Dear Customer
,
Thank you for choosing Fiat and congratulations on your choice of a Fiat Panda.
We have written this handbook to help you get to know all your new Fiat Panda’s features and use it in the best pos-
sible way. You should read it right through before taking the road for the first time. You will find information, tips
and important warnings regarding the driving of your car to help you derive the maximum from your Fiat Panda’s
technological features.
You are recommended to carefully read the warnings and indications, marked with the respective symbols, at the end
of the page:
personal safety;
car safety;
environmental protection.
The enclosed Warranty Booklet lists the services that Fiat offers to its Customers:
❒
the Warranty Certificate with terms and conditions for maintaining its validity;
❒
the range of additional services available to Fiat Customers.
Enjoy the reading and happy motoring!
This Owner Handbook describes all Fiat Panda versions.
As a consequence, you should only consider the information which is related
to the engine and bodywork version of the car you have purchased.
001-030 PANDA EN 7-10-2009 13:39 Pagina 1

REFUELLING
Petrol engines: only refuel with unleaded petrol with oc-
tane rating (RON) not less than 95 in compliance with
the European Standard EN 228.
Diesel engines: only refuel with diesel fuel for motor
vehicles in compliance with the European Standard
EN 590. The use of other products or mixtures may
damage the engine beyond repair and consequently
invalidate the warranty, due to the damage caused.
STARTING THE ENGINE
Petrol engines: make sure that the handbrake is engaged;
set the gearshift lever to neutral; fully depress the clutch
pedal without pressing the accelerator, then turn the ig-
nition key to AVV and release it as soon as the engine has
started.
Diesel engines: turn the ignition key to MAR and wait for
the warning lights Y(or symbol on the display) and m
to go off. Then, turn the ignition key to AVV and release
it as soon as the engine has started.
PARKING ON FLAMMABLE MATERIAL
