FORD ASPIRE 1996 1.G User Guide
Manufacturer: FORD, Model Year: 1996, Model line: ASPIRE, Model: FORD ASPIRE 1996 1.GPages: 268, PDF Size: 2.2 MB
Page 11 of 268
8
*
[IN07100(ALL)04/95]
Cleaning the Outside of Your
Vehicle
*
[IN07200(ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN07300(ALL)04/95]
Wash the outside of your vehicle, including the
underside, with a mild detergent.
*
[IN07400(ALL)06/95]
DO NOT:
*
[IN07500(ALL)04/95]
q
Wash your vehicle with hot water
*
[IN07600(ALL)04/95]
q
Wash your vehicle while it sits in direct
sunlight
*
[IN07700(ALL)04/95]
q
Wash your vehicle while the body is hot
*
[IN07800(ALL)07/95]
Pollen, bird droppings and tree sap can damage
the paint, especially in hot weather. Wash your
vehicle as often as necessary to keep it clean.
*
[IN07900(ALL)07/95]
Take similar precautions if your vehicle is
exposed to chemical industrial fallout.
*
[IN08000(ALL)07/95]
Paint damage resulting from fallout is not
related to a defect in paint materials or
workmanship and therefore is not covered by
warranty. Ford, however, believes that continual
improvement in customer satisfaction is a high
priority. For this reason, Ford has authorized its
dealers to repair, at no charge to the owner, the
surfaces of new vehicles damaged by
environmental fallout within 12 months or 12,000
miles (20,000 km) of purchase, whichever comes
first. Customers may be required to bring their
vehicle in for inspection by a Ford
representative.
*
[IN08100(ALL)04/95]
Polish your vehicle to remove harmful deposits
and protect the finish.
File:02icinf.ex
Update:Wed Jan 24 14:28:18 1996
Page 12 of 268
9
*
[IN08200(ALL)04/95]
Cleaning Chrome and Aluminum Parts
[IN08300(ALL)05/95]
Wash chrome and aluminum parts with a mild
detergent. Do not use steel wool, abrasive
cleaners, fuel or strong detergents.
*
[IN08400(ALL)04/95]
Cleaning Plastic Parts
*
[IN08500(ALL)04/95]
Some of your vehicle's exterior trim parts are
plastic. Clean with a tar and road oil remover if
necessary. Use a vinyl cleaner for routine
cleaning.
*
[IN08600(ALL)04/95]
Do not clean plastic parts with thinners, solvents
or petroleum-based cleaners.
%*
[IN08700(ALL)04/95]
If you have your vehicle rustproofed, remove
oversprayed rustproofing with a tar and road oil
remover. If rustproofing is not removed from
plastic and rubber parts, it can cause
deterioration.
File:02icinf.ex
Update:Wed Jan 24 14:28:18 1996
Page 13 of 268
11
Safety Restraints
*
[SR00500(ALL)04/95]
Important Safety Belt Information
*
[SR00600(ALL)03/95]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada the law requires their use.
*
[SR00700(ALL)01/95]
Safety belts provide best restraint when:
*
[SR00800(ALL)01/95]
q
the seatback is upright
*
[SR00900(ALL)01/95]
q
the occupant is sitting upright (not slouched)
*
[SR01000(ALL)01/95]
q
the lap belt is snug and low on the hips
*
[SR01100(ALL)01/95]
q
the shoulder belt is snug against the chest
*
[SR01200(ALL)01/95]
q
the knees are straight forward
*
[SR01350(ALL)07/95]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theWarning Lights and Gaugeschapter.
*
[SR02000(ALL)07/95]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
%*
[SR02100(ALL)05/95]
RWARNING
Make sure that you and your passengers
wear safety belts. Always drive and ride
with your seatback upright and the lap
belt snug and low across the hips.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 14 of 268
12
*
[SR02200(ALL)06/95]
RWARNING
Never wear the shoulder belt under the
arm. Never swing it around the neck over
the inside shoulder. Never use a single
belt for more than one person or across
more than one seating position. Each
seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair.
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision.
[SR02400(ALL)07/95]
RWARNING
Never drive or ride with a twisted or
jammed safety belt. If you cannot untwist
or unjam the safety belt, see the nearest
qualified technician immediately.
*
[SR02800(ALL)07/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR02825(ALL)07/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR02850(ALL)05/95]
Lock the doors of your vehicle before driving to
lessen the risk of the door coming open in a
collision.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 15 of 268
13
*
[SR03400(ALL)05/95]
Combination Lap and Shoulder
Belts
*
[SR03500(ALL)06/95]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, turn hard, or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap/shoulder belt locks
and helps reduce your forward movement.
*
[SR03600(ALL)05/95]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SR03700(ALL)07/95]
To fasten the belt, pull the combination
lap/shoulder belt from the retractor so that the
shoulder portion of the belt crosses your
shoulder and chest. Be sure the belt is not
twisted. If it is, remove the twist. Insert the belt
tongue into the proper buckle until you hear a
snap and feel it latch. Make sure the tongue is
securely fastened to the buckle by pulling on
tongue.
[SR03800(ALL)05/93]
one third page art:0032150-A
Fastening the safety belt
*
[SR03850(ALL)06/95]
Adjust the lap part of the belt by pulling up on
the shoulder belt until the lap belt fits snugly
and as low as possible around your hips.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 16 of 268
14
*
[SR03860(ALL)06/95]
NOTE: Be sure to read and understand
Important Safety Belt Informationat
the beginning of this chapter.
