Using the ªSCANº function
[AS04150(ALL)08/95]
Pressing the ªSCAN/TUNEº button once
enters the scan mode (display will indicate
ªSCNº). Pushing the right (
a) side of the
ªSEEKº button will begin the scan mode up
the frequency band, stopping on each
listenable station for approximately a
five-second sampling. Pushing the left (
b)
side of the ªSEEKº button will begin the scan
mode down the frequency band, again
stopping on each listenable station for
approximately a five-second sampling.
*
[AS04175(ALL)03/96]
To stop the scan mode on the presently
sampled station, press the ªSCAN/TUNEº
button again.
*
[AS04200(ALL)06/96]
q
Setting the Station Memory Preset buttons
[AS04225(ALL)08/95]
Your radio is equipped with 5 station
memory buttons. These buttons can be used
to select up to 5 preset AM stations and 10
FM stations (5 in FM1 and 5 in FM2).
*
[AS04250(ALL)08/95]
Follow the easy steps below to set these buttons
to the desired frequencies:
*
[AS04275(ALL)06/96]
1. Select a band, then select a frequency.
[AS04300(ALL)08/95]
2. Press one of the memory buttons and hold
the button until the sound returns. That
station is now held in memory on that
button.
*
[AS04325(ALL)06/96]
3. Follow the two steps above for each station
memory preset button you want to set.
[AS04350(ALL)08/95]
NOTE: If the vehicle's battery is disconnected,
the station memory preset buttons (if
programmed in auto mode) will need
to be reset.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 42 of 347
39
*
[AS04375(ALL)10/95]
q
Using the Automatic Memory Load feature
*
[AS04400(ALL)08/95]
You can activate theAuto Memory Load
feature by pressing and holding the ªAUTO
PRESETº buttonfor approximately three
seconds. Auto Memory Load sets all memory
buttons in AM, FM1 and FM2 sequentially by
seeking out the first five strong stations for
the respective band and storing them in
memory buttons 1-5. (FM2 will store the
second set of strong stations from the FM
band.)
*
[AS04425(ALL)05/96]
With Auto Memory Store, you can continually
set strong stations into your memory buttons
without losing your existing memory presets,
which is especially helpful while traveling. Your
radio will automatically set your memory
buttons to the strong local stations so you don't
have to continually manually tune to existing
stations.
*
[AS04450(ALL)02/96]
Activate Auto Memory Store by pushing the
ªAUTO PRESETº button once. Your radio will
set the first five strong stations of the band you
are in (AM, FM1 or FM2) into the memory
buttons. The display will show ªAUTO,º then
run through the frequencies, stopping
momentarily on the stations being set into the
memory buttons. The radio is now in the
ªAUTOº mode and the display will show
ªAUTOº each time a preset is activated.
*
[AS04475(ALL)10/95]
NOTE: If there are fewer than five strong
stations in the frequency band, the
remaining unfilled buttons will store
the last strong station detected on the
band.
*
[AS04500(ALL)03/96]
After all stations have been filled, the radio will
begin playing the station stored on memory
button 1.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 43 of 347
40
*
[AS04525(ALL)02/96]
To deactivate the Auto Memory Store mode and
return to the manually-set memory button
stations (or those stations set using Auto
Memory Load), simply push the ªAUTO
PRESETº button. Display will show ªAUTOº
then ªOFF.º The next time Auto Memory Store
is activated on that band, the radio will store the
next set of five strong stations.
*
[AS04550(ALL)10/95]
Adjusting the tone balance and speaker
output of your radio
*
[AS04575(ALL)02/96]
q
Increasing or decreasing bass response
*
[AS04600(ALL)08/95]
Push the ªAUDIOº button repeatedly until
the display reads ªBASS.º Push the ª+º side
of the ªVOLº button to increase bass (more
ªlowsº), and push the ª-º side to decrease
bass (less ªlowsº).
*
[AS04625(ALL)02/96]
q
Increasing or decreasing treble response
*
[AS04650(ALL)08/95]
Push the ªAUDIOº button repeatedly until
the display reads ªTREB.º Push the ª+º side
of the ªVOLº button to increase treble (more
ªhighsº), and push the ª-º side to decrease
treble (less ªhighsº).
