FORD BRONCO 1988 Owners Manual

121 [FV07201(B )02/92]
If you must drive with the rear window open:
[FV07301(B )03/95]
q
Adjust your climate control system to force
outside air into your vehicle.
[FV07401(B )02/92]
q
Completely open the outside air vents if your
vehicle is so equipped.
[FV07501(B )02/92]
q
You can prevent the tailgate from accidentally
opening by raising the glass one inch from
the fully opened position.
*
[FV14100(BEF )04/95]
Power Door Locks (If equipped)
*
[FV14500(BEF )05/95]
The power door lock switches are located in the
front doors. To lock all doors push the switch
marked L. To unlock all doors push the switch
marked U.
*
[FV14701(BEF )03/91]
The manual door locks will override the power
door lock controls.
*
[FV15001(BEF )05/95]
quarter page art:0020203-C
Power door lock controls
*
[FV15301(BEF )02/95]
Remote Entry System
(If equipped)
*
[FV15401(BEF )06/94]
If your vehicle has the remote entry system, you
can lock or unlock the vehicle doors without
using a key. The remote also has a personal
alarm feature. The buttons for the system are
located on the two hand held transmitters that
came with your vehicle.
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

122
*
[FV15600(BEF )02/95]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
*
[FV15700(BEF )02/95]
The remote entry features only operate with the
ignition in the OFF position.
*
[FV15800(BEF )04/94]
quarter page art:0020788-A
The remote entry transmitter
%*
[FV15901(BEF )02/95]
Unlocking the doors with the remote entry
system
*
[FV16001(BEF )02/95]
To unlock the driver's door, press the UNLOCK
button.
*
[FV16101(BEF )02/95]
To unlock the other doors, press the UNLOCK
button a second time within five (5) seconds of
unlocking the driver's door.
*
[FV16300(BEF )02/95]
Locking the doors with the remote entry
system
[FV16500(B F )04/95]
To lock all the doors, press the LOCK button.
*
[FV16600(B F )03/93]
If you would like a signal that the doors are
being locked, press the LOCK button again
within five seconds. The door will lock again,
the horn will beep, and the external lamps will
flash.
%*
[FV16800(BEF )02/95]
Remote entry personal alarm
*
[FV16900(BEF )04/95]
If you wish to activate the remote entry system
personal alarm, press the PANIC button. This
will honk the horn and flash the lights for
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

123
approximately 2 minutes 45 seconds. You can
turn it OFF by pressing the PANIC button again
from the same transmitter or by turning the
ignition to the ON or ACCESSORY position.
*
[FV17000(BEF )02/95]
When you use the remote entry UNLOCK or
PANIC buttons, the illuminated entry system
turns on the vehicle's interior lights for 25
seconds. You can turn these lights off with the
remote entry LOCK button or by turning the
ignition to the ON or ACCESSORY position.
*
[FV17100(BEF )04/94]
quarter page art:0060566-B
%*
[FV17501(BEF )02/95]
Replacing the batteries
*
[FV17601(BEF )02/95]
The remote entry transmitter is powered by two
coin type three-volt lithium 2016
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
*
[FV17701(BEF )02/95]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

124
*
[FV17801(BEF )03/93]
quarter page art:0020789-A
Opening the remote transmitter
*
[FV17901(BEF )02/95]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
*
[FV18001(BEF )02/95]
quarter page art:0020790-A
Replacing the batteries
%*
[FV18101(BEF )02/95]
Replacing lost transmitters
*
[FV18200(BEF )02/95]
In the event a transmitter is lost, you should
take all your vehicle's transmitters to your
dealer to have the remote entry system
deprogrammed for the lost transmitter. This is
necessary to prevent further unauthorized use of
the lost transmitter.
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

125
*
[FV18301(BEF )02/95]
You can also purchase additional transmitters
(up to 4 transmitters can be used) from your
dealer. You will need to take all your
transmitters to the dealer so they can program
them to the remote entry system all at the same
time.
*
[FV18601(BEF )04/95]
Illuminated Entry System (If equipped)
[FV18701(BEF )04/95]
This system will provide illumination of the
vehicle's interior courtesy lamps when either
outside front door handle is pulled or when the
Remote Entry System is used to unlock the door
or sound the Personal Alarm. The system will
automatically turn off after approximately 25
seconds or when the ignition is turned to the
START or ACCESSORY position.
*
[FV18801(BEF )04/94]
NOTE: The inside lights will not turn off if
you have turned them on with the
dimmer knob or if any door is open.
*
[FV18900(B F )04/94]
Battery Saver (with Remote Entry Ð If
equipped)
*
[FV19000(B F )03/95]
When the ignition is turned off, the vehicle will
turn off battery voltage to all of these lights after
40 minutes: glove box, engine compartment,
overhead console, mirror, courtesy and
interior (including cargo) lamps.
*
[FV19102(B F )03/95]
This will prevent draining of the battery if these
lights have been left on inadvertently or if a
door is not completely closed. Battery voltage to
these lamps will be restored when the remote
entry transmitter is used, any door is opened, or
the ignition key is turned on again.
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

