Page 61 of 254
58 [SS00310(ALL)01/96]
one third page art:0032183-ASeat slide adjustment lever
%*
[SS00315(ALL)01/96]
Seatback Recline
*
[SS00320(ALL)08/95]
To recline the seatback:
[SS00325(ALL)01/96]
1. Find the seatback recline lever located on the
outside of the seat, toward the rear.
[SS00330(ALL)01/96]
2. Lean forward slightly and lift up on the
lever.
[SS00335(ALL)01/96]
3. Lean back on the seat and adjust the back of
the seat to the position you desire.
[SS00340(ALL)01/96]
4. Release the lever and make sure the seatback
is locked in place. (The lever MUST return
to its original position for the seatback to
lock.)
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 62 of 254
59 [SS00345(ALL)01/96]
one third page art:0032184-B
The lever used to recline the back of the seat
[SS00350(ALL)04/96]
Rear Seat Access (2 door models)
[SS00355(ALL)01/96]
To gain access to the rear seat:
[SS00360(ALL)01/96]
1. Locate the seatback recline lever. The lever is
located on the outside of the seat cushion.
[SS00365(ALL)01/96]
2. Raise the seatback recline lever to tilt the
seatback forward. Raise the seat slide
adjustment lever and move the seat forward
if extra room is needed. The seatback should
automatically lock when returned to its
upright position. Make sure the seatback is
locked in place.
*
[SS00370(ALL)02/96]
WARNING
Check to see that the seat and seatback
are latched securely in position. Keep
floor area free of objects that would
prevent proper seat engagement. Never
attempt to adjust the seat while the
vehicle is in motion.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 63 of 254
60 [SS00375(ALL)01/96]Using the Folding Rear Seat (If equipped)
[SS00380(ALL)01/96]
Your vehicle may be equipped with a
full-folding or split-folding rear seat. In either
case, you can fold down the seatback (or
seatbacks) to provide extra cargo space. If you
have the rear safety belts routed through the
rear safety belt guides on either side of the seats,
the safety belts will not be trapped when the
seats are returned to their upright positions.
*
[SS00385(ALL)01/96]
To fold down the rear seatback:
[SS00390(ALL)01/96]
1. Pull up on the release knob(s) located in the
upper corner(s) of the seatback. The
split-folding rear seat has one knob for each
seatback. The full-folding rear seat has two
knobs, which must both be raised at the
same time to lower the entire seatback.
[SS00395(ALL)01/96]
2. Pull the seatback forward until it is flat.
*
[SS00400(ALL)01/96]
To raise the rear seatback:
*
[SS00405(ALL)01/96]
1. Push the seatback upward until it locks in
place.
[SS00410(ALL)01/96]
2. Make sure the seatback is firmly locked by
pushing forward and backward on it.
[SS00415(ALL)01/96]
one third page art:0032192-C
Folding down the full-folding rear seatback
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 64 of 254
61 [SS00420(ALL)01/96]
one third page art:0032242-A
Folding down the split-folding rear seatback
[SS00425(ALL)01/96]
Fold-up rear seat cushion (if equipped)
[SS00430(ALL)01/96]
If your vehicle is equipped with the fold-up rear
seat cushion, the rear seat cushion can also be
raised after you fold down the seatback(s) to
provide even more cargo space. After you pull
up the release knobs and fold the seatback(s)
forward, lift up the entire seat and push it
forward. When you return the seat cushion to its
unfolded position, reposition the rear safety belts
so that they can be used by rear seat passengers.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 65 of 254
62 [SS00435(ALL)01/96]
half page art:0030104-CFolding up the rear seat cushion
*
[SS00445(ALL)05/96]
WARNING
Cargo should always be secured to
prevent it from shifting and causing
damage to the vehicle or harm to the
passengers.
*
[SS00450(ALL)01/96]
WARNING
Do not remove the floor carpet in your
vehicle. Emission controls cause high
exhaust temperatures under the floor.
[SS00455(ALL)01/96]
NOTE: When returning the folding seats to the
upright position, remember to return
rear shoulder belts to their proper
position. Routing the safety belt
webbing through the rear safety belt
guides will help keep belts from being
trapped behind or under the seats.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 66 of 254
63
%*
[SS00500(ALL)02/96]
Important Safety Belt Information
*
[SS00600(ALL)05/96]
The use of safety belts helps to restrain you and
your passengers in case of a collision. In most
states and in Canada, the law requires their use.
