MODEL PLATE fig. 1
This is applied to the right-hand side of the
spare wheel shelf and shows the following
data:
BHomologation number.
CVehicle type code.
DChassis number.
EMaximum vehicle weight fully loaded.
FMaximum vehicle weight fully loaded
with trailer.
GMaximum vehicle weight on front axle.HMaximum vehicle weight on rear axle.
IEngine type.
LBody version code.
MSpare part code.
NSmoke opacity index (for diesel en-
gines).
IDENTIFICATION DATA
Take note of the identification codes. The
following identification codes are printed
and shown on the plates:
❒Model plate.
❒Chassis marking.
❒Bodywork paint identification plate.
❒Engine marking.fig. 1F0R0247m

201
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
CHASSIS MARKING fig. 3
This is printed on the passegner com-
partment floor bed near the front right
seat.
❒car model (ZFA 323000);
❒chassis number.ENGINE MARKING
Engine marking is stamped on the cylinder
block and includes the model and the
chassis number.
BODYWORK PAINT
IDENTIFICATION PLATE fig. 2
This plate is applied to the tailgate and
shows the following data:
APaint manufacturer.
BColour name.
CFiat colour code.
DRespray and touch up code.
fig. 2F0R0145mfig. 3F0R0146m

202
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
ENGINE CODES - BODYWORK VERSIONS
Versions Engine type code Bodywork version code
1.4 350A1000 323AXA1A 00
1.4 T-JET198A4000 323AXC1A 03
1.3 Multijet 199A3000 323AXB1A 01

203
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
1.4
350A1000
Otto
4 in line
72 x 84
1368
11.1 ± 0.2
57
77
6000
115
11.7
3000
NGK
ZKR7A-10
Unleaded petrol 95 RON
(EN228 Specifications)
1.3 Multijet
199A3000
Diesel
4 in line
69.6 x 82
1248
17.6 ± 0.4
66
90
4000
200
20.3
1750
–
Diesel fuel for
motor vehicles
(EN590 specifications)
1.4 T-JET
198A4000
Otto
4
in line
72,0 x 84,0
1368
9.8
88
120
5000
206
21
1750
NGK
IKR9F8
Unleaded petrol 95 RON
(EN228 Specifications)
ENGINE
GENERAL
Engine code
Cycle
Number and layout of cylinders
Piston bore and stroke mm
Total displacement cm3
Compression ratio
Maximum power (EEC) kW
HP
corresponding ratio rpm
Maximum torque (EEC) Nm
kgm
corresponding ratio rpm
Spark plugs
Fuel

204
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
Modifications or repairs to the fuel feed system that are not carried out properly or do not take the system’s
technical specifications into account can cause malfunctions leading to the risk of fire.
WARNING
TRANSMISSION
1.4 - 1.4 T-JET-1.3 Multijet
Gearbox Five forward gears plus reverse with synchronisers for forward gears
Clutch Self-adjusting with pedal without idle stroke
Drive Front
Fuel feedMultipoint electronic injection Multipoint sequential phased
electronic injection with
turbosupercharger and intercoolerMultijet direct injection
“Common Rail”
FUEL FEED/IGNITION
1.4 1.4 T-JET 1.3 Multijet

205
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
SUSPENSIONS
1.4 - 1.4 T-JET - 1.3 Multijet
Front
Rear
BRAKES
1.4 - 1.4 T-JET - 1.3 Multijet
Service brakes:
– front
– rear
Parking brake
IMPORTANT Water, ice and salt sprinkled on the roads may deposit on the brake disks reducing braking efficiency
the first time the brakes are applied.
Mc Pherson independent wheels
twisting axle with interconnected wheels controlled by hand lever, operating on rear brakesdrum / disk (T-JET version) disk
STEERING
1.4 - 1.4 T-JET - 1.3 Multijet
Type
Steering circle (kerb to kerb) m 10.5 (❏) / 11 (6)
(❏) With 15” tyres
(6) With 16” and 17” tyresrack and pinion with hydraulic power steering

