Page 11 of 347
8 [IS01800(ALL)01/96]
full page art:0095026-BAerostar mechanical cluster
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 12 of 347
9
%*
[IS03000(ALL)01/96]
The Mechanical Cluster
*
[IS03100(ALL)01/96]
The following warning lights and gauges are on
the mechanical cluster. All of the warning lights
and gauges alert you to possible problems with
your vehicle. Some of the lights listed are
optional. The following sections detail what each
of these indicators means.
%*
[IS03200(ALL)01/96]
Brake System Warning Light
*
[IS03300(ALL)03/96]
The warning light for the brakes can show two
things Ð that the parking brake is not fully
released, or that the brake fluid level is low in
the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by
your dealer or a qualified service technician.
*
[IS03400(ALL)03/96]
This light illuminates when you turn the ignition
key to START to verify that the indicator bulb is
working. If the light stays on or illuminates after
you have released the parking brake fully, have
the hydraulic brake system serviced.
*
[IS03500(ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
[IS03600(ALL)01/96]
one inch art:0095034-A
Brake warning light symbol
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 13 of 347
10 [IS03700(ALL)01/96]Rear Anti-Lock (ABS) Brake Warning Light
[IS03900(ALL)03/96]
To check the rear ABS brake warning light, turn
the ignition key to the ON position. The rear
ABS brake warning light should glow
momentarily.
*
[IS03950(ALL)03/96]
NOTE: If it does not glow momentarily, have
your vehicle's electrical system checked
immediately.
[IS03975(ALL)01/96]
NOTE: If the rear ABS brake warning light
begins to flash in a repeating flash
sequence, check the rear anti-lock
brake system continuous power fuse
and brake lights for proper operation.
[IS04000(ALL)01/96]
one inch art:0095035-A
Rear anti-lock warning light symbol
*
[IS04100(ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[IS04110(ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 14 of 347
11 %
*
[IS04150(ALL)03/96]
Safety Belt Warning Light and Chime
[IS04301(ALL)01/96]
This warning light and chime remind you to
fasten your safety belt. One of the following will
take place:
*
[IS04325(ALL)03/96]
q
If the safety belt is not buckled when the key
is turned to the ON position, the light comes
on for 1 to 2 minutes and the chime sounds
for 4 to 8 seconds.
*
[IS04351(ALL)03/96]
q
If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime turn off.
*
[IS04365(ALL)03/96]
q
If the safety belt is buckled before the
ignition is turned to the ON position, neither
the light nor the chime will come on.
*
[IS04400(ALL)04/96]
one inch art:0020046-B
Safety belt warning light
% [IS04425(ALL)04/96]
Door Ajar Light and Chime
[IS04450(ALL)03/96]
This light illuminates along with an audible
chime if one of the doors is not completely shut
when you turn the ignition to the ON position.
[IS04475(ALL)01/96]
one inch art:0020787-A
Door ajar light
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 15 of 347
12 %
*
[IS04500(ALL)03/96]
Check Engine Warning Light
[IS04560(ALL)05/96]
This light illuminates when the engine's
Emission Control System requires service. It will
also illuminate when the ignition key is in the
ON position and the engine is off.
*
[IS05300(ALL)04/96]
one inch art:0020048-A
Check engine warning light
[IS05525(ALL)01/96]
Electronic 4-Wheel Drive Warning Light
(If equipped)
[IS05550(ALL)03/96]
The Electronic 4-Wheel Drive Warning Light
illuminates when the Electronic 4-Wheel Drive
system is not working properly. This light
illuminates briefly when you turn the ignition
key to the ON position, but should turn off
when the engine starts. If the light does not
illuminate when you turn the ignition to the ON
position, or if it illuminates and stays on when
you are driving, have your vehicle serviced as
soon as possible.
[IS05560(ALL)03/96]
The 4WD light will go off after a few seconds
and stay off if all systems are operating
correctly. If a problem is detected, the 4WD
warning light will flash a certain number of
times indicating the location of the problem. The
flashing will continue until the problem is
corrected. Each time the ignition key is turned
on, the controller will detect the problem and
flash the signal. The 4WD system remains safe to
operate and the vehicle should be returned for
service.
