58GETTING TO KNOW YOUR VEHICLE
Turn knob fig. 83 under the roof to
turn the supplementary climate control
system on. It will only work when the
main system is running.
Air flow is distributed to the back
through the directional vents set under
the roof by lever A-fig. 84.
Like for Panorama and Combi, also the
Van versions can be equipped with an
optional climate control system to be set
in the load compartment and to be
switched on using the relevant console
controls.AIR CONDITIONING
(COOLING)
Control settings for quick cooling:
1)air temperature knob: pointer at
the blue sector
2)climate control system: press but-
ton √
3)air recirculation slider: at Ò
4) air distribution knob: pointer at O
5)fan knob: pointer at the required
speed.To reduce the cooling effect: posi-
tion the slider at Ú, to increase the
temperature and decrease the fan
speed.
Do not switch the climate control
system on for heating and ventilation.
Use the ordinary heating and ventila-
tion system (see previous section).
IMPORTANT The climate control
system is very useful for clearing the
windows rapidly because it dries the
air. Simply set the controls for demist-
ing and turn the climate control sys-
tem on with button √.
ADDITIONAL HEATER
Certain versions feature, under the
driver’s seat, an additional heater us-
ing the same heating system controls.
fig. 83
F0D0049m
fig. 84
F0D0075m

67GETTING TO KNOW YOUR VEHICLE
REARVIEW
CAMERA
Vehicles equipped with CONNECT
NAV+ can be fitted with an optional
rearview camera. This camerafig. 98,
set on roof rear cross member dis-
plays on the CONNECT NAV+ mon-
itor the images of the rear part of the
vehicle, thus supporting the driver
during parking or reverse manoeuvres.
When the reverse gear is engaged, the
camera is automatically activated. In
the same way, the camera is deacti-
vated when disengaging the reverse
gear.
PARKING SENSORS
The parking system fig. 99detects
and informs the driver about the pres-
ence of obstacles in the rear part of
the vehicle.
It is a valid support to identify fences,
walls, posts, vases with plants and the
like or children playing behind the ve-
hicle.
fig. 98
F0D0173m
SMART WASH fig. 97
Pull the stalk towards the steering
wheel to send a jet of fluid to the
windscreen and operate the wiper
with a simple gesture. The windscreen
wiper will be operated automatically
by holding the washer stalk for longer
than half a second.
The windscreen wiper will flick three
times after the lever is released.
Operate the control repeatedly and
rapidly (for less than half a second) to
spray the windscreen several times
without operating the windscreen
wiper.
fig. 97
F0D0020m
fig. 99
F0D0223m

101GETTING TO KNOW YOUR VEHICLE
RADIO
TRANSMITTERS AND
CELLULAR
TELEPHONES
Cellular telephones and other radio
transceiver equipment (e.g. HAM ra-
dio system) must not be used inside
the vehicle unless a separate aerial is
mounted on the outside of the vehicle.
IMPORTANTThe use of cellular
telephones, HAM transmitters or oth-
er similar devices inside the passenger
compartment (without external aeri-
al) produces RF electromagnetic fields
which, amplified by the resonance ef-
fects inside the passenger compart-
ment may cause vehicle electrical sys-
tem to malfunction.
Moreover, the transmission and re-
ceiving quality deteriorates due to the
screening effect of the vehicle body. Have the cellular phone and the con-
nections to the system installed by a
Fiat Dealership.
The hands-free tele-
phone you purchase will
need to be compatible
with your cellular telephone.
Have the cellular tele-
phone and the connec-
tions to the system in-
stalled by a Fiat Dealership only.
This will ensure the best results
and prevent problems which
could impair vehicle safety.
ROOF RACK/
SKI RACK
Use the special pins fitted to the edge
of the roof panel to attach the all-pur-
pose roof rack support bars fig. 150
Vehicles with long wheelbase have
eight pins and those with short or
medium wheelbase, six.
There are two different types of pins
for fastening the roof rack in place:
A- pins for vans with normal and
high roof
B- screw with housing for roof rack
closed with a threaded plug for vans
with extra high roof.
fig. 150
F0D0088m

