FORD AEROSTAR 1996 1.G Owners Manual

180
*
[AS07730(ALL)08/95]
Rear Seat Radio Controls
*
[AS07735(ALL)08/95]
Using the Rear Seat Radio Controls
[AS07740(ALL)08/95]
Rear seat radio controls are available on all
Aerostar models.
[AS07745(ALL)08/95]
The rear seat radio controls are located behind
the driver on the left hand side of the vehicle.
These controls duplicate several radio functions
of the radio and allow the use of headphones in
the vehicle.
[AS07750(ALL)08/95]
one inch art:0060647-B
Rear seat radio controls
[AS07755(ALL)08/95]
How to turn the rear seat radio controls on
and off
[AS07760(ALL)08/95]
Press memory preset buttons ª1º and ª3º
simultaneously on the face of your radio to turn
the rear seat radio controls on. A headphones
symbol (j) will appear in the display when the
rear seat controls are on. Press ª1º and ª3º
simultaneously again to turn the rear seat radio
controls off.
[AS07765(ALL)08/95]
How to adjust the volume
[AS07770(ALL)08/95]
Press the right (+) side of the ªVOLUMEº rocker
switch to increase volume; and push the left (s)
side to decrease the volume of the rear speakers.
[AS07775(ALL)08/95]
NOTE: Rear seat control volume can be set no
higher than current radio setting unless
speakers are turned off. See note under
How to turn the speakers on and off.
File:09cpasa.ex
Update:Tue Aug 29 17:42:51 1995

181 [AS07780(ALL)08/95]
Setting the AM or FM frequency band
[AS07785(ALL)08/95]
Push the ªBANDº button to change the
frequency band.
[AS07790(ALL)08/95]
Using the ªMEMORYº button
[AS07795(ALL)08/95]
Push the ªMEMORYº button to access the
station you have set into memory button 1 on
the face of the radio. Successively pushing this
button will access, numerically, all stations set
into the Station Memory Preset buttons (1
through 5).
[AS07800(ALL)08/95]
How to turn the speakers on and off
[AS07805(ALL)08/95]
When the rear seat controls are on, push the
ªSPKRS ON-OFFº button to turn all speakers
off. Push again to turn all speakers on.
[AS07810(ALL)08/95]
NOTE: Turning the ignition off then on again
will not turn the speakers back on, if
previously turned off by the ªSPKRS
ON-OFFº button on the rear seat
controls.
[AS07815(ALL)08/95]
Using the ªSEEKº function
[AS07820(ALL)08/95]
Press the right (
a) side of the ªSEEKº rocker
switch to seek to the next radio station. Press the
left (
b) side of the ªSEEKº rocker switch to
seek to the previous radio station.
[AS07825(ALL)08/95]
NOTE: When using the rear seat controls with
a High-Level Audio System, the
ªSEEKº function on the rear seat
controls will also function with
cassettes, seeking the next (ªSEEK
aº)
or previous (ª
bSEEKº) selection on
the tape.
File:09cpasa.ex
Update:Tue Aug 29 17:42:51 1995

182 [AS07850(ALL)00/95]Using headphones with the rear seat
controls
[AS07855(ALL)08/95]
Two 3.5mm headphone jacks have been
provided on the rear seat controls. Plug
headphone(s) into the provided jack(s) to
operate.
%*
[AS07860(ALL)08/95]
Common Radio Reception Conditions
*
[AS07865(ALL)08/95]
Several conditions prevent FM reception from
being completely clear and noise-free, such as
the following:
*
[AS07870(ALL)08/95]
1. Distance/Strength
*
[AS07875(ALL)08/95]
The strength of the FM signal is directly related
to the distance the signal must travel. The
listenable range of an average FM signal is
approximately 25 miles (40 kilometers). Beyond
this distance, the radio is operating in a fringe
area and the signal becomes weaker.
*
[AS07880(ALL)08/95]
NOTE: Always make sure your antenna
(whether you have a power antenna or
a manually adjustable antenna) is fully
extended to its maximum length for
proper reception. If your antenna is not
fully extended, you may experience
signal loss while traveling in fringe
reception areas.
*
[AS07885(ALL)08/95]
2. Terrain
*
[AS07890(ALL)08/95]
The terrain (hilly, mountainous, tall buildings) of
the area over which the signal travels may
prevent the FM signal from being noise-free.
*
[AS07895(ALL)08/95]
If there is a building or large structure between
the antenna and station, some of the signal
ªbendsº around the building, but certain spots
receive almost no signal. Moving out of the
ªshadowº of the structure will allow the station
to return to normal.
File:09cpasa.ex
Update:Tue Aug 29 17:42:51 1995

