[ST06800(ALL)04/95]
For a cold engine:
*
[ST06810(ALL)06/95]
q
At temperatures10ÊF (-12ÊC) andbelow:If
the engine does not start infifteen (15)
secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you
do not flood the engine, then try again.
*
[ST06820(ALL)04/95]
q
At temperaturesabove10ÊF(-12ÊC):If the
engine does not start infive (5) secondson
the first try, turn the key to OFF, wait
approximately ten (10) seconds so you do not
flood the engine, then try again.
%*
[ST06830(ALL)05/95]
For a warm engine:
*
[ST06840(ALL)04/95]
q
Do not hold the key in the START position
for more thanfive (5) secondsat a time. If
the engine does not start within five (5)
seconds on the first try, turn the key to the
OFF position. Wait a few seconds after the
starter stops, then try again.
*
[ST06843(ALL)07/95]
Whenever you start your vehicle, release the key
as soon as the engine starts. Excessive cranking
could damage the starter.
*
[ST06845(ALL)05/95]
After starting, allow the engine to idle for a few
seconds before driving away.
*
[ST06847(ALL)05/95]
NOTE: Automatic transaxle equipped vehicles
have an interlock that prevents you
from shifting out of P (Park) unless
your foot is on the brake pedal.
%*
[ST06860(ALL)04/95]
If the engine does not start after two attempts:
*
[ST06865(ALL)04/95]
1. Turn the ignition key to the OFF position.
*
[ST06870(ALL)04/95]
2. Press the accelerator all the way to the floor
and hold it.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

50
*
[ST06875(ALL)04/95]
3. Turn the ignition key to the START position.
*
[ST06880(ALL)04/95]
4. Release the ignition key when the engine
starts.
*
[ST06885(ALL)04/95]
5. Release the accelerator gradually as the
engine speeds up. Then drive away in the
normal manner.
*
[ST06890(ALL)04/95]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchlater in this chapter.
*
[ST08350(ALL)10/95]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs high. These faster
engine speeds will make your vehicle coast
slightly faster than its normal idle speed. It
should, however, slow down after a short time.
If it does not, have the idle speed checked.
*
[ST08365(ALL)07/95]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[ST08375(ALL)05/95]
RWARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
*
[ST08500(ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

51 %
*
[ST08700(ALL)06/95]
Using the Engine Block Heater
(If equipped)
*
[ST08900(ALL)03/95]
Engine block heaters are strongly recommended
if you live in a region where temperatures reach
-10ÊF (-23ÊC) orbelow. An engine block heater
warms the engine coolant, which improves
starting, warms up the engine faster, and allows
the heater-defrost system to respond quickly.
*
[ST09100(ALL)02/95]
To turn the heater on, simply plug it into a
grounded 110-volt outlet. Ford recommends that
you use a 110-volt circuit that is protected by a
ground fault circuit interrupter.
*
[ST09200(ALL)05/95]
RWARNING
To prevent electrical shock, do not use
your heater with ungrounded electrical
systems or two-pronged (cheater) adapters.
*
[ST09300(ALL)03/95]
For best results, plug the heater in at least three
hours before you start your vehicle. Using the
heater for longer than three hours will not
damage the engine, so you can plug it in at
night to start your vehicle the following
morning.
*
[ST09400(ALL)03/95]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
*
[ST09450(ALL)07/95]
Fuel Pump Shut-Off Switch
*
[ST09460(ALL)10/95]
If the engine cranks but does not start or does
not start after a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device intended to stop the fuel
pump when your vehicle has been involved in a
major jolt.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

52
*
[ST09470(ALL)03/95]
Once the shut-off switch is triggered, you must
reset the switch by hand before you can start
your vehicle.
[ST09480(ALL)02/95]
The reset switch on your vehicle is located in a
small compartment on the left side of the
luggage compartment.
[ST09490(ALL)02/95]
half page art:0032161-C
The location of the fuel pump shut-off switch (U.S. vehicle
shown Ð Canadian vehicles similar)
*
[ST09500(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