124GETTING THE BEST OUT OF YOUR VEHICLE
To get the most out of ABS:
– During emergency stops or when
grip conditions are poor, you will feel
a slight pulsation on the brake pedal.
This is the sign that the ABS is work-
ing. Do not release the brake pedal but
continue to press so as not to inter-
rupt the braking action;
– ABS enables you to brake and steer
at the same time. If you meet an un-
expected obstacle you can therefore
steer around it;
– the ABS prevents the wheels from
locking but it does not increase actu-
al grip conditions between tyre and
road. Therefore, even if your vehicle
is fitted with ABS, keep a safe distance
from the vehicle in front of you and
keep your speed down when driving
into bends.
ABS serves to increase your control
over the vehicle, not to enable you to
go faster.Some suggestions which may help
you to keep the running costs of the
vehicle down and lower the amount
of toxic emissions released into the at-
mosphere are given below.
GENERAL
CONSIDERATIONS
Vehicle maintenance
Carry out the checks and adjust-
ments/regulations specified in the
“Service Schedule”.
Tyres
Check tyre inflation pressure regu-
larly. Tyres should be checked at least
once every four weeks: if the pressure
is too low, fuel consumption increas-
es as the resistance to the rolling
movement of the tyre is greater.Unnecessary loads
Do not travel with too much load.
The weight of the vehicle (specially in
urban traffic) and its trim greatly ef-
fects consumption and stability.
Roof rack/ski rack
Remove the roof or ski racks from
the vehicle as soon as they are no
longer needed. These accessories re-
duce the aerodynamic penetration of
the vehicle and will increase con-
sumption. When transporting partic-
ularly large objects, use a trailer,
where possible.CONTAINING RUNNING COSTS

188TECHNICAL SPECIFICATIONS
Version 11
Van high sided medium wheelbase
Van high sided medium wheelbase
Chassis cab short wheelbase
Chassis cab short wheelbase Camping Car
Truck short wheelbase
Chassis cab with load bed short wheelbase
Chassis cab with load bed short wheelbase Camping Car
Chassis cowl short wheelbase
Chassis cowl short wheelbase Camping Car
Chassis cab medium wheelbase
Chassis cab medium wheelbase Camping Car
Truck medium wheelbase
Chassis cab with load bed medium wheelbase
Chassis cab with load bed medium wheelbase Camping Car
Panorama short wheelbase
Combi 6 seater short wheelbase
Combi short wheelbase low roof
Combi medium wheelbase low roof
Chassis cowl short wheelbase “city centre”
Chassis cab with load bed short wheelbase “city centre”
Truck short wheelbase “city centre”
Chassis cab with load bed medium wheelbase “city centre”
Truck medium wheelbase “city centre”
Van short wheelbase low roof “city centre”
Van short wheelbase high roof “city centre”
Van medium wheelbase low roof “city centre”
Van medium wheelbase high sided “city centre”
Van medium wheelbase extra high “city centre”
Van short wheelbase low roof (9 q)Engine
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTDEngine
code
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHV
RHVBodywork
version
244AAMNB AX
244AAMNB BX
244AAMAA AX
244AAMAA AXC
244AAMDA AX
244AAMCA AX
244AAMCA AXC
244AAMBA AX
244AAMBA AXC
244AAMAB AX
244AAMAB AXC
244AAMDB AX
244AAMCB AX
244AAMCB AXC
244AAMPA 02
244AAMRA 03
244AAMFA ZX
244AAMRB 26
244AAMRA 03
244DAMBA AX
244DAMCA AX
244DAMDA AX
244DAMCB AX
244DAMDB AX
244DAMFA AX
244DAMFA BX
244DAMFB AX
244DAMNB AX
244DAMNB BX

189TECHNICAL SPECIFICATIONS
Version 11
Van short wheelbase high roof (9 q)
Van medium wheelbase low roof (9 q)
Van medium wheelbase high sided (9 q)
Van medium wheelbase extra high (9 q)
Van short wheelbase low roof without EGR (9 q)
Van short wheelbase high roof without EGR (9 q)
Van short wheelbase high sided without EGR (9 q)
Van short wheelbase extra high without EGR (9 q)
Van short wheelbase without EGR
Van short wheelbase without EGR
Van short wheelbase
Van short wheelbase
Van medium wheelbase without EGR
Van high sided medium wheelbase without EGR
Van high sided medium wheelbase without EGR
Van long wheelbase high sided without EGR
Van long wheelbase extra high without EGR
Transport ambulance short wheelbase
Panorama short wheelbase
Combi 6 seater short wheelbase
Combi short wheelbase
Combi medium wheelbase
Van short wheelbase without EGR
Van short wheelbase without EGR
Van medium wheelbase without EGR
Van high sided medium wheelbase without EGR
Van high sided medium wheelbase without EGR
Van short wheelbase
Van short wheelbase
Van medium wheelbase Engine
2.0 JTD
2.0 JTD
2.0 JTD
2.0 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.3 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTDEngine
code
RHV
RHV
RHV
RHV
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
F1AE0481C
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43SBodywork
version
244EAMFA AX
244EAMFA BX
244EAMNB AX
244EAMNB BX
244ESMFA AY
244ESMFA BY
244ESMNB AY
244ESMNB BY
244ASMFA AY
244ASMFA BY
244ASMFA AX
244ASMFA BX
244ASMFB AY
244ASMNB AY
244ASMNB BY
244ASMNC AY
244ASMNC BY
244ASMTA AX
244ASMPA 04
244ASMRA 05
244ASMFA ZX
244ASMRB 31
244APMFA AY
244APMFA BY
244APMFB AY
244APMNB AY
244APMNB BY
244APMFA AX
244APMFA BX
244APMFB AX

