FORD AEROSTAR 1997 1.G Owner's Manual
Manufacturer: FORD, Model Year: 1997, Model line: AEROSTAR, Model: FORD AEROSTAR 1997 1.GPages: 347, PDF Size: 1.79 MB
Page 21 of 347
18
*
[IS11501(ALL)03/96]
If your engine overheats:
*
[IS11601(ALL)03/96]
1. Pull off the road as soon as it is safely
possible.
*
[IS11701(ALL)01/96]
2. Turn off the engine.
*
[IS11801(ALL)03/96]
3. Let the engine cool.DO NOT REMOVE
COOLANT SYSTEM FILL CAP UNTIL
THE ENGINE IS COOL.
*
[IS11901(ALL)01/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. Refer toEngine coolantin the
Index. If you do not follow these
instructions, you or others could be injured.
[IS12325(ALL)01/96]
quarter page art:0020541-B
Engine coolant temperature gauge
%*
[IS12601(ALL)03/96]
Speedometer
*
[IS12700(ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
*
[IS12750(ALL)03/96]
Your vehicle contains a speedometer which
receives its input from the Anti-Lock brake
sensor. The speedometer is also used to provide
a speed signal for correct operation of the
vehicle's Powertrain Control Module (PCM),
electronic transmission, and speed control (if so
equipped). Because of this, it is very
IMPORTANT to change the speedometer's
internal conversion constant if the size of the
tires on the vehicle is changed. Changing the
conversion constant to the proper value when
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 22 of 347
19
the tires are changed will also ensure that the
speedometer retains the original factory-set
accuracy.
[IS12752(ALL)01/96]
NOTE: The conversion constant can only be
changed six times once the vehicle
leaves the factory. Your Ford dealership
service personnel can change the
conversion constant.
*
[IS12753(ALL)03/96]
Some vehicles are equipped with a vehicle speed
(mph/km/h) limiting device that is contained
within the Powertrain Control Module (PCM).
The purpose of this device is to maintain peak
vehicle speed below a specified limit. (Vehicle
speed limits may vary based on engine
displacement.)
*
[IS12756(ALL)03/96]
If you are experiencing an ªengine cut-outº
condition at high speeds, it may be the result of
this limiting device. It is a normal condition and
can be avoided by reducing vehicle/engine
speed.
[IS12760(ALL)01/96]
one third page art:0095036-A
Speedometer
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 23 of 347
20 %
*
[IS13130(ALL)01/96]
Odometer/Trip Odometer
*
[IS13160(ALL)05/96]
The Liquid Crystal Display (LCD) odometer is a
combination trip odometer and total odometer.
The total odometer is normally displayed. To see
the trip odometer, press and release the SELECT
control on the upper right side of the
speedometer. To zero out the trip odometer,
press and release the RESET control on the
upper left side of the speedometer while the trip
odometer is displayed. If the trip odometer is
displayed, press and release the SELECT control
to return the display to the total odometer value.
File:03cpisa.ex
Update:Fri Jun 7 14:23:36 1996
Page 24 of 347
21
Electronic Sound Systems
*
[AS00200(ALL)08/95]
full page art:0060648-B
Compact Disc Radio
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 25 of 347
22
%*
[AS00250(ALL)10/95]
Compact Disc Radio
*
[AS00300(ALL)10/95]
The Compact Disc Radio combines the Electronic
Stereo Radio with the Ford Compact Disc Player.
*
[AS00350(ALL)08/95]
Using the Controls on Your New Radio/CD
Player
*
[AS00400(ALL)10/95]
Most of the features of this unit work for both
radio and CD operation. Also, some of the knobs
and buttons control several different functions,
so be sure to read all of the operating
instructions carefully.
*
[AS00450(ALL)03/96]
How to turn the radio on and off
*
[AS00500(ALL)10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS00550(ALL)03/96]
How to adjust the volume
[AS00600(ALL)08/95]
Press the (R/S) end of the ªVOLº button to
increase/decrease the volume. Bars illuminate in
the display to show the relative volume level.
*
[AS00650(ALL)02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS00700(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS00750(ALL)10/95]
Push the ªAM/FMº button to select the desired
frequency band. When in the radio mode,
pushing the button more than once will alternate
between AM, FM1 and FM2. These functions are
used with the station memory buttons described
underHow to tune radio stations.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 26 of 347
23 %
*
[AS00800(ALL)03/96]
How to tune radio stations
*
[AS00850(ALL)10/95]
There are four ways for you to tune in a
particular station. You can manually locate the
station using the ªSCAN/TUNEº button,
ªSEEKº the station, ªSCANº to the station or
select the station by using the memory buttons,
which you can set to any desired frequency.
These four methods are described below.