183
*
[AS07900(ALL)08/95]
When the radio waves are reflected off objects or
structures, the reflected signal cancels the normal
signal, causing the antenna to pick up noise and
distortion. Cancellation effects are most
prominent in metropolitan areas, but also can
become quite severe in hilly terrain and
depressed roadways.
*
[AS07905(ALL)08/95]
To minimize these conditions, a stereo/mono
blend circuit has been incorporated into this
system. This feature automatically switches a
weak stereo signal to a clearer monaural signal,
which improves the quality of reception.
*
[AS07910(ALL)08/95]
Several sources of static are normal conditions
on AM frequencies. These can be caused by
power lines, electric fences, traffic lights and
thunderstorms.
*
[AS07915(ALL)08/95]
Another reception phenomenon isStrong Signal
Capture and Overload. This can occur when
listening to a weak station and when passing
another broadcast tower. The close station may
capture the more distant station, although the
displayed frequency does not change. While
passing the tower, the station may switch back
and forth a few times before returning to the
original station.
*
[AS07920(ALL)08/95]
When several broadcast towers are present
(common in metropolitan areas) several stations
may overload the receiver, resulting in
considerable station changing, mixing and
distortion.
*
[AS07925(ALL)08/95]
Automatic gain control circuitry for both AM
and FM bands has been incorporated into this
system to reduce strong signal capture and
overload.
File:09cpasa.ex
Update:Tue Aug 29 17:42:51 1995

184
%*
[AS07930(ALL)08/95]
All About Radio Frequencies
*
[AS07935(ALL)08/95]
The Federal Communications Commission (FCC)
and the Canadian Radio Telecommunications
Commission (CRTC) establish the frequencies
that AM and FM radio stations may use for
their broadcasts. The allowable frequencies are,
AM: 530, 540...1600, 1610 kHz in 10 kHz steps;
FM: 87.9, 88.1...107.7, 107.9 MHz in 0.2 MHz
steps.
*
[AS07940(ALL)08/95]
Not all frequencies will be assigned to a given
area. This radio will tune to each of these
frequencies using manual tune and no fine
tuning is necessary as radio stations may not use
other frequencies.
*
[AS08175(ALL)08/95]
Some FM radio stations advertise a
ªrounded-offº frequency which is not the
frequency they actually broadcast on. For
example, a radio station that is assigned a
frequency of 98.7 MHz may call itself ªRadio 99º
even though 99.0 MHz is not an allowable FM
broadcast frequency.
%
*
[AS08200(ALL)08/95]
Important Warranty and Service
Information
*
[AS08225(ALL)08/95]
Warranty
*
[AS08250(ALL)08/95]
Your sound system is warranted for three years
or 36,000 miles (60,000 kilometers), whichever
comes first. Consult your vehicle warranty
booklet for further information. Ask your dealer
for a copy of this limited warranty.
*
[AS08275(ALL)08/95]
Service
*
[AS08300(ALL)08/95]
At Ford Electronics, we stand behind our audio
systems with a comprehensive service and repair
program. If anything should go wrong with
your Ford audio system, return to your dealer
for service. There is a nationwide network of
qualified Ford authorized repair centers to assist
you.
File:09cpasa.ex
Update:Tue Aug 29 17:42:51 1995

185
Driving Your Aerostar
[DR00300(ALL)08/95]
Automatic Transmission
Operation (4R44E/4R55E)
*
[DR00350(ALL)08/95]
The 4R44E and 4R55E transmissions are
electronically controlled four speed overdrive
automatic transmissions with lockup torque
converter. Transmission operation is controlled
by the Powertrain Control Module (PCM).
*
[DR00425(ALL)08/95]
The PCM will automatically adjust transmission
operation to make up for varying conditions.
Several sensors located on the engine and
transmission such as throttle position, engine
speed, vehicle speed and transmission
temperature are used by the PCM to shift the
transmission into a higher or lower gear when
required for the best performance and fuel
economy. For example, you may notice that the
transmission will upshift to a higher gear more
quickly when the vehicle has not reached normal
operating temperature.
*
[DR00475(ALL)08/95]
The PCM also controls the transmission's Torque
Converter Clutch (TCC) to further raise vehicle
performance and fuel economy. The TCC will
engage when the transmission operating
temperature and other conditions determined by
the PCM have been met. Engagement of the
clutch may be noted as a decrease in engine
speed.
[DR00500(ALL)08/95]
To help in troubleshooting, the PCM continually
performs self-tests on the electronic control
system and, if any faults are detected, stores
them in memory. The Overdrive Off Indicator
Light (O/D OFF), which is located on the
File:10cpdra.ex
Update:Tue Aug 29 17:45:28 1995

