The Enhanced Warning System (BeltAlertŸ) can be en-
abled or disabled by your authorized dealer or by
following these steps:
NOTE:The following steps must occur within the first
60 seconds of the ignition switch being turned to the ON
or START position. DaimlerChrysler does not recom-
mend deactivating the Enhanced Warning System
(BeltAlert).
1. Turn the ignition switch to the OFF position and
buckle the driver's seat belt.
2. Start the engine and wait for the Seat Belt Warning
Light to turn off.
3. Within 60 seconds of starting the vehicle, unbuckle
and then re-buckle the driver's seat belt at least three
times within 10 seconds, ending with the seat belt
buckled.4. Turn off the engine. A single chime will sound to
signify that you have successfully completed the pro-
gramming.
The Enhanced Warning System (BeltAlertŸ) can be reac-
tivated by repeating this procedure.
NOTE:Although the Enhanced Warning System (BeltA-
lertŸ) has been deactivated, the Seat Belt Warning Light
will continue to illuminate while the driver's seat belt
remains unbuckled.
Six Point Belt System - If equipped
This six point belt system meets SCCA standards and
should be only used when engaged in related perfor-
mance driving events. The standard lap/shoulder belt
should be used whenever the vehicle is operated on the
street.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31
2
Page 32 of 236
Six Point Belt Operating Instructions
With the anti-submarining belt placed on the seat point-
ing up, buckle the left and right lap belts and strap both
legs. Buckle the left and right shoulder belts. Adjust the
belts by pulling on the web ends and/or re-positioning
the web clips and straps as required. Release the belts by
turning the belt latch mechanism
1¤4turn in either the
clockwise or counter-clockwise direction.
NOTE:The anti-submarining belt and the shoulder belt
are attached to eye bolts at designated locations and
should be removed from the vehicle when not in use. The
lap belts and straps can be stored behind or to the sides
of the seat after removal.
Seat Belts and Pregnant Women
We recommend that pregnant women use the seat belts
throughout their pregnancy. Keeping the mother safe is
the best way to keep the baby safe.
Pregnant women should wear the lap part of the belt
across the thighs and as snug across the hips as possible.
Keep the belt low so that it does not come across the
abdomen. That way the strong bones of the hips will take
the force if there is a collision.
Seat Belt Extender
If a seat belt is too short, even when fully extended, your
dealer can provide you with a seat belt extender. This
extender should be used only if the existing belt is not
long enough.
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 33 of 236
WARNING!
A frayed or torn belt could rip apart in a collision
and leave you with no protection. Inspect the belt
system periodically, checking for cuts, frays, or loose
parts. Damaged parts must be replaced immediately.
Do not disassemble or modify the system. Seat belt
assemblies must be replaced after an accident if they
have been damaged (bent retractor, torn webbing,
etc.)
Child Restraint
Everyone in your vehicle needs to be buckled up all the
time, babies and children, too.
WARNING!
In a collision, an unrestrained child, even a tiny
baby, can become a missile inside the vehicle. The
force required to hold even an infant on your lap
could become so great that you could not hold the
child, no matter how strong you are. The child and
others could be badly injured. Any child riding in
your vehicle should be in a proper restraint for the
child's size.
All states and Canadian provinces require small
children to ride in proper restraint systems. This is
the law, and you can be prosecuted for ignoring it.
Infants and Small Children
There are two different sizes and types of restraints for
children from newborn size to the bigger child almost
large enough for an adult seat belt. Always check the
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33
2
Page 34 of 236
child seat owner's manual to ensure you have the right
seat for your child. Use the restraint system that is correct
for your child.
Two different child restraint systems are generally avail-
able:
²The infant carrier for babies weighing up to approxi-
mately 20 lbs. (9 kg).
²The child seat for small children over 20 lbs. (9kg).
WARNING!
A rearward facing infant restraint must not be used
in your Viper unless the passenger airbag has been
shut off. A rearward facing infant restraint may be
struck by a deploying passenger airbag which may
cause severe or fatal injury to the infant.
In addition, some manufacturers make systems that can
be first used as an infant carrier, then converted to a child
seat as the child grows.
Here are some tips on getting the most out of your child
restraint.
Before buying any restraint system, make sure that it has
a label certifying that it meets Motor Vehicle Safety
Standard 213. The manufacturer also recommends that
before you buy a child restraint, you try it in the seat
where you will use it.
The restraint must be appropriate for your child's weight
and height. Check the label on the restraint for this too.
Carefully follow the instructions that came with the
restraint. If you install the restraint improperly, it may not
work when you need it.
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 35 of 236
WARNING!
Improper installation can lead to failure of a child
restraint. It could come loose in a collision. The child
could be badly injured or killed. Follow the manu-
facturer's directions exactly when installing a child
restraint.
²Child restraints are secured in the passenger seat by
the lap part of the lap/shoulder belt.
Buckle the child into the seat exactly as the child seat
manufacturer's directions tell you. The cinching latch
plate on the lap/shoulder belt will keep the belt tight.
When your infant carrier or child seat is not in use, secure
it with the seat belt or remove it from the vehicle. Don't
leave it loose in the vehicle. In a sudden stop or collision,
it could strike occupants and injure them.
LATCH Ð Lower Anchors and Tether for CHildren
Your vehicle's passenger seat is equipped with the child
restraint anchorage system called LATCH, which stands
for Lower Anchors and Tether for Children. The LATCH
system provides for the installation of the child restraint
without using the vehicle seat belt. The passenger seat
has an exclusive lower anchorage.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35
2
Page 36 of 236
These are round bars, located at the lower area of the seat
back, one on each side of the passenger seat. You will
easily feel them if you run your finger along the inter-
section of the surface. Install your child seat as per child
seat manufacturer recommendations.
