FORD CROWN VICTORIA 1997 1.G Owners Manual

241
your vehicle. We recommend the use of
gasolines that meet the AAMA specification if
they are available.
*
[MC31560( ALL)05/96]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
*
[MC31600( ALL)04/96]
Clean air
*
[MC31701( ALL)05/96]
Ford approves the use of gasolines to improve
air quality, including reformulated gasolines that
contain oxygenates such as a maximum of 10%
ethanol or 15% MTBE. There should be no more
than 5% methanol with cosolvents and additives
to protect the fuel system.
%*
[MC32000( ALL)01/96]
Safety Information Relating to Automotive
Fuels
*
[MC32100( ALL)01/96]
RWARNING
Automotive fuels can cause serious injury
or death if misused or mishandled.
*
[MC32200( ALL)05/96]
q
Turn vehicle off when refueling.
*
[MC32300( ALL)08/95]
q
Do not smoke when refueling. Fuels are
extremely flammable.
*
[MC32400( ALL)08/95]
q
Do not siphon any fuel by mouth.
*
[MC32500( ALL)02/96]
RWARNING
Gasoline or gasoline blended with
methanol can cause blindness and
possible death when swallowed. If any
fuel is swallowed, call a physician or
poison control center immediately.
*
[MC32600( ALL)08/95]
q
Avoid breathing vapors while refueling.
*
[MC32700( ALL)08/95]
q
If fuel is splashed on the skin, wash with
soap and water.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

242
*
[MC32800( ALL)08/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[MC32900( ALL)01/96]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[MC33000( ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[MC33100( ALL)01/96]
Running Out of Fuel
*
[MC33200( ALL)08/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[MC33300( ALL)01/96]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
[MC33400( ALL)12/95]Calculating Fuel Economy
*
[MC33500( ALL)01/96]
Fuel economy is an estimate of the efficiency of
your vehicle, and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[MC33600( ALL)01/96]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

243
*
[MC33700( ALL)01/96]
To calculate fuel economy:
*
[MC33800( ALL)01/96]
1. Fill the fuel tank completely and record the
initial odometer reading.
*
[MC33900( ALL)01/96]
2. Every time you buy fuel, record the
amount (in gallons or liters) purchased.
*
[MC34000( ALL)01/96]
3. After at least 3-5 tankfuls, fill the fuel tank
and record the final odometer reading.
*
[MC34100( ALL)01/96]
4. Use these equations to calculate your fuel
economy:
*
[MC34200( ALL)01/96]
q
English: MPG = (total miles driven)v
(gallons used)
*
[MC34300( ALL)01/96]
q
Metric: L/100k = (liters used)v
(100 kilometers)
*
[MC34400( ALL)01/96]
Comparisons With EPA Estimates
*
[MC34500( ALL)05/96]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
*
[MC34600( ALL)01/96]
The following decrease fuel economy:
*
[MC34700( ALL)01/96]
q
Lack of regular, scheduled maintenance
*
[MC34800( ALL)01/96]
q
Rapid acceleration and excessive speed
*
[MC34900( ALL)01/96]
q
Driving with your foot on the brake
*
[MC35000( ALL)01/96]
q
Sudden stops
*
[MC35100( ALL)01/96]
q
Extended engine idling
*
[MC35200( ALL)01/96]
q
Using speed control in hilly terrain
*
[MC35300( ALL)01/96]
q
Extended use of the A/C, defroster, rear
window defroster and other accessories
*
[MC35400( ALL)01/96]
q
Underinflated tires
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

244
*
[MC35500( ALL)01/96]
q
Heavy loads
*
[MC35600( ALL)01/96]
q
Aftermarket add-ons such as bike, ski or
luggage racks, bug deflectors, etc.
*
[MC35700( ALL)12/95]
Self-Service Pointers
*
[MC35800( ALL)12/95]
If you choose to do your own fueling, you
should also perform a few simple maintenance
routines. This extra effort will save you
additional money and contribute to the driving
efficiency of your vehicle.
*
[MC35900( ALL)12/95]
The following procedures require only a tire
gauge, a rag, an oil can spout and windshield
washer fluid.
*
[MC36000( ALL)12/95]
q
Check the engine oil at every refueling stop
*
[MC36100( ALL)12/95]
q
Clean the windshield, outside mirrors and
headlights
*
[MC36200( ALL)12/95]
q
Check windshield washer fluid
*
[MC36300( ALL)12/95]
q
Check tires for excessive wear or worn edges
*
[MC36400( ALL)12/95]
q
Check the tire pressure at least monthly
%
*
[MC36500( ALL)01/96]
Emission Control System
*
[MC36600( ALL)01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC36700( ALL)05/96]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

