FORD ESCORT 1996 7.G Owners Manual

322 [SV33575(ALL)08/95]
half page art:0070083-CInside of the instrument fuse panel cover
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

323 [SV33730(ALL)05/93]
The instrument panel fuses and circuit
breakers
[SV33735(ALL)06/93]
thirty-six pica chart:0070054-EFile:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

324 [SV33738(ALL)09/95]
thirty-six pica chart:0070084-F
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

325 [SV33740(ALL)09/95]
thirty-six pica chart:0070098-C
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

326 [SV33742(ALL)06/93]The engine compartment fuse panel
[SV33744(ALL)09/95]
half page art:0070085-D
Engine compartment fuse panel (1.8 liter)
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

327 [SV33746(ALL)09/95]
half page art:0070086-D
Engine compartment fuse panel (1.9 liter)
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

328 [SV33750(ALL)12/89]The engine compartment fuse panel charts
[SV33775(ALL)05/94]
thirty-six pica chart:0070055-DFile:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

329 [SV33780(ALL)09/95]
thirty-six pica chart:0070056-E
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

330 [SV33800(ALL)09/95]
thirty-six pica chart:0070097-B
File:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995

331 [SV33850(ALL)08/95]
To remove and replace a fuse, use the fuse
puller tool provided.
[SV33900(ALL)09/95]
quarter page art:0030248-C[SV33950(ALL)08/95]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[SV34000(ALL)08/95]
To find a fuse's amperage rating, check the
number on the fuse or check the color.
[SV34025(ALL)09/95]
Color coding for fuses
[SV34050(ALL)08/95]
fourteen pica chart:0070082-BFile:15ctsve.ex
Update:Tue Sep 19 14:37:50 1995