*
[SS00700(ALL)02/96]
Safety belts provide best restraint when:
*
[SS00800(ALL)02/96]
q
the seatback is upright
*
[SS00900(ALL)02/96]
q
the occupant is sitting upright (not slouched)
*
[SS01000(ALL)02/96]
q
the lap belt is snug and low on the hips
*
[SS01100(ALL)02/96]
q
the shoulder belt is snug against the chest
*
[SS01200(ALL)02/96]
q
the knees are straight forward
*
[SS01350(ALL)02/96]
To help you remember to fasten your safety belt,
a warning light may come on and a chime may
sound. SeeSafety Belt Warning Light and Chimein
theInstrumentationchapter.
*
[SS02000(ALL)02/96]
See the following sections in this chapter for
directions on how to properly use these safety
belts. Also seeSafety Restraints for Childrenin this
chapter for special instructions about using
safety belts for children.
*
[SS02100(ALL)02/96]
WARNING
Always drive and ride with your seatback
upright and the lap belt snug and low
across the hips.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 67 of 254
64
*
[SS02200(ALL)05/96]
WARNING
Each seating position in your vehicle has a
specific safety belt assembly which is
made up of one buckle and one tongue
that are designed to be used as a pair. 1)
Use the shoulder belt on the outside
shoulder only. Never wear the shoulder
belt under the arm. 2) Never swing it
around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
*
[SS02400(ALL)01/96]
WARNING
Never drive or ride with a twisted or
jammed safety belt. If you cannot untwist
or unjam the safety belt, see the nearest
qualified technician immediately.
*
[SS02800(ALL)02/96]
WARNING
Children should always ride with the
seatback in the fully upright position.
*
[SS02825(ALL)02/96]
WARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SS02850(ALL)02/96]
WARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 68 of 254
65
%*
[SS03400(ALL)02/96]
Combination Lap and Shoulder
Belts
*
[SS03500(ALL)02/96]
While your vehicle is in motion, the combination
lap and shoulder belt adjusts to your movement.
However, if you brake hard, turn hard, or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the lap/shoulder belt locks
and helps reduce your forward movement.
*
[SS03600(ALL)01/96]
After you get into your vehicle, close the door
and lock it. Then adjust the seat to the position
that suits you best.
[SS03700(ALL)01/96]
To fasten the belt, pull the combination
lap/shoulder belt from the retractor so that the
shoulder portion of the belt crosses your
shoulder and chest. Be sure the belt is not
twisted. If it is, remove the twist. Insert the belt
tongue into the proper buckle until you hear a
snap and feel it latch. Make sure the tongue is
securely fastened to the buckle by pulling on
tongue.
[SS03800(ALL)01/96]
one third page art:0032150-A
Fastening the safety belt
*
[SS03860(ALL)02/96]
NOTE: Be sure to read and understand
Important Safety Belt Informationin
this chapter.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 69 of 254
66 [SS05300(ALL)01/96]
one third page art:0032252-BUnfastening the combination lap/shoulder belts Ð front
and rear outboard seating positions
*
[SS05400(ALL)02/96]
While the belt retracts, guide the tongue to its
original position to prevent it from striking you
or the vehicle.
[SS09320(ALL)01/96]
Passenger Seat Lap/Shoulder Belt
Retractors (Dual Locking Modes)
*
[SS09330(ALL)04/96]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for
passengers.
*
[SS09340(ALL)02/96]
Dual locking mode retractors operate in two
ways:
*
[SS09350(ALL)02/96]
Vehicle sensitive (emergency) locking mode
[SS09360(ALL)01/96]
In this operating mode, the shoulder belt
retractor will allow the occupant freedom of
movement, locking tight only on hard braking,
hard cornering, or impacts of approximately
5 mph (8 km/h) or more. The retractor can also
be made to lock by pulling on the belt.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
Page 70 of 254
67 %
*
[SS09370(ALL)02/96]
Automatic locking mode
*
[SS09380(ALL)01/96]
In this operating mode, the shoulder belt
retractor will be automatically locked and will
remain locked when the combination
lap/shoulder safety belt is buckled, and does not
allow the occupant freedom of movement. This
mode provides the following:
*
[SS09390(ALL)01/96]
q
A tight lap/shoulder belt on the occupant.
*
[SS09400(ALL)01/96]
q
Child safety seat installation.
*
[SS09410(ALL)05/96]
WARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
*
[SS09420(ALL)01/96]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SS09430(ALL)01/96]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SS09440(ALL)02/96]
1. Buckle the lap/shoulder combination belt.
*
[SS09450(ALL)01/96]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and, when allowed to retract, a
clicking sound is heard. At this time, the belt
retractor is in the automatic locking mode
(child restraint mode).
*
[SS09460(ALL)02/96]
3. A clicking sound will continue to be heard
as the belt is allowed to retract. This
indicates that the retractor is in the
automatic locking mode.
File:06icssf.ex
Update:Tue Mar 4 08:54:10 1997
