spark plugs replace FIAT FIORINO 2007 Owner handbook (in English)

158
SAFETY
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARDAND CONTROLS
STARTING
AND DRIVING
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
MAINTENANCE
AND CARE
Thousands of kilometres
Check antievaporation system
Replace fuel filter
Change spark plugs
Replace toothed belt for transmission control
Replace air cleaner cartridge
Top up fluids (engine coolant, brakes, battery, windscreen washer, etc.)
Check engine control system operation
(through diagnosis outlet)
Change engine oil and oil filter (or every 24 months)
Change brake fluid (or every 24 months)
Change pollen filter (or every 12 months)
30 60 90 120 150 180
●●
●●●
●●●
●
●●●
●●●●●●
●●●●●●
●●●●●●
●●●
●●●●●●

200
WARNING
LIGHTS AND
MESSAGES
DASHBOARDAND CONTROLS
SAFETY
STARTING
AND DRIVING
IN AN
EMERGENCY
MAINTENANCE
AND CARE
TECHNICAL
SPECIFICATIONS
INDEX
Safety.................................................. 83
Saving fuel ............................................. 106
SBR system .......................................... 85
Seat belt tensioners ........................... 86
Seat belts (use) .................................... 84
Seats
– adjustments .................................... 33
– cleaning ........................................... 176
– foldaway passenger seat .............. 34
– heated ............................................. 33
Snow chains ......................................... 110
Spark plugs (type) ............................... 181
Specifications ....................................... 177
Starting and driving...................... 101
Stationary vehicle ............................... 104
Steering ................................................. 183
Steering column controls
– left lever ......................................... 49
– right lever ....................................... 51
Steering lock ........................................ 14
Steering wheel ..................................... 38
Sun visors ............................................. 60
Suspensions .......................................... 183
Symbols ................................................. 7
Technical specifications............. 177
Tires
– inflation pressures ........................ 186– replacement ................................... 127
– snow tires .............................109-186
– standard .......................................... 186
– tire data .......................................... 184
Towing the vehicle ............................. 154
Trailer towing ...................................... 108
Transmission (operation) ................. 105
Transmission operation .................... 105
Trip computer ..................................... 31
Trunk
– emergency opening ...................... 67
– extension ........................................ 69
– load restraint ................................. 70
– shelf removal ................................. 68
Turn signal lights
– control ............................................ 50
– front bulb replacement ............... 138
– lane change function .................... 50
– rear bulb replacement ................. 140
– side bulb replacement ................. 139
Type approval ...................................... 197
Vehicle starting and driving ............. 101
Ventilation ............................................ 41
Warning lights and messages.. 111
Weights ................................................ 190 Performance ........................................ 189
Power socket ...................................... 59
Powertrain ........................................... 182
Prolonged inactivity ............................ 110
Provision for installation
of Pushout side windows ............... 60
– cleaning ........................................... 177
Radio transmitters
and mobile telephones .................... 80
Raising the vehicle .............................. 153
Rear fog light
– bulb replacement .......................... 140
– control rear roof lights ..... 143-144
Rear view mirrors
– external .......................................... 39
– interior ........................................... 39
– power-operated ........................... 40
Refueling ............................................... 81
Removable roof lamp ........................ 55
Roof lights ............................................ 53
Roof lights
– bulb replacement
– on/off control ......................53-54-55
Roof struts
– retentions ....................................... 72
Rubber hoses ....................................... 170