[SR05300(ALL)07/95]
one third page art:0032252-B
Unfastening the combination lap/shoulder belts Ð front
and rear outboard seating positions
*
[SR05400(ALL)05/95]
While the belt retracts, guide the tongue to its
original position to prevent it from striking you
or the vehicle.
[SR09320(ALL)05/95]
Passenger Seat Lap/Shoulder Belt
Retractors (Dual Locking Modes)
*
[SR09330(ALL)06/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for all
passengers.
[SR09340(ALL)05/95]
Dual locking mode retractors operate in two
ways:
*
[SR09350(ALL)06/95]
Vehicle sensitive (emergency) locking mode
[SR09360(ALL)05/95]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering, or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling on the belt.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 17 of 268
15
*
[SR09370(ALL)05/95]
Automatic locking mode
*
[SR09380(ALL)07/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and will
remain locked when the combination
lap/shoulder safety belt is buckled, and does not
allow the occupant freedom of movement. This
mode provides the following:
*
[SR09390(ALL)07/95]
q
A tight lap/shoulder belt on the occupant.
*
[SR09400(ALL)07/95]
q
Child safety seat installation.
*
[SR09410(ALL)07/95]
RWARNING
Rear-facing infant seats should never be
placed in the front seats.
*
[SR09420(ALL)07/95]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR09430(ALL)07/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR09440(ALL)07/95]
1. Buckle the lap/shoulder combination belt.
*
[SR09450(ALL)07/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted, and when allowed to retract, a
clicking sound will be heard. At this time,
the belt retractor is in the automatic locking
mode (child restraint mode).
*
[SR09460(ALL)07/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract. This
indicates that the retractor is in the
automatic locking mode.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 18 of 268
16
*
[SR09470(ALL)07/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
%*
[SR09475(ALL)07/95]
Safety Belt Extension Assembly
*
[SR09478(ALL)07/95]
For some people, the safety belt may be too
short even when it is fully extended. You can
add about eight inches (20 cm) to the belt length
with a safety belt extension assembly (part
number 611C22). Safety belt extensions are
available at no cost from your dealer.
*
[SR09482(ALL)07/95]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
*
[SR09484(ALL)07/95]
Safety Belt Maintenance
*
[SR09486(ALL)07/95]
Check the safety belt systems periodically to
make sure that they work properly and are not
damaged.
%*
[SR09488(ALL)07/95]
All safety belt assemblies, including retractors,
buckles, front seat belt buckle support assemblies
(slide bar) (if equipped), child safety seat tether
bracket assemblies (if equipped), and attaching
hardware, should be inspected after any
collision. Ford recommends that all safety belt
assemblies used in vehicles involved in a
collision be replaced. However, if the collision
was minor and a qualified technician finds that
the belts do not show damage and continue to
operate properly, they do not need to be
replaced. Safety belt assemblies not in use
during a collision should also be inspected and
replaced if either damage or improper operation
is noted.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 19 of 268
17 %
*
[SR09500(ALL)06/95]
Cleaning the Safety Belts
*
[SR09525(ALL)06/95]
Clean the safety belts with any mild soap
solution that is recommended for cleaning
upholstery or carpets. Do not bleach or dye the
belt webbing because this may weaken it.
*
[SR11700(ALL)06/95]
Air Bag Supplemental Restraint
System (SRS)
*
[SR11960(ALL)05/95]
The driver and right front passenger air bags are
Supplemental Restraint Systems (SRS), provided
at these seating positions in addition to the
lap/shoulder belt, and are designed to
supplement the protection provided to properly
belted occupants in moderate to severe frontal
collisions. The supplemental air bag system does
not provide restraint to the lower body.
*
[SR12000(ALL)05/95]
The Importance of Wearing Safety Belts
*
[SR12100(ALL)06/95]
RWARNING
Safety belts must be worn by all vehicle
occupants to be properly restrained and
help reduce the risk of injury in a
collision.
*
[SR12150(ALL)05/95]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, even when an air bag Supplemental
Restraint System is provided.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
Page 20 of 268
18
*
[SR12200(ALL)01/95]
There are four very important reasons to use
safety belts even with an air bag system. Use
your safety belts to:
*
[SR12300(ALL)01/95]
q
help keep you in the proper position (away
from the air bag) when it inflates
*
[SR12400(ALL)01/95]
q
reduce the risk of harm in rollover, side or
rear impact collisions, because an air bag is
not designed to inflate in such situations
*
[SR12500(ALL)01/95]
q
reduce the risk of harm in frontal collisions
that are not severe enough to activate the
supplemental air bag
*
[SR12600(ALL)01/95]
q
reduce the risk of being thrown from your
vehicle
%*
[SR12700(ALL)01/95]
The Importance of Being Properly Seated
*
[SR12800(ALL)05/95]
In a collision, the air bag must inflate extremely
fast to help provide additional protection for
you. In order to do this, the air bag must inflate
with considerable force. If you are not seated in
a normal riding position with your back against
the seatback, the air bag may not protect you
properly and could possibly hurt you as it
inflates.
*
[SR12850(ALL)07/95]
RWARNING
If a passenger is not properly seated and
restrained, an inflating air bag could cause
serious injury.
*
[SR12870(ALL)07/95]
RWARNING
Rear-facing infant seats should never be
placed in the front seat.
File:03icsrf.ex
Update:Wed Jan 24 14:30:01 1996