186gearshift lever, may flash steadily if a
malfunction has been detected. If the Overdrive
Off Indicator Light is flashing, contact your Ford
dealer as soon as possible. If this condition
persists, damage to the transmission could occur.
*
[DR00700(ALL)03/95]
Some vehicles are equipped with a Powertrain
Control Module that limits engine speeds with a
cut-out mode to promote durability.
[DR05700(ALL)06/95]Automatic Overdrive
Transmission
%*
[DR05750(ALL)01/95]
Putting Your Vehicle in Gear
[DR05800(ALL)03/93]
Your vehicle's gearshift is on the steering
column. You can put the gearshift in any one of
several positions.
[DR06001(ALL)06/95]
one third page art:0095027-A
The positions of the column-mounted gearshift
*
[DR06200(ALL)05/95]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
File:10cpdra.ex
Update:Tue Aug 29 17:45:28 1995

187
*
[DR06300(ALL)01/95]
Once you place the gearshift securely into
position, gradually release the brake pedal and
use the accelerator as necessary.
%*
[DR06310(ALL)01/95]
NOTE: Your vehicle is equipped with a
brake-shift interlock feature. This
feature prevents you from shifting
from P (Park) unless you have the
brake pedal depressed. (The ignition
must be in the ON position.) If you
cannot shift from P (Park) with the
brake pedal depressed:
*
[DR06320(ALL)01/95]
1. Apply the parking brake.
*
[DR06330(ALL)01/95]
2. Remove the key.
*
[DR06340(ALL)08/95]
3. Insert the key and rotate it one position
clockwise (ignition in the OFF position).
*
[DR06350(ALL)08/95]
4. Apply the brake pedal and shift to N
(Neutral). (If the vehicle is shifted back to P
[Park], you must repeat the previous steps.)
*
[DR06360(ALL)01/95]
5. Start the vehicle.
*
[DR06370(ALL)07/95]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Aerostar
in this Owner Guide for instructions on checking
and replacing fuses.
*
[DR06375(ALL)05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
File:10cpdra.ex
Update:Tue Aug 29 17:45:28 1995

188 %
*
[DR06401(ALL)01/95]
R (Reverse)
*
[DR06501(ALL)02/95]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[DR06520(ALL)01/95]
N (Neutral)
[DR06550(ALL)08/95]
In N (Neutral), the wheels of the vehicle are not
locked. Your vehicle will roll freely, even on the
slightest incline, unless the parking brake or
brakes are on.
%*
[DR06601(ALL)01/95]
Driving
%*
[DR06700(ALL)04/95]
When to usej(Overdrive)
[DR06800(ALL)08/95]
This is the normal driving position. As the
vehicle picks up speed, automatic upshifts to
second, third and fourth gears will occur when
jOverdrive is chosen on the selector and the
transmission control switch has not been
pressed. The transmission will shift into the
correct gear when the right speed is achieved,
for the accelerator pedal position you have
chosen.
[DR06810(ALL)08/95]
When to use Drive
[DR06830(ALL)08/95]
You will note there is not a drive position on
your gearshift indicator. However, you will find
a transmission control switch labeled
OVERDRIVE OFF located on the end of the
gearshift lever. Press this switch and the
indicator light (OFF) illuminates on the gearshift
lever. With overdrive cancelled and the word
OFF illuminated, the transmission will operate in
gears one through three. This is useful if you
experience frequent downshift/upshift
conditions, when operating with a heavy load or
in hilly terrain, or if additional engine braking is
File:10cpdra.ex
Update:Tue Aug 29 17:45:28 1995

189
useful. However, shift back toj(Overdrive)
whenever practical for optimum powertrain
cooling and fuel economy. This can be
accomplished by pushing the transmission
control switch again, to cancel the OVERDRIVE
OFF control and light.
[DR06850(ALL)06/95]
one third page art:0095028-A*
[DR07100(ALL)01/95]
When to use 2 (Second)
[DR07200(ALL)06/92]
With the gearshift in the 2 (Second) gear
position more engine braking is provided. Use 2
(Second) gear to drive up moderately steep
grades, to start up slippery roads, or to provide
moderate engine braking on downgrades. DO
NOT GO FASTER THAN 55 mph (88 km/h) IN
THIS GEARSHIFT POSITION.
*
[DR07400(ALL)01/95]
When to use 1 (Low)
[DR07500(ALL)06/92]
With the gearshift in the 1 (First) gear position
maximum engine braking is provided. This
position provides 1 (First) gear operation only
with no automatic upshifts. To obtain upshifts
the gearshift must be moved out of this position.
Use 1 (First) gear to drive up steep grades, or to
provide maximum engine braking on
downgrades.
File:10cpdra.ex
Update:Tue Aug 29 17:45:28 1995
