sensor FIAT CROMA 2009 2.G Owner's Manual

187
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE CAR
IN AN
EMERGENCY
F 45
F 46
F 47
F 48
F 49
F 50
F 51
F 52
F 5320
20
20
20
7.5
7.5
7.5
15
10
USERSFUSE AMPERE
Sun roof engine control unit power supply
Sun roof visor engine control unit power supply
Front driver door node power supply (front driver power window)
Front passenger door node power supply (front passenger power window)
+15 volumetric sensor control unit for antitheft device, emergency control display
plaque lights / Blue-tooth and roof visor on roof panel / driver and passenger front
seat console, driver side control dashboard lights / tunnel, DVD player presetting,
electrochromic mirror, air conditioning
+15 airbag control unit
+15 Connect, Blue-tooth control unit, after market radio presetting, pneumatic
pressure control unit, cruise control, rain / twilight sensor control unit, parking
sensor control unit, AQS sensor
+15 excluded during ignition for electronic column switch module (rear window
wiper), relay coil on boot compartment control unit
+30 instrument panel