*
[AS04675(ALL)02/96]
q
Adjusting speaker balance
*
[AS04700(ALL)08/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBAL.º
Push the ª+º side of the ªVOLº button to
shift the sound to the right speakers, and
push the ª-º side to shift the sound to the
left speakers.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 44 of 347
41
*
[AS04725(ALL)04/96]
q
Adjusting speaker fader
*
[AS04750(ALL)08/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADE.º
Push the ª+º side of the ªVOLº button to
shift the sound to the front speakers, and
push the ª-º side to shift the sound to the
rear speakers.
*
[AS04775(ALL)09/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble and
positions of speaker balance and fader
functions after adjustments are made,
then revert to volume level set.
[AS04800(ALL)05/96]
Using the Controls of Your Cassette Tape
Player (If equipped)
*
[AS04825(ALL)08/95]
How to insert a tape
*
[AS04850(ALL)08/95]
Your cassette tape player is equipped with
power loading. Once you insert a tape and push
slightly (with theopen edge to the right), the
loading mechanism draws the tape the rest of
the way in and play will begin after a
momentary tape tightening process. Display
indicates ªMº (for metal/CrO
2) while tape is
playing.
*
[AS04875(ALL)08/95]
NOTE: A cassette tape can be loaded with the
ignition on whether or not the radio
power is on.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 45 of 347
42
*
[AS04900(ALL)12/95]
How to locate a desired track on the tape
*
[AS04925(ALL)08/95]
There are four ways to quickly locate a desired
selection on the tape. You can use the fast
forward, rewind, ªSEEKº or ªSCANº function.
Following are brief descriptions of each.
*
[AS04950(ALL)09/95]
q
Fast forwarding the tape
*
[AS04975(ALL)03/96]
To fast forward the tape, press the ªFFº
button. The radio will automatically begin
playing until fast forward is manually
stopped. At the end of the tape, the direction
automatically reverses and plays the other
side of the tape.
*
[AS05000(ALL)08/95]
q
Rewinding the tape
*
[AS05025(ALL)08/95]
To rewind the tape, press the ªREWº button.
[AS05050(ALL)04/96]
The radio will automatically begin playing
until rewind is manually stopped or the
beginning of the tape is reached.
*
[AS05075(ALL)08/95]
q
Using the ªSEEKº function with your cassette
tape player
*
[AS05100(ALL)03/96]
While in the tape mode, push the right
a
side of the ªSEEKº button to seek forward to
the next selection on the tape. Push the left
bside to seek the previous tape selection.
*
[AS05125(ALL)03/96]
NOTE: If you want to restart a currently
playing tape selection, press the left
b
side of the ªSEEKº button after
approximately three seconds into the
current selection.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 46 of 347
43
*
[AS05150(ALL)03/96]
Whirling sprockets in the displaylindicate
the direction of tape travel.
*
[AS05175(ALL)08/95]
q
Using the ªSCANº function with your
cassette tape player
*
[AS05200(ALL)03/96]
Press the ªSCAN/TUNEº button to enter the
scan mode (display indicates ªSCNº).
Pushing the right
aside of the ªSEEKº
button will begin the forward scan mode on
the tape currently playing, stopping on each
tape selection for approximately an
eight-second sampling.
*
[AS05225(ALL)03/96]
Pushing the left
bside of the ªSEEKº
button will begin the reverse scan mode,
stopping on each previous tape selection for
approximately an eight-second sampling.
While scanning, the display indicates whirling
sprockets plus an ªSºm.
*
[AS05250(ALL)03/96]
To stop the scan mode on the presently
sampled tape selection, press the
ªSCAN/TUNEº button again.
*
[AS05275(ALL)08/95]
q
How to change the side of the tape being
played
*
[AS05300(ALL)08/95]
The alternate track of the tape can be selected
anytime by pressing the ªPLAY/PROGº
button.
