FORD CONTOUR 1996 2.G Owners Manual

Steering Column Controls
89
*
[SC09000(ALL)06/95]
If you drive up or down a steep hill, your vehicle may
momentarily slow down or speed up, even though the speed
control is on. This is normal.
[SC09010(ALL)05/95]
NOTE: If your vehicle is equipped with an automatic
transaxle, and if your speed increases above your set
speed while driving in Overdrive on a downhill
grade, you may want to turn the Overdrive off and
use Drive. You may turn the Overdrive off by
pressing the Transaxle Control Switch on the left side
of the gearshift lever. This will reduce vehicle speed
if it goes above your set speed on a downhill grade.
For the best fuel economy during normal driving
conditions, leave the vehicle in Overdrive, or resume
as soon as possible.
[SC09020(ALL)05/95]
NOTE: If your vehicle is equipped with a 5-speed manual
transaxle, and if your speed increases above your set
speed while driving in 5 (Fifth) gear on a downhill
grade, you may want to shift to 4 (Fourth) gear to
reduce vehicle speed. Depressing the clutch pedal
cancels speed control, therefore speed control must be
reset by pressing the SET/ACC or RES buttons. Speed
control cannot reduce the vehicle speed if it goes
above your set speed on a downhill grade.
[SC09150(ALL)05/94]
Speed control is cancelled when Traction Control (if equipped)
becomes active.
File:cdsco.ex
Update:Thu Jan 25 12:10:03 1996

90
%*
[SC09200(ALL)06/95]
Accelerating With the Speed Control Operating
*
[SC09300(ALL)05/95]
You can use the accelerator pedal to speed up momentarily.
When you take your foot off the accelerator, the vehicle will
return to the set speed.
*
[SC09400(ALL)01/95]
Resetting the Speed Control
*
[SC09410(ALL)03/95]
To reset the speed control to alower speed, use one of the
following procedures:
*
[SC09415(ALL)03/95]
n
COASTÐ Press and hold the COAST switch. Release the
switch when the vehicle slows down to the desired speed.
[SC09420(ALL)05/94]
n
Tap the brake pedal. When the vehicle attains the desired
speed, press the SET ACC switch and release it immediately.
[SC09427(ALL)05/94]
n
TAP-DOWNÐ Press and then quickly release the COAST
switch. Each time you ªtapº the switch, the set speed will
decrease by 1 mph (1.6 km/h).
*
[SC09430(ALL)05/95]
If vehicle speed is reduced below 30 mph (50 km/h) by any of
the above methods, then you must manually accelerate to a
speed over 30 mph (50 km/h) and reset the system.
*
[SC09435(ALL)03/95]
To reset the speed control toa higher speed, follow one of
these procedures:
[SC09440(ALL)05/94]
n
ACCÐ Press and hold the SET ACC switch. Release the
switch when the vehicle has accelerated to the desired speed.
[SC09445(ALL)03/95]
n
Depress the accelerator pedal. When the vehicle attains the
desired speed, press and release the SET ACC switch.
[SC09452(ALL)05/94]
n
TAP-UPÐ Press and then quickly release the SET ACC
switch. Each time you ªtapº the switch, the set speed will
increase by 1 mph (1.6 km/h).
File:cdsco.ex
Update:Thu Jan 25 12:10:03 1996

Steering Column Controls
91
[SC09500(ALL)05/95]
To Cancel Speed Control
[SC09600(ALL)05/95]
Speed control can be cancelled at any time by pressing the
brake pedal slightly. After cancelling, you can return to the
speed you set by pressing the RES switch, or set a new speed
by pressing the SET ACC or COAST switch.
%*
[SC10900(ALL)06/95]
Cancelling and Resuming a Set Speed
[SC11000(ALL)05/95]
If you press the brake pedal, the speed control is suspended.
You can return to the set speed by pressing the RES switch, as
long as you did not press the OFF switch. You must be driving
at least 30 mph (50 km/h).
*
[SC11300(ALL)05/95]
Your vehicle will gradually return to the previously set speed
and then maintain it.
%*
[SC11360(ALL)05/95]
To Turn Off the Speed Control System
*
[SC11370(ALL)05/95]
Press the OFF switch.
*
[SC11380(ALL)05/95]
In addition, the speed control is turned off each time you turn
the vehicle off.
File:cdsco.ex
Update:Thu Jan 25 12:10:03 1996