126
*
[FV19250(BEF )02/95]
Windows
[FV22000(B )05/90]
Tailgate Window
[FV22101(B )05/91]
The switch to operate the tailgate window is on
the instrument panel to the left of the steering
column next to the master lighting switch. With
the ignition in the ON or ACC position, move
the switch down to lower the window and move
it up to raise the window. You can also operate
the tailgate window by using the key from the
outside of the tailgate.
[FV22201(B )05/90]
RWARNING
When driving your vehicle make sure that
the tailgate door and window are closed
to prevent exhaust fumes from being
drawn into the vehicle. This will also
prevent passengers and cargo from falling
out.
[FV22301(B )02/92]
If you must drive with the rear window open:
[FV22401(B )03/95]
q
Adjust your climate control system to force
outside air into your vehicle.
[FV22501(B )02/92]
q
Completely open the outside air vents if your
vehicle is so equipped.
[FV22601(B )02/92]
q
You can prevent the tailgate from accidentally
opening by raising the glass one inch from
the fully opened position.
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

127 [FV22701(B )03/91]
quarter page art:0020215-B
Rear window switch
[FV22801(B )02/89]
When driving in extremely dusty areas, clean the
tailgate glass periodically to prevent build-up of
surface dust. This will prevent excessive wear or
damage to the tailgate window seals.
*
[FV22901(BEF )03/91]
Using the Power Windows (If equipped)
*
[FV23001(BEF )05/90]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control switch that operates
both front door windows. You must place the
ignition switch in the ON or ACC position to
use your power window controls.
*
[FV23501(BEF )05/95]
RWARNING
Do not let children play with the power
windows. They may seriously hurt
themselves. Make sure occupants are clear
of the window(s) before closing.
*
[FV23800(BEF )05/95]
quarter page art:0020203-C
Master control switch
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

128
*
[FV24101(BEF )01/95]
Seats
*
[FV24801(BEF )05/90]
Adjusting the Front Seat Manually
*
[FV24901(BEF )08/94]
To move the front seat forward or rearward:
*
[FV25001(BEF )08/94]
1. Find the adjustment lever at the lower left
corner of the front seat.
*
[FV25101(BEF )10/89]
2. Push the lever to the left to unlatch the seat.
*
[FV25201(BEF )04/95]
3. Move the seat to the desired position.
*
[FV25301(BEF )04/89]
4. Release the lever to latch the seat in its new
position. Make sure the seat locks securely in
place.
*
[FV25600(B F )03/91]
one third page art:0020218-B
Adjusting bucket seat
*
[FV25700(B F )05/95]
one third page art:0020220-E
Adjusting the bench seat
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

129
*
[FV26001(BEF )05/95]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
*
[FV26100(BEF )05/95]
RWARNING
Do not pile cargo higher than the
seatbacks to avoid injuring people in a
collision or sudden stop.
*
[FV26200(BEF )05/95]
RWARNING
To reduce the risk of serious injury in a
collision, always drive and ride with your
seatback upright and the lap belt snug
and low across the hips.
*
[FV26300(BEF )05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[FV26400(BEF )10/89]
Reclining Bucket Seats
*
[FV27301(BEF )02/92]
You can tilt the seat back of your bucket seats
backward.
*
[FV27401(B F )03/93]
1. On the outboard side of the seat, lift the
recliner handle up and hold it in place.
*
[FV27501(BEF )10/89]
2. Lean against the back of the seat and adjust
it to the position you want.
*
[FV27601(BEF )10/89]
3. Release the handle to lock the seat back in
place.
*
[FV27701(BEF )10/89]
4. To return the seat back upright, lift the
handle and lean forward.
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com

130
*
[FV27800(B F )02/92]
one third page art:0020222-B
Reclining bucket seat
*
[FV28001(B F )10/90]
Lifting the seat-back adjustment lever of an
unoccupied seat will allow the seat back to fold
forward for access to the rear. Pushing the seat
back backward with the handle released returns
the seat upright.
*
[FV30501(B F )01/89]
Seat Back Release (Bench Seat)
[FV30801(B )12/91]
The split back bench seat can be folded forward
on either side to gain access to the rear of the
vehicle. To do so, push up the latch button
located at the top of the seat back.
[FV31000(B )05/95]
one third page art:0020227-D
Seat back release
File:ltfvb.ex
Update:Fri Jun 9 15:28:41 1995
ProCarManuals.com
