
2. The seat belt latch plate is located at the side of your
seat back. Grasp the latch plate and pull out the belt.3. Slide the latch plate up the webbing as far as necessary
to make the belt go around your lap.
4. When the belt is long enough to fit, insert the latch
plate into the buckle until you hear a ªclick.º
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE

WARNING!
A belt that is too loose will not protect you as well. In
a sudden stop you could move too far forward,
increasing the possibility of injury. Wear your seat
belt snugly.
A belt that is worn under your arm is very danger-
ous. Your body could fall into the inside surfaces of
the vehicle in a collision, increasing head and neck
injury. And a belt worn under the arm can cause
internal injuries. Ribs aren't as strong as shoulder
bones. Wear the belt over your shoulder so that your
strongest bones will take the force in a collision.
5. Position the lap belt across your thighs, below your
abdomen. To remove slack in the lap belt portion, pull up
a little on the shoulder belt, as shown.6. To loosen the lap belt if it is too tight, tilt the latch plate
and pull on the lap belt. A snug belt reduces the risk of
sliding under the belt in a collision.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29
2

WARNING!
A lap belt worn too high can increase the risk of
internal injury in a collision. The belt forces won't
be at the strong hip and pelvic bones, but across your
abdomen. Always wear the lap belt as low as pos-
sible and keep it snug.
7. Position the shoulder belt on your chest so that it is
comfortable and not resting on your neck. The retractor
will withdraw any slack in the belt.
WARNING!
A twisted belt can't do its job as well. In a collision
it could even cut into you. Be sure the belt is straight.
If you can't straighten a belt in your vehicle, take it
to your dealer and have it fixed.
8. To release the belt, push the red button marked PRESS
on the buckle. The belt will automatically retract to its
stowed position. If necessary, slide the latch plate down
the webbing to allow it to retract fully.
Enhanced Driver Seat Belt Reminder System
(BeltAlertŸ)
If the driver's seat belt has not been buckled within 60
seconds of starting the vehicle and if the vehicle speed is
greater than 5 mph (8 km/h), the Enhanced Warning
System (BeltAlertŸ) will alert the driver to buckle their
seat belt. The driver should also instruct all other occu-
pants to buckle their seat belts. Once the warning is
triggered, the Enhanced Warning System (BeltAlertŸ)
will continue to chime and flash the Seat Belt Warning
Light for 96 seconds or until the driver's seat belt is
buckled. The Enhanced Warning System (BeltAlertŸ)
will be reactivated if the driver's seat belt is unbuckled
for more than 10 seconds and the vehicle speed is greater
than 5 mph (8 km/h).
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