206
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
READING TYRE
MARKINGS fig. 4
Example: 185/65 R 15 88T
185 = Nominal width (S, distance in mm
between sidewalls).
65 = Height/width ratio (H/S) in per-
centage.
R = Radial tyre.
15 = Rim diameter in inches (Ø).
88 = Load rate (capacity).
T = Maximum speed rating.
WHEELS
RIMS AND TYRES
Pressed steel or alloy rims. Tubeless ra-
dial carcass tyres. All approved tyres are
listed in the Log Book.
IMPORTANT In the event of discrepan-
cies between the information provided on
this “Owner’s handbook” and the “Log
book”, consider the specifications shown
in the log book only.
Respect the prescribed size to ensure
safety of the car in movement. Fit tyres
of the same make and type on all wheels.
IMPORTANT Do not use inner tubes
with Tubeless tyres.
fig. 4F0R0147m
SPARE WHEEL
Pressed steel rim Tubeless tyre.
WHEEL GEOMETRY
Toe-in total front: 0.3 ± 1 mm
Toe-in total rear: 1.7 ± 0.5 mm
The values refer to the car in running or-
der.

207
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
READING RIM
MARKINGS fig. 4
Example: 6J x 15 ET44
6 = rim width in inches 1.
J = rim drop centre outline (side
projection where the tyre bead
rests) 2.
15 = rim nominal diameter in inches
(corresponds to diameter of the
tyre to be mounted) 3= Ø.
ET44 = wheel camber angle (distance be-
tween the disc/rim supporting
plane and the wheel rim centre
line). Load rating (capacity)
70= 335 kg 81= 462 kg
71= 345 kg 82= 475 kg
72= 355 kg 83= 487 kg
73= 365 kg 84= 500 kg
74= 375 kg 85= 515 kg
75= 387 kg 86= 530 kg
76= 400 kg 87= 545 kg
77= 412 kg 88= 560 kg
78= 425 kg 89= 580 kg
79= 437 kg 90= 600 kg
80= 450 kg 91= 615 kg Maximum speed rating
Q= up to 160 km/h.
R= up to 170 km/h.
S= up to 180 km/h.
T= up to 190 km/h.
?U= up to 200 km/h.
H= up to 210 km/h.
V= up to 240 km/h.
Maximum speed rating
for snow tyres
QM + S= up to 160 km/h.
TM + S= up to 190 km/h.
HM + S= up to 210 km/h.

208
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
6J X 15'' - ET 44
6J X 15'' - ET 44
6J X 15'' - ET 44
6J X 15'' - ET 44
6J X 15'' - ET 44185/65 R15 84T
195/60 R15 88H
185/65 R15 84T (**)
185/65 R15 84T
195/60 R15 88H
185/65 R15 84T (**)
185/65 R15 84T (**) 185/65 R15 84T
195/60 R15 88H (❏)
195/55 R16 87H (❍)
185/65 R15 84T
195/60 R15 88H (❏)
195/55 R16 87H (❍)
205/45 R17 88V (*) (▲) 6J X 15'' - ET 44
6J X 16'' - ET 41
6J X 15'' - ET 44
6J X 16'' - ET 41
6.5J X 17'' - ET 41
Version Rims Tyres fitted Spare wheel (where provided)Rim Tyre
(❏) Alloy rim
(❍) Optional alloy rim for versions/markets where provided
(*) Not snow chains
(▲) Optional tyre for versions/markets where provided
(**) Using this spare wheel, vehicle max speed is 80 km/h 1.3 Multijet
1.4 T-JET 1.4

209
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT USE
OF THE
CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
COLD TYRE INFLATION PRESSURE (bar)
Tyre
Medium load Full load
Front Rear Front Rear
185/65 R15 84T 2.3 2.1 2.3 2.3
195/60 R15 88H 2.3 2.1 2.3 2.3
195/55 R16 87H 2.3 2.1 2.4 2.4
205/45 R17 88V 2.4 2.2 2.5 2.4
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
