Tone generator
*
[SR12500(BEF )03/95]
The air bag readiness light indicates the air bag
system condition. However, a series of five sets
of five beeps will be heard only if the readiness
light does not work and there is a problem with
the air bag system. This also means that the Air
Bag Supplemental Restraint System (SRS) is in
need of service. The tone pattern will repeat
(five sets of five beeps) periodically until the
problem and light are repaired. Unless serviced,
the Air Bag Supplemental Restraint System may
not function properly in the event of a collision.
*
[SR12600(BEF )05/95]
RWARNING
Do not attempt to service, repair, or
modify the Air Bag Supplemental
Restraint System or its fuses. See your
Ford or Lincoln-Mercury dealer.
[SR12700(BEF )04/95]
The air bag system is designed to stay out of
sight until it is activated. The air bag system is
designed to deploy in frontal and front-angled
collisions more severe than hitting a parked
vehicle of similar size and weight head-on at
about 28 mph (45 km/h). Because the system
senses the crash severity rather than vehicle
speed,somefrontal collisions at speeds above
28 mph (45 km/h) will not inflate the air bag.
The system activates when the sensors detect a
forward deceleration equal to or greater than the
deceleration experienced if you would drive
your vehicle into a solid wall at 14 mph. In
some side impacts, the forward deceleration of
your vehicle can be great enough to deploy your
air bag.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

30
*
[SR12720(BEF )03/95]
The following four steps show how the air bag
system works:
*
[SR12740(BEF )03/95]
1. Sensors in the vehicle will detect the degree
of severity of a frontal impact. When the
sensor system is activated, electric current
flows to the inflator and the system ignites
the gas generant.
*
[SR12760(BEF )03/95]
2. The propellant then rapidly burns in the
metal container. The rapid burning produces
nitrogen gas and small amounts of dust. The
nitrogen gas and dust are cooled and filtered
during inflation of the air bag.
*
[SR12780(BEF )03/95]
3. The inflating supplemental air bag splits
open the trim cover. The supplemental air
bag then rapidly unfolds and inflates in front
of the driver.
*
[SR12801(BEF )03/95]
NOTE: STEPS 1-3 TAKE PLACE IN A
FRACTION OF A SECOND.
*
[SR12820(BEF )03/95]
4. After inflation, the gas empties through holes
in the air bag. The air bag deflates at once.
*
[SR12840(BEF )03/95]
The surface of the air bags and the vehicle
interior may be dusted with a powdery residue.
The powder is cornstarch or talcum powder,
which is used to lubricate the air bag as it
inflates, and sodium compounds such as sodium
carbonates (e.g., baking soda), and possibly a
very small amount of sodium hydroxide that
may be irritating to the skin and eyes, but is not
toxic.
*
[SR12860(BEF )03/95]
Right after air bag inflation, you may notice
smoke (from the powder and dust) and smell
the burnt propellant. This is normal.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

31
*
[SR12880(BEF )05/95]
RWARNING
Air bag system components get hot after
inflation. Do not touch them after
inflation.
*
[SR12901(BEF )05/95]
Air bags may not inflate in certain frontal
collisions, even though the vehicle may be badly
damaged. The fact that your air bag did not
inflate in such a collision does not mean that
something is wrong with the air bag system.
Rather, it means the crash forces were not severe
enough to need an air bag to prevent serious
injury.
*
[SR13000(BEF )03/93]
half page art:0011063-A
Inflated driver side air bag
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

32
*
[SR13500(BEF )05/95]
RWARNING
If the air bag is inflated, THE AIR BAG
WILL NOT FUNCTION AGAIN AND
MUST BE REPLACED IMMEDIATELY. If
the air bag is not replaced, the unrepaired
area will increase the risk of injury in a
collision.
*
[SR13600(BEF )03/95]
Disposal of supplemental air bag equipped
vehicles
*
[SR13700(BEF )03/95]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer, or refer to the procedures in the 1995
Ford Service Manual. Information on how to
order a service manual is available at an
authorized Ford or Lincoln-Mercury dealer. You
can also order a service manual using the order
form in theAccessorieschapter of your Owner
Guide.
%*
[SR13800(BEF )05/95]
Service and information labels
*
[SR13900(BEF )05/95]
Service and information labels are attached to
the sun visors, the headliner above the sun
visors (Canadian vehicles), and the radiator
support in the engine compartment.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

