FORD CROWN VICTORIA 1997 1.G Owners Manual

90
%*
[CF20800( ALL)03/96]
Clock
[CF20900( GV)12/95]
quarter page art:0011295-B
The digital clock
[CF21200( ALL)12/95]
1. To set the hour, press and hold the H
button. When the desired hour appears,
release the button.
[CF21300( ALL)12/95]
2. To set the minutes, press and hold the M
button. When the desired minute appears,
release the button.
%
*
[CF21400( GV)12/95]
Ashtray and Cupholder
[CF21500( GV)12/95]
Your vehicle is equipped with an
ashtray/cupholder mounted to the lower center
of the instrument panel.
*
[CF21600( GV)12/95]
To open the ashtray, pull out the bottom edge of
the drawer until it stops.
*
[CF21700( GV)12/95]
To close, remove cup(s) and push drawer
forward until closed.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

91
[CF22600( ALL)01/96]
Storage Compartments
*
[CF22700(M GV)03/96]
Your vehicle may have several small storage
compartments:
[CF23100( BCGV)12/95]
q
a glove compartment that locks. Use the
round key to lock and unlock it.
[CF23200( ALL)01/96]
WARNING
Do not put objects on the ledge between
the back seat and the rear window, as
they can become dangerous projectiles and
injure someone.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

92
% [CF23300( ALL)03/96]
Using the Remote Control for the
Trunk (If equipped)
[CF23600( GV)03/96]
You can use the remote control on the driver's
door to unlock and open the trunk unless you
lock the button with main key. The valet key
equipped with your vehicle can only open the
doors and start the engine.
[CF23900( GV)12/95]
one third page art:0010670-C
The remote control for the trunk
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

93
*
[CF24100( ALL)01/96]
Ignition
%*
[CF24200( ALL)01/96]
Understanding the Positions of the Ignition
[CF24300( ALL)12/95]
quarter page art:0010035-B
The positions of the key in the ignition
*
[CF24500( BCGV)04/96]
ACC allows some of your vehicle's electrical
accessories such as the radio and the windshield
wipers to operate while the engine is not
running.
% [CF24600( ALL)12/95]
LOCK locks the steering wheel. It also locks the
automatic transmission gearshift lever.
*
[CF24700( ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
*
[CF24800( ALL)01/96]
OFF allows you to shut off the engine and all
accessories without locking the steering wheel or
the automatic transmission gearshift lever.
*
[CF24900( ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
*
[CF25000( ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

94 %
*
[CF25100( ALL)03/96]
Removing the Key From the Ignition
*
[CF25200( BCGV)03/96]
1. Put the gearshift in P (Park).
*
[CF25400( ALL)01/96]
2. Set the parking brake fully.
*
[CF25500( BCGV)03/96]
3. Turn the ignition key to LOCK.
*
[CF25700( BCGV)03/96]
4. Remove the key.
[CF26300( BCGV)12/95]
NOTE: The automatic transmission gearshift
must be in P (Park) to move the key to
the lock position.
%*
[CF26400( ALL)01/96]
If the key is stuck in the LOCK position, move
the steering wheel left or right until the key
turns freely.
%*
[CF26500( ALL)12/95]
If the driver's door is open while the key is still
in the ignition, a warning chime sounds.
*
[CF26700( BCGV)05/96]
WARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[CF26800( ALL)03/96]
WARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
%
*
[CF26900( ALL)02/96]
The Turn Signal Lever
*
[CF27000( ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
[CF27100( ALL)04/96]
q
operate the turn signals
*
[CF27200( ALL)03/96]
q
turn the high beams on/off
*
[CF27300( ALL)03/96]
q
flash the lamps
*
[CF27400( ALL)03/96]
q
turn the windshield wipers and washer
on/off
[CF27500( GV)12/95]
q
turn the cornering lamps on
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

