FORD AEROSTAR 1997 1.G Owners Manual

252
*
[MC24900(ALL)02/96]
Wiper blade replacement
*
[MC25000(ALL)01/96]
If the wiper blades still do not work properly
after you clean them, you may need to replace
the wiper blade assembly or the blade element.
When replacing the wiper blade assembly, blade
refill, or wiper arm always use a Motorcraft part
or equivalent. To replace the blades, follow the
instructions that come with them.
%
*
[MC25200(ALL)01/96]
Tires
*
[MC25300(ALL)03/96]
Look at your tires each time you fill your fuel
tank. If one tire looks lower than the others,
check the pressure in all of them. Always follow
these precautions:
*
[MC25400(ALL)02/96]
q
Use an accurate tire pressure gauge.
*
[MC25500(ALL)02/96]
q
Check the tire pressure when tires are cold,
after the vehicle has been parked for at least
one hour or has been driven less than 3 miles
(5 km).
*
[MC25600(ALL)03/96]
q
Make sure the weight of your load is evenly
distributed.
*
[MC25700(ALL)03/96]
q
Adjust tire pressure to recommended
specifications found on the Safety Compliance
Certification Label.
[MC25750(ALL)01/96]
q
Make sure the spare tire is mounted and
anchored properly in the tire carrier without
contacting functional parts such as brake
tubes, fuel lines, exhaust pipes, etc.
*
[MC25800(ALL)03/96]
If you do not take these precautions, your tires
may fail or go flat.
*
[MC25890(ALL)03/96]
Ford Motor Company recommends obeying
posted speed limits.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

253
*
[MC25900(ALL)03/96]
RWARNING
Driving too fast for conditions creates the
possibility of loss of vehicle control.
Driving at very high speeds for extended
periods of time may result in damage to
vehicle components.
%*
[MC26100(ALL)03/96]
At least once a month, check the pressure in all
your vehicle's tires, including the spare. Use an
accurate tire pressure gauge. Check the tire
pressure when tires are cold, after the vehicle
has been parked for at least one hour or has
been driven less than 3 miles (5 km). You can
find proper cold pressure and load limits of
recommended size tires on the Safety
Compliance Certification Label.
*
[MC26150(ALL)01/96]
RWARNING
Improperly inflated tires can affect vehicle
handling and can fail suddenly, possibly
resulting in loss of vehicle control.
%*
[MC26200(ALL)01/96]
Tire Inspection and Maintenance
*
[MC26300(ALL)03/96]
Inspect the tire treads, and remove stones, nails,
glass or other objects that may be wedged in the
tread grooves. Check for holes or cuts that may
permit air to leak from the tire, and make the
necessary repairs.
*
[MC26400(ALL)03/96]
Inspect the tire side walls for cuts, bruises and
other damage. If you suspect internal damage to
the tire, have it demounted and checked. You
may need to repair or replace it.
[MC26410(ALL)01/96]
Wheel inspection and maintenance
*
[MC26420(ALL)03/96]
Check for damage that would affect the runout
of the wheels. Wobble or shimmy will eventually
damage the wheel bearings.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

254
*
[MC26430(ALL)03/96]
Front wheel bearings require periodic repacking
and adjustment as specified in theMaintenance
Schedulebooklet. Loose or worn front wheel
bearings tend to let the vehicle wander or
shimmy, and can eventually cause excessive tire
wear.
*
[MC26435(ALL)03/96]
Whenever a wheel is removed and then
re-installed, always remove any corrosion that
may be present on the mounting surface of the
wheel and/or the surface of the hub, drum or
rotor that contacts the wheel.
*
[MC26440(ALL)03/96]
RWARNING
Installing wheels without a good
metal-to-metal contact at the wheel
mounting surface can cause the wheel lug
nuts to loosen and could allow the wheel
to come off while the vehicle is in motion.
[MC26447(ALL)01/96]
RWARNING
On-vehicle wheel balancing will cause
damage to the drivetrain of E-4WD
Aerostars.
%
*
[MC26450(ALL)05/96]
Traction-Lok Rear Axle
(If equipped)
*
[MC26460(ALL)05/96]
This axle provides added drive away traction on
slippery surfaces, particularly when one or more
wheels are on a surface with poor traction.
*
[MC26470(ALL)05/96]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

255 %
*
[MC26500(ALL)01/96]
Tire Rotation
*
[MC26600(ALL)01/96]
Because your vehicle's front and rear tires
perform different jobs, they often wear
differently. To make sure your tires wear evenly
and last longer, rotate them as indicated in the
following diagram.
*
[MC26700(ALL)05/96]
For tire rotation intervals, see theMaintenance
Schedulebooklet. If you notice that the tires wear
unevenly, have them checked.
*
[MC26750(ALL)03/96]
In situations where the tires differ from front to
rear (snow/traction), simply rotate using a side
to side pattern.
*
[MC26800(ALL)01/96]
half page art:0020364-A
Tire rotation pattern
*
[MC26900(ALL)03/96]
After each rotation, adjust individual tire
pressure as specified on the Safety Compliance
Certification Label. Tighten wheel lug nuts to the
required torque specification and retighten again
after 500 miles (800 km).
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

