FORD ESCORT 1996 7.G Owners Manual

181 [FV13400(ALL)08/95]
To gain access to the rear seat on the driver or
passenger side (2-door version only).
[FV13450(ALL)08/95]
one third page art:0070090-B[FV13500(ALL)08/95]
The seatback will return to its set reclined
position when pushed back.
[FV13550(ALL)08/95]
RWARNING
Rear seat passengers should not lean on
the front seatback while the vehicle is in
motion. A seatback which is folded
forward even a small degree may not lock
properly in the event of a sudden stop or
collision. Do not allow packages or other
objects to interfere with the normal
positions of the seatback or the emergency
seatback release. This may prevent the
seatback from locking in the event of a
sudden stop or collision and could cause
personal injury.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

182 [FV13600(ALL)08/95]Fold-Down Rear Seats
[FV13650(ALL)08/95]
Your vehicle is equipped with either a one-piece
or split folding rear seat. The rear seatback can
be folded down to provide additional cargo
space.
[FV13700(ALL)08/95]
NOTE: When folding down the rear seatback,
the safety belt tongue should be
disengaged.
[FV13750(ALL)08/95]
To lower the rear seatback:
[FV13800(ALL)09/95]
one third page art:0070051-A[FV13850(ALL)08/95]
To raise the seatback, lift the seatback rearward
until it latches. Make sure the seatback is locked
in position by pushing it forward and backward.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

183 [FV13900(ALL)08/95]
RWARNING
If you do not securely latch the seatback
in the upright position, the seatback or
objects could be thrown forward during a
sudden stop or collision, possibly injuring
you or other passengers.
[FV13950(ALL)08/95]
RWARNING
Luggage or other cargo should not be
piled higher than the seatbacks. This will
help keep items from being thrown about
and injuiring people in a collision or
sudden stop.
[FV14600(ALL)08/95]
RWARNING
To avoid the possiblity of burn injuries,
do not remove the floor carpet in the
cargo area. Emission controls cause high
exhaust temperatures under the floor.
[FV14650(ALL)08/95]
NOTE: When returning the folding seats to the
upright position, remember to return
the shoulder belts to their proper
position.
%*
[FV16000(ALL)04/95]
Cleaning the Seats
*
[FV16050(ALL)07/95]
Leather and vinyl
[FV16100(ALL)06/95]
For routine cleaning, wipe the surface with a
soft, damp cloth. For more thorough cleaning,
wipe the surface with a leather cleaner or a mild
soap.
%*
[FV16150(ALL)04/95]
Fabric
*
[FV16200(ALL)05/95]
Remove dust and loose dirt with a whisk broom
or a vacuum cleaner. Remove fresh spots
immediately. Follow the directions that come
with the cleaner.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

184
*
[FV16250(ALL)04/95]
NOTE: Before using any cleaner, test it on a
small, hidden area of fabric. If the
fabric's color or texture is adversely
affected by a particular cleaner, do not
use it.
%
*
[FV23600(ALL)01/95]
Mirrors
*
[FV23900(ALL)08/95]
You can tilt the mirror from day to night
position to reduce the glare from the headlamps
of vehicles behind you. Move the tab toward
you for the night position and away from you
for the day position.
[FV23950(ALL)06/93]
one third page art:0070008-D
The rearview mirror
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

185 %
*
[FV24800(ALL)05/95]
Side View Mirrors
[FV24850(ALL)11/93]
The standard side mirror is manually adjusted
by using the remote lever.
[FV24875(ALL)03/93]
one third page art:0070012-C
The side view mirror
[FV24900(ALL)06/93]
Electric Remote Control Mirrors
(If equipped)
[FV24925(ALL)04/94]
If your vehicle has dual electric remote control
mirrors, you can control both side view mirrors
with one switch. The ignition key must be in the
ACC or ON position to operate the electric
remote control mirror switch.
[FV24960(ALL)04/94]
one third page art:0000914-A
The electric remote control mirror switch
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

186 [FV24975(ALL)08/95]To adjust the driver-side mirror, set the mirror
selection switch to the L position. To adjust the
passenger-side mirror, set the selection switch to
the R position.
[FV25025(ALL)03/91]
After you choose the mirror you want to adjust,
you can move the mirror in any of four
directions. Move the knob in the direction you
would like the mirror to move. After completing
adjustment, move the switch to the center
position to avoid moving the mirror by mistake.
*
[FV25700(ALL)05/95]
RWARNING
The side view mirror on the right makes
objects appear smaller and farther away
than they actually are.
[FV27280(ALL)06/95]
Do not clean the plastic housing of any rearview
mirror with fuel or other petroleum-based
cleaning products.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

187
[FV31050(ALL)08/95]
Cupholder and Tray (If equipped)
[FV31060(ALL)04/94]
Your vehicle may have a removable cupholder
and storage tray for your convenience.
[FV31062(ALL)04/94]
If you have the removable cupholders and
storage tray, they can be washed in a
dishwasher.
[FV31070(ALL)07/93]
one third page art:0070013-B
The cupholder and tray
*
[FV31085(ALL)01/95]
RWARNING
Use only soft cups in the cupholder. Hard
objects can injure you in a collision.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

188
[FV33210(ALL)03/95]
Hatchback or Trunk
[FV33245(ALL)06/94]
Using the Remote Control for the Trunk or
Hatchback (If equipped)
[FV33250(ALL)06/94]
Your vehicle may have a remote control release
that allows you to open the trunk or hatchback
from inside your vehicle. To release the trunk or
hatchback, pull up on the release lever located
on the floor between the driver's seat and the
door.
[FV33255(ALL)09/95]
two third page art:0070089-C
The remote control trunk release
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

189
[FV38502(E )12/89]
Cargo Area Cover
[FV38503(E )12/89]
This removable cover hides cargo in the luggage
compartment. The cover lifts automatically when
you open the hatchback.
[FV38505(E )06/94]
half page art:0070263-A
The lift cords on the hatchback
[FV38510(E )04/94]
RWARNING
Do not place any items on the cargo area
cover. They may make it difficult to see
out the window, or they could be
dangerous if they strike any occupants of
the vehicle in the case of a sudden stop or
collision.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995

190
*
[FV38512(E )11/91]
To remove the luggage compartment cover:
*
[FV38514(E )12/89]
1. Raise the hatchback to the fully open
position.
[FV38516(E )07/93]
2. From the outside of your vehicle, unhook
the looped end of the nylon lift cords from
the pins in the hatchback.
[FV38519(E )12/91]
3. Grasp the rear of the cargo cover and hold
the cover at a 30-degree angle before sliding
it out of the mounting clips.
[FV38521(E )06/94]
half page art:0070262-A
The cargo cover push pins and hinge pins
[FV38522(E )07/93]
4. Remove the cargo cover from your vehicle.
File:08ctfve.ex
Update:Tue Sep 19 14:50:19 1995
