FIAT DUCATO BASE CAMPER 2018 Owner handbook (in English)

What it means What to do
amberGLOW PLUG PREHEATING / GLOW PLUG
PREHEATING FAILURE
Glow plugs
This warning light switches on when the key is turned
to MAR. It will switch off as soon as the glow plugs
have reached a preset temperature.
IMPORTANT At high ambient temperatures the
warning light may stay on for an extremely short time.Start the engine as soon as the warning light switches
off.
Glow plug preheating failure
The warning light flashes if there is a fault in the
preheating system.
On some versions the display shows the dedicated
message.Contact a Fiat Dealership as soon as possible.
amberLOW DIESEL EMISSIONS ADDITIVE (UREA) LEVEL
WARNING
(for versions/markets, where provided)
The Diesel Emissions Additive (UREA) low level
warning lightlights if the vehicle has a low UREA level.
69

What it means What to do
amberVEHICLE PROTECTION SYSTEM FAILURE - FIAT
CODE
When the key is turned to MAR the warning light will
flash only once and then switch off.
When the warning light comes on constantly, with key
at MAR-ON, this indicates:
a potential failure (refer to "The Fiat CODE system"
in the chapter "Knowing your vehicle").
a possible break-in attempt with an alarm; in this
case the warning light switches off after approximately
10 seconds.
The warning light
will blink with the engine running
to indicate that the vehicle is not protected by the
engine immobiliser.Contact a Fiat Dealership to have all the keys stored in
the memory.
amberREAR FOG LIGHTS
The warning light comes on when the rear fog lights
are turned on.
70
KNOWING THE INSTRUMENT PANEL

What it means What to do
amberGENERAL FAILURE INDICATION
(Versions with multifunction display)
The warning light turns on in the following
circumstances:
If the fuel inertia cut-off switch is activated
Light failure (rear fog lamps, direction indicators,
brake lights, number plate lights, side lights, daytime
running lights, main beam automatism, trailer direction
indicators, trailer side lights)The failure relating to these lights could be: one or
more blown bulbs, a blown protection fuse or a break
in the electrical connection.
Airbag warning light failure (generic failure warning
light flashing)In this case, the warning light may not indicate
problems with the restraint systems. Before
continuing, contact a Fiat Dealership to have the
system checked immediately.
Rain sensor failure
Diesel filter sensor failure
Trailer connection failure
Audio system failure
Engine oil pressure sensor failure
Parking sensor failure
Water in diesel fuel filterContact a Fiat Dealership as soon as possible to have
the fault fixed.
FOR VERSIONS WITH A MULTIFUNCTION DISPLAY,
THE WARNING LIGHT ALSO TURNS ON IN THE
FOLLOWING CIRCUMSTANCES:
Engine oil level sensor failure
Insufficient engine oil level
71

What it means What to do
amberDPF (PARTICULATE FILTER) CLEANING UNDERWAY
(for versions/markets, where provided)
The warning light switches on when the ignition key is
turned to MAR, but it should switch off after a few
seconds.
The warning light switches on constantly to inform the
driver that the DPF system needs to eliminate the
trapped pollutants (particulate) through the
regeneration process.
A specific message will appear on the display when
the warning light comes on (for versions/markets,
where provided).The warning light does not come on during every DPF
regeneration, but only when driving conditions require
that the driver is notified. The warning light will go off if
the vehicle stays in motion until regeneration has been
completed. The process normally takes about 15
minutes.
Optimum conditions for completing the process are
achieved by travelling at 60 km/h with engine revs
above 2000 rpm. If this warning light comes on, it
does not mean there is a vehicle defect, so there is no
need to take it to a garage.
10)
48)
amberESC-ASR SYSTEM / TRACTION PLUS FAILURE
On certain versions a dedicated message is displayed.
Flashing of the warning light while driving indicates the
intervention of the ESC system.If the warning light does not switch off, or stays on
when travelling, contact a Fiat Dealership.
Hill Holder failure
The warning light will turn on when the Hill Holder
system is faulty.
On certain versions a dedicated message is displayed.In this case, contact a Fiat Dealership as soon as
possible.
amberBRAKE PAD WEAR
The warning light switches on if the front or rear brake
pads are worn.
On certain versions a dedicated message is displayed.Have them replaced as soon as possible.
72
KNOWING THE INSTRUMENT PANEL

What it means What to do
amberDRIVING ADVISOR
The two warning lights on indicate that the system has
started recognising the operating conditions.
When the system recognises the operating conditions,
it becomes active, i.e. it can assist the driver with
visual and acoustic warnings. Therefore, the warning
lights switch off.
IMPORTANT If the operating conditions are no longer
present, the system is engaged but inactive, and
therefore the two warning lights on the panel switch
on.
When the system is active, if the vehicle gets close to
one of the side limit lines or one of the two
demarcation lines of the lane, the driver is warned with
an acoustic signal along with the direction warning
light (right or left) on the panel lighting up.
The system failure is indicated by the two direction
warning lights
andlighting on the display, along
with an acoustic signal and dedicated message.
73