*
[AS00900(ALL)10/95]
q
Using the ªSCAN/TUNEº button to manually
tune
[AS00950(ALL)09/95]
You can change the frequency up or down
one increment at a time (FM changes in
increments of 200kHz; AM changes in
increments of 10kHz) by first pressing the
ªSCAN/TUNEº button twice (display shows
ªTUNEº), then Ðwithin approximately five
secondsÐpressing and releasing either the
top (
a) or bottom (
b) half of the ªSEEKº
button. To change frequencies quickly, press
andhold downeither the top or bottom half
of the ªSEEKº button. While you are
manually tuning, the display will show a
blinking ªM.º
*
[AS01000(ALL)03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 27 of 347
24
*
[AS01050(ALL)04/96]
q
Using the ªSEEKº function
*
[AS01075(ALL)04/96]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the top (
a)
half of the ªSEEKº button to select the next
listenable station up the frequency band.
Press the bottom (
b) half of the button to
select the next listenable station down the
frequency band. By pressing and holding the
button, listenable stations can be passed over
to reach the desired station.
*
[AS01100(ALL)02/96]
q
Using the ªSCAN/TUNEº button to scan
radio stations
*
[AS01150(ALL)04/96]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the top (
a) half of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately five
seconds. Pushing the bottom (
b) half of the
ªSEEKº button will begin the scan mode
down the frequency band, again stopping on
each listenable station for approximately five
seconds.
*
[AS01200(ALL)03/96]
To stop the scan mode on the presently
sampled station, press the ªSCAN/TUNEº
button again.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 28 of 347
25
*
[AS01250(ALL)06/96]
q
Setting the Station Memory Preset buttons
%*
[AS01300(ALL)06/96]
Your radio is equipped with 5 station
memory buttons. These buttons can be used
to select up to 5 preset AM stations and 10
FM stations (5 in FM1 and 5 in FM2). Follow
the easy steps below to set these buttons to
the desired frequencies.
*
[AS01350(ALL)06/96]
1. Select a band, then select a frequency.
*
[AS01400(ALL)06/96]
2. Press one of the memory preset buttons and
hold the button until the sound returns. That
station is now held in memory on that
button.
*
[AS01450(ALL)06/96]
3. Follow the two steps above for each station
memory preset button you want to set.
*
[AS01500(ALL)06/96]
NOTE: If the vehicle's battery is disconnected,
the clock and station memory preset
buttons (if programmed in auto mode)
will need to be reset.
*
[AS01550(ALL)10/95]
q
Using the Automatic Memory Load feature
*
[AS01600(ALL)08/95]
You can activate theAuto Memory Load
feature by pressing and holding the ªAUTO
PRESETº buttonfor approximately three
seconds. Auto Memory Load sets all memory
buttons in AM, FM1 and FM2 sequentially by
seeking out the first five strong stations for
the respective band and storing them in
memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM
band.)
*
[AS01650(ALL)05/96]
With Auto Memory Store, you can continually
set strong stations into your memory buttons
without losing your existing memory presets,
which is especially helpful while traveling. Your
radio will automatically set your memory
buttons to the strong local stations so you don't
have to continually manually tune to existing
stations.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 29 of 347
26
*
[AS01700(ALL)02/96]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio will
set the first five strong stations of the band you
are in (AM, FM1 or FM2) into the memory
buttons. The display will show ªAUTO,º then
run through the frequencies, stopping
momentarily on the stations being set into the
memory buttons. The radio is now in the
ªAUTOº mode and the display will show
ªAUTOº each time a preset is activated.
*
[AS01750(ALL)10/95]
NOTE: If there are fewer than five strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band.
*
[AS01800(ALL)03/96]
After all stations have been filled, the radio will
begin playing the station stored on memory
button 1.
*
[AS01850(ALL)02/96]
To deactivate the Auto Memory Store mode and
return to the manually-set memory button
stations (or those stations set using Auto
Memory Load), simply push the ªAUTO
PRESETº button. Display will show ªAUTOº
then ªOFF.º The next time Auto Memory Store
is activated on that band, the radio will store the
next set of five strong stations.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 30 of 347
27
*
[AS01900(ALL)08/95]
Using the ªAUDIOº button to adjust the
tone balance and speaker output
*
[AS01950(ALL)02/96]
q
Increasing or decreasing bass response
*
[AS02000(ALL)08/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the ª+º side
of the ªVOLº button to increase bass (more
ªlowsº), and push the ª-º side to decrease
bass (less ªlowsº).
*
[AS02025(ALL)02/96]
q
Increasing or decreasing treble response
*
[AS02050(ALL)08/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the ª+º side
of the ªVOLº button to increase treble (more
ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS02100(ALL)02/96]
q
Adjusting speaker balance
*
[AS02150(ALL)08/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the ª+º side of the ªVOLº button to
shift the sound to the right speakers, and
push the ª-º side to shift the sound to the
left speakers.
*
[AS02200(ALL)04/96]
q
Adjusting speaker fader
*
[AS02250(ALL)08/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the ª+º side of the ªVOLº button to
shift the sound to the front speakers, and
push the ª-º side to shift the sound to the
rear speakers.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
