8 [IS01900(ALL)01/96]
full page art:0032163-EThe standard cluster
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 12 of 254
9
*
[IS01950(ALL)01/96]
Indicator Lights and Chimes
%*
[IS01975(ALL)03/96]
Safety Belt Warning Light and Chime
[IS01990(ALL)01/96]
one inch art:0030171-B
Safety belt light
[IS02000(ALL)01/96]
This warning light and chime remind you to
fasten your safety belt under the following
conditions:
[IS02100(ALL)04/96]
q
If the safety belt is not buckled when the
ignition is turned to the ON position, the
chime will turn on for four (4) to eight (8)
seconds and the light will illuminate for at
least 60 seconds.
*
[IS02200(ALL)01/96]
q
If the safety belt is buckled while the light is
on and the chime is sounding, both the light
and chime will turn off.
*
[IS02300(ALL)03/96]
q
If the safety belt is buckled before the
ignition is turned to the ON position, neither
the light nor the chime will come on.
%*
[IS02400(ALL)01/96]
Brake System Warning Light
[IS02550(ALL)01/96]
one inch art:0032206-B
Brake system and parking brake light
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 13 of 254
10 [IS02600(ALL)04/96]This light illuminates for a few seconds when
you turn the ignition key to START or ON. It
normally goes off shortly after the engine starts
and after you release the parking brake.
However, it may stay on for up to 60 seconds. If
the light doesn't illuminate after the engine is
started, stays on for longer than 60 seconds, or
illuminates after you have fully released the
parking brake, have the hydraulic brake system
checked.
[IS02605(ALL)02/96]
To test the brake warning light, release the
parking brake and turn the ignition key to the
START position. The brake warning light should
illuminate until the key is released.
*
[IS02650(ALL)03/96]
This light will also illuminate if the parking
brake does not release fully. If it does stay on
afterthe parking brake is fully released, it
means there may be a brake problem. Pull off
the road and stop carefully. You may notice that
the pedal is harder to push, the pedal may go
closer to the floor, or it may take longer to stop
the vehicle. Try the brakes again after you have
stopped.
[IS02675(ALL)04/96]
Your vehicle has a divided brake system. If one
part isn't working, the other part can still work
and stop the vehicle. For good braking, you
need both systems working well.
*
[IS02700(ALL)03/96]
WARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 14 of 254
11 %
*
[IS03200(ALL)01/96]
Charging System Light
*
[IS03300(ALL)04/96]
This light indicates that your battery is not being
charged and that you need to have the electrical
system checked.
[IS03400(ALL)01/96]
one inch art:0030172-C
Charging system light
*
[IS03500(ALL)03/96]
This light illuminates every time you turn the
ignition to the ON or START position (engine
off). The light should go off when the engine
starts and the alternator begins to charge.
*
[IS03550(ALL)03/96]
If the light stays on or illuminates when the
engine is running, have the electrical system
checked as soon as possible.
%*
[IS03615(ALL)01/96]
Engine Oil Pressure Warning Light
[IS03715(ALL)04/96]
This light indicates low oil pressure, not low oil
level. However, if the engine's oil level is low, it
could affect the oil pressure. This light
illuminates every time the ignition key is turned
to ON or START, but it normally turns off when
the engine starts.
[IS03800(ALL)01/96]
one inch art:0030173-C
Engine oil pressure light
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 15 of 254
12 [IS03900(ALL)04/96]If the light stays on or illuminates while the
engine is running:
*
[IS04000(ALL)03/96]
1. Pull off the road as soon as safely possible.
[IS04100(ALL)01/96]
2.Shut off the engine immediately.Continued
operation could cause severe engine damage.
[IS04200(ALL)01/96]
3. Check the engine oil level. Make sure the car
is on level ground.
[IS04300(ALL)01/96]
4. Add oil to the full mark on the dipstick
before you drive your car again. Do not
overfill. Do not operate the engine when the
oil light is on. For more information about
adding oil, seeEngine oil recommendationsin
the Index.
[IS04350(ALL)01/96]
WARNING
Do not rely on the oil light to tell you
when the oil is low. Have the oil checked
often. It is possible for damage to occur if
an engine is operated with a low oil level.
%*
[IS04500(ALL)03/96]
High Beam Light
*
[IS04600(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights. If your vehicle is equipped with daytime
running lights and you have your headlamps on
your high beam telltale will not illuminate when
you flash the lights.
