[TO06860(ALL)01/96]
If the engine does not start after two attempts:
*
[TO06865(ALL)01/96]
1. Turn the ignition key to the OFF position.
*
[TO06870(ALL)01/96]
2. Press the accelerator all the way to the floor
and hold it.
*
[TO06875(ALL)01/96]
3. Turn the ignition key to the START position.
*
[TO06880(ALL)01/96]
4. Release the ignition key when the engine
starts.
*
[TO06885(ALL)03/96]
5. Release the accelerator gradually as the
engine speeds up.
*
[TO06890(ALL)03/96]
If the engine still does not start, the fuel pump
shut-off switch may have been triggered. For
directions on how to reset the switch seeFuel
Pump Shut-Off Switchin the index.
%*
[TO08350(ALL)01/96]
A computer system controls the engine's idle
speed. When you start your vehicle, the engine's
idle speed normally runs high. These faster
engine speeds will make your vehicle coast
slightly faster than its normal idle speed. It
should, however, slow down after a short time.
If it does not, have the idle speed checked.
*
[TO08365(ALL)01/96]
If the engine idle speed does not slow down
automatically, do not allow your vehicle to idle
for more than 10 minutes. Have the vehicle
checked.
*
[TO08375(ALL)01/96]
WARNING
Extended idling at high engine speeds can
produce very high temperatures in the
engine and exhaust system, creating the
risk of fire or other damage.
File:08ictof.ex
Update:Tue Mar 4 08:54:32 1997

100
*
[TO09450(ALL)03/96]
3. Push and hold the thumb button.
*
[TO09460(ALL)01/96]
4. Move the gearshift lever.
*
[TO09470(ALL)03/96]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledRoadside Emergenciesin
this Owner Guide for instructions on checking
and replacing fuses.
*
[TO09480(ALL)03/96]
WARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
%
*
[TO09500(ALL)01/96]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
[TO09520(ALL)02/96]
If the engine cranks but does not start or does
not start even after a small collision, the fuel
pump shut-off switch may have been activated.
The shut-off switch is a device intended to stop
the fuel pump when your vehicle has been
involved in a major jolt.
*
[TO09530(ALL)03/96]
Once the shut-off switch is activated, you must
reset the switch by hand before you can start
your vehicle.
[TO09540(ALL)01/96]
The reset switch on your vehicle is located in a
small compartment on the left side of the
luggage compartment.
File:08ictof.ex
Update:Tue Mar 4 08:54:32 1997

101 [TO09550(ALL)01/96]
half page art:0032161-C
The location of the fuel pump shut-off switch (U.S. vehicle
shown Ð Canadian vehicles similar)
*
[TO09600(ALL)03/96]
WARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
[TO09650(ALL)02/96]
If your engine cranks but does not start after a
collision or major jolt:
*
[TO09700(ALL)03/96]
1. Turn the key in the ignition to the LOCK
position.
*
[TO09750(ALL)03/96]
2. Check under the vehicle for leaking fuel.
[TO09800(ALL)01/96]
3. If you do not see or smell fuel, remove the
door covering the fuel pump shut-off switch
compartment by pressing the tab toward the
rear seat. Push down the red reset button on
the fuel pump shut-off switch.
File:08ictof.ex
Update:Tue Mar 4 08:54:32 1997

122
*
[ER02985(ALL)01/96]
If the Engine Cranks but Does
Not Start or Starting After a
Collision
*
[ER02990(ALL)02/96]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[ER02995(ALL)03/96]
For information on how to check and reset the
fuel pump shut-off switch, seeFuel pump shut-off
switchin the Index.
%
*
[ER03000(ALL)01/96]
Fuses
[ER03005(ALL)01/96]
Fuses protect your vehicle's electrical system
from overloading. If electrical parts in your
vehicle are not working, the system may have
been overloaded and blown a fuse. Before you
replace or repair any electrical parts, check the
appropriate circuit protectors.
[ER03010(ALL)04/96]
The following charts tell you which fuses protect
each electrical part of your vehicle. If a fuse
blows, all the parts of your vehicle that use the
circuit will not work.
*
[ER03015(ALL)01/96]
Once you have determined which fuses to check,
follow the procedures underChecking and
replacing fuseslater in this chapter.
[ER03020(ALL)04/96]
Your vehicle has a main fuse block under the
hood and a regular fuse box mounted in the
instrument panel behind a cover.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

176
*
[MC43825(ALL)01/96]
To fill the tank properly:
*
[MC43830(ALL)01/96]
1. Remove the fuel cap. Proceed to add fuel to
the tank only if your vehicle is on level
ground.
[MC43835(ALL)01/96]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe. The fuel tank is normally full
after three automatic shutoffs of the nozzle.
*
[MC43840(ALL)01/96]
3. If you spill any fuel on the body of your
vehicle, clean it off immediately. The fuel
may dull or soften the paint if you do not
wash it off.
[MC43845(ALL)01/96]
4. Replace the fuel cap tightly when you are
finished. Turn it clockwise until you hear at
least three clicks.
*
[MC43850(ALL)01/96]
5. Push the fuel door closed.
%*
[MC43855(ALL)08/96]
Choosing the Right Fuel
*
[MC43861(ALL)05/96]
Use only UNLEADED FUEL. The use of leaded
fuel is prohibited by law and could damage
your vehicle. The damage may not be covered
by your warranty.
*
[MC43866(ALL)08/96]
Your vehicle was not designed to use fuel
containing manganese-based additives such as
MMT. Additionally, vehicles certified to
California emission standards (indicated on the
underhood Vehicle Emissions Control
Information label) are designed to operate on
California reformulated gasolines. If California
reformulated gasoline is not available when you
refuel, your vehicle can be operated on
non-California fuels. However, even though your
engine will perform adequately on other
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