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 16 of 347
13 [IS05575(ALL)01/96]
one inch art:0020529-B
Electronic 4-wheel drive warning light
%*
[IS05900(ALL)01/96]
Charging System Light
*
[IS06000(ALL)05/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS06050(ALL)01/96]
one inch art:0095040-A
Charging system light
*
[IS06100(ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS06300(ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
%*
[IS06305(ALL)05/96]
Supplemental Air Bag Readiness Light and
Tone Generator
*
[IS06310(ALL)05/96]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 17 of 347
14 [IS06315(ALL)04/96]
one inch art:0020778-BSupplemental air bag readiness light
%*
[IS06350(ALL)05/96]
High Beam Light
*
[IS06360(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
*
[IS06370(ALL)03/96]
one inch art:0020537-B
High beam indicator light
*
[IS06371(ALL)08/95]
Chime for Headlamps On
[IS06372(ALL)03/96]
This chime sounds if the driver or passenger
door is open when the parking lamps or
headlamps are on. The chime sounds until you
close the door, turn off the lamps or turn the
ignition to the ON position.
[IS06373(ALL)03/96]
NOTE: The chime will not sound when the
autolamp has activated the shutoff
delay.
%*
[IS06380(ALL)03/96]
Ignition Key Buzzer or Chime
*
[IS06390(ALL)05/96]
The buzzer or chime will sound if you open the
driver's door while the key is in the ignition and
in the OFF, LOCK, or ACCESSORY position.
Never leave your vehicle unattended with the
key in the ignition.
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 18 of 347
15 %
*
[IS06400(ALL)05/96]
Battery Voltage Gauge (Voltmeter)
*
[IS06601(ALL)04/96]
This gauge shows you the battery voltage when
the ignition key is in the ON position.
*
[IS06700(ALL)01/96]
If you are running electrical accessories (when
the engine is off, or idling at a low speed), the
pointer may move toward the lower end of the
normal band. If it stays outside the normal band
area, have your vehicle's electrical system
checked as soon as it is safely possible.
*
[IS06701(ALL)04/96]
If the battery is operating under cold weather
conditions, the pointer may indicate in the upper
range of the NORMAL band while the battery is
charging. If you are running electrical accessories
with the engine off or idling at a low speed, or
the battery is not fully charged, the pointer may
move toward the lower end of the NORMAL
band.
*
[IS06750(ALL)04/96]
If it stays outside the NORMAL band, have your
vehicle's electrical system checked as soon as it
is safely possible.
*
[IS06900(ALL)03/96]
quarter page art:0020052-D
Battery voltage gauge
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 19 of 347
16 %
*
[IS07500(ALL)04/96]
Engine Oil Pressure Gauge
*
[IS07601(ALL)01/96]
This gauge indicates the engine's oil pressure,
not the oil level. However, if your engine's oil
level is low, it could affect the oil pressure. With
the engine running, the pointer should move
into the NORMAL band. If the pointer drops
below the NORMAL band while the engine is
running, you have lost oil pressure and
continued operation will cause severe engine
damage.
*
[IS07701(ALL)05/96]
If you lose engine oil pressure:
*
[IS07801(ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS07901(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
*
[IS08001(ALL)01/96]
3. Check the engine's oil level, following the
instructions on checking and adding engine
oil. Refer toEngine oilin the Index. If you
do not follow these instructions, you or
others could be injured. To assure an
accurate reading, your vehicle should be on
level ground.
*
[IS08051(ALL)01/96]
4. If the level is low, add only as much oil as
necessary before you start the engine again.
Do not overfill. Do not operate the engine if
the pointer is below the NORMAL band,
regardless of the oil level. Contact your
nearest dealer for further service actions.
*
[IS08200(ALL)03/96]
quarter page art:0020057-D
Engine oil pressure gauge
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 20 of 347
17 %
*
[IS09500(ALL)05/96]
Fuel Gauge
*
[IS09700(ALL)01/96]
The fuel gauge displays approximately how
much fuel is in the fuel tank only when the
ignition switch is ON.
*
[IS09850(ALL)01/96]
For a proper fuel gauge indication after adding
fuel, the ignition switch should be in the OFF
position while the vehicle is being refueled.
*
[IS09900(ALL)01/96]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. An accurate reading
may be obtained with the vehicle on smooth,
level ground.
[IS10000(ALL)01/96]
one inch art:0020061-C
Fuel gauge
%*
[IS11100(ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS11201(ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
*
[IS11301(ALL)05/96]
The pointer moves from the C (cold) mark into
the NORMAL band as the engine coolant warms
up. It is acceptable for the pointer to fluctuate
within the NORMAL band under normal driving
conditions. Under certain driving conditions,
such as heavy stop and go traffic or driving up
hills in hot weather, the pointer may move to
the top of the NORMAL band.
*
[IS11401(ALL)04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