190TECHNICAL SPECIFICATIONS
Version 15
Combi short wheelbase automatic gearbox low roof
Van high sided medium wheelbase
Van high sided medium wheelbase
Ambulance van short wheelbase low roof without EGR
Transport ambulance short wheelbase
Panorama short wheelbase
Panorama short wheelbase automatic gearbox
Combi 6 seater short wheelbase
Combi short wheelbase
Van short wheelbase
Van short wheelbase
Van medium wheelbase
Van high sided medium wheelbase
Van high sided medium wheelbase
Van high sided long wheelbase
Van high sided long wheelbase
Chassis cab medium wheelbase crew cab
Chassis cab medium wheelbase crew cab Camping Car
Chassis cab short wheelbase
Chassis cab short wheelbase Camping Car
Chassis cab medium wheelbase
Chassis cab medium wheelbase Camping Car
Chassis cab long wheelbase
Chassis cab long wheelbase Camping Car
Truck short wheelbase
Truck medium wheelbase
Truck long wheelbaseEngine
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0Engine
code
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFL
RFLBodywork
version
244APARA 30
244APMNB AX
244APMNB BX
244ALMFA AY
244APMTA AX
244APMPA 06
244APAPA 07
244APMRA 08
244APMFA ZX
244BTMFA AX
244BTMFA BX
244BTMFB AX
244BTMNB AX
244BTMNB BX
244BTMNC AX
244BTMNC BX
244BTMHB AX
244BTMHB AXC
244BTMAA AX
244BTMAA AXC
244BTMAB AX
244BTMAB AXC
244BTMAC AX
244BTMAC AXC
244BTMDA AX
244BTMDB AX
244BTMDC AX

196TECHNICAL SPECIFICATIONS
Version 11
Chassis cab short wheelbase Camping Car without EGR
Truck short wheelbase without EGR
Chassis cab medium wheelbase without EGR
Chassis cab medium wheelbase Camping Car without EGR
Truck medium wheelbase without EGR
Chassis cab with load bed short wheelbase low roof automatic gearbox
Chassis cab with load bed short wheelbase low roof Camping Car automatic gearbox
Chassis cab with load bed medium wheelbase without EGR
Chassis cab with load bed medium wheelbase
Camping Car without EGR
Chassis cowl short wheelbase without EGR
Chassis cowl short wheelbase Camping Car without EGR
Chassis cowl medium wheelbase without EGR
Chassis cowl medium wheelbase Camping Car without EGR
Chassis cab with load bed short wheelbase without EGR
Chassis cab with load bed short wheelbase Camping Car without EGR
Chassis cab with load bed short wheelbase special Camping car without EGR
Chassis cab with load bed medium wheelbase special
Camping car without EGR
Chassis cab with load bed long wheelbase special
Camping car without EGR
Chassis cab long wheelbase without EGR
Chassis cab long wheelbase Camping Car without EGR
Truck long wheelbase without EGR
Chassis cab with load bed long wheelbase without EGR
Chassis cab with load bed long wheelbase Camping Car without EGR
Chassis cowl long wheelbase without EGR
Chassis cowl long wheelbase Camping Car without EGR
Chassis cab 4050 wheelbase without EGREngine
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTDEngine
code
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43SBodywork
version
244BPMAA AYC
244BPMDA AY
244BPMAB AY
244BPMAB AYC
244BPMDB AY
244BPACA AXC
244BPACA AXC
244BPMCB AY
244BPMCB AYC
244BPMBA AY
244BPMBA AYC
244BPMBB AY
244BPMBB AYC
244BPMCA AY
244BPMCA AYC
244BPMCA BYC
244BPMCB BYC
244BPMCC BYC
244BPMAC AY
244BPMAC AYC
244BPMDC AY
244BPMCC AY
244BPMCC AYC
244BPMBC AY
244BPMBC AYC
244BPMAG AY

