Starting Your Contour
49
%*
[ST10600(ALL)06/95]
Engine Block Heater (If equipped)
*
[ST10700(ALL)03/95]
Engine block heaters are strongly recommended if you live in a
region where temperatures reach-10ÊF (-23ÊC) orbelow. An
engine block heater warms the engine coolant, which improves
starting, warms up the engine faster, and allows the
heater-defrost system to respond quickly.
*
[ST10900(ALL)01/95]
To turn the heater on, simply plug it into a grounded 110-volt
outlet. Ford recommends that you use a 110-volt circuit that is
protected by a ground fault circuit interrupter.
*
[ST11100(ALL)05/95]
RWARNING
To prevent electrical shock, do not use your heater with
ungrounded electrical systems or two-pronged (cheater)
adapters.
*
[ST11150(ALL)03/95]
For best results, plug the heater in at least three hours before
you start your vehicle. Using the heater for longer than three
hours will not damage the engine, so you can plug it in at night
to start your vehicle the following morning.
File:cdsto.ex
Update:Thu Jan 25 12:13:36 1996

50
*
[ST11200(ALL)03/95]
If the Engine Cranks but Does Not Start or
Does Not Start After a Collision
%*
[ST11300(ALL)04/95]
Fuel Pump Shut-off Switch
*
[ST11400(ALL)03/95]
If the engine cranks but does not start or does not start after a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device intended to stop the
fuel pump when your vehicle has been involved in a substantial
jolt.
[ST11500(ALL)01/95]
Once the shut-off switch is triggered, you must reset the switch
by hand before you can start your vehicle. The switch is located
on the left hand kick panel in the driver's footwell.
[ST11600(ALL)01/95]
13-1/2 pica
art:0000530-D
The left-hand kick panel in the driver's footwell
*
[ST11700(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the switch or try to
start your vehicle. Have all the passengers get out of the
vehicle and call the local fire department or a towing
service.
File:cdsto.ex
Update:Thu Jan 25 12:13:36 1996

Starting Your Contour
51
*
[ST11800(ALL)03/95]
If your engine cranks but does not start after a collision or
substantial jolt:
*
[ST11900(ALL)04/95]1.
Turn the ignition key to the OFF position.
*
[ST12000(ALL)03/95]2.
Check under the vehicle for leaking fuel.
*
[ST12050(ALL)03/95]3.
If you do not see or smell fuel, push the red reset button
down. If the button is already set, you may have a different
mechanical problem.
*
[ST12100(ALL)03/95]4.
Turn the ignition key to the ON position for a few seconds,
then turn it to the OFF position.
*
[ST12150(ALL)03/95]5.
Check under the vehicle again for leaking fuel.If you see or
smell fuel, do not start your vehicle again.If you do not
see or smell fuel, you can try to start your vehicle again.
*
[ST12175(ALL)03/95]6.
Check all vehicle warning lights before driving the vehicle.
%*
[ST12300(ALL)05/95]
Guarding Against Exhaust Fumes
*
[ST12400(ALL)02/95]
Carbon monoxide, although colorless and odorless, is present in
exhaust fumes. Take precautions to avoid its dangerous effects.
*
[ST12500(ALL)05/95]
RWARNING
Do not start your vehicle in a closed garage or other
enclosed area. Never sit in a stopped vehicle for more
than a short period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding Against Exhaust
Fumesin this chapter for more instructions.
*
[ST12600(ALL)05/95]
RWARNING
If you smell exhaust fumes inside your vehicle, have
your dealer inspect your vehicle immediately. Do not
drive if you smell exhaust fumes.
File:cdsto.ex
Update:Thu Jan 25 12:13:36 1996

52
*
[ST12700(ALL)01/95]
Have the exhaust and body ventilation systems checked
whenever:
*
[ST12800(ALL)02/95]
n
your vehicle is raised for service
*
[ST12900(ALL)02/95]
n
the sound of the exhaust system changes
*
[ST13000(ALL)01/95]
n
your vehicle has been damaged in a collision
*
[ST13200(ALL)01/95]
Improve your ventilation by keeping all air inlet vents clear of
snow, leaves, and other debris.
*
[ST13300(ALL)03/95]
If the engine is idling while you are stopped in an open area
for long periods of time, open the windows at least one inch
(2.5 cm). Also, adjust the heating or air conditioning to bring in
outside air.
[ST13500(ALL)11/93]
If you use the heater, set the fan speed on medium or high with
the function control knob turned to FLR, PNL/FLR or PANEL.
[ST13800(ALL)12/88]
If you use the air conditioner, set the fan speed on medium or
high with the A/C button pressed. (Do not use MAX A/C.)
File:cdsto.ex
Update:Thu Jan 25 12:13:36 1996