256
*
[MC27000(ALL)03/96]
If your vehicle has aluminum wheels, you may
demount the full size, non-temporary spare
tire (if so equipped) and remount on an
aluminum wheel to rotate the spare tire into
your vehicle's rotation pattern. Rebalance the
wheel.
[MC27100(ALL)04/96]
You may discover uneven outside shoulder wear
on your vehicle's front radial tires if you drive
often in the city and turn frequently around
curbs. You can extend the life of your front tires
by remounting them so the outside of the tire
faces inside on the wheel rim.
%*
[MC27300(ALL)01/96]
Replacing the Tires
*
[MC27400(ALL)01/96]
Replace any tires that show wear bands. When
your tire shows a wear band, it has only 1/16
inch (2 mm) of tread left.
*
[MC27500(ALL)01/96]
quarter page art:0060006-A
Wear band
*
[MC27600(ALL)02/96]
Because your vehicle's tires may wear unevenly,
you may need to replace them before a wear
band appears across the entire tread.
*
[MC27700(ALL)03/96]
Your wheels and tires are match-mounted for
improved ride. Before you begin to repair a tire,
mark the wheel and tire so that they are
properly aligned when remounted. This will
ensure that the tires will continue to give you
the same ride level.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

257
*
[MC27851(ALL)01/96]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
*
[MC27860(ALL)03/96]
RWARNING
Make sure that all replacement tires are of
the same size, type, load-carrying capacity,
and tread design (e.g. ªAll Terrainº, etc.),
as originally offered by Ford.
*
[MC27885(ALL)03/96]
RWARNING
Do not replace your tires with ªhigh
performanceº tires or larger size tires.
*
[MC27895(ALL)03/96]
RWARNING
Failure to follow these precautions may
adversely affect the handling of the
vehicle and make it easier to lose control
and roll over.
*
[MC27900(ALL)01/96]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

258 [MC28100(ALL)01/96]
three fourths page art:0020366-ETire identification chart
*
[MC28700(ALL)03/96]
RWARNING
Use of aftermarket wheel assemblies may
damage your vehicle or cause accidents
resulting in serious injuries.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

259 %
*
[MC28800(ALL)03/96]
Wheel and Tire Matching
*
[MC28950(ALL)03/96]
See an authorized tire dealer for proper
servicing procedures. Wheels and tires must be
properly removed, matched and remounted to
maintain the best possible ride.
%*
[MC31100(ALL)01/96]
Snow Tires and Chains
*
[MC31200(ALL)03/96]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[MC31300(ALL)01/96]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[MC31400(ALL)01/96]
Do not use chains when using a temporary
spare. For full size tires, use chains on the tires
only in an emergency or if the law requires
them where you live. When you use the tire
chains:
*
[MC31500(ALL)01/96]
q
Make sure the chains are the right size for
your tires. Use only SAE Class ªSº chains.
Other types may damage your vehicle.
*
[MC31550(ALL)01/96]
q
Tire chains may scratch or chip aluminum
wheels. IT IS RECOMMENDED THAT TIRE
CHAINS ARE INSTALLED ON STEEL
WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before
using tire chains to avoid scratches or
damage.
*
[MC31575(ALL)01/96]
q
Local regulations may prohibit or restrict the
use of tire chains. Investigate the laws and
regulations in your area before installing
chains.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

260 [MC31625(ALL)01/96]q
Put the chains on tightly with the ends held
down securely. Verify that no chain touches
any wiring, brake lines or fuel lines.
Retighten the chains after driving 1/2 mile
(0.8 km). Follow the chain manufacturer's
instructions.
*
[MC31650(ALL)01/96]
q
Do not drive faster than 30 mph (48 km/h)
or the chain manufacturer's recommended
speed limit, whichever is lower. Avoid
bumps, holes and sharp turns. If you can
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[MC31750(ALL)01/96]
q
Tire chains may affect vehicle handling. Drive
carefully and avoid hard braking.
*
[MC31800(ALL)01/96]
q
Avoid fully loading your vehicle if possible.
*
[MC31900(ALL)01/96]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
*
[MC31950(ALL)01/96]
q
Make sure your suspension insulation and
bumpers are not missing or worn to avoid
damage to your vehicle.
%
*
[MC35000(ALL)01/96]
Filling the Fuel Tank
[MC35100(ALL)01/96]
quarter page art:0020347-C
Fuel filler door
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996

261 %
*
[MC35200(ALL)01/96]
Opening the Fuel Filler Door
[MC35300(ALL)01/96]
Fuel filler door remote release
[MC35400(ALL)05/96]
To open the fuel filler door latch, pull on the
release lever located between the driver's seat
and the door. You cannot open the fuel filler
door by pulling on the door itself.
[MC35500(ALL)01/96]
one third page art:0020353-B
Fuel filler door remote release lever
[MC35600(ALL)01/96]
If the release lever is stuck or damaged and you
cannot open the fuel filler door, you must use
the override cord located at the back of the left
rear wheelhouse. (On extended versions the
release lever is located in the stowage box.)
[MC35700(ALL)01/96]
The manual release cord is attached to a T
handle marked FUEL FILLER DOOR RELEASE
Ð MANUAL OVERRIDE. When you pull it, the
fuel filler door opens.
File:11cpmca.ex
Update:Fri Jun 7 14:30:56 1996