245
*
[MC36800( ALL)01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC36900( ALL)01/96]
q
Use only unleaded fuel.
*
[MC37000( ALL)01/96]
q
Avoid running out of fuel.
*
[MC37100( ALL)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC37200( ALL)01/96]
q
Do not push start your vehicle.
*
[MC37300( ALL)02/96]
q
Have the services listed in theMaintenance
Schedulebooklet performed according to the
specified schedule. The scheduled
maintenance services are required because
they are considered essential to the life and
performance of your vehicle and to its
emissions system.
*
[MC37400( ALL)01/96]
In general, maintenance, replacement, or service
of the emissions control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those which your vehicle or engine was
originally equipped.
*
[MC37500( ALL)01/96]
Ford strongly recommends the use of genuine
Ford replacement parts. If other than Ford or
Motorcraft parts or Ford authorized
remanufactured parts are used for maintenance
replacements or for the service of components
affecting emission control, such non-Ford parts
should be equivalent to genuine Ford Motor
Company parts in performance and durability. It
is the owner's responsibility to determine the
equivalency of such parts. Please consult your
warranty booklet for complete warranty
information.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

246
*
[MC37600( ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC37700( ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC37800( ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
*
[MC37900( ALL)01/96]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[MC38000( ALL)08/95]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[MC38100( ALL)01/96]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

247 %
*
[MC38200( ALL)01/96]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
%*
[MC38300( ALL)03/96]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC38400( ALL)05/96]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional city and highway driving is necessary
to complete the check of the OBD II system.
*
[MC38601( ALL)05/96]
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below:
*
[MC38701( ALL)05/96]
q
At least twenty minutes driving in stop and
go, city type traffic with at least four idle
periods.
*
[MC38801( ALL)05/96]
q
At least ten minutes of driving on an
expressway or highway.
[MC38901( ALL)04/96]
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not
be turned off during these driving modes.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

248
%*
[MC41200( ALL)03/96]
Lights and Bulb Replacement
*
[MC41300( ALL)01/96]
It is a good idea to check the operation of the
following lights frequently:
*
[MC41400( ALL)01/96]
q
headlamps
*
[MC41500( ALL)01/96]
q
tail lamps
*
[MC41600( ALL)01/96]
q
brakelamps
*
[MC41700( ALL)01/96]
q
hazard flasher
*
[MC41800( ALL)01/96]
q
high-mount brakelamp
*
[MC41900( ALL)01/96]
q
turn signals
*
[MC42000( GV)01/96]
q
side markers
*
[MC42100( ALL)05/96]
q
license plate lamps
%*
[MC42300( ALL)01/96]
The alignment of your headlamps should be
checked if:
*
[MC42400( ALL)01/96]
q
oncoming motorists frequently signal you to
turn off your vehicle's high beams when you
do not have the high beams on
*
[MC42500( ALL)01/96]
q
the headlamps do not seem to give you
enough light to see clearly at night
*
[MC42600( ALL)01/96]
q
the headlamp beams are pointed substantially
away from a position slightly down and to
the right
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

249 %
*
[MC42700( ALL)01/96]
Headlamp Bulb
*
[MC42800( ALL)03/96]
The headlamps on your vehicle use replaceable
bulbs. When the lamp burns out, simply replace
the bulb, rather than the whole lamp.
*
[MC42900( ALL)01/96]
RWARNING
Handle a halogen headlamp bulb carefully
and keep out of children's reach. Grasp
the bulb only by its plastic base and do
not touch the glass. The oil from your
hand could cause the bulb to break the
next time the headlamps are operated.
*
[MC43000( ALL)01/96]
Do not remove the burned-out bulb unless you
can immediately replace it with a new one. If a
bulb is removed for an extended period of time,
contaminants may enter the headlamp housing
and affect its performance.
[MC43300( GV)12/95]
one third page art:0010432-B
Headlamp bulb removal
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996

250
*
[MC43400( ALL)03/96]
Removing the headlamp bulb
*
[MC43500( ALL)01/96]
1. Make sure that the headlamp switch is in
the OFF position.
*
[MC43900( GV)12/95]
2. Lift the hood, open access panel above
headlamp and find the bulb in the headlamp
socket.
*
[MC44200( GV)12/95]
3. Remove the electrical connector by pulling
off the bulb base.
*
[MC44500( GV)12/95]
4. Remove the bulb by turning it 1/4 of a turn
to free it from the socket.
*
[MC44800( ALL)03/96]
Installing the headlamp bulb
*
[MC44900( GV)12/95]
1. Insert the glass envelope of the bulb into the
socket while aligning the locking tabs.
*
[MC45100( GV)12/95]
2. Rotate the bulb 1/4 turn to lock.
*
[MC45300( ALL)01/96]
3. Push the electrical connector into the rear of
the plastic base until it snaps, locking it into
position.
*
[MC45500( GV)12/95]
4. Close the access panel.
%*
[MC45700( BCGV)01/96]
High-Mount Brakelamp Bulbs
[MC45800( BCGV)12/95]
Your vehicle has a brakelamp mounted in the
rear window, called a high-mount brakelamp.
You may need to remove this lamp at times to
replace the brakelamp bulb or to clean the rear
window.
File:11rcmcv.ex
Update:Thu Jun 20 11:05:52 1996