197TECHNICAL SPECIFICATIONS
Version 15
Chassis cab 4050 wheelbase Camping Car without EGR
Truck 4050 wheelbase without EGR
Chassis cowl 4050 wheelbase without EGR
Chassis cowl 4050 wheelbase Camping Car without EGR
Chassis cab medium wheelbase crew cab without EGR
Chassis cab medium wheelbase crew cab Camping Car without EGR
Truck medium wheelbase crew cab without EGR
Chassis cab long wheelbase crew cab without EGR
Chassis cab long wheelbase crew cab Camping Car without EGR
Truck long wheelbase crew cab without EGR
Chassis cab short wheelbase special Camping Car without EGR
Chassis cowl short wheelbase special Camping Car without EGR
Chassis cab medium wheelbase special Camping Car without EGR
Chassis cowl medium wheelbase special Camping Car without EGR
Chassis cab long wheelbase special Camping Car without EGR
Chassis cowl long wheelbase special Camping Car without EGR
Chassis cab 4050 wheelbase special Camping Car without EGR
Chassis cowl 4050 wheelbase special Camping Car without EGR
Van short wheelbase
Van short wheelbase
Van medium wheelbase
Van short wheelbase low roof automatic gearbox
Van short wheelbase high roof automatic gearbox
Van medium wheelbase low roof automatic gearbox
Van high sided medium wheelbase
Van high sided medium wheelbase
Van high sided medium wheelbase automatic gearbox Engine
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTDEngine
code
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43SBodywork
version
244BPMAG AYC
244BPMDG AY
244BPMBG AY
244BPMBG AYC
244BPMHB AY
244BPMHB AYC
244BPMGB AY
244BPMHC AY
244BPMHC AYC
244BPMGC AY
244BPMAA BYC
244BPMBA BYC
244BPMAB BYC
244BPMBB BYC
244BPMAC BYC
244BPMBC BYC
244BPMAG BYC
244BPM BG BYC
244BPMFA AX
244BPMFA BX
244BPMFB AX
244BPAFA AX
244BPAFA BX
244BPAFB AX
244BPMNB AX
244BPMNB BX
244BPANB AX

201TECHNICAL SPECIFICATIONS
Version 15
Chassis cab long wheelbase crew cab Camping Car
Truck long wheelbase crew cab
Transport ambulance medium wheelbase
Panorama medium wheelbase
Panorama medium wheelbase automatic gearbox
Panorama Autonomy
Combi 6 seater medium wheelbase
Combi 6 seater medium wheelbase
Combi 6 seater medium wheelbase automatic gearbox
Combi 6 seater medium wheelbase automatic gearbox
Combi medium wheelbase
Combi medium wheelbase high sided
Combi medium wheelbase automatic gearbox
Chassis cab short wheelbase special Camping Car
Chassis cowl short wheelbase special Camping Car
Chassis cab medium wheelbase special Camping Car
Combi medium wheelbase high sided automatic gearbox
C
hassis cab with load bed short wheelbase low roof Camping Car Special automatic gearbox
Chassis cab with load bed medium wheelbase low roof
Camping Car Special automatic gearbox
Chassis cab with load bed long wheelbase low roof
Camping Car Special automatic gearbox
Chassis cab short wheelbase special Camping car automatic gearbox
Chassis cab medium wheelbase low roof special Camping car automatic gearbox
Chassis cab long wheelbase low roof special
Camping car automatic gearbox
Chassis cab 4050 wheelbase special Camping car automatic gearbox
Chassis cowl short wheelbase special Camping car automatic gearbox
Chassis cowl medium wheelbase low roof special Camping car automatic gearbox Engine
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTD
2.8 JTDEngine
code
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43S
8140.43SBodywork
version
244BPARB 17
244BPARB 17B
244BPMFB ZX
244BPMNB ZX
244BPAFB ZX
244BPAPA 32
244BPMAA BXC
244BPMBA BXC
244BPMAB BXC
244BPMHG AYC
244BPMHG AX
244BPMHG AXC
244BPADG AX
244BPMDG AX
244BPMDG AY
244BPMGG AX
244BPANB ZX
244BPACA BXC
244BPACB BXC
244BPACC BXC
244BPAAA BXC
244BPAAB BXC
244BPAAC BXC
244BPAAG BXC
244BPABA BXC
244BPABA BXC
