CONVERTIBLE TOP OPERATION
To Raise the Top:
1. To raise the convertible top, first ensure that the door
windows are lowered at least an inch.
2. Then open the trunk.
3. Release the lever located behind the driver's seat and
nestled in the folded convertible top (as pictured). To aid
in disengaging the latch, press down on the convertible
top while pressing on the latch lever.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 51
3

4. Manually raise the top until it meets the windshield
header (as pictured).
5. Close the trunk.6. While sitting inside the vehicle, hold onto the handles
and pull the top towards the windshield header. Push the
latch handle forward and engage the latch hook to the
windshield receiver rod.
52 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

7. Ensure the outboard locating pins are in their respec-
tive receiving holes in the windshield header. Push the
latch handle forward all the way to close the latch.
NOTE:Until the convertible top system has had ad-
equate time to break in, it may take greater effort to
engage the latch hook and close the latch. Several weeks
of normal convertible top usage will reduce these efforts.To Lower the Top:
1. To lower the top, first ensure that the door windows
are lowered at least an inch.
2. Depress the button at the top of the latch upwards and
then pull the handle down and rearward, towards you.
(See the picture shown)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 53
3

3. Disengage the latch hook from the windshield rod
making sure to pull the latch all the way back to the
detent stow position and pull the top away from the
windshield header.
4. Open the trunk.
5. Pull the convertible top back away from the wind-
shield and all the way back to the folded position into the
storage well to the back of the seating positions. Push the
leading edge of the top down to engage the downstack
latch.
6. Finally lower and close the trunk.CONSOLE FEATURES
The front console has a removable ashtray, power outlet/
cigarette lighter and power window switches.
The center console compartment is equipped with a
cigarette lighter/power outlet and a passenger airbag
on/off switch.
54 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

MIRRORS
Inside Day/Night Mirror
Adjust the mirror to center on the view through the rear
window. A pivot system allows for horizontal and verti-
cal mirror adjustment.
Annoying headlight glare can be reduced by moving the
small control under the mirror to the night position(toward rear of vehicle). The mirror should be adjusted
while set in the day position (toward windshield).Electric Remote Control Mirrors
Both of the outside mirrors can be adjusted by using the
remote controls mounted inside the driver's door, below
the door handle and power door switch.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 55
3

NOTE:Place the mirror selector switch in the center
(neutral) position to prevent accidental movement of the
mirrors.
Mirror Adjustment
Outside Mirror Ð Driver's Side
Adjust the outside mirror to center on the adjacent lane of
traffic, with a slight overlap of the view obtained on the
inside mirror.
Right Side Mirror
Adjust the convex outside mirror so you can just see the
side of your vehicle. This type of mirror will give a much
wider view to the rear, and especially of the lane next to
your vehicle.
WARNING!
Vehicles and other objects seen in the right side
convex mirror will look smaller and farther away
than they really are. Relying too much on your right
side mirror could cause you to collide with another
vehicle or other object. Use your inside mirror when
judging the size or distance of a vehicle seen in this
convex mirror.
56 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

SEATS
Manual Front Seat Adjustments
The adjusting bar is at the front of the seats, near the floor.
Pull the bar up to move the seat to the desired position.
Using body pressure, move forward and rearward on the
seat to be sure the seat adjusters have latched.
WARNING!
Adjusting a seat while the vehicle is moving is
dangerous. If you are driving, the sudden movement
of the seat could cause you to lose control. You could
be injured. Adjust any seat only while the vehicle is
parked. Do not ride with the seatback reclined so
that the shoulder belt is no longer riding against
your chest. In a collision you could slide under the
seat belt and be seriously or even fatally injured. Use
the recliner only when the vehicle is parked.
Reclining Seat
The recliner control is on the side of the seat on the
door-side. To recline, lean forward slightly before pulling
the lever, then lean back to the desired position, and
release the lever. Lean forward and pull the lever to
return the seatback to its original position.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 57
3

To Open And Close The Hood
Two latches must be released to open the hood. First,
reach into the lower right grille opening and pull the
primary hood latch forward. Raise the front of the hood
slightly for access to the safety catch.Then push the safety catch handle located under the front
edge of the hood toward the right. Raise the front of the
hood.
NOTE:Assist props will raise the hood to a normal
customer usage position. If greater access is required, the
58 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

hood may be pushed up at the front, raising the hood
beyond the initial opening height. Simply pull the hood
down to close it.
CAUTION!
Do not leave the hood open in areas where strong
gusts of wind are likely. Such a place might be by the
side of the road where large trucks pass by. Strong
gusts of wind may damage your hood. Always close
the hood in such situations.
WARNING!
If the hood is not fully latched, it could open when
the vehicle is moving and block your forward vision.
Be sure the hood latches are fully latched before
driving.
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 59
3

LIGHTS
Courtesy/Reading Lights
These lights, located under the rearview mirror, come on
whenever a door is opened or the illuminated entry
system is activated. The lights can also be turned on with
the doors closed by means of switches located on the
bottom of the rearview mirror. These lights also function
by rotating the dimmer control in the multi-function
control lever.
There are also courtesy lights located in both the driver
and passenger footwell areas. They will turn on as part of
the illuminated entry system by either opening a door,
unlocking the door from the remote keyless entry, or by
the multi-function control lever dimmer control.