*
[IS04700(ALL)01/96]
one inch art:0030174-A
High beam light
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 16 of 254
13 %
*
[IS05300(ALL)03/96]
Check Engine Warning Light
*
[IS05400(ALL)04/96]
This light illuminates when the electronic engine
control system is not working properly. This is
the computer system that controls the operating
conditions of the engine.
*
[IS05450(ALL)01/96]
one inch art:0030175-B
Check engine warning light
*
[IS05600(ALL)04/96]
This light illuminates briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
illuminate when you turn the ignition to the ON
position or if it illuminates and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
*
[IS05800(ALL)04/96]
If the light flashes briefly while you are driving,
it means that the condition is no longer present.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 17 of 254
14 %
*
[IS05825(ALL)03/96]
Air Bag Readiness Light
*
[IS05850(ALL)03/96]
This light illuminates for six seconds when the
ignition is turned to the ON position. If the light
fails to illuminate, continues to flash, remains on,
or if a series of five beeps is heard, have the
system serviced as soon as possible.
[IS05875(ALL)01/96]
one inch art:0032124-A
Air bag readiness light
[IS05900(ALL)01/96]
Rear Window Defroster Indicator Light
(If equipped)
[IS05925(ALL)01/96]
When the rear window defroster is activated, the
indicator light in the instrument cluster
illuminates. After the rear window is clear, push
the defroster switch to turn off the defroster. The
light in the cluster goes out.
[IS05950(ALL)01/96]
one inch art:0032125-A
Rear window defroster indicator light
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 18 of 254
15 %
*
[IS05975(ALL)01/96]
Anti-lock Brake System Warning Light
(If equipped)
[IS06000(ALL)04/96]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light illuminates. When the engine is started, the
Anti-lock Brake System (ABS) control unit
determines if all components of the system are
operating correctly. The warning light could
remain on up to 60 seconds.
[IS06025(ALL)01/96]
one inch art:0032123-B
Anti-lock brake system light
*
[IS06050(ALL)03/96]
WARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
*
[IS06060(ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 19 of 254
16
*
[IS06075(ALL)01/96]
NOTE: If your vehicle must be jump-started
because of a low battery, the Anti-Lock
Brake System warning light could
remain on. This is due to low battery
voltage and does not indicate a
malfunction in the system. Under these
circumstances, you should drive your
vehicle only after the battery has had
time to charge and the light has gone
out.
[IS06090(ALL)02/96]
After starting the engine, check all the warning
lights to make sure that they are off. If any one
of them is still lit, it indicates a situation that
needs your attention. When you release the
parking brake, the brake warning light should
go off.
%*
[IS06100(ALL)01/96]
Ignition Key Chime
*
[IS06105(ALL)01/96]
If the driver or passenger door is open while the
key is still in the ignition, a warning chime
sounds.
[IS06115(ALL)02/96]
Headlamps On Chime
[IS06120(ALL)01/96]
This chime will sound when a door is opened
while the headlamps or parking lamps are on.
*
[IS06200(ALL)04/96]
Gauges
%*
[IS06300(ALL)03/96]
Fuel Gauge
*
[IS06325(ALL)01/96]
The fuel gauge displays approximately how
much fuel you have in the fuel tank.
*
[IS06350(ALL)01/96]
The ignition must be turned off while putting
fuel in the tank in order to get a correct fuel
gauge reading after the ignition is turned on.
*
[IS06375(ALL)01/96]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. You can get a more
accurate reading with the vehicle on smooth,
level ground.
File:03icisf.ex
Update:Tue Mar 4 08:51:24 1997
Page 20 of 254
17 %
*
[IS06400(ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS06500(ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS06600(ALL)04/96]
The pointer normally moves from C (cold) into
the normal band as your vehicle warms up.
Under most driving conditions, the pointer
should stay in the normal band. If you are
driving in heavy traffic or on an extended grade
in hot weather, the pointer may reach to the top
of the normal band.
*
[IS06700(ALL)04/96]
If, under any circumstances, the pointer moves
above the normal band, the engine is
overheating and continued operation may cause
engine damage.
*
[IS06800(ALL)03/96]
If your engine overheats:
*
[IS06900(ALL)03/96]
1. Pull off the road as soon as safely possible.
*
[IS07000(ALL)01/96]
2. Turn off the engine.
*
[IS07100(ALL)01/96]
3. Let the engine cool.
*
[IS07200(ALL)01/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. (SeeEngine coolantin the
Index.) If you do not follow these
instructions, you or others could be injured.
*
[IS07300(ALL)04/96]
5. Refer toAdding Engine Coolantin the
Maintenance and Carechapter. Add as much
coolant as your engine needs. If the engine
continues to overheat, have the cooling
system serviced.
