navigation FIAT CROMA 2009 2.G Instant Navigation Manual

33
INSTANT NAV
Insert address
By selecting this item it is possible to en-
ter the name of the Country, the town,
the road and the house number (fig. 15).
The system will then ask you to set the
navigation criteria. Choose one of the fol-
lowing three possibilities:
– “Shortest route”
– “Quickest route”
– Best “distance/time” ratio
To exit the screen, press the
Nbutton
or insert the SD card in the special slot.
If the SD card has not been inserted or
is not recognized, the display will show a
warning message.Destination address
“Country” selection
After having selected the “Country”
item, the display will show a list of coun-
tries, in English. Turn the OK button/knob
to scroll through the list and then press
the button/knob to confirm the selection.“City” selection
After having selected the “City” item, the
display will show a keypad with numbers
and letters (fig. 16) for entering the name
of the town. The following items are also
present in the lower part:
– Delete: this allows you to delete the
last character entered;
– Small: this allows you to change the let-
ter (Upper-case/Lower-case) and select
special symbols;
– List XX: the list of cities in a country
is displayed (XX = number of the city);
– OK: this allows you to confirm the se-
lection and return to the screen activated
previously.
fig. 15F0L5007gfig. 16F0L5033g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 33

34
INSTANT NAV
“Road” selection
After having selected the “Road” item,
the display will show a keypad with num-
bers and letters for entering the name of
the road. The procedure for entering the
road is the same as described for the city.
After having entered the name of the
road the display will show a screen for en-
tering the civic number or the crossroad
(fig. 17). Select the desired choice using
the OK button/knob. When the “Civic nº”
is selected, the Instant Nav will display the
available house numbers in that road. If,
on the other hand, you select the item
“Crossroad”, the Instant Nav will display
a list of roads that intersect the destina-
tion selected“Centre” selection
If you want to get to a town centre, se-
lect the item Centre. If there is more than
one centre present, the display will show
a list of available centres.
After entering all the information for the
address, select “Save” to save the address
under “Personal destinations”. The Instant
Nav will display the position in the “Per-
sonal destinations” memory for a few sec-
onds.POI (Points of Interest)
This function makes it possible to access
a list with information and the location of
places of general interest, such as, for ex-
ample, restaurants, museums, stations,
etc., divided by category.
Select “POI”: the display will show the
following screen (fig. 18):
The first 3 items are alternatives and are
designed to specify whether the point of
interest being searched for is located:
– “Near”: destination entered or place
selected on the map
– “Along the route”: along the navigation
route
– “Near by”: in the locality of the cur-
rent position
– “Search by name”: since the list of POI
is normally displayed in order of increas-
ing distance. By selecting this item, the
POI are displayed in alphabetical order.
fig. 17F0L5030gfig. 18F0L5034g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 34

36
INSTANT NAV
STOPS MANAGEMENT
This makes it possible to change the
route during navigation inserting stop-
overs.
The following items can be selected:
– “Add stop”
– “Organize stops”
– “Show destination”
Add stop
This makes it possible to add a stop-over
by selecting one of the following items:
– “Insert address”
– “Personal destinations”
– “Last destinations”
Organize stops
This makes it possible to organize the
stop-overs for the route: the order of
stop-overs entered can be changed and/or
removed.Show destination
This makes it possible to show details of
the destination set in the display. By se-
lecting “Modify” you return to the “En-
ter destination” menu.
By selecting “Map” the display will show
the map surrounding the current desti-
nation, full screen, which can be moved by
pressing the
N/O/
/buttons.INSERT DIVERSION
This allows a detour to be inserted into
the route set (fig. 21). In this case the sys-
tem will select an alternative way. The In-
stant Nav will search for the closest al-
ternative way and will calculate a new
route so that you rejoin the previous
route after X km (X is the value that you
can set on the screen).
A message will be displayed if no alter-
native roads are available.
If, on the other hand, alternative roads
are available, the display will show the new
distance from the destination. Select “Yes”
or “No” to confirm or cancel the new
route.
fig. 21F0L5046g
RIVOLI
TORINO
5km
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 36