95 [CF27600( ALL)12/95]
one third page art:0011292-A
The turn signal lever
%*
[CF27700( ALL)01/96]
Turn Signals
*
[CF27800( ALL)01/96]
Move the lever up to signal a right turn. Move
it down to signal a left turn. The corresponding
indicator light in the instrument cluster will
flash.
*
[CF27900( ALL)01/96]
If the turn signal stays on after you turn, move
the lever back to the center (off) position.
*
[CF28000( ALL)01/96]
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
[CF28100( GV)12/95]
If your vehicle is equipped with cornering
lamps, they will automatically light on either the
right or left side (depending on the direction of
the turn), when the headlamps are ON.
%*
[CF28200( ALL)01/96]
High Beams
*
[CF28300( ALL)01/96]
To turn on the high beams, turn the headlamp
control knob to the headlamp ON position and
push the turn signal lever away from you until
it latches. When the high beams are ON, the
high beam indicator light on the instrument
panel comes on.
*
[CF28400( ALL)01/96]
To turn off the high beams, pull the lever
toward you until it latches. The high beam
indicator light turns off.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

96 %
*
[CF28700( ALL)01/96]
Flashing the Lights
*
[CF28800( ALL)01/96]
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp
knob is in the on or off position.
%
*
[CF28900( ALL)01/96]
Windshield Wipers and Washer
*
[CF29000( ALL)04/96]
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
[CF29100( ALL)12/95]
Rotate the end of the lever away from you to
activate the wipers. The first seven detents are
interval wipe positions, the eighth detent is the
LO position and the ninth detent is the HI
position.
[CF29200( ALL)04/96]
To turn the wipers off, turn the knob toward
you to the OFF position.
%*
[CF29300( ALL)01/96]
Variable Interval Wipers
*
[CF29400( ALL)12/95]
In addition to two speed wipers, your vehicle
has wipers that you can set to operate at
varying intervals. For example, you can set the
interval so they wipe less often when it drizzles
or more often in heavier rain.
[CF29500( ALL)12/95]
one third page art:0011293-A
The variable interval wiper on the turn signal lever
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

97 [CF29600( ALL)04/96]
To set the interval wipers, turn the knob at the
end of the turn signal lever toward or away
from you until the wipers are going at the
desired interval.
*
[CF29700( ALL)01/96]
Windshield Washer
*
[CF29800( ALL)12/95]
To clean the windshield, push in the end of the
wiper knob. For a constant spray, keep the knob
pushed in. After you release the knob, the
wipers operate for two to three cycles before
turning off (if the wipers were OFF) or
returning to HI, LO, or the interval setting
selected.
*
[CF29900( ALL)03/96]
If the washer does not work, check the washer
fluid level and fill it if it is low. See the
Maintenance and Carechapter. If there is enough
fluid, consult your nearest Ford or
Lincoln-Mercury dealer.
*
[CF30000( ALL)08/95]
Do not try to clean the windshield when the
washer fluid container is empty or activate the
washers at any time for more than 15 seconds
continuously. This could damage the washer
pump system.
*
[CF30100( ALL)01/96]
WARNING
Always warm up the windshield with the
defroster before you use the washer fluid.
In freezing weather, the washer solution
may freeze on the windshield and obscure
your vision.
*
[CF30200( ALL)03/96]
For information about refilling the washer fluid
or replacing your windshield wiper blades, see
Windshield washer fluid and Wipersin the Index.
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

98
%*
[CF30300( ALL)03/96]
Hazard Flasher
[CF30400( ALL)05/96]
To alert other drivers to hazardous situations,
push in the hazard flasher on the top of the
steering column. The same control turns the
flashers off.
[CF30500( BCGV)05/96]
one third page art:0010216-B
The control for the hazard flashers
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997

99
%*
[CF30700( ALL)05/96]
Horn
*
[CF30800( ALL)01/96]
To sound the horn, push the center pad area of
the steering wheel.
[CF31100( GV)12/95]
half page art:0010086-F
The horn on the steering wheel
File:05rccfv.ex
Update:Thu Mar 27 07:20:00 1997