53
Warning Lights and Gauges
*
[LG00500(O )05/92]
In your vehicle, the warning lights and gauges are grouped
together on the instrument panel. We call this grouping a
cluster. Your vehicle has one of the following clusters:
*
[LG00600(O )05/91]
n
Standard Cluster
*
[LG00700(O )12/89]
n
Sport Cluster
*
[LG01100(O )05/94]
If you are not sure which cluster your vehicle has, check the
diagrams on the following pages.
File:cdlgo.ex
Update:Thu Jan 25 12:16:21 1996

54
[LG01350(O )05/95]
33-1/2 pica
art:0001262-B
The standard cluster
File:cdlgo.ex
Update:Thu Jan 25 12:16:21 1996

Warning Lights and Gauges
55
[LG01600(ALL)05/95]
33-1/2 pica
art:0000012-G
The sport cluster
File:cdlgo.ex
Update:Thu Jan 25 12:16:21 1996

56
*
[LG01700(O )12/89]
Standard Cluster
*
[LG01800(O )12/89]
The following warning lights and gauges are on the standard
cluster. All of the warning lights and gauges alert you to
possible problems with your vehicle. The following sections
detail what each of these indicators means.
*
[LG02400(ALL)01/95]
Indicator Lights and Chimes
%*
[LG02500(ALL)05/95]
Safety Belt Warning Light and Chime
*
[LG02612(ALL)01/95]
This warning light and chime remind you to fasten your safety
belt. The following conditions will take place:
*
[LG02614(ALL)03/95]
n
If the driver's safety belt is not buckled when the ignition is
turned to the ON position, the light will turn on for 1 to 2
minutes and the chime will sound for 4 to 8 seconds.
*
[LG02616(ALL)03/95]
n
If the driver's safety belt is buckled while the light is on or
the chime is sounding, both the light and the chime will turn
off.
*
[LG02618(ALL)03/95]
n
If the driver's safety belt is buckled before the ignition is
turned to the ON position, neither the light nor the chime
will turn on.
[LG02800(ALL)01/95]
6 pica art:0000291-CFile:cdlgo.ex
Update:Thu Jan 25 12:16:21 1996

Warning Lights and Gauges
57
*
[LG02900(ALL)03/95]
Brake System Warning Light
*
[LG03000(ALL)03/95]
The warning light for the brakes can show two things Ð that
the parking brake is not fully released, or that the brake fluid
level is low in the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by a qualified service
technician.
[LG03400(ALL)01/95]
6 pica art:0000971-D*
[LG03500(ALL)01/95]
This light comes on when the parking brake is set, or if it is not
set, it comes on briefly when you turn the ignition to the
START position. It normally goes off shortly after the engine
starts and you release the parking brake. If the light stays on
after you have fully released the parking brake, have the
hydraulic brake system serviced by your dealer or a qualified
service technician.
*
[LG03700(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
File:cdlgo.ex
Update:Thu Jan 25 12:16:21 1996

58
*
[LG03800(ALL)01/95]
Charging System Light
*
[LG03900(ALL)03/95]
This light indicates that your battery is not being charged and
that you need to have the electrical system checked.
[LG04100(ALL)01/95]
6 pica art:0000293-C*
[LG04300(ALL)05/95]
This light comes on every time you turn the ignition to the ON
or START position (engine off). The light should go off when
the engine starts and the alternator begins to charge.
*
[LG04400(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
%*
[LG04800(ALL)02/95]
Engine Oil Pressure Warning Light
*
[LG04900(ALL)01/95]
This light indicates the engine's oil pressure, not the oil level.
However, if your engine's oil level is low, it could affect the oil
pressure. The light will come on briefly when you turn your
key to the START and ON position. The light should stay off
when the engine is running with normal oil pressure. If the
light comes on while the engine is running, you have lost oil
pressure and continued operation will cause severe engine
damage.
[LG05010(ALL)01/95]
6 pica art:0000294-BFile:cdlgo.ex