38
INSTANT NAV
Hotels, restaurants, businesses
– Hotels
– Restaurants
– Wine producers, wineries
– Big companies
– Shopping, supermarkets
Culture, tourism, shows
– Tourism, historical monuments
– Culture, museums
– Casinos, night life
– Cinemas, theatres
– Shows, exhibitionsSports centres, attractions
– Sports centres
– Golf courses
– Skating, bowling
– Winter sport resorts
– Parks, gardens
– Theme parks
Transport & vehicles
– Airports, ports
– Train stations, bus stations
– Car hire
– Car parking, parking areas
– Mechanics, assistanceMap size
This makes it possible to change the map
display mode. It is possible to choose be-
tween “Full screen map” (full screen map
display) and “Navigation with info”.
Explore map
By selecting “Explore map” the full
screen map is displayed. When this screen
is activated, press the
N/O/
/but-
tons to scroll through the map.
NOTE Pressing the OK button/knob in
this mode displays the specific menu for
the map (fig. 24).
fig. 24F0L5020g
TORINO
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 38

39
INSTANT NAV
NAVIGATION OPTIONS
This makes it possible to change the fol-
lowing navigation parameters (fig. 25):
– “Set up calculation criteria”
– “Voice message volume”
– “Map information”
– “Delete last destinations” Set up calculation criteria
This makes it possible to select the fol-
lowing navigation parameters:
– “Quickest route”: the quickest route
for reaching the destination is displayed.
– “Shortest route”: the shortest route
for reaching the destination is displayed.
– “Distance/time”: this is the “average”
of the two previous items.
– “With tolls”: it is possible to define
whether or not the route should include
motorways.
– “With ferries”: it is possible to define
whether or not the route should include
ferries.
– “Traffic info (TMC)”: it is possible to
define whether the route should take in-
to account traffic information received
from the radio via the RDS-TMC/TMC
Premium service.Voice message volume
The voice instructions given by the sys-
tem guide you to the destination recom-
mending all the manoeuvres to be carried
out: the manoeuvre is announced first and
then detailed instructions are given.
By selecting the “Voice message volume”
item it is possible to adjust the volume of
these instructions.
Map information
This makes it possible to show the ver-
sion of the map on the display.
Delete last destinations
This makes it possible to delete the last
destinations entered. Select “Yes” or
“No”.
fig. 25F0L5019g
RIVOLI
TORINO
5km
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 39

40
INSTANT NAV
LAUNCH NAVIGATION
After having selected and confirmed a
destination, the display will show all the in-
formation needed for navigation.Map display with navigation
information
The display fig. 26 is divided into 3 zones:
– left zone (A): if no destination is se-
lected, the compass will be displayed. If
not, the navigation symbol will be dis-
played which can, for example, be a road
with an arrow or a junction detail. The
lower part of the left zone will display the
altimeter and the following navigation in-
formation;
– centre zone (B): displays the navi-
gation map and the scale;
– upper zone (C): displays information
relating to the Time, Audio and Temper-
ature.Full screen map display
The display fig. 27 is divided into 3 zones:
– upper zone: displays the destination;
– centre zone: displays the map and
navigation information;
– lower zone: displays the altimeter,
the current location and the scale.
fig. 26F0L5021ifig. 27F0L5022g
CORSO REGINA MARGHERITA
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 40

41
INSTANT NAV
SPECIFIC NAVIGATION MENU
It is possible to access the specific menu
from the Navigation application (by press-
ing the NAV button). The Menu displays
the following information fig. 28:
– “Select destination”
– “Full screen map/map with pictograms”
– “Resume/stop navigation”
– “Traffic info (TMC)”
– “Navigation options”
– “Explore map”. Select destination
See the description in the "Select desti-
nation" paragraph.
Full screen map/map with
navigation information
This makes it possible to move from the
full screen display of the map to a partial
display with navigation information and
vice versa.
Resume/stop navigation
This allows the navigation to be stopped/
resumed. Traffic Info (TMC/TMC Premium)
See the description in the “Traffic Info”
chapter.
CAUTION Traffic information can be
displayed only if the radio station
sets/sends messages next to the stated
point or along the route if a destination
has been entered.
Navigation options
See the description on previous pages.
Explore map
See the description on previous pages.
fig. 28F0L5403g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 41