NOTE:If your child restraint seat is not LATCH com-
patible, install the restraint using the vehicle seat belts.
Child Restraint Tether Anchor
Child restraints having tether straps and hooks for con-
nection to tether anchors have been available for some
time. In fact, many child restraint manufacturers will
provide add-on tether strap kits for some of their older
products. There is a tether strap anchor located in the
child tether access cover behind the passenger seat.
Remove the child tether access cover by prying either
side with a screwdriver or similar tool, as shown inillustration which follows. While the child tether is in
use, keep the access cover in a safe place so that it can be
replaced after use of the child tether.
To attach the tether strap to the anchor, move the
seatback fully forward. Pass the child restraint tether
hook through either opening in the seatback under the
head restraint. Attach the tether hook to the anchor loop,
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 37 of 236
recline the seatback full rearward and move the seat to its
most rearward position. Install the child restraint accord-
ing to the manufacturer's directions. Return the seatback
to an upright position. Remove slack from the tether
strap according to the child restraint manufacturer's
directions.WARNING!
An incorrectly anchored tether strap could lead to
increased head motion and possible injury to the
child. Use only the anchor position directly behind
the child seat to secure a child restraint top tether
strap.
Children Too Large For Child Seats
Children who are too large for child seats and who can sit
upright by themselves should use the lap/shoulder belt
for best protection.
²Make sure that the child is seated upright in the seat.
²The lap belt should be low on the hips and as snug as
possible.
²Check belt fit periodically. A child's squirming or
slouching can move the belt out of position.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37
2
Page 38 of 236
²If the shoulder belt contacts the face or neck, move the
child closer to the side of the vehicle.
Booster seats that may help overcome this problem are
also available for use with lap/shoulder belts. Before
buying a booster seat, make sure that it has a label
certifying that it meets applicable Motor Vehicle Safety
Standards. Make sure that it is satisfactory for use in this
vehicle.
Supplemental Restraint System (SRS) - Airbag
This vehicle has airbags for the driver and passenger as a
supplement to the seat belt restraint systems. The driver's
airbag is mounted in the steering wheel. The passenger
side airbag is mounted in the instrument panel, under a
cover marked SRS/AIRBAG. These airbags inflate in
higher speed impacts. They work with the instrument
panel knee bolsters and the seat belts to provide im-
proved protection for the driver and right front passen-
ger.
WARNING!
²Relying on the airbags alone could lead to more
severe injuries in a collision. The airbags work
with your seat belt to restrain you properly. In
some collisions the airbags won't deploy at all.
Wear your seat belts even though you have air-
bags.
²Being too close to the steering wheel or instru-
ment panel during airbag deployment could cause
serious injury. Airbags need room to inflate. Sit
back, comfortably extending your arms to reach
the steering wheel or instrument panel.
The seat belts are designed to protect you in many types
of collisions. The airbags deploy only in frontal collisions
and will not deploy in collisions at slow speed. But even
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
Page 39 of 236
in collisions where the airbags deploy, you need the seat
belts to keep you in the right position for the airbags to
protect you properly.
Here are four simple steps you can take to minimize the
risk of harm from a deploying airbag.
1.Infants in rear facing child safety seats designed for
children up to one year or approximately 20 pounds (9
kg) should never ride in the front seat of a vehicle with
a passenger side airbag unless the airbag is shut OFF.
See ªPassenger Side Airbag On/Off Switch.º An airbag
deployment can cause severe injury or death to infants in
this position.
Children that are not big enough to properly wear the
vehicle seat belt (see section on ªChild Restraintº) should
be secured in child safety seats or booster seats.
Older children who do not use child safety seats or
booster seats should ride properly buckled.Never allow children to place the shoulder belt behind
them or under the arm.
Infants up to 1 year or approximately 20 pounds (9 kg)
should never ride in the vehicle, because the rear facing
child seat places them too close to the passenger air bag
in the event of a crash.
Children from 1 to 12 years old: Move the passenger seat
as far back as possible. Children from 20 to 60 pounds (9
kg to 27 kg) should be secured in the appropriate child
safety seat or booster seat. If too large for a booster seat,
the child should wear the lap/shoulder belt properly.
Children should never be allowed to lean forward to-
ward the instrument panel as a passenger air bag deploy-
ment could cause severe injury or death to a child in this
position.
You should read the instructions provided with your
child restraint to make sure that you are using it properly.
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39
2
Page 40 of 236
2.All occupants should wear their lap and shoulder
belts properly.
3.The driver and passenger seats should be moved
back as far as practical to allow the airbags room to
inflate. Additionally, the pedals are power adjustable,
so the driver seat can be moved back and the pedals
moved closer as needed so the driver can be as far from
the airbag as possible. (See section on Power Adjust-
able Pedals for operation.)
4.You should read the instructions provided with your
child safety or booster seat to make sure that you are
using it properly.
The airbag system consists of the following:
²Airbag control module and internal crash sensor
²AIRBAG Readiness Light
²Driver and Passenger Airbag/inflator Units
²Passenger Side Airbag On/Off Switch
²Passenger Airbag Off Indicator Light
²Unique Steering Wheel and Column
²Unique Instrument Panel
²Interconnecting Wiring
²Knee Impact Bolster
How The Airbag System Works
²
A crash sensor in the occupant compartment deter-
mines if a frontal impact is severe enough to require
the airbag. The sensor will not detect side, roll over, or
rear impacts. The crash sensor is connected to the
diagnostic unit and to the airbag/inflator unit.
²The Diagnostic Unit monitors the readiness of the
electronic parts of the system whenever the ignition
switch is in the START or RUN position. These include
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