What it means What to do
amberTPMS SYSTEM
TPMS failure
The warning light flashes for about 75 seconds and
then stays on constantly (along with a dedicated
message on the display) to indicate that the system is
temporarily deactivated or faulty.In this case, contact a Fiat Dealership as soon as
possible
Tyre pressure low
The warning light turns on to indicate that the pressure
of one or more tyres is lower than the recommended
value and/or that slow pressure loss is occurring. In
these circumstances, optimal tyre duration and fuel
consumption may not be guaranteed.In this case it is advisable to restore the correct
pressure value.
IMPORTANT Do not continue driving with one or more
flat tyres as vehicle handling may be compromised.
Stop the vehicle, avoiding sharp braking and steering.
WARNING
48)The driving speed must always be suitable for traffic and weather conditions and the driver must always comply with the Highway Code.
The engine may be stopped if the DPF light is on; however, repeated interruption of the regeneration process may result in premature
deterioration of the engine oil. For this reason, always wait until the warning light switches off before stopping the engine as described above.
It is not advisable to complete DPF regeneration with the vehicle stationary.
WARNING
9)If, when the ignition key is turned to MAR, thewarning light does not switch on, switches on constantly or flashes when driving (on
certain versions together with the message on the display), contact a Fiat Dealership as soon as possible.
10)During regeneration, the fan could be operated.
74
KNOWING THE INSTRUMENT PANEL

What it means What to do
greenDIPPED BEAM HEADLIGHTS
The warning light switches on when the dipped beam
headlights are turned on.
FOLLOW ME HOME
The warning light switches on (together with a
message shown on the display) when this device is in
use (see "Follow me home device" paragraph in
"Exterior lights" in the "Knowing your vehicle" chapter).
greenLEFT DIRECTION INDICATOR
The warning light switches on when the direction
indicator control stalk is moved downwards or,
together with the right direction indicator, when the
hazard warning light button is pressed.
greenRIGHT DIRECTION INDICATOR
The warning light switches on when the direction
indicator control stalk is moved upwards or, together
with the left direction indicator, when the hazard
warning light button is pressed.
greenFOG LIGHTS
The warning light comes on when the front fog lights
are turned on.
75

What it means What to do
greenCRUISE CONTROL
(for versions/markets, where provided)
On turning the key to the MAR position, the warning
light on the display turns on, but it must turn off after a
few seconds if the Cruise Control is disabled.
The warning light is lit up on the display by turning the
Cruise Control selector wheel to ON or, according
to the versions. On certain versions a dedicated
message is displayed.
greenSPEED LIMITER
(for versions/markets, where provided)
The warning light on the dial switches on when the
function is activated.
On certain versions a dedicated message is displayed.
greenAUTOMATIC MAIN BEAM HEADLIGHTS
This warning light comes on when the automatic main
beam headlights are activated.
blueMAIN BEAM HEADLIGHTS
The warning light switches on when the main beam
headlights are turned on.
76
KNOWING THE INSTRUMENT PANEL

What it means What to do
green"UP" FUNCTION
(only with COMFORT-MATIC gearbox, for versions/
markets, where provided)
The UP function can be activated only with automatic
logic enabled on the COMFORT-MATIC gearbox.
The UP function can be activated by pressing the UP
button located amongst the controls in the dashboard.
After turning this function on, the
warning light on
the instrument panel turns on, together with a
confirmation message on the reconfigurable
multifunction display.
77

Messages on display
What it means What to do
EXTERIOR LIGHTS FAILURE
(Versions with reconfigurable multifunction display)
The symbol switches on when a fault is detected on
one of the following lights:
direction indicators
rear fog lights
brake lights
side lights
daytime running lights
number plate lights
reversing lights
main beam automatism
trailer side lights
trailer direction indicators.The fault relating to these lights could be: one or more
blown bulbs, a blown protection fuse or a break in the
electrical connection.
LOW ENGINE OIL PRESSURE WARNING LIGHT
FAILURE
The symbol turns on to indicate a failure of the low
engine oil pressure warning light.Contact a Fiat Dealership.
BRAKE LIGHT FAILURE
(Versions with reconfigurable multifunction display)
The symbol switches on when a fault is detected in the
brake lights.The fault could be: one or more blown bulbs, a blown
protection fuse or a break in the electrical connection.
MAIN BEAM AUTOMATISM FAULT
(Versions with reconfigurable multifunction display)
The symbol switches on when a fault is detected in the
automatic switching-on system for the main beam
headlights.
78
KNOWING THE INSTRUMENT PANEL