93
Features
*
[FV00401(ALL)02/95]
Your vehicle has a variety of features designed for your
comfort, convenience and safety. Read this chapter to find out
about standard and optional features.
*
[FV00500(ALL)01/95]
Doors
%*
[FV01000(ALL)02/95]
Childproof Locks for the Rear Doors
[FV01100(ALL)05/94]
In addition to standard or power locks, your vehicle has
childproof locks for the rear doors. If you set these locks, the
rear doors cannot be opened from the inside of the vehicle. The
doors can still be opened from the outside if the doors are
unlocked.
[FV01200(ALL)11/93]
17-1/2 pica
art:0001247-A
The childproof locks for the rear door
*
[FV01220(ALL)03/95]
To set the childproof lock on each rear door, open the rear
door.
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996

94
[FV01240(ALL)01/95]
Find the lever at the black label with word LOCKED in white
letters. Move the lever toward the inside of the door.
*
[FV01260(ALL)03/95]
To release the childproof lock, open the rear door from the
outside.
[FV01280(ALL)01/95]
Move the lever toward the outside of the door.
*
[FV01300(ALL)04/95]
Power Door Locks (If equipped)
[FV01400(ALL)01/95]
If your vehicle has power door locks, the controls to lock the
doors are on the trim panel of the front door. When you close
the doors after you set the door locks, the doors remain locked.
If the power mechanism fails, the manual door lock will
automatically override the power controls.
[FV01500(ALL)05/94]
10-1/2 pica
art:0001250-B
The power door lock on the driver's door
%*
[FV01530(ALL)01/95]
Using the Illuminated Entry System (If equipped)
[FV01560(ALL)05/95]
If your vehicle is equipped with the illuminated entry system,
the interior lights turn on when you lift the outside door handle
on either front door.
[FV01590(ALL)01/95]
These lights automatically turn off after 12 seconds or when you
turn the ignition key to ON or ACC. The inside lights will not
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996

Features
95 turn off if you have turned them on with the switch in the
dome lamp or if the front door is open.
[FV01600(ALL)05/95]
Remote Entry System (If equipped)
*
[FV01700(ALL)03/94]
If your vehicle has the remote entry system, you can lock and
unlock the vehicle doors and open the trunk without using a
key. The remote also has a personal alarm feature. The buttons
for the system are located on the hand held transmitter(s) that
came with your vehicle.
[FV01800(ALL)02/95]
The system will work with up to four transmitters. Additional
transmitters can be ordered from your dealer.
*
[FV01900(ALL)02/95]
The remote entry features only operate with the ignition in the
OFF position.
[FV02000(ALL)11/93]
10-1/2 pica
art:0001221-A
Remote entry transmitter
%*
[FV02100(ALL)02/95]
Unlocking the doors and opening the trunk
*
[FV02200(ALL)02/95]
To unlock the driver's door, press the UNLOCK button.
*
[FV02300(ALL)02/95]
To unlock the other doors, press the UNLOCK button a second
time within five seconds of unlocking the driver's door.
*
[FV02400(ALL)02/95]
To open the trunk, press the TRUNK button.
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996

