FORD ASPIRE 1997 1.G Owners Manual
Manufacturer: FORD, Model Year: 1997, Model line: ASPIRE, Model: FORD ASPIRE 1997 1.GPages: 254, PDF Size: 1.85 MB
Page 1 of 254
[PI00100(ALL)02/96]
thirty-six pica chart:File:01icpif.ex
Update:Tue Mar 4 08:50:44 1997
Page 2 of 254
[PI00105(ALL)02/96]
thirty-six pica chart:File:01icpif.ex
Update:Tue Mar 4 08:50:44 1997
Page 3 of 254
*
[PI00560(ALL)05/95]
Table of ContentsIntroduction ...................................................... 1
Instrumentation ................................................ 7
Electronic Sound Systems ........................... 19
Controls and Features .................................. 31
Seating and Safety Restraints .................... 57
Starting ............................................................. 93
Driving ........................................................... 105
Roadside Emergencies ................................ 121
Maintenance and Care ............................... 145
Capacities and Specifications ................... 199
Reporting Safety Defects
(U.S. Only) .................................................... 209
Customer Assistance ................................... 211
Accessories .................................................... 223
Quick Index .................................................. 233
Index ............................................................... 243
Service Station Information --
1.3L Engine ................................................... 260
File:01icpif.ex
Update:Tue Mar 4 08:50:44 1997
Page 4 of 254
1
Introduction
*
[II00300(ALL)01/96]
Ford's Commitment to You
*
[II00400(ALL)01/96]
At Ford Motor Company, excellence is the
continuous commitment to achieve the best
result possible. It is dedication to learning what
you want, determination to develop the right
concept, and execution of that concept with care,
precision, and attention to detail. In short,
excellence means being the standard by which
others are judged.
*
[II00500(ALL)01/96]
Our Guiding Principles
*
[II00600(ALL)01/96]
q
Quality comes first.For your satisfaction, the
quality of our products and services must be
our number one priority.
*
[II00700(ALL)01/96]
q
You are the focus of everything we do.Our
work must be done with you in mind,
providing better products and services than
our competition.
*
[II00750(ALL)01/96]
q
Continuous improvement is essential to our
success.We must strive for excellence in
everything we do: in our products Ð in their
safety and value Ð and in our services, our
human relations, our competitiveness, and
our profitability.
*
[II00800(ALL)01/96]
q
Employee involvement is our way of life.
We are a team. We must treat one another
with trust and respect.
*
[II00900(ALL)01/96]
q
Dealers and suppliers are our partners.We
must maintain mutually beneficial
relationships with dealers, suppliers, and our
other business associates.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997
Page 5 of 254
2
*
[II01000(ALL)01/96]
q
Integrity is never compromised.Our conduct
worldwide must be pursued in a manner that
is socially responsible and commands respect
for its integrity and for its positive
contributions to society.
*
[II01040(ALL)03/96]
NOTES and WARNINGS
*
[II01042(ALL)02/96]
NOTESgive you additional information about
the subject matter you are referencing.
*
[II01044(ALL)01/96]
WARNINGSremind you to be especially careful
in those areas where carelessness can cause
damage to your vehicle or personal injury to
yourself, your passengers or other people. Please
read allWARNINGScarefully.
*
[II01046(ALL)01/96]
WARNING
*
[II01050(ALL)01/96]
Finding Information in This Guide
*
[II01060(ALL)01/96]
After you have read this guide once, you will
probably return to it when you have a specific
question or need additional information. To help
you find specific information quickly, you can
use the Quick Index, Table of Contents, or the
Index.
*
[II01070(ALL)03/96]
TheQuick Indexat the end of the book
provides a page number following each item
which indicates where detailed information can
be found.
*
[II01080(ALL)01/96]
To use theIndex, turn to the back of the book
and search in the alphabetical listing for the
word that best describes the information you
need. If the word you chose is not listed, think
of other related words and look them up. We
have designed the Index so that you can find
information under a technical term.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997
Page 6 of 254
3 %
*
[II01090(ALL)01/96]
Canadian Owners Ð French Version
*
[II01100(ALL)01/96]
French Owner Guides can be obtained from your
dealer or by writing to Ford Motor Company of
Canada, Limited, Service Publications, P.O. Box
1580, Station B, Mississauga, Ontario L4Y 4G3.
%
*
[II02400(ALL)01/96]
Your Maintenance Schedule and
Record Booklet
*
[II02500(ALL)03/96]
TheMaintenance Schedulebooklet lists the
services that are most important for keeping
your vehicle in good condition. A record log is
also provided to help you keep track of all
services performed.
%
*
[II02600(ALL)01/96]
About the Warranties
*
[II02700(ALL)01/96]
Your vehicle is covered by three types of
warranties:Basic Vehicle Warranty,Extended
Warrantieson certain parts, andEmissions
Warranties.
