Instrumentation
11 Brake system warning
Extinguishes when the parking
brake is released. Illuminates after
releasing the parking brake to
indicate low brake fluid level.
BRAKE
BRAKE
Alternative design
BRAKE
BRAKE
Engine oil pressure
Briefly illuminates when the
ignition is turned on and the engine
is off. The light also illuminates
when engine oil pressure has been
lost. Refer to the Maintenance
and carechapter to check the
engine oil level as soon as possible.
If the engine oil level is correct and
the light stays on, see your dealer
or qualified service technician. Anti-lock brake system (ABS)
(if equipped)
Momentarily illuminates when the
ignition is turned on and the engine
is off. If the light stays on or
continues to flash, the ABSneeds
to be serviced.
BRAKE
BRAKE
Alternative design Alternative design
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 11

Instrumentation
12
EF 1
/
2
UNLEADED FUEL ONLY
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFF
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
CHECK
ENGINE
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
EF 1
/
2
UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFFCHECK
ENGINE
Testing the warning and
indicator lights and chimes
Turn the ignition key to the on
position without starting the
engine. The following warning and
indicator lights will illuminate
briefly: charging system, safety belt
(does not illuminate, if the driver’s
safety belt is fastened), low
coolant, low fuel, engine oil
pressure, check engine and air bag
readiness.
If any of these lights do not
illuminate, see your dealer or
qualified service technician.
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 12

Instrumentation
13
Headlamps on warning chime
Sounds when the headlamps are
on, the ignition is off (and the key
is not in the ignition) and the
driver’s door is open.
Key-in-ignition warning chime
Sounds when the key is left in the
off/lock or accessory position and
the driver’s door is open.
Air bag supplemental restraint
system (SRS) warning chime
For information on the SRS
warning chime, refer to the
Seating and safety restraints
chapter.
Safety belt warning chime
For information on the safety belt
warning chime, refer to the
Seating and safety restraints
chapter.
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 13

Instrumentation
14
EF 1
/
2
UNLEADED FUEL ONLY
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFF
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
CHECK
ENGINE
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
EF 1
/
2
UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFFCHECK
ENGINE
INSTRUMENT CLUSTER
GAUGES
Tachometer (if equipped)
Indicates the engine speed in
revolutions per minute (rpm).
12
03
x 1000
4
5
6
7
8
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 14

Instrumentation
15
NORMALEngine coolant temperature
gauge
Indicates the temperature of the
engine coolant. At normal
operating temperature, the needle
remains within the NORMAL area.
If it enters the red section, the
engine is overheating. Switch off
the ignition and determine the
source of the problem. Refer to
Checking and adding engine
coolant in the Maintenance and
care chapter.
Speedometer
Indicates the current vehicle
speed.
Odometer
Registers the total mileage of the
vehicle.
Trip odometer
The trip odometer can register the
mileage of individual journeys. To
reset, depress the button.
000123
0000
10 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
Speedometer
Odometer
Trip odometerReset button
CDW IIA2Instrum_en C 5/15/97 8:42 PM Page 15

Instrumentation
16
EF 1
/
2
UNLEADED FUEL ONLY
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFF
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
CHECK
ENGINE
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
EF 1
/
2
UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMAL
BRAKE
TRACTION
CONTROLO/D
OFFCHECK
ENGINE
EF 1
/
2
UNLEADED FUEL ONLY
Fuel gauge
The fuel gauge displays the
approximate level of usable fuel left
in the fuel reservoir.
CDW IIA2Instrum_en C 5/15/97 8:43 PM Page 16

Controls and features
17
MIRRORS
HM:
I0 20
OFF LOPNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
INSTRUMENT PANEL
CONTROLS
Headlamp control
Lamps off.
Turn one position clockwise:
Parking lamps, instrument panel
lamps, license plate lamps and tail
lamps on.
Turn two positions clockwise:
Headlamps on.
CDW IIA2Instrum_en C 5/15/97 8:43 PM Page 17

Controls and features
18Daytime running lights (DRL)
(Canadian vehicles only)
The DRL system turns on the
highbeam headlamps, with a
reduced light output, when:
•the vehicle is running and the
ignition is in the on position,
•the vehicle has a fully released
parking brake, and
•the headlamp system is in the off
position.
The daytime running light
(DRL) system will not
illuminate the tail lamps and
parking lamps. Turn on your
headlamps at dusk. Failure to do
so may result in a collision.
Foglamp control (if equipped)
Pull out the control while the
headlamps are on to turn the
foglamps on.
Push in the control to deactivate
the foglamps.
CDW IIIC3Controls en C 5/15/97 8:44 PM Page 18

Controls and features
19 Panel dimmer control
Adjust the control to vary the
intensity of the panel lighting.
Operates only when the exterior
lights are switched on.
Rear window defroster
(if equipped)
Press the defroster control to clear
the rear window of thin ice and fog.
The ignition must be in the on
position to operate the rear
window defroster.
The defroster turns off
automatically after 10 minutes or
when the ignition is turned to the
off position. To manually turn off
the defroster, push the control
again.
CDW IIIC3Controls en C 5/15/97 8:44 PM Page 19

Controls and features
20Power mirrors (if equipped)
The control can be swivelled and
turned.
Turn the control counterclockwise
to adjust the driver’s side mirror,
clockwise to adjust the passenger
side mirror. Adjust the selected
mirror by moving the center
control in the desired direction.
Then turn the control back to the
center position.
MIRRORS
MIRRORS
HM:
I0 20
OFF LOPNL/FLR
PANEL
A/CFLOOR
DEF FLR
DEF
MAX
A/C HI/
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
000123
000010 20 3040506070
80
90
100
110
120
130MPH20 406055
80120 100
140
160
180
200EF 1
/
2UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMALBRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
MIRRORS