33
*
[SR14000(BEF )04/95]
full page art:0020847-D
The label located on the back of the driver's sun visor
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

34
*
[SR14200(BEF )02/94]
one third page art:0010605-D
Label on radiator support in the engine compartment
%*
[SR14300(BEF )05/95]
Safety Restraints for Children
*
[SR14400(BEF )02/95]
In the U.S. and Canada, you are required by law
to use safety restraints for children. If small
children ride in your vehicle Ð this generally
includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or
less Ð you must put them in safety seats that
are made specially for children. Safety belts
alone do not provide maximum protection for
these children. Check your local and state laws
for specific requirements.
*
[SR14500(BEF )05/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

35
*
[SR14600(BEF )05/95]
RWARNING
Passengers should not be allowed to ride
in the cargo area. Persons not riding in a
seat with a fastened seat belt are much
more likely to suffer serious injury in a
collision. Cargo should always be secured
to prevent it from shifting and causing
damage to the vehicle or harm to
passengers.
*
[SR14700(BEF )05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SR14800(BEF )05/95]
When possible, put children in the rear seat of
your vehicle. Accident statistics suggest that
children are safer when properly restrained in
the rear seating positions than in the front
seating positions.
*
[SR15000(BEF )05/95]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
*
[SR15025(BEF )05/95]
RWARNING
Never leave a child unattended in your
vehicle.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

36 %
*
[SR15250(BEF )05/95]
Safety Belts for Children
*
[SR15300(BEF )05/95]
Children who are too large for child safety seats
should always wear safety belts. (See instructions
with your child seat, or contact its manufacturer,
to determine maximum size of child that will
safely fit in the seat.)
*
[SR15400(BEF )05/95]
RWARNING
If safety belts are not properly worn and
adjusted as described, the risk of serious
injury to the child in a collision will be
much greater.
*
[SR15500(BEF )05/95]
If the shoulder belt portion of one of the lap and
shoulder belts can be positioned so that it does
not cross or rest in front of the child's face or
neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the
vehicle may help provide a good shoulder belt
fit.
*
[SR15600(BEF )01/95]
RWARNING
If the shoulder belt cannot be properly
positioned, move the child to one of the
seats with a lap belt only (preferably in a
rear seat) and use the lap belt.
*
[SR15700(BEF )05/95]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
*
[SR15800(BEF )05/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

37
*
[SR15900(BEF )01/95]
Safety Seats for Children
*
[SR16000(BEF )05/95]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SR16015(BEF )02/95]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
[SR16025(BEF )05/95]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position making sure the tongue is securely
fastened in the buckle and for a shoulder/lap
belt combination with a sliding tongue make
sure the retractor is in the ªautomatic locking
mode.º
*
[SR16095(BEF )05/95]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
*
[SR16100(BEF )05/95]
RWARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
File:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
ProCarManuals.com

38
*
[SR16200(BEF )05/95]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat you
put in your vehicle. If you do not install and
use the safety seat properly, the child may be
injured in a sudden stop or collision.
*
[SR16250(BEF )10/94]
RWARNING
Seatbacks should be upright for use with
child safety seats.
*
[SR16275(BEF )05/95]
RWARNING
Always keep the buckle release button
pointing upward and away from the child
seat, with the tongue between the child
seat and the release button as shown in
the following illustration.
[SR16280(BEF )05/95]
half page art:0021377-BFile:ltsrb.ex
Update:Tue Jun 20 16:58:10 1995