*
[AS05325(ALL)08/95]
How to eject the tape
*
[AS05350(ALL)08/95]
To stop the tape and eject the cassette, press the
ªEJCTº button. The radio will resume playing if
the radio power is on. The tape cartridge can be
ejected with radio power (and/or ignition) on or
off.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 47 of 347
44
*
[AS05375(ALL)08/95]
How to store the tape
*
[AS05400(ALL)08/95]
Press the ªAM/FMº button to stop the tape
player and resume radio play. The cassette will
be stored in the tape player and the
Xsymbol
in the display will be lit until you push the
ªPLAY PROGº button to resume tape play. Fast
forward and fast rewind can be used while the
tape is in storage mode without interrupting
radio play.
*
[AS05425(ALL)02/96]
Using the DolbyHB noise reduction feature
*
[AS05450(ALL)09/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS05475(ALL)08/95]
Push thekbutton to activate. When on, the
ksymbol above the button will be lit.
%*
[AS05500(ALL)05/96]
Clock Operation
*
[AS05525(ALL)05/96]
How to view the clock mode
*
[AS05550(ALL)08/95]
Press the ªCLOCKº button to alternate the
frequency and time in the display. In the clock
mode, pressing any radio function will
automatically display the radio frequency for
approximately ten seconds before changing back
to the clock mode.
*
[AS05575(ALL)05/96]
How to set the clock
*
[AS05600(ALL)05/96]
1. Turn the radio on.
*
[AS05625(ALL)04/96]
2. Press and hold in the ªCLOCKº button.
Press the ªSEEKº button left (
b) to advance
the hours and right (
a) to advance the
minutes.
*
[AS05650(ALL)05/96]
NOTE: The clock displays 12-hour time with
no AM/PM indications.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 48 of 347
45
*
[AS05675(ALL)09/95]
NOTE: On the High-Level Audio System, the
clock can be set with the radio power
on or off.
*
[AS05700(ALL)08/95]
Tape error messages
*
[AS05725(ALL)08/95]
Your cassette tape player is equipped to
diagnose certain problems you may experience.
Error codes are as follows:
*
[AS05750(ALL)08/95]
Error 0Ð Communication error between the
radio controller and the tape controller. The
cassette player will eject the tape. Insert the tape
again. If the same error code appears, turn the
ignition off, then back on again and insert the
tape.
*
[AS05775(ALL)08/95]
Error 1Ð Possible problem cartridge. The
cassette tape player will eject the tape. Insert the
tape again. If the same error code appears in the
display, try a different cartridge.
*
[AS05800(ALL)08/95]
Error 2Ð Tape eject or load failure. Your
cassette tape player will go into the pause mode.
Push ªEJCTº to eject the tape. If the tape doesn't
eject, refer the problem to qualified personnel for
service.
*
[AS05825(ALL)05/96]
Tips on Caring for the Cassette Player and
Tapes
*
[AS05850(ALL)08/95]
In order to keep your cassette tape player
performing the way it was meant to, read and
follow these simple precautions:
*
[AS05875(ALL)05/96]
q
Using a Ford or equivalent cassette cleaning
cartridge to clean the tape player head after
10-12 hours of play will help maintain the
best playback sound and proper tape
operation.
*
[AS05900(ALL)08/95]
q
Only cassettes that are 90 minutes long or
less should be used. Tapes longer than 90
minutes are thinner and subject to breakage
or may jam the tape player mechanism.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 49 of 347
46
*
[AS05925(ALL)08/95]
q
Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions, allow them to reach a moderate
temperature before playing.
*
[AS05950(ALL)08/95]
q
If a tape is loose inside the cassette, tighten it
before playing by putting your finger or a
pencil into one of the holes and turning the
hub until the tape is tight.
*
[AS05975(ALL)08/95]
q
Loose labels on cassette tapes can become
lodged in the mechanism. Remove any loose
label material before inserting cassette.
*
[AS06000(ALL)08/95]
q
Do not leave a tape in the cassette tape
player. High heat in the vehicle can cause the
cassette to warp.
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
Page 50 of 347
47
*
[AS06550(ALL)02/96]
full page art:0060586-C
Electronic Stereo Radio
File:04cpasa.ex
Update:Fri Jun 7 14:24:14 1996