179
*
[MC44010(ALL)01/96]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[MC44015(ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[MC44020(ALL)01/96]
Running Out of Fuel
*
[MC44025(ALL)08/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[MC44030(ALL)01/96]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[MC44035(ALL)03/96]
Fuel Economy
*
[MC44040(ALL)01/96]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K). Do not calculate the fuel economy
during your vehicle's break-in period. This
would not be an accurate estimate of how much
fuel your vehicle will normally use.
*
[MC44045(ALL)01/96]
To calculate fuel economy:
*
[MC44050(ALL)01/96]
1. Fill the tank completely and record the
initial odometer reading.
*
[MC44055(ALL)01/96]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

194
*
[MC72000(ALL)01/96]
Cleaning the Engine
*
[MC72100(ALL)01/96]
A clean engine is more efficient because the
engine is able to cool properly. A build up of
grease and dirt acts as an insulator, keeping the
engine warmer than normal.
*
[MC72200(ALL)01/96]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[MC72300(ALL)04/96]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[MC72400(ALL)04/96]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[MC72500(ALL)01/96]
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%*
[MC73000(ALL)03/96]
Cleaning the Seats
*
[MC73100(ALL)01/96]
Vinyl
*
[MC73200(ALL)01/96]
Wipe the surface with a damp, soft cloth, then
dry and buff with a dry, soft cloth.
%*
[MC73300(ALL)05/96]
Fabric
*
[MC73400(ALL)05/96]
Remove dust and loose dirt with a whisk broom
or a vacuum cleaner. Remove fresh spots
immediately. Follow the directions that come
with the cleaner.
*
[MC73500(ALL)05/96]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

197 %
*
[MC81500(ALL)01/96]
Engine
*
[MC81600(ALL)01/96]
q
Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature.
*
[MC81700(ALL)01/96]
q
With your foot on the brake, shift through all
the gears while the engine is running.
%*
[MC81800(ALL)01/96]
Fuel system
%*
[MC81900(ALL)01/96]
q
Fill fuel tank with high-quality unleaded fuel
until the first automatic shutoff of the fuel
pump nozzle.
*
[MC82000(ALL)01/96]
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
*
[MC82100(ALL)01/96]
Ford Gas Stabilizer should be added whenever
actual or expected storage periods exceed 60
days. Follow the instructions on the label. The
vehicle should then be operated at idle speed to
circulate the additive throughout the fuel system.
*
[MC82200(ALL)01/96]
A volatile corrosion inhibitor added to the fuel
system will protect the fuel system's inner
surfaces from corrosion. Follow the instructions
packaged with the product.
%*
[MC82300(ALL)01/96]
Cooling system
*
[MC82400(ALL)01/96]
q
Protect against freezing temperatures.
%*
[MC82500(ALL)01/96]
Battery
*
[MC82600(ALL)01/96]
q
Check and recharge as necessary.
*
[MC82700(ALL)01/96]
q
Keep connections clean and covered with a
light coat of grease.
File:11icmcf.ex
Update:Tue Mar 4 08:57:16 1997

248 Index
Engine (continued)
fuel injected engine, starting.....93±94
fuel pump shut-off switch....... 100
preparing to start............ 93
starting................. 94
starting after a collision........ 100
storing your vehicle........195, 197
Engine block heater............ 97
Engine coolant............. 155
checking and adding......... 155
checking hoses............ 159
disposal...........146, 152, 162
drain and flush............ 159
preparing for storage......... 197
proper solution........146, 152, 162
recovery reservoir........... 155
temperature gauge........... 17
Engine coolant temperature gauge..... 17
description............... 17
mechanical............... 17
Engine coolant temperature
guage:electronic............. 17
Engine fan............... 146
Engine:idle speed control.......... 96
Engine knocking............. 177
Engine oil............... 149
changing oil and oil filter.....150, 152
checking and adding......... 150
check oil warning light......... 11
dipstick............... 150
disposal...........146, 152, 162
engine oil pressure warning light..... 11
filter, specifications.......... 199
low oil warning light.......... 11
specifications............. 149
synthetic oil............. 149
ªbreak-inº oils............. 5
viscosity............... 149
Exhaust fumes............. 102
Extended Service Plan, Ford........ 4
File:icixf.ex
Update:Tue Mar 4 08:59:36 1997

250 Index
Fuel gauge................ 16
Fuel pump shut-off switch
engine does not start......... 100
starting after a collision........ 100
Fuse panels............... 122
instrument panel........... 128
Fuses
charts..............122, 128
checking and replacing........ 128
G
Gas cap (see Fuel cap).......... 174
Gas mileage (see Fuel economy) . . . 176, 179
Gasoline (see Fuel)............ 174
Gauges, Electronic
engine coolant temperature gauge.... 17
fuel gauge............... 16
odometer................ 18
speedometer.............. 18
Gauges, Mechanical
engine coolant temperature gauge.... 17
fuel gauge............... 16
odometer................ 18
speedometer.............. 18
trip odometer.............. 18
GAWR (Gross Axle Weight Rating)
definition............... 118
driving with a heavy load....... 118
Gearshift
automatic operation.......... 111
column-mounted........... 111
downshifting............. 117
floor-mounted............ 115
locking the gearshift........... 44
positions.............111, 115
shifting the gears.........111, 115
upshifting.............. 117
Gearshift:shifting the gears......111, 115
File:icixf.ex
Update:Tue Mar 4 08:59:36 1997