53
*
[ST09510(ALL)10/95]
If your engine cranks but does not start after a
collision or major jolt:
*
[ST09520(ALL)02/95]
1. Turn the key in the ignition to the LOCK
position.
*
[ST09530(ALL)03/95]
2. Check under the vehicle for leaking fuel.
[ST09540(ALL)02/95]
3. If you do not see or smell fuel, remove the
door covering the fuel pump shut-off switch
compartment by pressing the tab toward the
rear seat. Push down the red reset button on
the fuel pump shut-off switch.
*
[ST09550(ALL)02/95]
4. Attempt to start your vehicle. If the vehicle
starts, let it run a few seconds, then turn the
key to the LOCK position.
*
[ST09560(ALL)03/95]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
*
[ST09600(ALL)09/95]
RWARNING
Do not start your vehicle in a closed
garage or other enclosed area. Never sit in
a stopped vehicle for more than a short
period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding
Against Exhaust Fumesin this chapter for
more instructions.
%*
[ST11700(ALL)05/95]
Guarding Against Exhaust Fumes
*
[ST11800(ALL)02/95]
Carbon monoxide, although colorless and
odorless, is present in exhaust fumes. Take
precautions to avoid its dangerous effects.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

54
*
[ST12000(ALL)05/95]
RWARNING
If you smell exhaust fumes inside your
vehicle, have your dealer inspect your
vehicle immediately. Do not drive if you
smell exhaust fumes.
*
[ST12100(ALL)01/95]
Have the exhaust and body ventilation systems
checked whenever:
*
[ST12200(ALL)02/95]
q
your vehicle is raised for service
*
[ST12300(ALL)02/95]
q
the sound of the exhaust system changes
*
[ST12400(ALL)01/95]
q
your vehicle has been damaged in a collision
*
[ST12500(ALL)01/95]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
[ST12600(ALL)02/95]
If you must allow your engine to idle for long
periods of time, be sure you are in an open area
and open the windows at least one inch
(25 mm). Also, adjust the heating or air
conditioning to bring in outside air.
[ST12700(ALL)02/95]
If you are using the heater, set the fan speed on
1, 2, or 3 with the function lever on the position
of your choice and the air door control lever in
the fresh (outside air) position.
[ST12900(ALL)02/95]
If you are using the air conditioner, set the fan
speed on 1, 2, or 3 with the function lever in the
position of your choice. Set the air door control
lever in the fresh (outside air) position.
File:04icstf.ex
Update:Wed Jan 24 14:30:41 1996

55
Warning Lights and
Gauges
[LG00600(ALL)07/95]
The following lights and gauges are on the
instrument cluster. All of the warning lights and
gauges alert you to possible problems with your
vehicle. The following section details what each
of these indicators means.
[LG00650(ALL)05/95]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster. Your vehicle has
a standard cluster.
File:05iclgf.ex
Update:Wed Jan 24 14:32:51 1996

56 [LG01600(ALL)07/95]
full page art:0032162-EInstrument panel
File:05iclgf.ex
Update:Wed Jan 24 14:32:51 1996

57 [LG01900(ALL)07/95]
full page art:0032163-E
The standard cluster
File:05iclgf.ex
Update:Wed Jan 24 14:32:51 1996

58
*
[LG01950(ALL)01/95]
Indicator Lights and Chimes
%*
[LG01975(ALL)07/95]
Safety Belt Warning Light and Chime
[LG01990(ALL)09/93]
one inch art:0030171-B
Safety belt light
[LG02000(ALL)07/95]
This warning light and chime remind you to
fasten your safety belt under the following
conditions:
[LG02100(ALL)02/95]
q
If the safety belt is not buckled when the
ignition is turned to the ON position, the
chime will turn on for four (4) to eight (8)
seconds and the light will come on for at
least 60 seconds.
[LG02200(ALL)02/95]
q
If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime will turn off.
[LG02300(ALL)07/95]
q
If the safety belt is buckled before the
ignition is turned to the ON position, neither
the light nor the chime will come on.