42
INSTANT NAV
TRAFFIC INFORMATION
(TMC/TMC Premium)
Some stations on the FM band (FM1,
FM2 FM3 and FM
AST) can transmit infor-
mation about traffic conditions.
During navigation, information will be
shown through specific icons (see fig. 28a).
“Explore Map” from the Navigation
menu will bring up an overview of all traf-
fic events in the area of interest. For more
details on an individual event, move the
cursor over the desired icon, and press
OK.If the station selected does not broad-
cast traffic information, the display will
show a warning message and suggest the
option of moving to the automatic
TMC/TMC Premium station selection
mode.
IMPORTANTIn some countries there
are radio stations that do not broadcast
traffic information even with the TMC/
TMC Premium function activated.
Note
The TMC Premium Service is available in
Italy, France, Germany and the UK. Only
the radio navigators sold in one of these
countries are enabled to receive the ser-
vice.
TMC Premium is provided by:TMC/TMC Premium settings
Press the MENU button and select the
corresponding symbol.
The display will show the following
items:
– “Read messages”
– “Set up filters”
– “Select TMC station”
– “Message display on/off”
I I
N N
F F
O O
T T
R R
A A
F F
I I
C C
fig. 28aF0L5056g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 42

46
INSTANT NAV
INTRODUCTION
The trip computer provides a series of
information relating to the route (e.g.
time, distance, speed, fuel consumption).
Some of this information is only available
with the navigation function activated and
depends on the navigation route set.
IMPORTANTSome information/op-
erations described below are only possi-
ble/available with the ignition key in the
MAR position.
To access the main trip computer
screen, press the TRIP button.All the measurements are shown in the
display through symbols (see fig. 31).
By turning the OK button/knob it is pos-
sible to select information relating to:
– Trip A (by selecting the letter “A”) or
for Trip B (by selecting the letter “B”).
The display will show the following in-
formation:
– Route distance (km or miles)
– (*) Consumption (km/l, mpg or
l/100km)
– Average speed (km/h or mph)
– Journey time (hh:mm)
– Instant information (car symbol). The
display will show the following infor-
mation:
– (*) Range
– (*) Instant consumption
– Distance to the destination
(*) Note for LPG versions: please re-
fer to that reported in the specific sup-
plement.TRIP COMPUTER SPECIFIC
MENU
With the trip computer function acti-
vated it is possible to access the specific
Menu by pressing the OK button/knob.
The display will show the following screen
(fig. 32).
T T
R R
I I
P P
C C
O O
M M
P P
U U
T T
E E
R R
fig. 32F0L5015gfig. 31F0L5028g
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 46

53
INSTANT NAV
Show info on dashboard
By selecting this item it is possible to set
the repetition of the information relating
to the audio (radio) and Trip B in the in-
strument panel display.
By selecting the “Radio” item the fol-
lowing information will appear on the dis-
play:
– Audio source activated;
– Frequency (only in Radio mode);
– Radio station search (only in Radio
mode);
– Track number (only Audio CD, MP3
or Media Player);
– Disc number (only Audio CD, MP3 or
Media Player);
By selecting the item “Trip B” on the dis-
play or pressing the TRIP button on the
right steering column switch the Trip B in-
formation will appear.Select the "Navigation" item: the follow-
ing information will appear on the display:
– Distance remaining to the next ma-
noeuvre;
– Pictogram of the next manoeuvre (on-
ly if the car is on the navigation map and
a destination has been entered) or direc-
tion indication (if the car is not on the nav-
igation map and a destination has been en-
tered).
NOTE The "Navigation" item is only
present if the car is equipped with a re-
configurable multifunction display.Status day running lights (DRL)
(for versions/markets, where provided)
By selecting this item it is possible to ac-
tivate/deactivate the DRL (daytime run-
ning lights) function.
This adjustment is only possible if the
“Status day running lights” function has
been activated in the car Setup Menu (see
description in Owner Handbook).
Courtesy lights
(for versions/markets, where provided)
By selecting this item it is possible to ac-
tivate/deactivate the “Courtesy lights”
function.
Headlight sensitivity sensor
(for versions/markets, where provided)
By selecting this item it is possible to ad-
just the dusk sensor setting.
This adjustment is only possible if the car
is equipped with a dusk sensor.
603_97_471 CROMA_INSTANT NAV_GB_1ed 23-10-2009 15:29 Pagina 53