96
[FV02500(ALL)05/94]
When you use the remote entry UNLOCK, TRUNK or PANIC
buttons, the illuminated entry system turns on the interior
lights for 12 seconds. You can turn these lights off by turning
the ignition to the ON position. The interior lights will not turn
off if you have turned them on manually or if a door is open.
[FV02550(ALL)05/94]
NOTE: The illuminated entry system will only work when
the dome light switch is in the ª12º position.
*
[FV02600(ALL)02/95]
Locking the doors
*
[FV02700(ALL)02/95]
To lock all the doors, press the LOCK button.
*
[FV02800(ALL)01/95]
If you would like a signal that the doors are being locked, press
the LOCK button again within five seconds. The doors will lock
again, the horn will beep and the low beam headlamps and tail
lamps will flash.
%*
[FV02900(ALL)02/95]
Activating the remote personal alarm
[FV03000(ALL)04/94]
If you wish to activate the remote personal alarm, press the
PANIC button. This will honk the horn and flash the low beam
headlamps and tail lamps for approximately two minutes
forty-five seconds. You can turn it off by pressing the PANIC
button again on the same transmitter or by turning the ignition
key to the ON position.
%*
[FV03100(ALL)02/95]
Replacing the batteries
*
[FV03200(ALL)02/95]
The remote entry transmitter is powered by two coin type
three-volt lithium 2016 batteries (included) that should last for
several years of normal use. If you notice a significant decrease
in operating range, the batteries should be replaced.
Replacement batteries can be purchased at most pharmacies,
watch stores or at your Ford or Lincoln-Mercury dealer.
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996

Features
97
*
[FV03300(ALL)11/93]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet
(10 meters) away from your vehicle.
[FV03400(ALL)05/94]
7-1/2 pica art:0001315-A
Replacing the batteries
*
[FV03500(ALL)02/95]
The transmitter can be snapped apart to replace the batteries by
twisting a thin coin between the two halves of the transmitter.
DO NOT TAKE THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be sure to place the
positive (+) side down as marked. Snap the two halves back
together.
%*
[FV03600(ALL)02/95]
Replacement/additional transmitters
*
[FV03700(ALL)02/95]
In the event a transmitter is lost, return the remaining
transmitters to your dealer for reprogramming of your remote
entry system. This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[FV03800(ALL)02/95]
Additional transmitters may be purchased from your dealer
(remote entry system will work with up to four transmitters).
Return your existing transmitters to your dealer so the remote
entry system can be reprogrammed with your new and existing
transmitters.
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996

98
*
[FV03900(ALL)02/95]
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC
RULES. OPERATION IS SUBJECT TO THE FOLLOWING
TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST
ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED
OPERATION.
*
[FV07800(ALL)02/95]
Windows
*
[FV08200(ALL)02/94]
Power Windows (If equipped)
*
[FV08300(ALL)02/95]
Each door has a power control that opens and closes the
window on that door. The driver's door has a master control
panel that operates all four windows.
[FV08400(ALL)04/94]
In order to use your power window controls, the ignition switch
must be in the ON position.
[FV08450(ALL)05/94]
10-1/2 pica
art:0001191-B
The master controls on the driver's door
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996

Features
99
*
[FV08500(ALL)05/95]
RWARNING
Do not let children play with the power windows. They
may seriously hurt themselves. Make sure occupants are
clear of the window(s) before closing.
[FV08600(ALL)01/95]
One-touch-down window
[FV08700(ALL)11/93]
The one-touch-down feature allows you to completely open the
driver's window by briefly pressing and releasing the bottom of
the window switch. To stop the window before it opens
completely, press the switch again.
[FV08800(ALL)11/93]
The one-touch feature only opens the window. To close the
window, you must press and hold the top of the switch.
[FV09000(ALL)01/95]
Rear window lockout
[FV09100(ALL)11/93]
To lock out the rear window switches with the master controls,
slide the lockout switch to the left. To restore individual control,
slide the switch to the right.
*
[FV09200(ALL)02/95]
Moon Roof (If equipped)
*
[FV09300(ALL)03/95]
You can move the moon roof back to open the glass panel, or
you can tilt it up to ventilate the vehicle.
[FV09350(ALL)01/95]
The rocker type switch is used to open and close the moon roof.
You must press and hold the switch until the desired position is
reached. At open and closed positions, the motor will
automatically turn off. Release the switch at this time to avoid
motor damage.
File:cdfvo.ex
Update:Thu Jan 25 12:20:30 1996
