width FIAT MULTIPLA 2006 1.G Owners Manual

240
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
WHEELS
RIMS AND TYRES
Pressed steel or alloy rims (where provided). Tubeless
tyres with radial carcass.
All homologated tyres are listed in the log book.
IMPORTANT In the event of discrepancies between
the information provided on this OWNER
HANDBOOK and the LOG BOOK, consider the
specifications shown in the log book only.
Attaining to the prescribed size, to ensure safety of
the car in movement, it must be fitted with tyres of
the same make and type on all wheels.
IMPORTANT Do not use inner tubes with Tubeless
tyres.
WHEEL GEOMETRY
Front wheel toe-in measured from rim to rim: –3 ±1
mm.
SPACE-SAVER SPARE WHEEL
Pressed steel rim. Tubeless tyre.SNOW TYRES
Use the snow tyres specified in section “Driving your
car” in paragraph “Snow tyres”.
SNOW CHAINS
Only use low profile chains, see section “Driving your
car” in paragraph “Snow chains”.
UNDERSTANDING TYRE MARKING
Example: 185/65 R15 88H
185 = Nominal width (distance between sidewalls
in mm).
65 = Height/width ratio (as a percentage).
R = Radial tyre.
15 = Rim diameter in inches.
88 = Load rating.
H = Maximum speed rating.

242
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
UNDERSTANDING RIM MARKING
The following are the necessary indications to understand the meaning of
the markings on the rim, as shown in the figure.
Example: 6 J x 15 H2
6 = rim width in inches (1)
J = rim drop center outline (side projection where the tyre bead rests)
(2)
15 = rim nominal diameter in inches (corresponds to diameter of the
tyre to be mounted) (3 =Ø)
H2 = “hump“ shape and number (relief on the circumference holding the
TUBELESS tyre bead on the rim)
F0E0228m
Snow Space-saver spare wheel
Rim Tyre Tyre Rim Tyre
100
16V- JTD 1206 J x15 185/65 R15 88H 185/65 R15 88Q 4B x 15 125/80 R15 95M
6
bJ x15 195/60 R15 88H (*) 195/60 R15 88Q
7 J x17 205/45 R17 88V (*) (❒)–
VAN 100 16V6 J x15185/65 R15 88H 185/65 R15 88Q spare wheel VAN JTD 120195/60 R15 88H (*) 195/60 R15 88Q with standard size
(*) Where provided.
(❒) Tyre that cannot be fitted with snow chains

245
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
CAR
MAINTENANCE
INDEX
DASHBOARD
AND CONTROLS
IN AN
EMERGENCY
TECHNICAL
SPECIFICATIONS
Boot4-seat 5-seat
Length mm 690 690
Max. width mm 1440 1440
Width between wheelhouse mm 1215 1215
Effective height mm 1168 1168
Boot volume:
– up to waist dm
3––
– up to rear parcel shelf dm3355 355
– up to roof dm3495 495