%*
[II03100(ALL)01/96]
Read yourWarranty Information Bookletcarefully
to find out about your vehicle's warranties and
your basic rights and responsibilities.
*
[II03250(ALL)03/96]
If you lose yourWarranty Information Booklet,you
can get a new one free of charge. Contact any
Ford or Lincoln-Mercury dealer, or refer to the
addresses and phone numbers on the first page
of this Owner's Guide.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997
Page 7 of 254
4 %
*
[II04000(ALL)03/96]
Ford Extended Service Plan
*
[II04100(ALL)04/96]
More Protection for Your Vehicle
*
[II04200(ALL)04/96]
You can get more protection for your new car or
light truck by purchasing a Ford Extended
Service Plan (Ford ESP). Ford ESP is the only
extended service program with the Ford name
on it and the only service contract backed by
Ford Motor Company.
*
[II04300(ALL)04/96]
Ford ESP is an optional service contract, backed
and administered by Ford. It provides:
*
[II04400(ALL)04/96]
q
protection against repair costs after your
Bumper to Bumper Warranty expires;
*
[II04500(ALL)04/96]
and
*
[II04600(ALL)04/96]
q
other benefits during the warranty period
(such as: reimbursement for rentals; coverage
for certain maintenance and wear items).
*
[II04700(ALL)04/96]
You may purchase Ford ESP from any
participating Ford Motor Company dealer. There
are several Ford ESP plans available in various
time-and-mileage combinations. Each plan can be
tailored to fit your own driving needs, including
reimbursement benefits for towing and rental.
(In Hawaii, rules vary. See your dealer for
details.)
*
[II04800(ALL)04/96]
When you purchase Ford ESP, you receive
peace-of-mind protection throughout the United
States and Canada, provided by a network of
more than 5,100 participating Ford Motor
Company dealers.
*
[II04850(ALL)04/96]
NOTE: Repairs performed outside the United
States and Canada are not eligible for
ESP coverage.
*
[II04900(ALL)04/96]
This information is subject to change, ask your
dealer for complete details about Ford ESP
coverage.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997
Page 8 of 254
5 %
*
[II05850(ALL)01/96]
Federal Highway Administration
Regulation
*
[II05875(ALL)01/96]
Regulations such as those issued by the Federal
Highway Administration or issued pursuant to
the Occupational Safety and Health Act (OSHA),
and/or state and local laws and regulations may
require additional equipment for the way you
intend to use the vehicle. It is the responsibility
of the registered owner to determine the
applicability of such laws and regulations to
your intended use for the vehicle, and to
arrange for the installation of required
equipment. Your Ford dealer has information
about the availability of many items of
equipment which may be ordered for your
vehicle.
%
*
[II06000(ALL)01/96]
Breaking Your Vehicle In
*
[II06100(ALL)01/96]
Your new vehicle goes through an adjustment or
break-in period during the first 1,000 miles
(1,600 km) that you drive it. During the break-in
period, you need to pay careful attention to how
you drive your vehicle.
%*
[II06300(ALL)01/96]
q
Avoid sudden stops.Because your vehicle
has new brake linings, you should take these
steps:
*
[II06400(ALL)01/96]
Ð Watch traffic carefully so that you can
anticipate when to stop.
*
[II06500(ALL)01/96]
Ð Begin braking well in advance.
*
[II06600(ALL)01/96]
Ð Apply the brakes gradually.
*
[II06700(ALL)01/96]
The break-in period for new brake linings
lasts for 100 miles (160 km) of city driving or
1,000 miles (1,600 km) of highway driving.
%*
[II06800(ALL)03/96]
q
Use only the type of engine oil that Ford
recommends.SeeEngine oil recommendations
in the Index. Do not use special ªbreak-inº
oils.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997
Page 9 of 254
6
*
[II09000(ALL)03/96]
Things to Know About Using
This Guide
*
[II90100(ALL)03/96]
Congratulations on the purchase of your new
vehicle. This guide has information about the
equipment and the options for your new vehicle.
You may not have bought all of the options
available to you. If you do not know which
information applies to your vehicle, talk to your
dealer.
*
[II90200(ALL)03/96]
This guide describes equipment and gives
specifications for equipment that was in effect
when this guide was approved for printing. Ford
may discontinue models or change specifications
or design without any notice and without
incurring obligation.
File:02iciif.ex
Update:Tue Mar 4 08:50:54 1997
Page 10 of 254
7
Instrumentation
[IS00600(ALL)04/96]
The warning lights and gauges alert you to
possible problems with your vehicle. The
following section details what each of these
indicators means.
[IS00650(ALL)01/96]
In your vehicle, the warning lights and gauges
are grouped together on the instrument panel.
We call this grouping a cluster. Your vehicle has
a standard cluster.
